2011 VOLKSWAGEN PASSAT Owners Manual

Fig. 61 Adjusting the rear head restraints.

Removing and reinstalling head restraints

Fig. 62 Removing the front head restraints.

Fig. 63 Removing the rear head restraints.

Installing the front head restraints
x Position head restraint properly over the head restraint guides of the respective seat backrest and insert the head restraint into the guides.
x Push the head restraint down while pressing button (2).
x Adjust the head restraint according to the occupant's size, Adjusting front and rear head restraints.
Removing the rear head restraint
x Unlock the backrest of the rear seat bench and fold it forward, Luggage compartment.
x Pull the head restraint all the way up ⇒ .
x If necessary, press the flat blade of the screwdriver from the vehicle tool kit into the slit of the trim
cap ⇒ fig. 63 (1) in the direction of the arrow and hold it in this position.
x At the same time press button (2) while a second person pulls out the head restraint completely.
x Fold the backrest of the rear seat bench back so that it locks securely.
Reinstalling the rear head restraint
x Unlock the backrest of the rear seat bench and fold it forward, Luggage compartment.
x Position head restraint properly over the head restraint guides of the respective seat backrest and insert the head restraint into the guides.
x Push the head restraint down while pressing button (2).
x Fold the backrest of the rear seat bench back so that it locks securely.
x Adjust the head restraint according to the occupant's size, Adjusting front and rear head restraints.
WARNING
Driving without head restraints or with improperly adjusted head restraints increases the risk of serious injuries in a collision.
x Always drive with the head restraints in place and properly adjusted to help minimize the risk of neck injury in crash.
x Always reinstall head restraints as soon as possible so that vehicle occupants are properly protected.
NOTICE
When removing or reinstalling the head restraint, take care that the head restraint does not strike the headliner or other parts of the vehicle. The headliner or other parts of the vehicle could otherwise be damaged.

Adjusting the steering wheel position

Fig. 64 Manual adjustment for the steering wheel position.

Center armrest

Fig. 65 Front center armrest.

Fig. 66 Folded down rear center armrest with storage compartment (arrow).

WARNING
The center armrest can restrict the driver's arm movement and cause crashes and serious personal injury.
x Always keep storage compartments in the center armrest closed while driving.
x Never let a passenger, especially a child, ride on the center armrest. Improper seating position can increase the risk of serious personal injury in a crash.
x Never put hot drinks or other liquids in the cup holder. Hot liquids can spill when the vehicle is moving as well as during braking or other sudden maneuvers.

Seat functions

x If the outside temperature or the temperature inside the passenger compartment is 77 °F (25 °C) or more.

Function Action for seat heating ⇒ fig. 67
Switch on: Press the A button. Seat heating is switched on to maximum.
Adjust the heating level: Press the button Arepeatedly until the desired heating level is set.
Switch off: Press the buttonArepeatedly until all indicator lights in the button are off.
Special seat heating features
On the driver and the passenger side, the seat heating will resume at the setting that was set when the ignition was switched off. However, this feature only works if the key is not taken out of the ignition switch, or, for vehicles with Keyless Access, the driver door is not opened or the vehicle is not locked.
People suffering from a low level of perceived pain or a lowered awareness of pain as from medication, paralysis, or chronic illness (e.g. diabetes) should NEVER use the seat heating feature
⇒ !
The use of seat heating by persons with these conditions could result in burns to the back, buttocks, and legs that may take a long time to heal and may never heal completely. If you have any of these conditions, you should take regular breaks and get out of the vehicle, particularly on long trips. Consult your doctor for advice regarding your specific condition.
WARNING
Certain medical conditions, such as paralysis and diabetes, and certain medications can increase the risk of serious burns when the seat heating feature is switched on.
x Vehicle occupants who have a low level of perceived pain or a lowered awareness of pain can receive serious burns to the back, buttocks, and legs that take a long time to heal or may never heal completely.
x Never use the seat heating feature if you or your passengers are at risk of being burned because of a medical condition. Take regular breaks and get out of the vehicle, particularly on long trips. Consult your doctor for advice regarding your specific condition.
x Never let exposed skin remain in contact with the seat upholstery when the seat heating is being used.
WARNING
A wet seat can cause the seat heating to malfunction and increase the risk of serious burns.
x Always make sure the seats are dry before using the seat heating.
x Never sit on the seat with wet clothes.
x Never put damp or wet things including clothes on the seat.
x Never spill liquids on the seats.
NOTICE
x To help prevent damage to electrical and other parts in the seat, do not kneel on the front seats or apply concentrated pressure to a small area of the seat or backrest.
