2012 Citroen C1 engine

34Comfort






















Heating
1. Temperature adjustment
Turn the control from blue (cold) to red(hot) to adjust the temperature to suit your requirements.
2. Air fl ow adjustment
When the ignition is switched on, turn the control to obtain a flow of air which is sufficient
to ensure your comfort.
To maintain a certain level of comfort in thepassenger compar tment, avoid position 0whenever possible.
In position 0, a slight flow of air, due to themovement of the vehicle, can still be felt. Win
dscreen and side windows.


4. Rear screen demisting
With the engine running, press button 4
, the indicator lamp comes on.
The system demists the rear screen.
It is switched off by pressing control 4.

3. Air distribution adjustment
Footwells, diffusion grille and side
vents.
Di
ffusion grille and side vents.

Demisting and defrosting

To quickly demist or defrost the windscreen and side windows:


- set the air distribution to "Windscreen and side windows",

- place the temperature control 1
and the air
fl
ow control 2at maximum,

- close the side vents.
The air distribution can be adjusted byplacing the control in an intermediate
position.
Switch the system off as soon as you consider this necessary as a lower consumption of current reduces fuel consumption.
Windscreen, side windows and
f
ootwells.

Footwells.

3
35 Comfort

1. Air conditioning On/Off
With the engine running, press thebutton, the indicator lamp comes on.
1.
Air conditioning On/Off 2.Te m p e r a t u r e a djustment3.Air flow adjustment





























Air conditioning


2. Temperature adjustment

Turn the control from blue (cold) to red(hot) to adjust the temperature to suit your
requirements.
4. Air recirculation / Air intake
5. Air distribution adjustment 6.
Rear screen demisting


3. Air fl ow adjustment
When the ignition is switched on, turn the control to obtain a flow of air which is sufficient
to ensure your comfort.
To maintain a certain level of comfort in the
passenger compartment, avoid position 0whenever possible.
In position 0
, a slight flow of air, due to the
movement of the vehicle, can still be felt. The air conditionin
g will not operate if the air flow adjustment control 3 is in position 0.
To quickly obtain cooled air, you can use air recirculation for a few moments. Then return to exterior air intake.

42Driving
The position of the gear lever ( R
, N
, Eor M )
and the gear engaged (1 to 5 ) are displayed in
the instrument panel screen.




















Electronic gearbox
Reverse "R". This gear will beengaged when stationary or at a
speed below approximately 4 mph (6 km/h).
Engagement of reverse gear is accompanied
by an audible signal.


Moving off

With the parking brake applied, press the brakepedal then select position Nto star t the engine.
With your foot on the brake, select position R , Eor M.
Release the parking brake, take your foot off
the brake
pedal, then accelerate. The
five-speed electronic gearbox gearboxoffers a choice between the ease of automated operationor the driving pleasure of manual gear changing
.
You can chan
ge from position Eto position Mand vice versa at any time.
Gear lever positions
Select the driving mode by moving the gear
lever.
N eutral "N".
Position the lever to the right inposition N, to star t the engine.
E
asy "E": automatic gear changing.
M
anual (+ / -) "M" : manual gear changing.


Steering mounted control paddles
Press behind the +steering mounted control
paddle to change up.
Press behind the -steering mounted control
paddle to change down.
With the engine running, in these three positions, an audible signal is heard when the driver's door is opened.

Display in the instrument panel

5
43 Driving

EASY mode (automatic
mode)
Select position E
using the gear lever.
The gear engaged is displayed in the
instrument panel screen.
The gearbox continuously selects the mostsuitable gear.
Manual mode
Place the gear lever in position M, then changeup or down using:
- the gear lever, pushing:


- rearwards, "+"to change up,

- forwards, "-"to change down.
- or the steering mounted controls paddles.
The gear engaged is displayed on the
instrument panel screen.
If the engine speed is too low, the gearbox automatically changes down to prevent stalling.
In the event of overheating of the clutch, position N is selected automatically and the
symbol N flashes accompanied by an audible
signal.


Operating fault
Stoppin
g the engine

Before switching off the engine, you can change to position Nto be in neutral.
In all cases, it is essential that you apply the
parking brake to immobilise the vehicle.
With the i
gnition on, illumination
of this warning lamp indicates a gearbox fault.
Contact a CITROËN dealer or a qualified
workshop.

Stopping - Moving off on a
slo
pe
The gearbox is an electronically controlledmanual gearbox without a clutch pedal.
To hold the vehicle on a slope, it is necessary
to use the brake pedal or the parkin
g brake and not the accelerator pedal.
When moving off on a slope, accelerateprogressively while releasing the parking brake.

Always press the brake pedal while starting the engine.
Never select neutral N
while the vehicle is moving.In all cases, it is essential to apply the parking brake to immobilise the vehicle.

