CONTENTS
Ventilation 50Heating 52Manual air conditioning 52Digital air conditioning 55Rear screen demist - defrost 57Scented air freshener 58Front seats 59Rear seats 61Mirrors 62Steering wheel adjustment 63
3 - COMFORT 50 Î 63
Remote control key 64Alarm 68Window controls 70Doors 72Boot 75Fuel tank 76Misfuel prevention (Diesel) 78
4 - ACCESS 64 Î 78
Lighting controls 79Headlamp adjustment 82Wiper controls 83Courtesy lamps 86Interior mood lighting 87Boot lamp 87
5 - VISIBILITY 79 Î 87
Child seats 94
ISOFIX child seats 99Electric child lock 102
7 - CHILD
SAFETY 94 Î 102
FAMILIARISATION 4 Î20
Monochrome screen A 43Monochrome screen C 4516/9 colour screen (MyWay) 48
2 - MULTIFUNCTION
SCREENS 43 Î49
Interior fi ttings 88Boot fi ttings 92
6 - FITTINGS88 Î 93
Instrument panels 23Indicator and warning lamps 25Indicators 35Adjustment buttons 38Trip computer 40
1 - MONITORING 23 Î42
ECO-DRIVING 21 Î22
Page 10 of 252
8
1.
Audio equipment steering mounted
controls.
2.
Steering lock and ignition.
3.
Wipers/screenwash/trip computer
control stalk.
4.
Instrument panel.
5.
Scented air freshener.
6.
Driver’s airbag.
Horn.
7.
Gear lever.
8.
Parking brake.
9.
Central armrest with storage.
10.
Door mirror controls.
Electric window controls.
Rear doors and electric windows
deactivation control.
11 .
Storage compartment.
12.
Electric child lock button or
alarm button.
Electronic stability programme
button (ESP/ASR).
Stop & Start switch.
13.
Side adjustable air vent.
14.
Front door window demisting/
defrosting vent.
15.
Speaker (tweeter).
16.
Windscreen demisting/defrosting
vent.
Page 11 of 252
9
FAMILIARI
S
AT I
ON
1.
Steering wheel adjustment control.
2.
Headlamp height adjustment.
3.
Cruise control/speed limiter
controls.
4.
Lighting and direction indicator
control stalk.
5.
Microphone.
6.
Central locking button.
7.
Multifunction screen.
8.
Hazard warning lamps button.
9.
Central adjustable air vents.
10.
Sunshine sensor
Hi-Fi audio system central speaker.
11 .
Passenger’s airbag.
12.
Glove box/Passenger’s airbag
deactivation/Fusebox.
13.
Bonnet release lever.
14.
12 V accessory socket
USB port/auxiliary socket.
15.
Upper and lower storage.
16.
MyWay or Audio system.
17.
Heating/air conditioning controls.
INSTRUMENTS AND CONTROLS
Page 13 of 252
FAMILIARI
S
AT I
ON
Other adjustments
4.
Head restraint height adjustment.
60
Steering wheel adjustment
1.
Releasing the steering wheel ad-
justment mechanism.
2.
Height and reach adjustment.
3.
Locking the steering wheel adjust-
ment mechanism.
63
For reasons of safety, these op-
erations must only be carried out
with the vehicle stationary.
Page 19 of 252
17
FAMILIARI
S
AT I
ON
Electronic gearbox
Display in the instrument panel
Starting and moving off
Five or six speed electronic gearbox of-
fering the choice of the comfort of au-
tomated operation or the pleasure of
manual gear changing.
1.
Gear lever.
2.
Steering mounted "-" control paddle.
3.
Steering mounted "+" control paddle. The gear engaged or the driving mode se-
lected appears in the instrument panel.
N.
Neutral.
R.
Reverse.
1 to 5/6.
Gears engaged.
AUTO.
Automated mode.
)
Select position N
.
)
Press the brake pedal fi rmly.
)
Start the engine.
)
Select automated mode (position A
)
or manual mode (position M
) by mov-
ing the gear lever 1
,
or
engage reverse by pushing the gear
lever 1
to position R
.
)
Release the parking brake.
)
Progressively take your foot off the
brake pedal, then move off.
11 4
DRIVING SAFELY
Page 36 of 252
1
34
MONITORING
Warning lamp
is on
Cause
Action/Observations
Water in
Diesel
fi xed. The Diesel fuel fi lter
contains water. Risk of damage to the injection system on Diesel
engines.
Contact a CITROËN dealer or a qualifi ed
workshop without delay.
Power
steering
fi xed. The power steering has a
fault. Drive carefully at reduced speed.
Have it checked by a CITROËN dealer or a
qualifi ed workshop.
Particle
emissions
fi lter (Diesel)
fi xed,
accompanied
by an audible
signal. This indicates that the
particle emissions fi lter
is starting to become
saturated. As soon as driving conditions allow, regenerate
the fi lter by driving at a speed of at least 35 mph
(60 km/h) until the warning lamp goes off (see
the "Checks - Particle emissions fi lter" section).
fi xed,
accompanied
by an audible
signal. This indicates the low level
of the additive reservoir. Have the reservoir topped up as soon as
possible by a CITROËN dealer or a qualifi ed
workshop (see the "Checks - Additive level"
section).
Page 65 of 252
3
63
COMFORT
STEERING WHEEL ADJUSTMENT
)
When stationary
, pull the con-
trol lever to release the adjustment
mechanism.
)
Adjust the height and reach to suit
your driving position.
)
Push the control lever to lock the
adjustment mechanism.
As a safety precaution, these
operations should only be car-
ried out while the vehicle is sta-
tionary.
Adjustable mirror providing a central
rearward view.
Equipped with an anti-dazzle system,
which darkens the mirror glass: this re-
duces the nuisance to the driver caused
by the headlamps from following vehi-
cles, low sun...
Adjustment
)
Adjust the mirror so that the glass is di-
rected correctly in the "day" position.
Day/night position
)
Pull the lever to change to the "night"
anti-dazzle position.
)
Push the lever to change to the normal
"day" position.
Automatic day/night model
By means of a sensor, which measures
the light from the rear of the vehicle, this
system automatically and progressively
changes between the day and night
uses.
In order to ensure optimum vis-
ibility during your manoeuvres,
the mirror lightens automatically
when reverse gear is engaged.
As a safety measure, the mirrors
should be adjusted to reduce the
"blind spot".
Manual day/night model
Page 92 of 252
6
90
FITTINGS
USB PLAYER
The USB port is located in the "AUX"
box on the centre console.
It permits the connection of a portable
device, such as a digital audio player of
the iPod
® generation 5 and later type or
USB memory stick type.
It reads the audio fi le formats (mp3,
ogg, wma, wav...) which are transmitted
to your audio equipment and played via
the vehicle's speakers.
You can manage these fi les using the
steering mounted controls or the audio
equipment control panel and display
them on the multifunction screen.
When it is in use, the portable
device charges automatically.
For more information on the use of this
equipment, refer to the Audio system part
of the "Audio and Telematics" section.
12 V ACCESSORY SOCKET
)
To connect a 12 V accessory (max
power: 120 W), lift the cover and
connect a suitable adaptor.
AUXILIARY SOCKET
The auxiliary socket is located in the
" AUX
" box on the centre console.
It permits the connection of a portable
device, such as a digital audio player of
the iPod
® type, to listen to your music
fi les using the vehicle's speakers.
For more information on the use of
this equipment, refer to the MyWay or
Audio system part of the "Audio and
Telematics" section. The management of the fi les is
done using your portable device.
