INSTRUMENT AND CONTROL FUNCTIONS
3-6
3
EAU11872
Tachometer The electric tachometer allows the rider
to monitor the engine speed and keep it
within the ideal power range.
When the key is turned to “ON”, the ta-
chometer needle will sweep once
across the r/min range and then return
to zero r/min in order to test the electri-
cal circuit.NOTICE
ECA10031
Do not operate the engine in the ta-
chometer red zone.
Red zone: 9000 r/min and above
EAU2686H
Multi-function display
WARNING
EWA14431
Be sure to stop the vehicle before
making any setting changes to the
multi-function display. Changing
settings while riding can distract the
operator and increase the risk of an
accident.The multi-function display is equipped
with the following:
an odometer
two tripmeters (which show the
distance traveled since they were
last set to zero)
a fuel reserve tripmeter (which
shows the distance traveled on the
fuel reserve)
a clock
a fuel meter
a coolant temperature meter
a transmission gear display
an ambient temperature display
a fuel consumption display (instan-
taneous and average consumption
functions)
a self-diagnosis device
TIPBe sure to turn the key to “ON” before
using the select and reset buttons.
1. Tachometer
2. Tachometer red zone
1. Multi-function display
2. Select button
3. Reset button
