2011 VOLVO S60 mirror controls

Contents
* Option/accessory, for more information, see Introduction.5
03
03 Your driving environment
Instruments and controls.......................... 74
Ignition modes.......................................... 81
Seats......................................................... 83
Steering wheel.......................................... 89
Lighting..................................................... 90
Wipers and washers................................. 96
Power windows......................................... 98
Mirrors..................................................... 100
Compass*............................................... 102
Power moonroof*.................................... 103
HomeLink® Wireless Control System*. . . 105
Starting the engine.................................. 108
Transmission...........................................111
Brakes..................................................... 114
Parking brake.......................................... 116
04
04 Comfort and driving pleasure
Menus and messages............................. 122
My Car ................................................... 124
Climate system....................................... 129
Trip computer......................................... 137
Stability system....................................... 138
Active chassis system–Four C*............... 140
Cruise control.......................................... 141
Adaptive Cruise Control (ACC)*.............. 143
Distance Alert* ....................................... 153
City Safety™ .......................................... 156
Collision warning with Full Auto-brake and
Pedestrian Detection*............................. 162
Driver Alert System* ............................... 169
Park assist*............................................. 175
Rear Park Assist Camera (PAC)* ............ 178
Blind Spot Information System*.............. 182
Passenger compartment convenience. . . 186
05
05 Infotainment
Introduction............................................. 192
Getting started ....................................... 194
General infotainment functions .............. 199
Radio....................................................... 202
Media player........................................... 211
AUX/USB sockets................................... 215
Bluetooth
Ÿ media ................................... 218
Bluetooth® hands-free connection ........ 221
Cell phone voice control......................... 229
Infotainment system menus ................... 233

72* Option/accessory, for more information, see Introduction.
Instruments and controls........................................................................ 74
Ignition modes........................................................................................ 81
Seats....................................................................................................... 83
Steering wheel........................................................................................ 89
Lighting................................................................................................... 90
Wipers and washers................................................................................ 96
Power windows....................................................................................... 98
Mirrors................................................................................................... 100
Compass*.............................................................................................. 102
Power moonroof*.................................................................................. 103
HomeLink® Wireless Control System*................................................. 105
Starting the engine................................................................................ 108
Transmission......................................................................................... 111
Brakes................................................................................................... 114
Parking brake........................................................................................ 116

03 Your driving environment
Instruments and controls
03

* Option/accessory, for more information, see Introduction.75
FunctionPage
Menus and mes-
sages, turn signals,
high/low beams,
trip computersee
page 124,
93, 90,
137
Cruise control141
Horn, airbag89, 25
Main instrument
panel75
Infotainment sys-
tem/Bluetooth
hands-free controls192, 221
START/STOP
ENGINE button81
Ignition slot81
Information display75
Door handle–
In-door control pan-
els (power win-
dows, mirrors, cen-
tral locking button)98, 100,
65
Hazard warning
flashers92
FunctionPage
Infotainment sys-
tem controls192
Climate system
controls132
Gear selector111
Controls for active
chassis (Four-C)*140
Wipers and washers96, 97
Steering wheel
adjustment89
Hood opening con-
trol289
Parking brake116
Power seat* adjust-
ment controls83
Lighting panel, con-
trols for opening
fuel filler door/trunk90, 244,
67
Information displays
Information displays in the instrument panel
The information displays (1) show information
on some of the vehicle's functions, such as
cruise control, the trip computer and mes-
sages. The information is shown with text and
symbols.
More detailed information can be found in the
descriptions of the functions that use the infor-
mation displays.

03 Your driving environment
Seats
03
84* Option/accessory, for more information, see Introduction.
Power seat*
Front edge of seat cushion up/down
Seat forward/rearward and up/down
Backrest tilt
OperationThe seats can be adjusted for a short period
after unlocking the door with the remote con-
trol without the key in the ignition slot. Seat
adjustment is normally made when the ignition
is on and can always be made when the engine
is running.
NOTE
•Only one of the power seat's controls
can be used at the same time.
•The power seats have an overload pro-
tector that activates if a seat is blocked
by any object. If this occurs, switch off
the ignition (key in position 0) and wait
for a short period before operating the
seat again.
Seat with memory function
Stored seat position
Stored seat position
Stored seat position
Memory button
Programming the memoryThree different seating and door mirror posi-
tions can be stored in the driver seat's memory.
The following example explains how button (1)
can be programmed. Buttons (2) and (3) are
programmed in the same way.
To program (store) a seat position and door
mirror position in button (1):
1. Move the seat (and door mirrors) to the
desired position using the seat and mirror
adjustment controls.
2. Press and hold down the memory button
(4).
3. With the memory button depressed, press
button (1) briefly to store the current posi-
tion for the seat/mirrors.
To move the seat and mirrors to the position
that they were in when a button was pro-
grammed:

