Page 4 of 244
2
CONTENTS
Instrument panel 22Indicator and warning lamps 23Indicators 31Adjustment buttons 34
Ventilation 45Rear screen demist/defrost 47Heating 47Manual air conditioning 47Dual-zone digital air conditioning 49Scented air freshener 51Front seats 52Rear seats 54Mirrors 56Steering wheel adjustment 57
3 - COMFORT 45 Î 57
Remote control key 58Window controls 62Doors 64Boot 66Panoramic sunroof 67Fuel tank 68Misfuel prevention (Diesel) 70
4 - ACCESS 58 Î 70
Lighting controls 71Headlamp adjustment 74Wiper controls 75Courtesy lamps 78Boot lamp 79
5 - VISIBILITY 71 Î79
Conventional child seats 90ISOFIX child seats 95Child lock 98
7 - CHILD
SAFETY 90 Î98
FAMILIARISATION 4 Î 19
1 - MONITORIN
G22 Î 34
Screens with audio equipment 35Trip computer 42
2 - MULTIFUNCTION
SCREENS 35 Î44
Front fi ttings 80Rear fi ttings 84Boot fi ttings 87
6 - FITTINGS 80 Î89 ECO-DRIVING 20
Î21
Page 10 of 244
8
1.
Steering lock and ignition.
2.
Audio system steering mounted
controls.
3.
Wipers/screenwash/trip computer
control stalk.
4.
Instrument panel.
5.
Driver’s airbag.
Horn.
6.
Gear lever.
7.
Open storage compartment.
8.
Door mirror controls.
Electric window controls.
Rear electric windows and doors
deactivation control.
9.
Passenger’s airbag deactivation.
10.
Manual headlamp height
adjustment.
11 .
Front side window demisting vent.
12.
Windscreen demisting vent.
INSTRUMENTS AND CONTROLS
Page 14 of 244
12
Door mirror adjustment
This operates with the ignition on.
From the driver’s seat, select the mirror
by moving the control 1
, to the left or to
the right, then adjust the mirror in the
four directions by moving the control 2
.
The demisting - defrosting of the mirrors
is linked with that of the rear screen.
Rear view mirror adjustment
1.
Selection of the "day" position of the
mirror.
2.
Mirror adjustment.
Front seat belt
1.
Fastening.
2.
Height adjustment.
57
102
Folding the mirrors
When parking, the mirrors can be folded
manually or electrically.
56
SITTING COMFORTABLY
