Changing a bulb
)
Turn the bulb holder A
one quar ter of a turn and remove it. )
Remove the bulb and change it.

5
.Tighten the wheel bolts using the wheelbrace 1.6.Refit the trim. 7. Store the tools and the wheel in the boot.
1
.Sidelamps2.Direction indicators3.Dipped beam / Main beam headlamps
Never go underneath a vehicle suppor tedonly by a jack (use an axle stand). The jack and the tool kit are specific to your vehicle. Do not use them for other
purposes.
In cer tain climatic conditions (low temperatures, humidity), the presence
of condensation on the internalsur face of the headlamps is normal ; it disappears a few minutes after the lighting is switched on.
Front lamps
1. Sidelamps (W5 W)
After changing a wheel: -have the tightness of the bolts and thepressure of the spare wheel checked as soon as possible,
-have the punctured wheel repaired andrefit it on the vehicle as soon as possible. Contact a CITROËN dealer or a qualifiedworkshop.

68Practical information
) Disconnect the connector. )
Remove the rubber cap C.)
Push the side of the tongue D.)
Remove the bulb holder and change thebulb. )
Refit the bulb holder, the tongue then the
rubber cap.
If
you encounter any difficulties, contact a CITROËN dealer or a qualified workshop.



LED daytime running lamps

For the replacement of these lamps, contact aCITROËN dealer or qualified workshop.

Front foglamps

For replacement of these bulbs, contact a CITROËN dealer or a qualified workshop.

)Turn the bulb holder Bone quar ter of a turnand remove it.)Turn the bulb one quar ter of a turn.)Remove the bulb and change it.
If you encounter any difficulties, contact aCITROËN dealer or a qualified workshop.

2. Direction indicators(PY 21 W amber)3. Dipped / Main beam headlamps(H4 - 60/55W)

9
73 Practical information
*
Fuses located behind the instrument panel. To change them, contact a CITROËN dealer or a qualified workshop.
FuseN°Rating(A)Functions
110Brake lamps - ABS - Electronic gearbox
225Central locking/unlocking - Remote control
320Rear screen demisting
47.5Rear lamps - Number plate lamps - Instrument panel - Screen - headlamp adjustment - LED daytime runninglamps - Sidelamps
57.5Diagnostic socket
67.5Electronic gearbox - Rear foglamp - ESP - LED daytime running lamps - Instrument panel - Rev counter
7-Not used
87.5
ABS/ESP - Power steering - Fan assembly
910Reversing lamps - Central locking/unlocking - Electric windows - Rear screen demisting - Speedometer -Air conditioning - Heating - Rev counter - Remote control
1020Front and rear wipers and screenwash
1115
Audio equipment - 12 V socket (120 W max)
127.5
Heated rear screen - ABS - Fan assembly - Front and rear wipers and screenwash - Power steering - Central
locking/unlocking - Air conditioning - Heating - Electric windows - Speedometer - Rev counter - Remote control -Reversing lamp
1315
Airbag - Fuel injection system - Electronic gearbox - Instrument panel - Rev counter - LED daytime running lamps
147.5 Air conditioning - Heating
15 *40
Audio system - 12 V socket - Front and rear wipers - Power steering - ABS/ESP - Cooling fan assembly
16 * 30Electric windows
17 *40
Air conditioning - Heating

128Visual search
Exterior


Keys, remote control, locating the vehicle 4, 26
Remote control battery 27
Starting 4, 42

Opening the bonnet 84


To w i ng 80-81


Tyres, pressures 65, 92


Parking brake 48, 88
ABS (EBFD-CSC) 49
ASR/ESP 50

Fuel tank, filler cap,filling with fuel 5, 30
Fuel gauge 23


Mirrors 37
Roof bars 81

Opening/closing, locking/unlocking doors 28


Front lamps, foglamps 44
Direction indicators 45 Changing bulbs 67- 68
Adjusting the headlamps 46


Boot 29, 41
Spare wheel, jack, changing,fitting 41, 65 - 67


Rear lamps, foglamp 44
Changing bulbs 69
Number plate lamps, 3rd brake lamp, siderepeaters 70

LED daytime running lamps 45

.
131 Visual search
Steering mounted controls
Rev counter 19


Door mirrors 37


Lighting, sidelamps, dipped/main beam headlamps, front foglamps, directionindicators 44-45
LED daytime running lamps 45


Headlamp adjustment 46
Instrument panel 19Warning lamps, indicator lamps 20-22Screen, indicators, total/trip distance recorder 19, 23-24Fuel gauge 23Instrument panel fuses 71-73
Deactivating the passenger's airbag 55 Opening the bonnet 84


Wipers, screenwash 47


Ignition, star ting,engine immobiliser 4, 16, 42


Horn 37


Steering wheel, height adjustment 48

.
