2011 VOLVO V60 Owners Manual

05 Infotainment system
Voice recognition* mobile phone
05

* Option/accessory, for more information, see Introduction.257 Using voice commands
The driver initiates a dialogue with the voice
commands by pressing the button for voice
recognition (see illustration on page 255).
Once a dialogue has been started, commonly
used commands will be shown in the TV
screen. Greyed-out text or text within brackets
is not included in the spoken command.
When the driver becomes accustomed to the
system, he/she can speed up the command
dialogue and skip the prompts from the sys-
tem, by briefly pressing the button for voice
recognition.
Commands can be given in several ways
The command "Phone call contact" can be
pronounced as e.g.:
•"Phone > Call contact" - Say "Phone", wait
for the system's reply, and then continue
by saying "Call contact."
or
•"Phone call contact" - Say the whole com-
mand in one sequence.
Quick commandsQuick commands for the phone can be found
in the menu system MY CAR under Settings
Voice settingsVoice command list
Phone commands and Generalcommands
. For a description of the menu
system, see page 142.
Dial a numberThe system understands the numbers 0 (zero)
to 9 (nine). These numbers can be pronounced
individually, in groups of several numbers at a
time, or the whole number all at once. Numbers
greater than 9 (nine) cannot be handled by the
system, e.g. 10 (ten) or 11 (eleven) are not pos-
sible.
The following is an example of a dialogue with
voice commands. The system's reply will vary
depending on the situation.
The user starts the dialogue by saying:Phone > call number
or
Phone call number
System replyNumber?
User actionStart saying the numbers (as individual units,
i.e. six-eight-seven, etc.) in the phone number.
If you say several numbers and pause, the sys-
tem will repeat them, and then say "Continue".
Continue to say the numbers. When finished,
finish the command by saying "Call".
•You can also change the number by saying
the commands "Correct" (which deletesthe last spoken group of numbers) or
"Delete" (which deletes the whole spoken
phone number).
Dialling from the call registerThe following dialogue allows you to make a
phone call from one of your mobile phone's call
registers.
The user starts the dialogue by saying:Phone > call from the call register
or
Phone call from the call register
Continue by responding to the system's
prompts.
Call a contactThe following dialogue allows you to call your
pre-defined contacts in the mobile phone.
The user starts the dialogue by saying:Phone > call contact
or
Phone call contact
Continue by responding to the system's
prompts.
Consider the following when you call a contact:
•If there are several contacts with similar
names, they will be presented in the dis-
ProCarManuals.com

05 Infotainment system
Voice recognition* mobile phone
05
258* Option/accessory, for more information, see Introduction.
play in the numbered rows and the system
prompts you to select a row number.
•If there are more rows in the list than can
be displayed simultaneously, saying
"Down" allows you to scroll down in the list
(and saying "Up" allows you to scroll up in
the list).
Calling voice mailboxThe following dialogue allows you to call your
voice mailbox to check if you have received
any messages. The phone number for your
voice mailbox must be registered in the
Bluetooth
Ÿ function, see page 250.
The user starts the dialogue by saying:Phone > call voice mailbox
or
Phone call voice mailbox
Continue by responding to the system's
prompts.
ProCarManuals.com

05 Infotainment system
Menu navigation, Infotainment
05

* Option/accessory, for more information, see Introduction.259 To navigate in the menus
The infotainment system's functions are con-
trolled via the system's menus. Each source in
the infotainment system (e.g. RADIO, MEDIA)
has its own separate menus. In order to access
the menus and activate a function a source
must first have been selected (e.g.
RADIO/FM1). Then press OK/MENU for access into
the menu for the selected source.
The menu options are selected by means of the
buttons in the centre console or via the steering
wheel keypad*. The functions are described
under their respective sections.
Controls in the centre console
RADIO
MEDIA
TEL
TUNE
OK/MENU
Search pathsThe search paths to the menu functions are
specified in the owner's manual with the form:Audio settings
Equalizer, which requires
that the following is carried out beforehand:
1. Select a source by pressing one of the but-
tons (e.g. RADIO, MEDIA etc.). Continue
to press in order to scroll down among the
options on the TV screen (e.g.
FM1),
release and wait a second and the selec-
tion is accepted automatically. Alterna-
tively, turn TUNE and confirm with OK/
MENU.
2.
Press OK/MENU and turn TUNE, or use
the thumbwheel* on the steering wheel
keypad to reach the desired menu option
e.g.
Audio settings and press OK/
MENU.
3.
Turn TUNE again to reach the desired sub-
menu, e.g.
Equalizer, and press OK/
MENU.
Menus RADIO
Main menu AMAM menu
Show presets1
Scan
1Only applies to High Performance Multimedia and Premium Sound Multimedia.
ProCarManuals.com

