INSTRUMENT AND CONTROL FUNCTIONS
EAU13445
Catalytic convertersThis vehicle is equipped with catalytic
converters in the exhaust system.
EWA10862
WARNING
The exhaust system is hot after op-
eration. To prevent a re hazard or
burns:● Do not park the vehicle near
possible re hazards such as
grass or other materials that
easily burn.● Park the vehicle in a place
where pedestrians or children
are not likely to touch the hot
exhaust system.● Make sure that the exhaust
system has cooled down be-
fore doing any maintenance
work.● Do not allow the engine to idle
more than a few minutes. Long
idling can cause a build-up of
heat.
ECA10701
NOTICEUse only unleaded gasoline. The
use of leaded gasoline will cause
unrepairable damage to the cata-
lytic converter.
EAU13680
KickstarterZAUM00**
1
1. Kickstarter To start the engine, fold out the kick-
starter lever, move it down lightly with
your foot until the gears engage, and
then push it down smoothly but force-
fully.
2 ( ' K P F F
J`.,*f J`.,Q/f2J`.,`oJ`.,I\6"
Page 26 of 80

1
2
3
4
5
6
7
8
9
3-10
EAU1044E
INSTRUMENT AND CONTROL FUNCTIONS
EAUT1503
SeatTo open the seat
1. Place the scooter on the center-
stand.
2. Insert the key into the main
switch, and then turn it coun-
terclockwise to the fi rst “OPEN”
position. If the main switch is in
the “LOCK” position, turn the key
counterclockwise to the second
“OPEN” position.ZAUM00**TIPDo not push inward when turning the
key from “OFF” to “OPEN” or from
“LOCK” to “OPEN”.
3. Fold the seat up.
To close the seat
1. Fold the seat down, and then
push it down to lock it in place.
2. Remove the key from the main
switch if the scooter will be left
unattended.TIPMake sure that the seat is properly se-
cured before riding.
EAUT1712
Storage compartmentsFront storage compartmentZAUM00**
1
1. Front storage compartment
EWA11191
WARNING
● Do not exceed the load limit of
1.5 kg (3.3 lb) for the front stor-
age compartment.● Do not exceed the maximum
load of 157 kg (346 lb) for the
vehicle.
2 ( ' K P F F
J`.,*f J`.,Q/f2J`.,`oJ`.,I\6"
Page 27 of 80

1
2
3
4
5
6
7
8
9
3-11
EAU1044E
INSTRUMENT AND CONTROL FUNCTIONS
Rear storage compartmentZAUM00**
1
1. Rear storage compartmentThe rear storage compartment is
located under the seat. (See page
3-10.)
ECAT1030
NOTICEKeep the following points in mind
when using the rear storage com-
partment.● Since the rear storage com-
partment accumulates heat
when exposed to the sun, do
not store anything susceptible
to heat inside it.● To avoid humidity from spread-
ing through the rear storage
compartment, wrap wet articles
in a plastic bag before storing
them in the compartment.
● Since the rear storage com-
partment may get wet while the
scooter is being washed, wrap
any articles stored in the rear
compartment in a plastic bag.● Do not keep anything valuable
or breakable in the rear storage
compartment.
EWAT1051
WARNING
● Do not exceed the load limit of
5 kg (11 lb) for the rear storage
compartment.● Do not exceed the maximum
load of 157 kg (346 lb) for the
vehicle.
EAU15304
SidestandZAUM00**
1
1. SidestandThe sidestand is located on the left
side of the frame. Raise the sidestand
or lower it with your foot while holding
the vehicle upright.TIPThe built-in sidestand switch is part
of the ignition circuit cut-off system,
which cuts the ignition in certain situa-
tions. (See page 3-12 for an explana-
tion of the ignition circuit cut-off sys-
tem.)
2 ( ' K P F F
J`.,*f J`.,Q/f2J`.,`oJ`.,I\6"
Page 28 of 80

1
2
3
4
5
6
7
8
9
3-12
EAU1044E
INSTRUMENT AND CONTROL FUNCTIONS
EWA10241
WARNING
The vehicle must not be ridden with
the sidestand down, or if the sid-
estand cannot be properly moved
up (or does not stay up), otherwise
the sidestand could contact the
ground and distract the operator,
resulting in a possible loss of con-
trol. Yamaha’s ignition circuit cut-
off system has been designed to
assist the operator in ful lling the
responsibility of raising the sides-
tand before starting off. Therefore,
check this system regularly and
have a Yamaha dealer repair it if it
does not function properly.
EAUT1095
Ignition circuit cut-off systemCheck the operation of the sidestand
switch according to the following pro-
cedure.Turn the key on.
Put the sidestand up.Push the start switch while applying
either of the brake levers. The engine will
start.Put the sidestand down.
If the engine stalls:
The sidestand switch is OK.
WARNING
● The vehicle must be placed on
the centerstand during this in-
spection.● If a malfunction is noted, have
a Yamaha dealer check the
system before riding.
2 ( ' K P F F
J`.,*f J`.,Q/f2J`.,`oJ`.,I\6"
Page 29 of 80
1
2
3
4
5
6
7
8
9
4-1
EAU15582
FOR YOUR SAFETY - PRE-OPERATION CHECKS
EAU15582
FOR YOUR SAFETY - PRE-OPERATION CHECKS
EAU15596
Inspect your vehicle each time you use it to make sure the vehicle is in safe operating condition. Always follow the in-
spection and maintenance procedures and schedules described in the Owner’s Manual.
EWA11151
WARNING
Failure to inspect or maintain the vehicle properly increases the possibility of an accident or equipment dam-
age. Do not operate the vehicle if you nd any problem. If a problem cannot be corrected by the procedures pro-
vided in this manual, have the vehicle inspected by a Yamaha dealer.
2 ( ' K P F F
J`.,*f J`.,Q/f2J`.,`oJ`.,I\6"
Page 30 of 80

