CHILD SAFETY




ADVICE ON CHILD SEATS

As a safety precaution, do not leave:


- a child or children alone and un-
supervised in a vehicle,

- a child or an animal in a vehicle
which is exposed to the sun, with
the windows closed,

- the keys within reach of children
inside the vehicle.
To prevent accidental opening of the
doors and rear windows, use the
"Child lock".
Take care not to open the rear win-
dows by more than one third.
To protect young children from the
rays of the sun, fi t side blinds on the
rear windows.
Children under the age of 10 must
not travel in the "forwards-facing"
position on the front passenger seat,
unless the rear seats are already oc-
cupied by other children, cannot be
used or are absent.
Deactivate the passenger airbag
when a "rearwards-facing" child seat
is installed on the front seat.
Otherwise, the child would risk being
seriously injured or killed if the airbag
were to infl ate.

Installing a booster seat
The chest part of the seat belt must
be positioned on the child's shoulder
without touching the neck.
Ensure that the lap part of the seat
belt passes correctly over the child's
thighs.
CITROËN recommends the use of
a booster seat which has a back, fi t-
ted with a seat belt guide at shoulder
level. The incorrect installation of a child
seat in a vehicle compromises the
child's protection in the event of an
accident.
Remember to fasten the seat belts or
the child seat harnesses keeping the
slack relative to the child's body to a
minimum, even for short journeys.
When installing a child seat using the
seat belt, ensure that the seat belt is
tightened correctly on the child seat
and that it secures the child seat fi rm-
ly on the seat of your vehicle. If your
passenger seat is adjustable, move it
forwards if necessary.
For optimum installation of the "for-
wards-facing" child seat, ensure that
the back of the child seat is in contact
with the back of the vehicle's seat
and that the head restraint does not
cause any discomfort.
If the head restraint has to be removed,
ensure that it is stored or attached
securely to prevent it from being
thrown around the vehicle in the event
of sharp braking.

7
100
CHILD SAFETY
Any other status of the indica-
tor lamp indicates a fault with
the electric child lock. have it
checked by a CITROËN dealer
or a qualifi ed workshop.
MANUAL CHILD LOCK

Mechanical system to prevent open-
ing of the rear door using its interior
control.
The control is located on the edge of
each rear door.

Locking


)
With the ignition key, turn the red
control one quarter of a turn:


- to the right on the left-hand rear
door,

- to the left on the right-hand rear
door.



Unlocking


)
With the ignition key, turn the red
control one quarter of a turn:


- to the left on the left-hand rear
door,

- to the right on the right-hand rear
door.



ELECTRIC CHILD LOCK

Remote control system to prevent open-
ing of the rear doors using their interior
controls and use of the rear electric
windows.
The control is located on the driver's
door, with the electric window controls.

Activation


)
Press this button.
The indicator lamp on the button comes
on, accompanied by a message in the
multifunction screen.
This indicator lamp remains on until the
child lock is deactivated.
Deactivation


)
Press the button again.

The indicator lamp on the button switches
off, accompanied by a message in the
multifunction screen.
This indicator lamp remains off until the
child lock is activated.
This system is independent and
in no circumstances does it take
the place of the central locking
control.
Check the status of the child lock
each time you switch on the igni-
tion.
Always remove the key from the
ignition when leaving the vehicle,
even for a short time.
In the event of a serious impact,
the electric child lock is deacti-
vated automatically to permit the
exit of the rear passengers.

8
108
SAFETY
Lateral airbags
System which protects the driver and
front passenger in the event of a seri-
ous side impact in order to limit the risk
of injury to the chest, between the hip
and the shoulder.
Each lateral airbag is fi tted in the seat
backrest frame, door side.

Deployment

The lateral airbags are deployed unilater-ally in the event of a serious side impact
applied to all or part of the side impact
zone B
, perpendicular to the longitudinal
centreline of the vehicle on a horizontal
plane and directed from the outside to-
wards the inside of the vehicle.
The lateral airbag infl ates between the
hip and shoulder of the front occupant
of the vehicle and the corresponding
door trim panel.
Impact detection zones


A.
Front impact zone.

B.
Side impact zone.


Curtain airbags

System which protects the driver and
passengers (with the exception of the
rear centre passenger) in the event of a
serious side impact in order to limit the
risk of injury to the side of the head.
Each curtain airbag is built into the pillars
and the upper passenger compartment
area.
Deployment
The curtain airbag is deployed at the
same time as the corresponding later-
al airbag in the event of a serious side
impact applied to all or part of the side
impact zone B
, perpendicular to the
longitudinal centreline of the vehicle on
a horizontal plane and directed from
the outside towards the inside of the
vehicle.
The curtain airbag infl ates between the
front or rear occupant of the vehicle and
the windows.