05 Infotainment system
Menu navigation, Infotainment
05
260* Option/accessory, for more information, see Introduction.
Audio settings2
Sound stage3
Equalizer4
Volume compensation
Reset all audio settings
Main menu FM1/FM2FM menu
TP (traffic information)
Show radio text
Show presets1
Scan
News settings
Advanced settings
REG
Alternative frequency
EON
Set TP favourite
PTY settingsReset all FM settings
Audio settings5
Main menu DAB1*/DAB2*DAB menu
Ensemble learn
PTY filtering
Turn off PTY filtering
Show radio text
Show presets1
Scan
Advanced settings
DAB linking
DAB band
Sub channels
Show PTY text
Reset all DAB settings
Audio settings5
Menus MEDIA
Main menu CD AudioDisc menu
Random
Scan
Audio settings5
Main menu CD/DVD1 DataDisc menu
Play/Pause
Stop
Random
Repeat folder
Change subtitles
Change soundtrack
Scan
Audio settings5
2The menu options for audio settings are the same for all audio sources.3Only applies to Premium Sound Multimedia.4Does not apply to Performance.1Only applies to High Performance Multimedia and Premium Sound Multimedia.5For submenus, see "Main menu AM".
ProCarManuals.com

05 Infotainment system
Menu navigation, Infotainment
05

* Option/accessory, for more information, see Introduction.261
Main menu DVD1 VideoDisc menu
DVD disc menu
Play/Pause/Continue
Stop
Subtitles
Audio tracks
Advanced settings
Angle
DivX® VOD code
Audio settings5
Main menu iPod4
iPod menu
Random
Scan
Audio settings5
Main menu USB4
USB menu
Play/Pause
Stop
Random
Repeat folder
Select USB device
Change subtitles
Change soundtrack
Scan
Audio settings5
Main menu Media Bluetooth4
Bluetooth menu
Random
Change unit
Remove Bluetooth device
Scan
Bluetooth software version in car
Audio settings5
Main menu AUXAUX menu
AUX input volume
Audio settings5
Main menu TV*TV menu
Select country
Reorganise presets
Autostore
Scan
Audio settings5
Pop-up menu6 video and TV*
Press OK/MENU when playing back a video or
TV* is being displayed in order to access the
pop-up menu.
Image settings
1Only applies to High Performance Multimedia and Premium Sound Multimedia.5For submenus, see "Main menu AM".4Does not apply to Performance.6Only applies when playing back videos or displaying TV*.
ProCarManuals.com

05 Infotainment system
Menu navigation, Infotainment
05
262
Source menu7
DVD root menu8
DVD title menu8
Menus TEL
Main menu BluetoothŸŸ handsfree4
Phone main menu
Call list
All calls
Missed calls
Answered calls
Dialled calls
Call duration
Phone book
Search
New contact
Speed dials
Receive vCard
Memory status
Clear phone bookChange phone
Remove Bluetooth device
Phone settings
Discoverable
Sounds and volume
Download phone book
Bluetooth software version in
car
Call options
Auto answer
Voicemail number
Phone off
7What is shown in the pop-up menu for the source menu depends on what is being played back or displayed, it can be e.g. Disc menu or USB menu.8Only applies to DVD video discs.4Does not apply to Performance.
ProCarManuals.com

05 Infotainment system

05
263ProCarManuals.com
