XI
184
PRACTICAL INFORMATION
Front foglamps
)
Remove the fi xing screw of
cover A
using a torx tool, tip the
cover over and remove.
)
Remove the fi xing screw of
lamp B
using a torx tool and pull
the headlamp unit to remove it
from the bumper.
)
Disconnect the connector D
.
)
Remove the bulb by performing
a quarter of a turn.
)
Replace the bulb.
)
Refi t the connector D
.
)
Refi t the headlamp unit in the
bumper.
)
Refi t the lamp screws.
)
Position the cover using its
guides and refi t the screws.
Bulbs:
H8
Direction indicators
)
Remove the fi xing screw of
cover A
using a torx tool, tip the
cover over and remove.
)
Remove the fi xing screw of
lamp B
using a torx tool and pull
the headlamp unit to remove it
from the bumper.
)
Detach the bulb C
by pressing
on bars 1
and 2
.
)
Disconnect the connector (pull
whilst pressing on the grey
tongue using a fl at screwdriver).
)
Replace the bulb.
)
Refi t the connector (push the
grey tongue in well).
)
Refi t the headlamp unit in the
bumper.
)
Refi t the lamp screws.
)
Position the cover using its
guides and refi t the screws.
Bulbs:
HP24W
Page 196 of 316
XI
194
PRACTICAL INFORMATION
Fuses under the bonnet
After a repair, carefully refi t the
cover.
Any repairs on the MAXI fuses
(that give additional protection),
located in the fuseboxes, must
be left to a CITROËN dealer or a
qualifi ed workshop.
Access to the fuses
)
Undo each screw by a 1/4 turn.
)
Replace the fuse.
Table of fuses
Fuse N°
Rating
Function
F1
20 A
Engine control unit
F2
15 A
Horn
F3
10 A
Screen wash pump
F4
10 A
Headlamp wash pump
F5
15 A
Starter
F6
10 A
Airfl ow sensor - Directional headlamps -
Diagnostic socket
F7
10 A
Automatic gear lever lock - Power steering
F8
25 A
Starter motor
F9
10 A
Clutch switch - Stop switch
F10
30 A
Actuator motors
F11
40 A
Air conditioning blower
F12
30 A
Wipers
F13
40 A
BSI supply (ignition on)
F14
30 A
-
F15
10 A
Right-hand main beam
F16
10 A
Left-hand main beam
F17
15 A
Right-hand dipped beam
F18
15 A
Left-hand dipped beam
F19
15 A
Actuator motors
F20
10 A
Actuator motors
F21
5 A
Actuator motors
Page 199 of 316
XI
!
197
PRACTICAL INFORMATION
Starting using another
battery
)
Lift the pins to remove the front
left headlamp cover (V6 HDi en-
gine).
)
Connect the red cable to the
positive terminal (+) of the fl at
battery A
, then to the positive ter-
minal (+) of the slave battery B
.
)
Connect one end of the green or
black cable to the negative ter-
minal (-) of the slave battery B
.
V6 HDi engine: the positive ter-
minal (-) is located under the red
cover.
)
Connect the other end of the green
or black cable to the earth point C
on the broken down vehicle.
)
Operate the starter, let the en-
gine run.
)
Wait until the engine returns to
idle and disconnect the cables.
Charging the battery using a
battery charger
The batteries contain harmful
substances such as sulphuric
acid and lead. They must be
disposed of in accordance with
regulations and must not, in any
circumstances, be discarded with
household waste.
Take used remote control batteries
and vehicle batteries to an autho-
rised collection point.
It is advisable to disconnect the
battery if the vehicle is to be left un-
used for more than one month.
Do not disconnect the terminals
while the engine is running.
Do not charge the batteries without
disconnecting the terminals fi rst.
Do not touch the clips during the
operation.
Do not lean over the batteries.
Disconnect the cables in the re-
verse order to connection, ensur-
ing that they do not touch.
Before disconnecting the battery
Wait 2 minutes after switching off
the ignition before disconnecting
the battery.
Close the windows and the doors
before disconnecting the battery.
Following reconnection of the
battery
Following reconnection of the bat-
tery, switch on the ignition and wait
1 minute before starting to permit
initialisation of the electronic sys-
tems. However, if slight malfunctions
remain following this operation, con-
tact a CITROËN dealer or a qualifi ed
workshop.
Referring to the corresponding sec-
tion, you must yourself reinitialise:
- the remote control key,
- the glass panoramic roof blind,
-
the GPS satellite navigation system.
)
Disconnect the battery from the
vehicle.
)
Follow the instructions for use
provided by the manufacturer of
the charger.
)
Reconnect starting with the neg-
ative terminal (-).
)
Check that the terminals and
connectors are clean. If they are
covered with sulphate (whitish or
greenish deposit), remove them
and clean them.
Do not disconnect the battery to
charge it.
Page 200 of 316
XI
!