Operating fault
If this warning lamp comes on
in the instrument panel, accom-
panied by an audible signal and
a message in the screen, con-
tact a CITROËN dealer or a qualifi ed
workshop to have the system checked.
The airbags may no longer be deployed
in the event of a serious impact.
In the event of a minor impact or
bump on the side of the vehicle
or if the vehicle rolls over, the air-
bag may not be deployed.
In the event of a rear or front colli-
sion, the airbag is not deployed.

11
152
PRACTICAL INFORMATION

Dashboard fusebox

The fusebox is located in the lower
dashboard (left-hand side).

Access to the fuses


)
Refer to the paragraph "Access to
the tools".

Fuse tables


Fuse N°



Rating


Functions



FH36



5 A

Trailer relay unit.


FH37



-

Not used.


FH38



20 A

Hi-Fi amplifi er.


FH39



20 A

Heated seats.


FH40



40 A

Trailer relay unit.


Fuse N°



Rating


Functions



F1



15 A

Rear wiper.


F2



-

Not used.


F3



5 A

Airbags and pretensioners control unit.


F4



10 A

Air conditioning, clutch switch, electrochromatic
mirror, particle fi lter pump (Diesel), diagnostic
socket, airfl ow sensor (Diesel).


F5



30 A

Electric windows panel, passenger's electric
window control, front electric window motor.


F6



30 A

Rear electric windows motors and driver's electric
window motor.


F7



5 A

Courtesy lamp, glove box lighting, side reading
lamps.

198
07MUSIC MEDIA PLAYERS






CD, MP3/WMA CD
INFORMATION AND ADVICE
In order to be able to play a recorded CDR or CDRW, when recording it is preferable to select the ISO 9660 level 1, 2 or Jolietstandard.
I
f the disc is recorded in another format it may not be playedcorrectly.
It is recommended that the same recordin
g standard is alwaysused for an individual disc, with as low a speed as possible(4x maximum) for optimum sound quality.
In the particular case o
f a multi-session CD, the Joliet standard is recommended.
The M
yWay will only play audio fi les with the extension ".mp3"
with a speed of between 8 Kbps and 320 Kbps and the extension
".wma" with a speed of between 5 Kbps and 384 Kbps.
It also supports the VBR
(Variable Bit Rate) mode.
No other t
ype of fi le (.mp4, .m3u...) can be played. The MP3
format, an abbreviation of MPEG 1, 2 & 2.5 Audio Layer 3 and the WMA format, an abbreviation of Windows Media Audio and
the property of Microsoft, are audio compression standards which permit the recording of several tens of music fi les on a single disc.

It is advisable to restrict fi le names to 20 characters
, without
using special characters (e.g.: " ? ; ù) to avoid any play or display
problems.

235
VISUAL SEARCH
Remote control key............... 64-67


- opening/closing

- anti-theft protection

- starting

- battery

EXTERIOR

Lighting controls ................... 77-80
Headlamp adjustment................ 80
Changing bulbs................. 145-147


- front lamps

- foglamps

- direction indicator repeaters Door mirrors ............................... 62
Doors .................................... 70-73


- opening/closing

- central locking

- emergency control
Child lock ................................. 100
Electric windows ................... 68-69 Accessories ...................... 165-166 Wiper controls....................... 81-83
Changing a wiper blade ........... 160
Boot ........................................... 73
Temporary puncture
repair kit ..................... 136-140
Changing a wheel ............. 141-144


- tools

- removing/refi tting
Changing bulbs................. 148-149


- rear lamps

- 3rd brake lamp

- number plate lamps
Rear parking sensors ....... 127-128
Towbar ..................................... 163
Towing .............................. 161-162
Hill start assist ......................... 122
Braking assistance .................. 102
Trajectory control ..................... 103
Tyre pressures ................. 140, 177 Fuel tank ............................... 74-75
Misfuel prevention ..................... 76

237
VISUAL SEARCH
Instrument panels ................. 23-24
Warning lamps ...................... 25-34
Indicators .............................. 35-37
Adjustment buttons ............... 38-39


- trip distance recorder/clock

- lighting dimmer/black panel

INSTRUMENTS AND CONTROLS

Lighting controls ................... 77-80
Headlamp adjustment................ 80
Stop & Start ...................... 119-121
Speed limiter..................... 123-124
Cruise control ................... 125-126
Dashboard fuses .............. 151-153
Opening the bonnet ................. 130 Rear view mirror ........................ 63
Zenith windscreen blind ............... 6
Sun visor.................................... 87

