436 4-3. Do-it-yourself maintenance
AVALON_U (OM41428U)
FuseAmpereCircuit
21 EFI No.1 25 AMultiport fuel injection system/
sequential multiport fuel injection
system, fuel pump
22 HORN 10 A Horn
23 HEAD LH UPR 15 A Left-hand headlight (high beam)
24 HEAD RH UPR 15 A Right-hand headlight (high beam)
25 A/F 25 A Air fuel ratio sensor
26 WASHER 20 A Windshield washer
27 S-HORN 7.5 A Horn
28 DOME 7.5 AGauges and meters, clock, front
personal lights, door courtesy
lights, garage door opener, rear
personal lights, trunk light
29 ECU-B 10 ACenter display, multiplex
communication system
30 RAD No.1 15 AAudio system, center display,
navigation system
31 EFI No.2 10 AMultiport fuel injection system/
sequential multiport fuel injection
system
32 STOP No.2 7.5 AStop lights, high mounted
stoplight, vehicle stability control
system, anti-lock brake system
33 HEAD RH LWR 15 A Right-hand headlight (low beam)
34 HEAD LH LWR 15 A Left-hand headlight (low beam)

5
When trouble arises
465
5-1. Essential information
AVALON_U (OM41428U)
Event data recorder
In a crash or a near car crash event
The SRS airbag sensor assembly contains the EDR. In a crash or a
near car crash event, this device may record some or all of the follow-
ing information:
●Engine speed
●Whether the brake pedal was applied or not
●Vehicle speed
●To what extent the accelerator pedal was depressed
●Position of the transmission shift lever
●Whether the driver and front passenger wore seat belts or not
●Driver’s seat position
●Front passenger’s occupant classification
●SRS airbag deployment data
●SRS airbag system diagnostic data
The information above is intended to be used for the purpose of
improving vehicle safety performance. Unlike general data recorders,
the EDR does not record sound data such as conversation between
passengers.
Your vehicle has computers that monitor and control certain aspects
of your vehicle. These computers assist in driving and maintaining
optimal vehicle performance.
Besides storing data useful for troubleshooting, there is a system to
record data in a crash or a near car crash event. This is called an
Event Data Recorder (EDR).

474 5-2. Steps to take in an emergency
AVALON_U (OM41428U)
■If the malfunction indicator lamp comes on while driving
First check the following:
●Is your vehicle low on gas?
If it is, refuel the vehicle immediately.
●Is the fuel tank cap loose?
If it is, tighten it securely.
The light will go off after taking several driving trips.
If the light does not go off even after several trips, contact your Toyota dealer
as soon as possible.
■SRS warning light
This warning light system monitors the following:
●The airbag sensor assembly
●Front airbag sensors
●The curtain shield airbag sensors
●The side and curtain shield airbag sensor assemblies
●The driver’s seat position sensor
●Driver’s seat belt buckle switch
●The front passenger occupant classification ECU
●The pressure sensor
●The belt tension sensor
●“AIR BAG ON” and “AIR BAG OFF” indicator lights
●Front passenger’s seat belt buckle switch
●The inflators
●The warning light
●The interconnecting wiring and power sources
■Front passenger detection sensor and passenger seat belt reminder
If luggage is placed on the front passenger seat, the front passenger detec-
tion sensor may cause the warning light to flash, even if a passenger is not
sitting in the seat.

534 6-2. Customization
AVALON_U (OM41428U)
*: Vehicles sold outside Canada
ItemFunctionDefault settingCustomized
setting
Door lock
(
P. 43)Unlocking using a keyDriver’s door
unlocked in 1-
step, all doors
unlocked
in 2-stepAll doors
unlocked
in 1-step
Speed-detecting auto-
matic door lock functionOFF ON
Opening driver’s door
unlocks all doors OFF ON
Shift the shift lever to
“P” unlocks all doorsON OFF
Shift the shift lever to
position other than “P”
locks all doorsON OFF
Automatic
light control
system
(P. 173)Light sensor sensitivity Level 3 Levels 1 to 5
Time elapsed before
headlights automati-
cally turn off after doors
are closed60 seconds0 seconds
30 seconds
90 seconds
Daytime running light ON OFF
*
