2012 HONDA CR-Z clock setting

Contents
This owner’s manual should be considered a permanent part of the
vehicle and should remain with the vehicle when it is sold.
This owner’s manual covers all models of your vehicle. You may find
descriptions of equipment and features that are not on your
particular model.
Images throughout this owner’s manual (including the front cover)
represent features and equipment that are available on some, but
not all, models. Your particular model may not have some of these features.
This owner's manual is for vehicles sold in the United States and Canada.
The information and specifications included in this publication were
in effect at the time of approval for printing. Honda Motor Co., Ltd.
reserves the right, however, to discontinue or change specifications
or design at any time without notice and without incurring any
obligation.2 Safe Driving P. 29
For Safe Driving P. 30 Seat Belts P. 34 Airbags P. 41
2Instrument Panel P. 67
Indicators P. 68 Gauges and Multi-Information Display P. 81
2Controls P. 97
Setting the Clock P. 98 Locking and Unlocking the Doors P. 99
Operating the Switches Around the Steering Wheel P. 109
Interior Lights/Interior Convenience Items P. 124
2Features P. 135
Audio System P. 136 Audio without Navigation System P. 141
General Information on the Audio System P. 169
2Driving P. 191
Before Driving P. 192 Towing a Trailer P. 197
Refueling P. 232 Fuel Economy P. 235
2Maintenance P. 237
Before Performing Maintenance P. 238 Maintenance Minder ™
P. 241
Checking and Maintaining Wiper Blades P. 266
Climate Control System Maintenance P. 280
2 Handling the Unexpected P. 285
Tools P. 286 If a Tire Goes Flat P. 287
Overheating P. 297 Indicator, Coming On/Blinking P. 299
2Information P. 311
Specifications P. 312 Identification Numbers P. 314
Emissions Testing P. 317 Warranty Coverages P. 319
Main Menu2012 CR-Z Online Reference Owner's Manual

97
Controls
This chapter explains how to operate the various controls necessary for driving.
Setting the Clock................................ 98
Locking and Unlocking the Doors
Key Types and Functions .................... 99
Locking/Unlocking the Doors from the Outside .......................................... 100
Locking/Unlocking the Doors from the Inside ............................................. 102
Auto Door Locking/Unlocking .......... 103
Opening and Closing the Hatch ....... 104
Security System Immobilizer System .......................... 105
Security System Alarm ...................... 105
Opening and Closing the Windows ..... 107Operating the Switches Around the
Steering Wheel
Ignition Switch ................................. 109
Turn Signals ..................................... 110
Light Switches.................................. 110 Fog Lights *
...................................... 112
Daytime Running Lights ................... 112
Wipers and Washers ........................ 113
Brightness Control ........................... 115
Rear Defogger/Heated Door Mirror *

Button ........................................... 116
Adjusting the Steering Wheel........... 117 Adjusting the Mirrors
Interior Rearview Mirror ................... 118
Power Door Mirrors ......................... 118
Adjusting the Seats Adjusting the Seat Positions ............. 119
Interior Lights/Interior Convenience ItemsInterior Lights .................................. 124
Interior Convenience Items .............. 125
Climate Control System Using Automatic Climate Control .... 132
Automatic Climate Control Sensors ...... 134
* Not available on all models

98
Controls
Setting the Clock
Clock
You can adjust the time in the clock display, using the CLOCK (AM/FM) button with
the ignition switch in ON
(w.
1. Press and hold the CLOCK button until the clock display begins to blink.
2. Press the
(1 (Hour) button to change the hours.
3. Press the
(2 (Minute) button to change the minutes.
4. Press the CLOCK button to go back to the normal display.
■Adjusting the Time
1Clock
To set the time to the nearest hour:
Press and hold the CLOCK button until the clock
display begins to blink, then press the
(3 (Reset)
button.
Depending on the displayed time, the clock sets
forward or backward.
Example: 1:06 will reset to 1:001:53 will reset to 2:00
The clock is automatically updated through the navigation system, so the time does not need to be
adjusted.
Models with navigation system
Models without navigation system
(2 Button
(1 Button
(3 Button
CLOCK Button Clock Display

