Dimensions:Overall length:
2202 mm (86.7 in)
Overall width:
689 mm (27.1 in)
Overall height:
1175 mm (46.3 in)
Seat height:
820 mm (32.3 in)
Wheelbase:
1341 mm (52.8 in)
Ground clearance:
151 mm (5.94 in)
Minimum turning radius:
2900 mm (114.2 in)
Weight:With oil and fuel:
124.0 kg (273 lb)
Engine:Engine type:
Liquid cooled 2-stroke
Cylinder arrangement:
Forward-inclined single cylinder
Displacement:
49.7 cm
3
Bore x stroke:
40.3 x 39.0 mm (1.59 x 1.54 in)
Compression ratio:
11.50 :1
Starting system:
Electric starter
Lubrication system:
Separate lubrication (Yamaha autolube)Type:
YAMALUBE 2 or 2-stroke engine oil
(JASO FC grade) or (ISO EG-C or EG-D
grade)
Quantity:
1.40 L (1.48 US qt, 1.23 Imp.qt)
Transmission oil:Oil change quantity:
0.75 L (0.79 US qt, 0.66 Imp.qt)
Type:
SAE 10W-30 type SE motor oil
Cooling system:Coolant reservoir capacity (up to the maxi-
mum level mark):
0.29 L (0.31 US qt, 0.26 Imp.qt)
Radiator capacity (including all routes):
0.70 L (0.74 US qt, 0.62 Imp.qt)
Air filter:Air filter element:
Wet element
Fuel:Recommended fuel:
Regular unleaded gasoline only
Fuel tank capacity:
13.8 L (3.65 US gal, 3.04 Imp.gal)
Fuel reserve amount:
2.2 L (0.58 US gal, 0.48 Imp.gal)
Carburetor:Manufacturer:
DELL’ORTO
Type x quantity:
PHBN 16 x 1
Spark plug (s):Manufacturer/model:
NGK / BR9 ES
Spark plug gap:
0.6–0.7 mm (0.024–0.028 in)
Clutch:Clutch type:
Wet, multiple-disc
Transmission:Primary reduction system:
Helical gear
Primary reduction ratio:
71/20 (3.55)
Secondary reduction system:
Chain drive
Secondary reduction ratio:
60/11 (5.45)
Transmission type:
Constant mesh 6-speed
Operation:
Left foot operation
Gear ratio:1st:
36/12 (3.00)
2nd:
33/16 (2.062)
3rd:
29/19 (1.526)
4th:
27/22 (1.227)
5th:
25/24 (1.041)
6th:
24/25 (0.960)
SPECIFICATIONS
8-1
8
5WX-F819D-E3 15/11/08 15:27 Página 79
Rear turn signal light:
12 V, 10.0 W x 2
License plate light:
12 V, 5.0 W x 1
Meter lighting:
12 V, 1.2 W x 2
Neutral indicator light:
LED
Oil level warning light:
LED
Turn signal indicator light:
LED
Coolant temperature warning light:
LED
Engine trouble warning light:
LED
Fuse:Main fuse:
10.0 A
SPECIFICATIONS
8-3
8
5WX-F819D-E3 15/11/08 15:27 Página 81
AAir filter element .......................................6-15
Anti-theft device housing .........................3-12
Autolube pump, adjusting........................6-27
BBattery......................................................6-30
Brake and clutch levers, checking and
lubricating ..............................................6-27
Brake and shift pedals, checking and
lubricating ..............................................6-27
Brake fluid level, checking .......................6-22
Brake fluid, changing ...............................6-23
Brake lever .................................................3-6
Brake pedal ................................................3-6
Brake pedal free play, adjusting ..............6-20
CCables, checking and lubricating ............6-26
Carburetor, adjusting ...............................6-16
Care............................................................7-1
Catalytic converter .....................................3-9
Clutch lever ................................................3-5
Clutch lever free play, adjusting...............6-19
Coolant.....................................................6-13
Coolant temperature warning light ............3-3
Cowlings and panels, removing and
installing ...................................................6-8
DDimmer switch ...........................................3-4
Drive chain slack ......................................6-24
Drive chain, cleaning and lubricating.......6-25
EEngine break-in ..........................................5-3
Engine idling speed .................................6-16
Engine oil ...................................................3-9Engine stop switch ....................................3-5
Engine trouble warning light ......................3-3
Engine, starting a warm .............................5-2
FFront and rear brake pads, checking ......6-21
Front brake lever free play, checking.......6-20
Front fork, checking .................................6-28
Fuel ............................................................3-7
Fuel cock..................................................3-10
Fuel consumption, tips for reducing ..........5-3
Fuel tank breather/overflow hose ..............3-8
Fuel tank cap .............................................3-6
Fuse, replacing.........................................6-31
HHandlebar switches ...................................3-4
Headlight bulb, replacing .........................6-32
Horn switch ................................................3-4
IIdentification numbers ...............................9-1
Ignition circuit cut-off system ..................3-13
Indicator and warning lights ......................3-2
KKey identification number ..........................9-1
LLicense plate light bulb, replacing ...........6-35
MMain switch/steering lock ..........................3-1
Maintenance and lubrication, periodic ......6-4
Maintenance, emission control system .....6-3
Matte color, caution ...................................7-1
Model label ................................................9-2
NNeutral indicator light.................................3-2
OOil level warning light .................................3-2
PParking .......................................................5-4
Part locations .............................................2-1
Pass switch ................................................3-4
Pre-operation check list .............................4-2
RRear brake light switch, adjusting ...........6-21
Rear view mirrors .....................................3-12
SSafety information ......................................1-1
Seat ..........................................................3-11
Shift pedal ..................................................3-5
Shift pedal position, adjusting .................6-21
Shifting .......................................................5-2
Sidestand .................................................3-13
Sidestand, checking and lubricating .......6-28
Spark plug, checking ...............................6-10
Specifications.............................................8-1
Speedometer unit ......................................3-3
Start switch ................................................3-5
Starter (choke) lever .................................3-11
Starting a cold engine ................................5-1
Steering, checking ...................................6-29
Storage.......................................................7-3
TTachometer ................................................3-4
Tail/brake light bulb, replacing .................6-33
Throttle cable free play, adjusting ............6-17
Throttle grip and cable, checking and
lubricating ..............................................6-26
Tires .........................................................6-17
Tool kit ........................................................6-1
INDEX
