2012 Citroen C1 display

04
106
USING THE TELEPHONE
Press MENU then select "Bluetooth"
.
Select "BT management"
and confi rm. The list of
paired telephones is displayed.
Indicates connection of the audio profi le.


MANAGING CONNECTIONS

Select a telephone and confi rm "OK".

Indicates connection o
f the hands-free profi le.
Then select or deselect:
- "Tel."
: hands-free connection
-
"Audio"
: play audio fi les
"OK"to confi rm the choice.
Select "Delete"to delete the
pairing.

04
107
USING THE TELEPHONE
Make along press on SRC/TEL
to display the calls list.

In the list o
f calls, select the number and choose "Missed calls", "Dialed calls"or "Answered calls".

Previous or next page in the calls list.
"OK"
starts the call.


MAKING A CALL - RECENTLY CALLED NUMBERS *


Navigation in the calls list. The calls list includes the calls sent from and b
y from the vehicle via
the connected telephone.
It is possible to make a call directl
y from the telephone; stop the
vehicle as a safety measure.


*
Depending on the compatibility of the telephone.
For access to the calls list, it is also
possible to press MENU, select "Telephone"
, then select "Call"
, and fi nally select "Calls list".

04
108
USING THE TELEPHONE
Press MENU , select "Telephone".

Select Call
then "Directory" .

An incoming call is announced by a ring and a superimposed display in the screen.
Select the desired number and confi rm.
"OK"
to start the call.
Press SRC/TEL
or select "YES " to
accept the call,
or
select "NO"
to reject the call.


MAKING A CALL -
FROM THE DIRECTORY
RECEIVING A CALL

A long press on ESC
or on SRC/TEL
also rejects an incoming call.

05
110
Press ‘to display the audio settings menu.
Press ‘to go to the next setting.

The settin
gs available are:


- AMBIANCE: BASS
, TREBLE and LOUDNESS.

- BALAN
CE (left/right balance).

The AMBIANCE, TREBLE and BASS audio settin
gs are different
and independent for each sound source.

AUDIO SETTINGS

06
111
CONFIGURATION

DISPLAY AND LANGUAGE SETTINGS

Select "System"
when you want to install an update. Information can be obtained from a CITROËN dealer.yyp

Select "Language"to modify the display language. Pr
ess MENU then "Confi g.".

Select "Displaying"
to activate or deactivatescrolling text. Select "Version"
for information on the software.

07
11 2
SCREEN MENU MAP
1
2
2
2
2
1
2
2
2
1
2
2
2
2
3
3
1
2
2
4
4
4
1
2
3
2
3
3
3
3
3
3
3
2
2
3
3
3
MENU
Radi
o
TA
RD
S
TXT
Write freq.
Media
Normal
Random
Random all
Telephone
Call
Repeat
TA
Phone status
Directory
Calls list
Bluetooth
BT mana
gement
Search
Missed calls
Dialed calls
An
swered calls
Confi g.
Time
Scrolling text
Language
D
eutsch
En
glish
Español
Français
It
aliano

Nederlands

Português
Version
System Portu
guês-Brasil
Р
усский
T
ürkçe
2Displaying

113
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWERSOLUTION
There is a difference in sound quality between
the different audiosources (radio, CD...).
For optimum sound quality, the audio settings
(Bass, Treble, Ambience, loudness) can be adapted to the different sound sources, which mayresult in audible differences when changing source (radio, CD...).
Check that the audio settings (Bass, Treble, Ambience, Loudness) are adapted to the sources listened to. It is advisable to adjust audio settings(Bass, Treble, Front-Rear balance, Left-Right balance)
to the middle position, select the musical ambience
and set the loudness correction to the "Active" position
in CD mode or to the "Inactive" position in radio mode.
When chan
ging the settings for treble and
bass, the ambience
setting is deselected.

When changing the
ambience setting, treble and bass are reset to zero.
Choosing an ambience imposes settings for treble and bass. Modifyingone without the other is only possible with a personalised ambience. Modify the treble and bass settings or the
ambience setting to obtain the desired sound quality.
The qualit
y of receptionof the radio station
listened to graduallydeteriorates or the stored stations do not function(no sound, 87.5 MHz is
displayed...). The vehicle is too
far from the transmitter used by the station listened
to or there is no transmitter in the geographical area through which the
vehicle is travellin
g.
Activate the RDS function to enable the system
to check whether there is a more powerful
transmitter in the geographical area.
The environment
(hills, buildings, tunnels, basement car parks...) block reception, including in RDS mode. This phenomenon is normal and does not indicate
a failure of the audio equipment.
The aerial is absent or has been dama
ged (for example when goingthrough a car wash or into an underground car park). Have the aerial checked by a CITROËN dealer.

Sound cut-outs of 1 to
2 seconds in radio mode.During this brief sound cut-out, the RDS searches for any frequency
permitting better reception of the station. Deactivate the RDS function if the phenomenon is
too frequent and always on the same route. The
following tables contain answers to the most frequently asked questions.

11 4
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWER SOLUTION
Traffi c announcement
TA is displayed. I donot receive any traffi c
information.Th
e radio station does not broadcast traffi c information. Tune to a radio station which broadcasts traffi c
information.
Th
e stored stations arenot found (no sound, 87.5 MHz is displayed...). An in
correct waveband is selected. Press the SRC/TEL button to return to thewaveband (FM1 or FM2) on which the stations arestored.
The CD is e
jected
automatically or is not played by the player. The CD is inserted upside down, is unpla
yable, does not contain any audio data or contains an audio format which the player cannot play.
The
CD is protected by an anti-pirating protection system which is not recognised by the audio equipment.
- Check that the CD is inserted in the pla
yer the
right way up.

-
Check the condition of the CD: the CD cannot
be played if it is too damaged.

-
Check the content in the case of a recordedCD: consult the advice in the "Audio" section.

- The audio equipment's CD pla
yer does not
play DVDs.

- Due to their qualit
y level, certain writeableCDs will not be played by the audio system.
The CD pla
yer sound ispoor.The CD used is scratched or of poor quality. Insert good quality CDs and store them in suitable conditions.
The audio settin
gs (bass, treble, ambience) are unsuitable. Set the treble or bass level to 0, without selectingan ambience.
Th
e Bluetooth connection
is cut. The battery of the peripheral may not be suffi ciently charged. Recharge the battery of the peripheral device.
The messa
ge "USB
device error" is displayedon the screen.The USB memor
y stick is not recognised.
The memor
y stick may be corrupt. Reformat the memor
y stick in FAT 16 or FAT 32.
