2011 TOYOTA CAMRY Owners Manual

193
2-5. Driving information
2
When driving
●
In order to maintain efficient engine braking and electrical charging
performance, do not use overdrive (automatic transmission) or the
5th gear (manual transmission).
● Due to the added load of the trailer, your vehicle's engine may
overheat on hot days (at temperatures over 85°F [30°C]) when
driving up a long or steep grade. If the engine coolant temperature
gauge indicates overheating, immedi ately turn off the air condition-
ing (if in use), pull your vehicle off the road and stop in a safe spot.
(  P. 479)
● Always place wheel blocks under both the vehicle and the trailer
wheels when parking. Apply the parking brake firmly, and put the
transmission in P (automatic transmission) or in first or R (manual
transmission). Avoid parking on a slope, but if unavoidable, do so
only after performing the following:
Apply the brakes and keep them applied.
Have someone place wheel blocks under both the vehicle and
trailer wheels.
When the wheel blocks are in pl ace, release the brakes slowly
until the blocks absorb the load.
Apply the parking brake firmly.
Shift into first or R (manual transmission) or P (automatic
transmission) and turn off the engine.
● When restarting after parking on a slope:
With the transmission in the P position (automatic transmis-
sion) or the clutch pedal (m anual transmission) depressed,
start the engine. On vehicles with an automatic transmission,
be sure to keep the brake pedal pressed.
Shift into a forward gear. If reversing, shift into the R position.
Release the parking brake (also brake pedal on vehicles with
automatic transmission), and sl owly pull or back away from
the wheel blocks. Stop and apply the brakes.
Have someone retrieve the blocks.
STEP1
STEP2
STEP3
STEP4
STEP5
STEP1
STEP2
STEP3
STEP4

194 2-5. Driving information
CAUTION
■To avoid an accident
●Do not exceed 45 mph (72 km/h) or posted towing speed limit, whichever
is lower. As instability (swaying) of the towing vehicle-trailer combination
increases as speed increases, exceeding 45 mph (72 km/h) may cause
loss of control.
● Slow down and downshift before descending steep or long downhill
grades. Do not make sudden downshifts.
● Avoid holding the brake pedal down too long or applying the brakes too
frequently. This could cause the brakes to overheat and result in reduced
braking efficiency.

195
2-5. Driving information
2
When driving
Dinghy towing (automatic transmission)
NOTICE
■To avoid serious damage to your vehicle
Do not tow your vehicle with four wheels on the ground.
Your vehicle is not designed to be dinghy towed (with 4 wheels on
the ground) behind a motor home.

196
2-5. Driving information
Dinghy towing (manual transmission)
Towing your vehicle with 4 wheels on the groundTo prevent damage to your vehicle, perform the following procedures
before towing. Shift the shift lever to neutral.
Switch to the “ACC” position. ( P. 137)
Ensure that the audio system and other powered devices have been
turned off.
Release the parking brake.
After towing, run the engine in idle for at least 3 minutes before driv-
ing the vehicle.
■Necessary equipment and accessories
Specialized equipment and accessories are required for dinghy towing. Con-
tact the service branch of the motor home manufacturer regarding recom-
mended equipment.
Your vehicle can be dinghy towed in a forward direction (with 4
wheels on the ground) behind a motor home.
STEP1
STEP2
STEP3

197
2-5. Driving information
2
When driving
NOTICE
■
Dinghy towing direction
■ To prevent the steering from locking
Ensure the engine switch is in the “ACC” position.
Do not tow the vehicle backwards.
Doing so may cause serious damage.

198
3-1. Using the air conditioning system and defogger
Automatic air conditioning system ....... 200
Manual air conditioning system ........................... 208
Rear window and outside rear view mirror
defoggers ....................... 214
3-2. Using the audio system Audio system types .......... 216
Using the radio ................. 220
Using the CD player ......... 228
Playing MP3 and WMA discs ..................... 236
Operating an iPod ............ 244
Operating a USB memory .......................... 251
Optimal use of the audio system.................. 258
Using the AUX port .......... 263
Using the steering wheel audio switches ..... 265 3-3. Using the Bluetooth®
audio system
Bluetooth
® audio
system ........................... 268
Using the Bluetooth
®
audio system.................. 271
Operating a Bluetooth
®
enabled portable
player ............................. 276
Setting up a Bluetooth
®
enabled portable
player ............................. 278
Bluetooth
® audio
system setup .................. 283
Interior features3

Interior features3
199
3-4. Using the hands-free phone system
(for cellular phone)
Hands-free phone system (for cellular phone)
features .......................... 284
Using the hands-free phone system
(for cellular phone) ......... 288
Making a phone call ......... 297
Setting a cellular phone ... 301
Security and system setup .............................. 306
Using the phone book ...... 310
3-5. Using the interior lights Interior lights list ............... 318
• Interior light .................... 319
• Personal lights ............... 320
3-6. Using the storage features List of storage features .... 321
• Glove box....................... 322
• Console box ................... 322
• Cup holders ................... 324
• Auxiliary boxes............... 326 3-7. Other interior features
Sun visors ........................ 329
Vanity mirrors ................... 330
Clock ................................ 331
Ashtray ............................. 332
Power outlets ................... 333
Seat heaters..................... 335
Armrest ............................ 337
Rear sunshade................. 338
Trunk storage extension ....................... 339
Floor mat .......................... 340
Trunk features .................. 341
Garage door opener......... 343
Compass .......................... 349

200
3-1. Using the air conditioning system and defogger
Automatic air conditioning system
Using the automatic modePress .
The air conditioning system will begin to operate. Air outlets
and fan speed are automatically adjusted according to the
temperature setting.
Turning to the right increases the temperature and
turning to the left decreases the temperature on the
driver’s side.
: If equipped
Air outlets are automatically select ed and fan speed is automatically
adjusted according to the temperature setting.
Air conditioning
on/off switch
Front passenger’s side temperature
setting display
Driver’s side
temperature control “DUAL” button
Automatic mode Off
Driver’s side temperature
setting display
Fan speed
(fan speed selector) Outside air or recirculated air mode
Fan speed
display
Change the air outlets used
(air flow selector button)
Front passenger’s side
temperature control
Windshield defogger
Air outlet display
STEP1
STEP2
