2012 Citroen C4 Owner's Manual

11
PRACTICAL INFORMATION
191

)
Connect the compressor's electric
plug to the vehicle's 12 V socket.

)
Start the vehicle again and leave
the engine running.

)
Visit a CITROËN dealer or a
qualifi ed workshop as soon
as possible.
You must inform the techni-
cian that you have used this
kit. After inspection, the tech-
nician will inform you wheth-
er the tyre can be repaired or
must be replaced.



)
Turn the selector A
to the
"air" position.

)
Uncoil the black pipe H
fully.

)
Connect the black pipe to
the valve of the wheel.
2. Infl ation

)
Adjust the pressure using the com-
pressor (to infl ate: switch B
in po-
sition "I"
; to defl ate: switch B
in
position "O"
and press button C
), in
accordance with the vehicle's tyre
pressure label (located on the left
hand door aperture).
A loss of pressure indicates that the
puncture has not been fully plugged;
contact a CITROËN dealer or quali-
fi ed workshop for assistance.

)
Remove and stow the kit.

)
Drive at reduced speed (50 mph
[80 km/h] max) limiting the distance
travelled to approximately 120 miles
(200 km).

11
PRACTICAL INFORMATION
192

Removing the cartridge




)
Stow the black pipe.

)
Detach the angled base from the
white pipe.

)
Support the compressor vertically.

)
Unscrew the cartridge from the bot-
tom.

)

Connect the compressor's electrical
connector to the vehicle's 12 V socket.

)
Start the vehicle and let the engine
run.

)
Adjust the pressure using the com-
pressor (to infl ate: switch B
in posi-
tion "I"
; to defl ate: switch B
in position
"O"
and press button C
), according
to the vehicle's tyre pressure label or
the accessory's pressure label.

)
Remove the kit then stow it.


Beware of discharges of fl uid.
The expiry date of the fl uid is in-
dicated on the cartridge.
The sealant cartridge is designed
for single use; even if only partly
used, it must be replaced.
After use, do not discard the car-
tridge into the environment, take
it to an authorised waste dispos-
al site or a CITROËN dealer.
Do not forget to obtain a new
sealant cartridge, available from
CITROËN dealers or from a
qualifi ed workshop.



Checking tyre pressures/
inflating accessories

You can also use the compressor, with-
out injecting any product, to:


- check or adjust the pressure of your
tyres,

- infl ate other accessories (balls, bi-
cycle tyres...).


)
Turn the selector A
to the
"Air" position.

)
Uncoil the black pipe H
fully.

)
Connect the black pipe to
the valve of the wheel or accessory.
If necessary, fi t one of the adaptors
supplied with the kit fi rst.

11
PRACTICAL INFORMATION
193














CHANGING A WHEEL

Procedure for changing a faulty wheel
for the spare wheel using the tools pro-
vided with the vehicle.

Access to the tools

The tools are installed in the boot under
the fl oor.
To gain access to them:


)
open the boot,

)
raise the fl oor,

)
secure it by hooking its cord on the
hook on the rear shelf support,

)
with a standard size spare wheel,
unclip and remove the box in the
middle of the wheel containing the
tools,
or

)
with a "space-saver" spare wheel;
lift the wheel at the rear towards
you for access to the storage box
containing the tools.
List of tools
All of these tools are specifi c to your
vehicle. Do not use them for other
purposes.


1.
Wheelbrace.
For removing the wheel trim and
the wheel fi xing bolts.

2.
Jack with integral handle.
For raising the vehicle.

3.
"Bolt cover" tool.
For removing the bolt protectors
(covers) on alloy wheels.

4.
Socket for the security bolts (located
in the glove box).
For adapting the wheelbrace to the
special "security" bolts.


Wheel with trim

When removing the wheel
, detach the trim fi rst using the wheelbrace 1

pulling at the valve passage hole.

When refi tting the wheel
, refi t the trim starting by placing its notch facing
the valve and press around its edge with the palm of your hand.

11
PRACTICAL INFORMATION
194

Access to the spare wheel

The spare wheel is installed in the boot
under the fl oor.
Depending on version, the spare wheel
may be a standard size steel or alloy
wheel, or for some countries it is the
"space saver" type.
For access to the spare wheel, refer to
the paragraph "Access to the tools" on
the previous page.
Putting the standard wheel back in
place


)
Put the wheel back in its housing.

)
Unscrew the yellow central bolt by a
few turns then put it in place in the
centre of the wheel.

)
Tighten fully until the central bolt
clicks to retain the wheel correctly.

Tyre under-infl ation detection
The spare wheel is not fi tted with
a sensor. The punctured wheel
must be repaired by a CITROËN
dealer or aqualifi ed workshop.

Taking out the standard wheel


)
Unscrew the yellow central bolt.

)
Raise the spare wheel towards you
from the rear.

)
Take the wheel out of the boot.


)
Put the box back in place in the centre
of the wheel and clip it.

11
PRACTICAL INFORMATION
195









Removing a wheel


Parking the vehicle
Immobilise the vehicle where it
does not block traffi c: the ground
must be level, stable and non-
slippery ground.
Apply the parking brake unless it
has been programmed to auto-
matic mode, switch off the ignition
and engage fi rst gear * to lock the
wheels.
Check that the braking warning
lamps in the instrument panel
are on (not fl ashing).
The occupants must get out of
the vehicle and wait where they
are safe.
If necessary, place a chock under
the wheel diagonally opposite the
wheel to be changed.
Never go underneath a vehicle
raised using a jack; use an axle
stand.