198
PRACTICAL INFORMATION
ENERGY ECONOMYMODE
System which manages the duration
of use of certain functions to con-
serve a suffi cient level of charge in
the battery.
After the engine has stopped, you can
still use functions such as the audio
and telematics system, windscreen
wipers, dipped headlamps, courtesy
lights, etc. for a maximum combined
duration of thirty minutes.
This period may be signifi cantly re-
duced if the battery charge is low.
Exiting economy mode
These functions are reactivated auto-
matically next time the vehicle is driven.
)
In order to resume the use of
these functions immediately, start
the engine and let it run for a few
minutes.
The time available will then be dou-
ble the duration for which the en-
gine was left running. However, this
time will always be between fi ve and
thirty minutes.
A fl at battery prevents the en-
gine from starting (refer to the
corresponding section).
TOWING THE VEHICLE
Procedure for having your vehicle
towed or for towing another vehicle
using a removable towing eye.
Access to the tools
The towing eye is installed in the
jack box placed in the spare wheel.
For access to it:
)
open the boot,
)
raise the fl oor,
)
remove the towing eye from the
jack box.
Switching to economy mode
Once the thirty minutes are over, a
message appears on the multi-function
screen indicating that the vehicle has
switched to economy mode and the
active functions are put on standby.
If the telephone is being used at this
time:
- it will be maintained for fi ve min-
utes with hands-free kit of your
Audio system,
- it will be maintained for ten minutes
with your eMyWay.
Page 269 of 316
267
10CONFIGURATION
Press SETUP
to display the"Confi guration
" menu.
Select " Choose colour" and confi rm torselect the screen colour harmony and
the map presentation mode:
-
day mode,
- n
ight mode,
- automatic day
/night mode,according to whether the
headlamps are on.
Select " Adjust luminosity" and confi rm
to adjust the screen brightness.
Pr
ess " OK" to save the changes.
The settings
for day and night are independent.
Select " Display confi guration" andconfi rm.
DISPLAY CONFIGURATION
Page 273 of 316
271
11SCREEN MENU MAP
2
3
3
1
2
Lighting confi guration
Select language
Parking assistance
En
gage rear wiper in REVERSE
Duration of guide-me home lighting
1
Define vehicle parameters *
2
Operation of wipers
3Directional headlamps
3Mood lighting
3Daytime running lamps
* The parameters var
y according to the vehicle.
Page 301 of 316
299
VISUAL SEARCH
Exterior (Saloon)
Accessories ..................................... 205
Panoramic sunroof ............................ 82
Roof bars ......................................... 201
Changing bulbs................. 185-186, 189
- rear lamps
- 3
rd
brake lamp
- number plate lamps
Tailgate .............................................. 79
Temporary puncture repair kit ... 174-176
Changing a wheel ..................... 177-180
- tools
- removing
Tyre under-infl ation detection ....115-116
Braking assistance ...........................117
Trajectory control ..............................118
Tyre pressures ................................. 221
Fuel tank ............................................ 84
Remote control key....................... 67-72
- opening / closing
- anti-theft protection
- starting
- battery
Door mirrors ....................................... 65
Very cold climate screen.................. 203
Exterior lighting controls ............... 86-89
Headlamp adjustment........................ 89
Changing bulbs......................... 181-185
- front lamps
- foglamps
- direction indicator repeaters
Lane departure warning system ...... 154
Doors ............................................ 77-79
- opening / closing
- central locking
- emergency control
Child lock ..........................................113
Electric windows ........................... 75-76
Front and/or rear visual and
audible parking sensors................... 157
Towbar ............................................. 200
Towing ...................................... 198-199
Page 302 of 316
300
VISUAL SEARCH
Exterior (Tourer)
Accessories ..................................... 205
Panoramic sunroof ............................ 83
Roof bars ......................................... 201
Changing bulbs......................... 187-189
- rear lamps
- 3rd brake lamp
- number plate lamps
Boot ................................................... 80
Reversing camera ........................... 158
Temporary puncture repair kit ... 174-176
Changing a wheel ..................... 177-180
- tools
- removing
Tyre under-infl ation detection ....115-116
Braking assistance ...........................117
Trajectory control ..............................118
Tyre pressures ................................. 221
Fuel tank ............................................ 84
Remote control key....................... 67-72
- opening / closing
- anti-theft protection
- starting
- battery
Door mirrors ....................................... 65
Very cold climate screen.................. 203
Exterior lighting controls ............... 86-89
Headlamp adjustment........................ 89
Changing bulbs......................... 181-185
- front lamps
- foglamps
- direction indicator repeaters
Lane departure warning system ...... 154
Doors ............................................ 77-79
- opening / closing
- central locking
- emergency control
Child lock ..........................................113
Electric windows ........................... 75-76
Front and/or rear visual and
audible parking sensors................... 157
Towbar ............................................. 200
Towing ...................................... 198-199
