2012 Citroen C5 fuse box

XI
194
PRACTICAL INFORMATION

Fuses under the bonnet


After a repair, carefully refi t the
cover.


Any repairs on the MAXI fuses
(that give additional protection),
located in the fuseboxes, must
be left to a CITROËN dealer or a
qualifi ed workshop.

Access to the fuses


)
Undo each screw by a 1/4 turn.

)
Replace the fuse.

Table of fuses



Fuse N°



Rating



Function




F1



20 A

Engine control unit


F2



15 A

Horn


F3



10 A

Screen wash pump


F4



10 A

Headlamp wash pump


F5



15 A

Starter


F6



10 A

Airfl ow sensor - Directional headlamps -
Diagnostic socket


F7



10 A

Automatic gear lever lock - Power steering


F8



25 A

Starter motor


F9



10 A

Clutch switch - Stop switch


F10



30 A

Actuator motors


F11



40 A

Air conditioning blower


F12



30 A

Wipers


F13



40 A

BSI supply (ignition on)


F14



30 A

-


F15



10 A

Right-hand main beam


F16



10 A

Left-hand main beam


F17



15 A

Right-hand dipped beam


F18



15 A

Left-hand dipped beam


F19



15 A

Actuator motors


F20



10 A

Actuator motors


F21



5 A

Actuator motors

XI
!
195
PRACTICAL INFORMATION

Table of fuses



Fuse N°



Rating



Function




F6



25 A

Rear 12 V socket (max power: 100 W)


F7



15 A

Foglamps


F8



20 A

Additional burner (Diesel)


F9



30 A

Electric parking brake


Your vehicle’s electrical sys-
tem is designed to operate
with either standard or op-
tional equipment.
Before installing electrical equip-
ment or accessories on your vehi-
cle, consult a CITROËN dealer or a
qualifi ed workshop.
CITROËN declines all responsibil-
ity for the consequences and costs
that are caused by faults or repairs
on your vehicle resulting from the
installation of accessories that
are not supplied and/or not rec-
ommended by CITROËN and not
installed in conformity with its re-
quirements, particularly when the
total consumption of additional de-
vices exceeds 10 milliamperes.
The Maxi fuses give additional pro-
tection to electrical systems. Any
work on them must be carried out
by a CITROËN dealer or a quali-
fi ed workshop.
After a repair, carefully refi t the
cover.


If the cover is not correctly po-
sitioned or not properly closed,
this could cause serious prob-
lems on your vehicle. For the
same reason, take care not to
spill any liquid in the fusebox.

XI
!
196
PRACTICAL INFORMATION
BATTERY
Procedure for charging your battery
when it is fl at or for starting the en-
gine using another battery.

Access to the battery

V6 HDi engine

The battery is located under the bonnet.

For access to it:


)
open the bonnet using the interi-
or release lever, then the exterior
safety catch,

)
secure the bonnet stay,

)
remove the plastic cover to gain
access to the two terminals,

)
unclip the fusebox to remove the
battery, if necessary. The battery is located in the boot
under the left-hand wing trim.
For access to it:


)
open the boot,

)
open the fl ap and remove the
battery.







The presence of this label, in
particular with the Stop & Start
system, indicates the use of a
12 V lead-acid battery with special
technology and specifi cation; the
involvement of a CITROËN dealer
or a qualifi ed workshop is essential
when replacing or disconnecting
the battery.
Failure to observe this recommen-
dation may cause premature wear
of the battery.

After refi tting the battery by a
CITROËN dealer or a qualifi ed
workshop, the Stop & Start system
will only be active after a continu-
ous period of immobilisation of the
vehicle, a period which depends
on the climatic conditions and the
state of charge of the battery (up to
about 8 hours).

XI
!
206
PRACTICAL INFORMATION
The fi tting of electrical equip-
ment or accessories which
are not recommended by
CITROËN may result in a failure of
your vehicle's electronic system and
excessive electrical consumption.
Please note this precaution. You
are advised to contact a CITROËN
representative to be shown the
range of recommended equipment
and accessories.

Depending on the legislation in
force in the country, it may be com-
pulsory to have a high visibility
safety vest, warning triangle and
spare bulbs and fuses available in
the vehicle.
Installation of radio
communication transmitters
Before installing any after-market ra-
dio communication transmitter, you
can contact a CITROËN dealer for
the specifi cation of transmitters which
can be fi tted (frequency, maximum
power, aerial position, specifi c instal-
lation requirements), in line with the
Vehicle Electromagnetic Compatibility
Directive (2004/104/EC).