On a slope, use the brake to immobilisethe vehicle and place the gear lever in position N , E
or R.
Do not keep the vehicle immobilisedusing the accelerator.

If you press the accelerator pedal beyond the point of resistance, theelectronic gearbox gearbox changes
down for sharper acceleration.
Te m p o r a r i ly taking control of gear changes
You can temporarily take control of gear changes using the "+"and "-"
steering
mounted controls; if the engine speed allows,
the
gear change command is acted on.
This function allows you to anticipate cer tain
situations such as over taking a vehicle or approaching a corner.
After a few moments with no action on thecontrols, the gearbox returns to automaticcontrol of the gears.

6
45 Visibility








LED daytime running lamps *
On starting the vehicle, the LED daytime running lamps come on automatically, if the lighting stalk is in the OFFposition.
If the sidelamps and headlamps are switched on manually or automatically, the LED lamps switch off.
Deactivation/activation

Vehicles fi tted with front
foglamps and a rear foglamp (ring C)
Turn the ring C
: )forwards a 1 st
time to switch on the front
foglamps, )forwards a 2nd time to switch on the rear foglamp, )rearwards a 1 sttime to switch off the rear foglamp, )rearwards a 2nd
time to switch of the frontfoglamps.


Direction indicators
Left:
stalk downwards. Right:
stalk upwards.
The front foglamps only operate if thesidelamps or dipped beam / main beamheadlamps are on. The rear foglamp only operates if the front foglamps are on.
In countries where exterior lighting by day is nota legal requirement, it is possible to deactivate
the function in the following way.
- Engine stopped, lighting off and parking brake applied, switch on the ignition (key in
the Running position (2nd notch)).
- Within a period of 5 seconds, turn the
lighting control stalk ring Afrom the OFF
position to the Sidelamps
position thenreturn to the OFF
position three times.
An audible signal con
firms the deactivation of
the daytime running lamps.

*
LED: li
ght-emitting diodes.
In countries where daytime running lamps are required by law, this "Daytimerunning lamps" function is alwaysactivated by default and must not dedeactivated.



To reactivate the daytime running lamps, repeat this procedure. An audible signal confirms the
reactivation of the daytime running lamps.

VSC
50Safety














Anti-slip regulation (ASR) and electronic
stability programme (ESP)


Operating check
Operation of the ASR and ESP
s
ystems
When one of these two systems is
operating, this warning lamp comes on.
If a fault occurs with the s
ystems, this
warning lamp comes on.
Contact a CITROËN dealer or aqualified workshop to have thesystems checked.
These systems are linked and supplement the
ABS.
The ASR system optimises drive to prevent the
wheels skidding, by acting on the brakes of the
driving wheels and on the engine. It also allows
the directional stability of the vehicle to be
improved on acceleration.
If there is a variation between the trajectory followed by the vehicle and that required by
the driver, the ESP system automatically acts on the brake of one or more wheels and on theengine to put the vehicle back on course, within
the limits of the laws of physics.
The ASR/ESP systems offer exceptional safety during normal driving, but this should not encourage the driver to take extra risks or drive athigh speed. Correct operation of these systemsdepends on obser vation of the manufacturer's recommendationsregarding the wheels (tyres and rims), thebraking components and the electronic components as well as the repair procedures use by a CITROËN dealer or qualified workshop.
After an impact, have these systemschecked by a CITROËN dealer or aqualified workshop.

52Safety
Front seat belts(s) not fastened /
unfastened warning lamp *
Not fastened
Unfastened
When the ignition is switched on, the
warning lamp flashes if the driver
and
/or front passenger has not fastened their seat belt.
Above a speed of about 12 mph (20 km/h) and for two minutes, the warning lamp flashes accompanied by an increasing audible signal.
After these two minutes, the warning lampcontinues to flash but without the audiblesignal, if the driver and/or front passenger hasnot fastened their seat belt.
The warnin
g lamp flashes when the
driver and/or the front passenger unfastens their seat belt with the engine running.
Above a speed of about 12 mph (20 km/h) and for two minutes, the warning lamp flashes accompanied by an increasing audible signal.
After these two minutes, the warning lampcontinues to flash but without the audiblesignal, if the driver and/or front passenger has
not fastened their seat belt.

*
Dependin
g on version.

9
71 Practical information




















Changing a fuse


Removing and fitting a fuse
Failed
Tweezer A
Th
ese are located on each side of the
instrument panel under the trim.
) If necessary, unlock the steering using the
key. ) Turn the steering wheel to the left, remove bolt B.
)
Turn the steering wheel to the right, removebolt C.


Always replace a failed fuse with a fuse of the same rating (same colour).


Instrument panel fuseboxes


The fuseboxes are located under the instrument panel trim and next to the battery in the engine compartment.

Before chan
ging a fuse, the cause of the
incident must be found and rectified. )Use the tweezer A located in the fusebox under the bonnet.