*
position R
for the electronic gearbox
system; P
for an automatic gearbox.
List of operations


)
Remove the chromed bolt cover
from each of the bolts using the
tool 3
(according to equipment).

)
Fit the security socket 4
on the
wheelbrace 1
to slacken the secu-
rity bolt.

)
Slacken the other bolts using the
wheelbrace 1
only.

)
Place the jack 2
in contact with one
of the two front A
or rear B
locations
provided on the underbody, which-
ever is closest to the wheel to be
changed.

)
Extend the jack 2
until its base plate
is in contact with the ground. Ensure
that the centreline of the jack base
plate is directly below the location A

or B
used.

)
Raise the vehicle until there is suffi -
cient space between the wheel and
the ground to admit the spare (not
punctured) wheel easily.

)
Remove the bolts and store them in
a clean place.

)
Remove the wheel.

11
PRACTICAL INFORMATION
196

Fitting a wheel


Fitting a steel or "space-
saver" spare wheel
If your vehicle is fi tted with al-
loy wheels, when tightening the
bolts on fi tting it is normal to
notice that the washers do not
come into contact with the steel
or "space-saver" spare wheel.
The wheel is secured by the
conical contact of each bolt.

After changing a wheel
To store the punctured wheel in
the boot correctly, fi rst remove
the central cover.
When using the "space-saver"
type spare wheel, do not exceed
50 mph (80 km/h).
Have the tightening of the bolts and
the pressure of the spare wheel
checked by a CITROËN dealer or
a qualifi ed workshop without delay.

Have the punctured wheel re-
paired and replace it on the vehicle
as soon as possible.
List of operations


)
Put the wheel in place on the hub.

)
Screw in the bolts by hand to the
stop.

)
Pre-tighten the security bolt using
the wheelbrace 1
fi tted with the se-
curity socket 4
.

)
Pre-tighten the other bolts using the
wheelbrace 1
only.

)
Lower the vehicle fully.

)
Fold the jack 2
and detach it.

)
Tighten the security bolt using the
wheelbrace 1
fi tted with the security
socket 4
.

)
Tighten the other bolts using the
wheelbrace 1
only.

)
Refi t the chromed bolt covers on
each of the bolts (according to
equipment).

)
Store the tools in the box.

11
PRACTICAL INFORMATION
197











CHANGING A BULB

The headlamps are fi tted with
polycarbonate glass with a pro-
tective coating:


)
do not clean them using a
dry or abrasive cloth, nor
with a detergent or solvent
product,


)

use a sponge and soapy water,

)
when using a high pressure
washer on persistent marks,
do not keep the lance direct-
ed towards the lamps or their
edges for too long, so as not
to damage their protective
coating and seals.



)
Do not touch the bulb directly
with your fi ngers, use lint-
free cloths.
Changing a bulb should only be
done after the headlamp has been
switched off for a few minutes (risk
of serious burns).
It is imperative to use only anti-
ultraviolet (UV) type bulbs in
order not to damage the head-
lamp.
Always replace a failed bulb with
a new bulb with the same type
and specifi cation.
Risk of electrocution
Xenon bulbs (D1S-35W) must be
replaced by a CITROËN dealer
or a qualifi ed workshop.



Front lamps



1.
Direction indicators (H21 clear).


2.
Dipped beam headlamps
(H7 - 55W).


3.
Main beam headlamps
(H1 - 55W).


4.
Daytime running lamps/
sidelamps (P21/5W XL).


5.
Foglamps (H11 - 55W).



1.
Directional dipped/main beam
headlamps (D1S-35W).


2.

Direction indicators (PY21W amber).


3.
Daytime running lamps/sidelamps
(P21/5W XL).

4.
Foglamps (H11-55W).









Model with halogen headlamps




























Model with xenon and directional
headlamps
Bulbs with lugs, type H1, H7...
take care to position them cor-
rectly to ensure the best lighting.

11
PRACTICAL INFORMATION
198
Amber coloured bulbs, such as
the direction indicators, must be
replaced with bulbs of identical
specifi cations and colour.
When refi tting, close the protec-
tive cover carefully to preserve
the sealing of the headlamp.













Changing direction indicator bulbs

Model with halogen headlamps
Rapid fl ashing of the direction
indicator warning lamp (right
or left) indicates the failure of a
bulb on that side.

Access to bulbs


)
Remove the air defl ector by unclip-
ping each of its three attachment
points.

)
Unclip the bonnet release cable at
its two fi xings.

)
Move the cable down.
After changing the failed bulb, remember
to put everything back in place (cable and
air defl ector). Depending on the engine and only on
the left hand side, you must fi rst carry
out the following operations for access
to the protective covers on the bulbs.


)
Turn the bulb holder a quarter of a
turn and extract it.

)
Pull out the bulb and change it.
To reassemble, carry out these opera-
tions in reverse order.
Model with Xenon headlamps



)
Remove the protective cover by
pulling on its tongue.

)
Disconnect the electrical connector.

)
Separate the springs to release the
bulb.

)
Pull the bulb out and replace it.
To reassemble, carry out these opera-
tions in reverse order.