"Multimedia":
Wi-Fi on board, 230V socket, audio
systems, speakers, semi-integral
navigation systems, portable navi-
gation systems, hands-free kit, DVD
player, USB Box, mapping update
CD, driving aid, Hi-Fi module...

302
VISUAL SEARCH

Instruments and controls


Instrument panels .............................. 26
Warning lamps .............................. 32-38
Indicators ...................................... 39-41
Gear effi ciency indicator .................. 136
Buttons .............................................. 42


- trip recorder

- lighting dimmer
Parking space sensors .................... 155

Windows ....................................... 75-76
Door mirrors ....................................... 65

Opening the bonnet ......................... 162
Dashboard fuses ...................... 191-193

"Hydractive III +"
electronic suspension ...................... 159
Manual / electronic /automatic
gearboxes .......... 135, 137-140, 144-147
Hill start assist ................................. 134
Courtesy lamps............................. 94-95
Rear view mirror ........................... 65-66
Interior mood lighting ......................... 96
Sun visor............................................ 98

Parking brake, manual..................... 126
Parking brake, electric .............. 127-133
Stop & Start ..................................... 141
Multifunction screens .................... 43-46
Hazard warning lamps ......................114

Ventilation ..................................... 47-48
Mono-zone digital air conditioning .... 49-51
Dual-zone digital air conditioning ... 52-55
Programmable heating ................. 56-59

Emergency or
assistance call .................. 114, 223-224
eMyWay ........................................... 225
Audio system ................................... 279
Setting the date/time.................... 44, 46

Steering wheel adjustment ................ 66
Interior fi ttings ............................. 98-100


- glove box

- ski fl aps

- auxiliary sockets

- mats...

305
ALPHABETICAL INDEX
A ABS and EBFD systems ....... 117
Accessories ........................... 205
Accessory socket,
12 volt .................................. 100
Adjusting headlamps ............... 89
Adjusting head
restraints ......................... 60, 63
Adjusting seat belt height ...... 120
Adjusting the steering
wheel ..................................... 66
Airbags, curtain ............. 124, 125
Airbags, front ......................... 125
Airbags, lateral .............. 124, 125
Air conditioning ...... 24, 48, 49, 53
Air conditioning,
digital ..................................... 52
Air conditioning,
mono-zone ............................ 49
Air diffuser ............................... 47
Air distribution
adjustment ....................... 50, 53
Air fi lter .................................. 172
Air fl ow .................................... 24
Air fl ow adjustment ............ 49, 52
Air intake ................................. 49
Air recirculation ................. 49, 52
Air vents ............................ 47, 48
Alarm ....................................... 73
Alert / warning log ............. 31, 45
Alloy wheels .......................... 204
Anti-lock braking system
(ABS) ................................... 117
Anti-pinch .................... 75, 82, 83
Anti-theft .................................. 69
Armrest, front .......................... 99
Armrest, rear ......................... 100
Assistance call .............. 114, 224
Audible warning ..................... 114
Audio streaming
(Bluetooth) ................... 264, 291A Audio
system .......................... 279-298
Automatic illumination of
headlamps ....................... 86, 88
Automatic operation
of hazard warning lamps ..... 114
Automatic rain sensitive
windscreen wipers ........... 92, 93
Auxiliary
sockets .......... 99, 261, 246, 286
B Battery ........................... 172, 196
Battery, charging ................... 197
Battery, remote control ...... 71, 72
Battery compartment
fuse box ............................... 191
Blind for panoramic
sunroof .................................. 83
Blinds .................................... 100
Bluetooth
(hands-free) ................. 248, 289
Bluetooth (telephone) .... 248, 289
Bonnet ................................... 162
Bonnet stay ........................... 162
Boot ................................... 79, 80
Boot (fi ttings) ................. 101, 102
Brake discs ............................ 173
Brake lamps .................. 185, 187
Brake pads ............................ 173
Brakes ................................... 173
Braking assistance system .... 117
C Capacity, fuel tank ................... 84
CD MP3 ......................... 261, 285
Central locking .................. 68, 77C Changing
a bulb ........................... 181-190
Changing a fuse ............. 191-195
Changing a wheel .......... 177-180
Changing a wiper blade .......... 94
Changing the remote
control battery ....................... 71
CHECK .................................... 31
Checking levels ............. 170, 171
Checking the engine
oil level .......................... 40, 170
Checks ........................... 162-173
Child lock ............................... 113
Children .... 76, 106-113, 121, 123
Child seats .................... 105, 107
Child seats,
conventional ................ 107, 108
Closing the boot ...................... 68
Closing the doors .............. 68, 77
Cold climate screen ............... 203
Connectors,
audio ............. 99, 261, 264, 286
Control for panoramic
sunroof blind .......................... 83
Coolant level ................... 41, 171
Coolant temperature
indicator ................................. 41
Courtesy lamps ....................... 94
Cruise control ........................ 152
Cup holder ....................... 99, 100
D Date (setting) ..................... 44, 46
Daytime running lamps ... 88, 181
Deactivating the passenger
airbag .................................. 123
Deadlocking ............................ 68
Defrosting .......................... 50, 55
Demisting .......................... 50, 55