Wiper controls....................... 81-83
Trip computer ....................... 40-42
Audio system .................... 213-234
Setting the date/time................ 227
MyWay .............................. 181-212
Setting the date/time................ 204
Emergency or assistance call .... 179
Ventilation/Heating................ 50-54
Manual air conditioning......... 52-54
Digital air conditioning .......... 55-56
Demisting - Defrosting
(rear screen) ........................ 57

Interior mood lighting ................. 85
Steering wheel adjustment ........ 63
Horn ......................................... 101 Scented air freshener ................ 58
Multifunction screens ............ 43-49
Hazard warning lamps ............. 101
Manual gearbox ........................110
Gear shift indicator ................... 111
Electronic gearbox ............. 112-115
Automatic gearbox............. 116-118
Parking brake ...........................110 Door mirrors ............................... 62
Electric windows ................... 68-69

239
ALPHABETICAL INDEX
A ABS and EBFD systems ............ 102
Accessories ................................ 165
Accessory socket, 12 V ................ 88
Adjusting headlamps .................... 80
Adjusting head restraints .............. 60
Adjusting
the steering wheel ...................... 63
Airbags, curtain .................. 108, 109
Airbags, front ...................... 106, 109
Airbags, lateral ................... 108, 109
Air conditioning ............................. 21
Air conditioning, digital ........... 51, 55
Air conditioning, manual ......... 51, 52
Air filter ....................................... 134
Air flow ......................................... 50
Air intake ...................................... 50
Air recirculation ...................... 53, 56
Air vents ....................................... 50
Ambient temperature (display) ..... 23
Anti-lock braking system
(ABS) ........................................ 102
Anti-pinch ..................................... 68
Anti-theft ....................................... 65
Armrest, front ............................... 87
Assistance call ................... 102, 180
Audible warning .......................... 101
Audio streaming
(Bluetooth) ................................ 225
Audio system .......................213-234
Automatic illumination
of headlamps ........................ 77, 79
Automatic operation of hazard
warning lamps .......................... 101
Automatic rain sensitive
windscreen wipers ................ 81, 83
Auxiliary socket .... 88, 200, 220, 222C Child seats .............................92-99
Clock ............................ 38, 204, 227
Closing the boot ..................... 64, 73
Closing the doors ................... 64, 70
Connectors,
audio .................. 88, 200, 220, 222
Coolant level .............................. 133
Courtesy mirror ............................ 87
Cruise control ............................. 125
Cup holder .................................... 86
D Date (setting) .............. 204, 226, 227
Daytime running lamps ................ 79
Deactivating
the passenger airbag ............... 107
Deactivating the rear windows ..... 69
Defrosting ............................... 54, 55
Demisting ............................... 54, 55
Dials and gauges ................... 23, 24
Diesel additive level ................... 134
Dimensions ................................ 176
Dipped beam ........................ 77, 146
Dipstick ................................. 37, 133
Direction indicators ..... 101, 146, 148
Door pockets ................................ 86
Doors ............................................ 70
Doors emergency control ............. 72
Driving economically ................... 21
E EBA (Emergency braking
assistance) ............................... 102
Eco-driving (advice) ..................... 21
Economy mode .......................... 160
Electric window controls ............... 68 B Battery ................................ 134, 158
Battery, charging ........................ 159
Battery, remote control ........... 66, 67
Black panel ................................... 39
Blind ............................................... 6
Bluetooth
(hands-free) ...................... 201, 223
Bluetooth (telephone) ......... 201, 223
Bonnet ........................................ 130
Boot .............................................. 73
Boot lamp ............................. 85, 150
Brake discs ................................. 135
Brake lamps ............................... 148
Brake pads ................................. 135
Brakes ........................................ 135
Braking assistance system ......... 102
C Capacity, fuel tank ........................ 74
CD MP3 .............................. 199, 219
Central locking ....................... 64, 71
Changing a bulb ..................145-150
Changing a fuse ..................151-157
Changing a wheel ...............141-144
Changing a wiper blade ....... 83, 160
Changing the date ...... 204, 226, 227
Changing the remote
control battery ............................ 66
Changing
the time .............. 38, 204, 226, 227
Checking levels .................. 133, 134
Checking the engine oil level ....... 37
Checking tyre pressures
(using the kit) ............................ 140
Checks ................................130-135
Child lock .................................... 100
Children .................92-100, 105, 107