1
2
3
4
5
6
7
8
9
4-2
EAU15582
FOR YOUR SAFETY - PRE-OPERATION CHECKSBefore using this vehicle, check the following points:
ITEM CHECKS PAGE
Fuel• Check fuel level in fuel tank.
• Refuel if necessary.
• Check fuel line for leakage.3-7
Engine oil• Check oil level in engine.
• If necessary, add recommended oil to specifi ed level.
• Check vehicle for oil leakage.6-10
Final transmission oil• Check vehicle for oil leakage. 6-12
Front brake• Check operation.
• If soft or spongy, have Yamaha dealer bleed hydraulic system.
• Check brake pads for wear.
• Replace if necessary.
• Check fl uid level in reservoir.
• If necessary, add recommended brake fl uid to specifi ed level.
• Check hydraulic system for leakage.6-18~6-20
Rear brake• Check operation.
• Lubricate cable if necessary.
• Check lever free play.
• Adjust if necessary.6-18, 6-19
Throttle grip• Make sure that operation is smooth.
• Check throttle grip free play.
• If necessary, have Yamaha dealer adjust throttle grip free play and lubricate
cable and grip housing.6-15, 6-21
Wheels and tires• Check for damage.
• Check tire condition and tread depth.
• Check air pressure.
• Correct if necessary.6-16, 6-17
Brake levers• Make sure that operation is smooth.
• Lubricate lever pivoting points if necessary.6-21
2 ( ' K P F F
J`.,*f J`.,Q/f2J`.,`oJ`.,I\6"
Page 31 of 80
1
2
3
4
5
6
7
8
9
4-3
EAU15582
FOR YOUR SAFETY - PRE-OPERATION CHECKS
ITEM CHECKS PAGE
Centerstand, sidestand• Make sure that operation is smooth.
• Lubricate pivots if necessary.6-22
Chassis fasteners• Make sure that all nuts, bolts and screws are properly tightened.
• Tighten if necessary.-
Instruments, lights, signals
and switches• Check operation.
• Correct if necessary.3-2~3-5
Sidestand switch• Check operation of ignition circuit cut-off system.
• If system is not working correctly, have Yamaha dealer check vehicle.3-11
2 ( ' K P F F
J`.,*f J`.,Q/f2J`.,`oJ`.,I\6"
Page 32 of 80

1
2
3
4
5
6
7
8
9
5-1
EAU15943
OPERATION AND IMPORTANT RIDING POINTS
EAU15943
OPERATION AND IMPORTANT RIDING POINTS
EAU15951
Read the Owner’s Manual carefully
to become familiar with all controls.
If there is a control or function you
do not understand, ask your Yamaha
dealer.
EWA10271
WARNING
Failure to familiarize yourself with
the controls can lead to loss of
control, which could cause an ac-
cident or injury.
EAU45310
TIPThis model is equipped with a lean
angle sensor to stop the engine in
case of a turnover. To start the en-
gine after a turnover, be sure to turn
the main switch to “OFF” and then to
“ON”. Failing to do so will prevent the
engine from starting even though the
engine will crank when pushing the
start switch.
EAUT1863
Starting the engine
ECA10250
NOTICESee page 5-3 for engine break-in
instructions prior to operating the
vehicle for the rst time.
In order for the ignition circuit cut-off
system to enable starting, the sides-
tand must be up.
See page 3-12 for more information.
1. Turn the key to “ON”.
2. Close the throttle completely.
3. Start the engine by pushing the
start switch while applying the
front or rear brake.
NOTICE:
For
maximum engine life, never ac-
celerate hard when the engine
is cold!
[ECA11041]
If the engine does not start, re-
lease the start switch, wait a few
seconds, and then try again.
Each starting attempt should be
as short as possible to preserve
the battery. Do not crank the en-
gine more than 5 seconds on any
one attempt. If the engine does not start with the starter motor, try
using the kickstarter.
2 ( ' K P F F
J`.,*f J`.,Q/f2J`.,`oJ`.,I\6"