Press and hold down button (1) until the
seat and mirrors stop moving.
NOTE
As a safety precaution, the seat will stop
automatically if the button is released before
the seat has reached the preset position.

03 Your driving environment
Seats
03

* Option/accessory, for more information, see Introduction.85
Remote keyless entry system and the
driver's seat and door mirrors1
The remote control transmitter also controls
the position of the power driver's seat and door
mirrors in the following way:
1. Adjust the seat to your preferences.
2. When you leave your vehicle, lock it using
the remote control.
The position of the driver's seat and door mir-
rors is now stored in the remote control's mem-
ory.
Automatic seat/mirror adjustmentTo move the seat and door mirrors to the posi-
tion in which you left them:1. Unlock the driver's door with the same
remote control (the one used to lock the
doors).
2. Open the driver's door within 2 minutes.
The driver's seat and door mirrors will auto-
matically move to the position in which you left
them.
NOTE
•The key memory is independent of the
seat memory.
•The seat will move to this position even
if someone else has moved it to a dif-
ferent seating position and locked the
vehicle with a different remote control.
•This feature will work in the same way
with all of the remote control transmit-
ters that you use with your vehicle.
The function can be activated/deactivated
under MY CAR under Settings
Car
settings
Car key memoryPosition of
door mirrors and driver's seat in key. See
page 124 for a description of the menu sys-
tem.
Emergency stopIf the seat accidentally begins to move, press
one of the buttons to stop the seat.
WARNING
•Because the driver's seat can be
adjusted with the ignition off, children
should never be left unattended in the
vehicle.
•Movement of the seat can be STOPPED
at any time by pressing any button on
the power seat control panel.
•Do not adjust the seat while driving. The
seat should be adjusted so that the
brake pedal can be depressed fully. In
addition, position the seat as far rear-
ward as comfort and control allow.
•The seat rails on the floor must not be
obstructed in any way when the seat is
in motion.
Heated seats*See page 133.
1See page 63 for information regarding vehicles with the optional keyless drive.

03 Your driving environment
Mirrors
03
100* Option/accessory, for more information, see Introduction.
Power door mirrors
Door mirror controls
Adjusting1.
Press the L button for the left door mirror
or the R button for the right door mirror.
The light in the button comes on.
2. Adjust the position with the joystick in the
center.
3.
Press the L or R button again. The light
should no longer be on.
WARNING
Objects seen in the mirrors may appear fur-
ther away than they actually are.
Retractable power door mirrors*The mirrors can be retracted for parking/driving
in narrow spaces:
1.
Press down the L and R buttons at the
same time.
2. Release them after approximately one sec-
ond. The mirrors automatically stop in the
fully retracted position.
Fold out the mirrors by pressing down the L
and R buttons at the same time. The mirrors
automatically stop in the fully extended posi-
tion.
Storing the position*The mirror positions are stored in the key mem-
ory when the vehicle has been locked with the
remote key. When the vehicle is unlocked with
the same remote control the mirrors and the
driver's seat adopt the stored positions when
the driver's door is opened.
The function can be activated/deactivated in
MY CAR under Settings
Car settings
Car key memoryPosition of door mirrors
and driver's seat in key. See page 124 for a
description of the menu system.
Tilting the door mirrors when parking*The door mirrors can be tilted down to help
give the driver a better view along the sides of
the vehicle, for example when parallel parking.To activate this function, select reverse gear
and press the L or R mirror control button to tilt
the mirror down.
The function can be activated/deactivated in
MY CAR under Settings
Car settings
Side mirror settingsTilt left mirror or Tilt
right mirror
. See page 124 for a description
of the menu system.
The door mirror will reset to its normal position:
•after 10 seconds when reverse is disen-
gaged and the car remains stopped.
•immediately when reverse is disengaged
and the vehicle's forward speed exceeds
approximately 6 mph (10 km/h).
•immediately if you press the correspond-
ing L or R button again.
•when the engine is turned off.
•when the side mirrors are folded in.
NOTE
Only one mirror can be tilted down at a time.
Automatically tilting the door mirrors
when parking
The door mirrors can tilt down automatically to
help give the driver a better view along the
sides of the vehicle, for example when parallel
parking. When the transmission is no longer in

