2012 Citroen C4 AIRCROSS bluetooth

8
Familiarisation
Interior
4-wheel drive system with
electronic control *
This system allows the selection of a
transmission mode, according to the drivingconditions.
CVT gearbox
This system offers driving combining a fully automatic mode and a manual mode.

Digital air conditioning

This automatic air conditioning system maintains
the desired comfor t level and adequate air circulation in the passenger compartment.

Audio and communication
systems
These systems benefit from the following
technologies: radio, CD player, USB player, Bluetooth system, satellite navigation system
with colour screen, auxiliary sockets.
AUDIO-TELEMATIC system
122
113
92 28
3
223
AUDIO- CD system
*
Depending on version.

.
9
Familiarisation
Instruments and controls
Door mirror controls.
Electric window controls. 2.Bonnet release.
3.Fusebox.4. Manual headlamp height adjustment.
Side switch panel.
5. Side adjustable air vent.
6.Instrument panel.
7. Lighting and direction indicator controlstalk.8.Steering wheel adjustment control. 9.
Controls for Bluetooth system or telephone.10.Controls for Audio-CD and Audio-telematicsystems.11.
Driver's airbag.
Horn. 12. Cruise control switches.13.Parking brake.

187
7
Practical information

Dashboard fuses

The fusebox is located in the lower dashboard(left-hand side).


Access to the fuses
)Open the cover and remove it completely
by pulling it towards you.
Fuse N°RatingFunctions
1*30 A Cabin fan.
2 15 A
Brake lam
ps, third brake lamp.
310 A
Rear foglamps.
430 A Windscreen wiper, screenwash.
620 A
Central locking, electric door mirrors.
7 15 A
Audio equipment, telematics, USB unit, Bluetooth s
ystem.
87. 5 A
Remote control key, air conditioning control unit, instrument
panel, electric windows, rain and sunshine sensors, alarm,
switch panel, steering mounted controls.
915 A
Instrument panel and interior lighting.
1015 A
Hazard warning lamps
1115 A Rear wiper.
12 7.5
A Instrument panel, multifunction screen, parking sensors, heated seats, heated rear screen, electric blind, automatic headlampadjustment.
1
315 A
Cigarette lighter, accessory socket.
1520 A
Electric blind.
1
610 A Door mirrors, audio equipment.

223
AUDIO-TELEMATIC system

The system is protected in such a way that it will onlyoperate in your vehicle.

01 First steps - Control panel


For safety reasons, the driver must carry out operations
which require prolonged attention while the vehicle is stationary.
When the en
gine is switched off and to prevent
discharging of the battery, the system switches off following the activation of the energy economy mode.



CONTENTS

02 General operation

03 Navigation - Guidance

04 Audio / Video

05 Settings

06 Information

07 USB player p.
p.
p.
p.
p.
p.
p. 224
225
226
236
258
261
264

08 BLUETOOTH
®
streaming - telephone

09 BLUETOOTH
®
telephone p.
p. 269
271

263
06INFORMATION

ENVIRONMENT, AIR CONDITIONING, TELEPHONE
- View the air conditioning settings:F
- the fan speed indicator,F1
- the air selection indicator, F2
- the windscreen demisting indicator,F3
- the air conditioning indicator, F4
- the rear screen demisting indicator, F5
- the AUTO mode indicator.F6
- View the environment information:E
- the altitude,E1
- the atmospheric pressure, E2
- the ambient temperature. The iceE3 symbol fl ashes if there is a risk of ice.
- Make and receive telephone calls: G
- enter the telephone number, G1
- delete a character, G2
- make the call.G3


Refer to the hands-free telephone section to connect your Bluetooth®
mobile telephone.
F1F2
F3F4
F5
F6
E1
E2
E3
G1G2
G3
G
EF

269
08








MATCHING A TELEPHONE, PLAYING A TRACK
Press on
Explanation
Results
Press the MODE button then Bluetooth Audio.
BLUETOOTH®
STREAMING - TELEPHONE®
Press on [Matching] to start matching.
Press on [New device] to detect a telephone.
Enter the PIN in the audio s
ystem.
Refer to the instructions for
your telephone to authorise the matching.
Enter the PIN in the telephone then a
fter a short time it appears in the list.
Select the telephone in the list, then choose [Hands free] for telephone and/or [Audio
Bluetooth] for streaming (an iPhone is recognised automatically).
Then con
fi rm with [Yes].

Once the telephone is matched, select a track then press [
] to play it.

270
08BLUETOOTH® STREAMING - TELEPHONE®
Enter the number using the keypad.


A.
Erasing a number one at a time.B.
Return to the previous screen. C.
To display the list of contacts (in theD. Bluetooth telephone or the vehicle).
Select a contact in the list.
To start [Dial] or start again [Redial] aE. telephone call
To display the secondary menu:F.
Is displayed if the personal identifi cationF1. number has not been defi ned.
Press to enter it.
Is displayed if the personal identifi cationF2. number has been defi ned.
To display the list of matched telephones. F3.
To display the list of voice commands.F4.
To reset all settings.
F5.
INFORMATION DISPLAYED IN TELEPHONE MODE
Refer to the section "matching a
telephone" to connect your telephone
by Bluetooth® .
AB
FCDEF1F2F4F3F5

271
09BLUETOOTH ® TELEPHONE ®
SPEAK
Press this button to activate voice recognition
(" Listening
" is displayed).
Durin
g a voice recognition, press this button briefl y to put this voice recognition on hold.
Make a lon
g press on this button to deactivate voice recognition.
Press this button briefl
y to activate voice recognition, even during a call.

Audio system on/off.

AN
SWER A CALL
Press this button to accept an incoming
call.
In th
e event of a 2 nd
incoming call, press
to put the 1stcall on hold and speak to thesecond caller.
In this case, press briefl
y to switch from one call to the other.

To establish a three-way conversation,press on SPEAK to change from voice
recognition and say " Incorporate the call
".
END
CALL
Press this button to re
ject an incoming call.
During a conversation, press this button to end the call.
In
crease the audio volume.

D
ecrease the audio volume.
