2012 Citroen C4 AIRCROSS engine

80
Comfort











Front seats
Electric adjustments
Forwards-backwards
)Push the control forwards or rearwards toslide the seat.


Seat backrest angle
)
Tilt the control forwards or rearwards to
adjust the angle of the seat backrest.


Driver's seat cushion height and angle
)Pull or push the front part of the control
upwards or downwards to raise or lower thefront of the seat cushion. )Pull or push the rear par t of the control
upwards or downwards to raise or lower the
rear of the seat cushion. )Pull or push all of the control upwards or downwards to raise or lower the whole seatcushion

.


To avoid discharging the battery, carry outthese adjustments with the engine running.

82
Comfort
order to use it as an armrest.
Front armrest
Heated seats adjustment
With the engine running, tilt the button to theposition required.
The temperature of the seat is regulated automatically.
There are two setting positions:
- "HI": Hi
gh heating
- "LO": Low heating

When the button is in the intermediate position,
the heatin
g is switched off.The indicator lamps Acome on when thesystem is activated.

85
3
Comfort





Mirrors
Adjustment is possible when the ignition switch
is in the "ON" or "ACC" position.) Move control Ato the right or to the left toselect the corresponding mirror.)
Move control Bin all four directions toadjust.
)
Return control A
to the central position. Each
fitted with an adjustable mirror glass permitting the lateral rearward vision necessary for overtaking or parking. They can also be folded for parking in confined spaces.
Demisting - Defrosting


Door mirrors

If your vehicle is fitted with heated
mirrors, the demisting-defrosting operates with the engine running, byswitching on the heated rear screen
(see "Rear screen demist-defrost").
The objects observed are, in reality,closer than they appear. Ta k e this into account in order tocorrectly judge the distance of vehiclesapproaching from behind.

89
3
Comfort
In order for these systems to be fully effective, follow the operation and maintenance guidelines below: )
To obtain an even air distribution, take care not to obstruct the exterior air intake grilles
located at the base of the windscreen, the nozzles, the vents and the air outlets, as wellas the air extractor located in the boot. )
Do not cover the sunshine sensor, located on the dashboard; this is used for regulation of the digital air conditioning system. )
Operate the air conditioning system for at least 5 to 10 minutes, once or twice a monthto keep it in per fect working order. )
Ensure that the passenger compar tment filter is in good condition and have the filter elements replaced regularly. We recommend the use of a combined passenger compartment filter. Thanks to its special active additive, it contributes to the purification of the air breathed by theoccupants and the cleanliness of the passenger compartment (reduction of allergic symptoms, bad odours and greasy deposits).)
To ensure correct operation of the air conditioning system, you are also advised to haveit checked regularly as recommended in the ser vicing booklet. )
If the system does not produce cold air, switch it off and contact a CITROËN dealer or a qualified workshop.











Recommendations for ventilation and air conditioning


If after an extended stop in sunshine, the interior temperature is very high, firstventilate the passenger compartment for
a few moments. Put the air flow control at a setting high enough to quickly change the air in the passenger compartment.

The air conditioning system does notcontain chlorine and does not present any danger to the ozone layer.

The condensation created by the air conditioning results in a dischargeof water under the vehicle which is perfectly normal.


When towing the maximum load on a steep gradient in high temperatures, switching off theair conditioning increases the available engine power and so improves the towing ability.

90
Comfort
Manual heating / air conditioning
The system operates with the engine running.
1. Temperature setting
)
Turn the temperature control
dial to the right to raise the
temperature, and to the left to
l
ower it.
To avoid misting and deterioration of the air quality in the passenger compar tment, ensurethat an adequate air flow is maintained.


3. Air distribution setting
)
Place the dial in the desired
position, to direct air towards:
t
he centre and side vents,

The air distribution can be modulated byplacing the dial in intermediate positions.


2. Air fl ow setting
)Turn the dial to the right to
increase and to the left to reduce the air flow.
the centre, side and footwell
vents,
the
footwells,
the windscreen, side windows
and footwells,
t
he windscreen and side
windows.

92
Comfort




















Automatic air conditioning
1.
Te m p e r a t u r e a djustment 2.
Air flow adjustment 3.Air distribution adjustment4.
Intake of exterior air / Recirculation of interior air 5.
Air conditioning On / Off



Automatic operation
)
Set the temperature control dial 1to thetemperature required.)
Place the air flow control dial 2
in the "AUTO"
position.)
Place the air distribution adjustment dial 3in the "AUTO"position.


When the engine is cold, to avoid an excessive distribution of cold air, theventilation will reach its optimum level gradually.
On entering the vehicle, the interior temperature may be much colder (or warmer) than the temperature setting. There is no need to change thetemperature setting in order to reachthe comfor t required rapidly.
The automatic regulation of the air conditioning will operate to correct thetemperature difference as quickly aspossible. In
automatic mode:)when the temperature is set to maximum (Rapid heating), the intake of exterior air is
activated and the air conditioning stops.)when the temperature is set to minimum(Rapid cooling), air recirculation isactivated and the air conditioning operates.

The system controls the air distribution, the flow, the temperature and the air intake to ensure the level of comfort selected and
adequate air circulation in the passenger compartment. No further action on your part is
required.

97
3
Comfort








Rear screen demist - defrost


Switching on

The rear screen demisting/defrosting can onlyoperate when the engine is running.
Switching off
The demisting/defrosting switches off automatically to prevent an excessive consumption of current.)
It is possible to stop the demisting/
defrosting operation before it is switched
off automatically by pressing the button
again. The indicator lamp associated with
the button goes off. )
Switch off the demisting/defrosting of the rear screen and door mirrors as soon asappropriate, as lower current consumption results in reduced fuel consumption.

The control button is located on the air conditioning system control panel.
) Press this button to demist/defrost the rear screen and(depending on version) the door mirrors. The indicator lamp associated with the buttoncomes on.

101
3
Comfort





Front armrest

Pull the right-hand lever to open the storage compartment lid, which serves as an armrest.
To close, fold down the lid until it locks. Pull the left-hand lever to open the lid.
To c l o s e , fold down the lid until it locks.
This storage compar tment may contain up
to 3 accessory sockets.
This operates when the i
gnition switch is in the
"LOCK", "ACC" or "ON" position.
Open the cover of the front armrest to gain access to the socket.


Upper storage compartment Lower storage compartment

Check that the electrical equipment operates on 12 V and that its maximum electrical power is 120 W.
The prolonged use of electrical equipment without running the engine may discharge the battery.






12 V socket
(120 W max)