306
ALPHABETICAL INDEX
D Demisting the rear
screen ................. 49, 51, 52, 55
Diesel additive level .............. 171
Dimensions ........................... 217
Dipped beam ................... 86, 181
Dipstick ............................ 40, 170
Directional lighting ............. 90, 91
Direction
indicators ............. 114, 181, 187
Doors ....................................... 77
Doors emergency control ........ 78
Driving economically ............... 24
Driving positions
(storing) ................................. 63
E EBA (Emergency braking
assistance) .......................... 117
Eco-driving .............................. 24
Economy mode ..................... 198
Electric window controls .......... 75
Electronic brake force
distribution (EBFD) .............. 117
Electronic engine
immobiliser ...................... 69, 72
Emergency boot release ......... 79
Emergency braking
system ................................. 117
Emergency call .............. 114, 224
Emergency warning lamps .... 114
eMyWay .......................... 45, 225
Energy economy mode ......... 198
Engine, Diesel ................. 85, 167
Engine, petrol .................. 85, 165
Engine compartment ..... 165, 167
Engine compartment
fusebox ................................ 196E Engine oil .............................. 170
Engine oil level indicator ...40, 170
Engines ......................... 207, 210
Environment ...... 24, 72, 173, 199
Equipment settings .................. 45
ESP/ASR ............................... 118
F Filling with fuel ................... 84, 85
Fitting a wheel ....................... 179
Fitting roof bars ..................... 201
Fittings, boot .................. 101, 102
Flashing indicators ................ 114
Foglamps, front ............... 87, 184
Foglamps, rear ........ 87, 185, 187
Folding the rear seats ............. 64
Front seats ......................... 60-63
Fuel ............................. 24, 84, 85
Fuel consumption .................... 24
Fuel fi ller cap ........................... 84
Fuel fi ller fl ap ..................... 84, 85
Fuel gauge ........................ 41, 84
Fuel tank ........................... 84, 85
Fusebox, dashboard ............. 191
Fuses .................................... 191
G G.P.S. .................................... 231
Gearbox, automatic ....... 144, 173
Gearbox, electronic ....... 137, 141
Gearbox,
manual ........ 135, 136, 141, 173
Gear effi ciency indicator ........ 136

Gear lever, automatic gearbox ... 144
Gear lever,
electronic gearbox system ... 137G Gear lever, manual gearbox ... 135
Glove box ................................ 98
Guidance ....................... 232, 239
Guide-me-home .......... 69, 88, 89
H Hands-free kit ................ 248, 289
Hazard warning lamps .......... 114
Headlamp adjustment ............. 89
Headlamps, directional ....... 89-91
Headlamp wash ...................... 93
Headlamp wash reservoir ..... 171
Head restraints, front ......... 60, 61
Head restraints, rear ......... 63, 64
Heated seats ..................... 60, 62
Heating .................. 24, 48, 49, 53
Height and reach adjustment,
steering wheel ....................... 66
High load retaining net .......... 103
Hill start assist ....................... 134
Horn ...................................... 114
Hydractive III+ suspension .... 159
I Identifi cation plates ............... 221
Indicators, direction ............... 114
Indicator lamps,
status ................................ 32-38
Infl ating tyres ................... 24, 221
Inputs for audio
system ........... 91, 261, 264, 286
Instrument panel lighting ......... 42
Instrument panels .................... 26
Instrument panel screen... 26, 136
Interior mood lighting ............... 96
ISOFIX child seats ...109, 111, 112
ISOFIX mountings ................. 109