278
Maintenance
12 Volt Battery
Checking the 12 Volt BatteryCheck the battery condition monthly. Look at
the test indicator window and check the
terminals for corrosion.
If your vehicle's battery is disconnected or goes dead: • The audio system is disabled.
2 Reactivating the audio system P. 139
• The clock resets.
2 Setting the Clock P. 98
• The navigation system *
is disabled. A PIN code will be required.
2 Refer to the navigation system manual
Charging the 12 Volt Battery
Disconnect both battery cables to prevent damaging your vehicle's electrical system.
Always disconnect the negative (-) cable first, and reconnect it last.
112 Volt Battery
WARNING: Battery post, terminals,
and related accessori es contain lead
and lead compounds. Wash your hands after handling.
The test indicator's color information is on the
battery.
When you find corrosion, clean the battery terminals
by applying a baking powder and water solution.
Rinse the terminals with water. Cloth/towel dry the
battery. Coat the terminals with grease to help
prevent future corrosion.
3WARNING
The battery gives off explosive hydrogen
gas during normal operation.
A spark or flame can cause the battery to
explode with enough force to kill or seriously hurt you.
When conducting any battery
maintenance, wear protective clothing and
a face shield, or have a skilled technician do
it.
Test Indicator Window
* Not available on all models

328
Index
O Odometer.................................................... 84
Oil (Engine) ............................................... 247
Adding .................................................... 249
Checking ................................................. 248
Displaying Oil Life .................................... 241
Low Oil Pressure Indicator .................. 68, 299
Recommended Engine Oil ........................ 247
Viscosity .................................................. 247
Opening/Closing Hatch ...................................................... 104
Hood ....................................................... 246
Power Windows ...................................... 107
Outside Temperature ................................. 85
Overheating .............................................. 297
P
Panic Mode ............................................... 106
Parking ...................................................... 224
Parking Brake ............................................ 220
Parking Brake and Brake System Indicator ............................................ 68, 302
Passenger Airbag Off Indicator ................. 53
Passing Indicators ..................................... 110
Power Door Mirror ................................... 118
Power Flow Monitor ................................... 89
Power Windows ........................................ 107
Precautions While Driving ........................ 201
Rain ......................................................... 201
Pregnant Women ....................................... 39 Puncture (Tire)
.......................................... 287
R
Radiator .................................................... 253
Radio (AM/FM) ................................. 143, 154
Radio Data System (RDS) ......................... 144
Range .......................................................... 85
Readiness Code (Emissions Testing) ........ 317
Rear Defogger/Heated Door Mirror
Button ..................................................... 116
Rear Luggage Console ............................. 128
Rear Side Marker Light ............................ 263
Rear Turn Signal Light ............................. 263
Rearview Mirror ....................................... 118
Refueling .................................................. 232
Fuel Gauge................................................ 81
Gasoline .......................................... 232, 312
Low Fuel Indicator ..................................... 70
Regulations ............................... 218, 271, 315
Remote Transmitter ................................. 100
Replacement Battery .................................................... 278
Bulbs ....................................................... 258
Fuses ............................................... 304, 305
Tires ........................................................ 275
Wiper Blade Rubber ........................ 266, 268
Reporting Safety Defects ......................... 316
Resetting a Trip Meter ............................... 84 S Safe Driving
................................................ 29
Safety Check ............................................... 33
Safety Labels .............................................. 65
Safety Message .......................................... 27
Seat ........................................................... 119
Adjusting ................................................ 119
Seat Heaters ........................................... 131
Seat Belts .................................................... 34
Automatic Seat Belt Tensioners ................. 36
Checking .................................................. 40
Fastening .................................................. 37
Installing a Child Seat................................ 60
Pregnant Women...................................... 39
Reminder .................................................. 35
Warning Indicator ............................... 35, 70
Seat Heaters ............................................. 131
Security System Immobilizer System Indicator ..................... 76
Security System Alarm Indicator ................ 76
SEL/RESET Button ....................................... 90
Selecting a Child Seat ................................ 59
Selector Knob (Audio) ............................. 141
Setting the Clock ........................................ 98
Shift Lever .......................................... 20, 203
Operation ......................................... 20, 204
Releasing ................................................ 296
Won’t Move ........................................... 296
Shift Lever Position Indicator .................. 204
Shifting ..................................................... 203
Side Airbags ............................................... 48