03 Your driving environment
Power moonroof*
03

* Option/accessory, for more information, see Introduction.103 Introduction
The moonroof controls are located in the ceil-
ing console near the rearview mirror. The
moonroof can be opened vertically and hori-
zontally. The vehicle's must be in ignition mode
I or II for the moonroof to be operated.
CAUTION
•Remove ice and snow before opening
the moonroof.
•Do not operate the moonroof if it is fro-
zen closed.
•Never place heavy objects on the
moonroof.
Sliding moonroof
G021343
Sliding moonroof, forward/rearward
Opening, automatic
Opening, manual
Closing, manual
Closing, automatic
Automatic opening
Pull the switch as far back as possible (to
the position for automatic opening) and
release it to automatically fully slide open
the moonroof.
Manual opening
Pull the switch back to the first stop (the
position for manual opening) and hold it
until the moonroof has opened to the posi-
tion of your choice.
Manual closing
Push the switch forward to the first stop
(the position for manual closing) and hold
it until the moonroof has closed to the posi-
tion of your choice, or has closed com-
pletely.
Automatic closing
Push the switch as far forward as possible
(the position for automatic closing) and
release it to automatically close the moon-
roof.
WARNING
•During manual closing, if the moonroof
is obstructed, immediately open it
again.
•Never open or close the moonroof if it is
obstructed in any way.
•Never allow a child to operate the
moonroof.
•Never leave a child alone in a vehicle.
•Never extend any object or body part
though the open moonroof, even if the
vehicle's ignition is completely
switched off.

10 Index
10
333
Bulbs
headlights...........................294, 295, 296
introduction......................................... 294
license plate lights.............................. 298
specifications...................................... 299
trunk lighting....................................... 298
C
Camera, Park Assist................................ 178
Capacity weight....................................... 267
Catalytic converter................................... 245
Cell phone, hands-free connection......... 221
Cell phone voice control.......................... 229
Central locking system, introduction......... 54
Chains...................................................... 270
Check engine light..................................... 76
Child restraints
recalls and registration......................... 50
Child restraint systems.............................. 41
booster cushions.................................. 47
convertible seats.................................. 45
infant seats........................................... 43
ISOFIX/LATCH anchors........................ 48
top tether anchors................................ 49Child safety.......................................... 39, 40
booster cushions.................................. 47
child restraint systems.......................... 41
convertible seats.................................. 45
infant seats........................................... 43
Child safety locks...................................... 51
City Safety™............................................ 156
Climate system........................................ 134
air distribution............................. 130, 136
air vents.............................................. 131
Interior Air Quality System.................. 130
introduction......................................... 129
passenger compartment filter............ 130
refrigerant........................................... 129
Clock, setting............................................. 80
Cold weather driving................................ 240
Collision warning system.................162, 163
Compass in rearview mirror..................... 102
Conserving electrical current................... 239
Controls, center console.......................... 233
Convertible seats....................................... 45
Coolant............................................292, 326
Cooling system, general information....... 239
Corner Traction Control........................... 138
Courtesy lighting.................................. 93, 94Crash event data....................................... 11
Crash mode............................................... 38
Cruise control..................................141, 142
adaptive.............................................. 143
Curb weight............................................. 267
Current, conserving................................. 239D
Defroster.................................................. 134
Detachable key blade..........................59, 61
Disconnecting the front passenger’s air-
bag....................................................... 29, 30
Dome lighting....................................... 93, 94
Door mirrors............................................. 100
Driver alert............................................... 169
Driver distraction warning.......................... 14
Driving economically................................ 238
Driving in cold weather............................ 240
Driving through water..............................239
