AVALON_U (OM41428U)
3-6. Using the storage features
List of storage features ....... 337
3-7. Other interior features
Sun visors ........................... 345
Vanity mirrors ...................... 346
Clock ................................... 347
Ashtrays .............................. 348
Power outlets ...................... 349
Seat heaters/ventilators ...... 351
Armrest ............................... 353
Rear sunshade.................... 354
Floor mats ........................... 356
Trunk features ..................... 358
Garage door opener............ 360
Compass ............................. 3684-1. Maintenance and care
Cleaning and protecting
the vehicle exterior ........... 374
Cleaning and protecting
the vehicle interior ............ 377
4-2. Maintenance
Maintenance
requirements .................... 380
General maintenance ......... 383
Emission inspection and
maintenance (I/M)
programs .......................... 386
4-3. Do-it-yourself maintenance
Do-it-yourself service
precautions....................... 387
Hood ................................... 391
Positioning a floor jack ....... 392
Engine compartment .......... 394
Tires ................................... 409
Tire inflation pressure ......... 418
Wheels ............................... 422
Air conditioning filter ........... 425
Key battery ......................... 428
Checking and replacing
fuses................................. 432
Headlight aim (with
discharge headlights) ....... 441
Light bulbs .......................... 443
4Maintenance and care

TABLE OF CONTENTSIndex
6
AVALON_U (OM41428U)
5-1. Essential information
Emergency flashers ........... 458
If your vehicle needs
to be towed ...................... 459
If you think something is
wrong ............................... 463
Fuel pump shut off
system .............................. 464
Event data recorder............ 465
5-2. Steps to take in an emergency
If a warning light turns
on or a warning buzzer
sounds... .......................... 467
If you have a flat tire ........... 479
If the engine will
not start ............................ 489
If the shift lever cannot be
shifted from P ................... 491
If you lose your keys .......... 492
If the electronic key does
not operate properly (with
smart key system) ............ 493
If the vehicle battery is
discharged ....................... 496
If your vehicle overheats .... 500
If the vehicle becomes
stuck................................. 503
If your vehicle has to be
stopped in an
emergency ....................... 5046-1. Specifications
Maintenance data
(fuel, oil level, etc.) ........... 508
Fuel information .................. 516
Tire information................... 519
6-2. Customization
Customizable features ........ 532
6-3. Initialization
Items to initialize ................. 536
Reporting safety defects
for U.S. owners ................. 538
Seat belt instructions
for Canadian owners
(in French) ........................ 539
SRS airbag instructions
for Canadian owners
(in French) ........................ 542
Abbreviation list ............... 554
Alphabetical index ............ 555
What to do if... ................... 562
5When trouble arises6Vehicle specifications
7For owners
Index

24
AVALON_U (OM41428U)
1-1. Key information
Keys
Using the mechanical key (vehicles with smart key system)
Take out the mechanical key.
After using the mechanical key,
store it in the electronic key. Carry
the mechanical key together with
the electronic key. If the electronic
key battery is depleted or the
smart key system does not oper-
ate properly, you will need the
mechanical key.
The following keys are provided with the vehicle.
Vehicles with smart key system
Electronic keys
• Operating the smart key
system (P. 26)
• Operating the wireless
remote control function
(P. 38)
Mechanical keys
Key number plate
Vehicles without smart key system
Master keys
Operating the wireless remote
control function (
P. 38)
Key number plate

30 1-2. Opening, closing and locking the doors and trunk
AVALON_U (OM41428U)
■Operation signals
A buzzer sounds and the emergency flashers flash to indicate that the doors
have been locked/unlocked. (Locked: Once; Unlocked: Twice)
■Conditions affecting operation
The smart key system uses weak radio waves. In the following situations,
the communication between the electronic key and the vehicle may be
affected, preventing the smart key system and wireless remote control from
operating properly. (Way of coping:
P. 493)
●When the electronic key battery is depleted
●Near a TV tower, electric power plant, gas station, radio station, large dis-
play, airport or other facility that generates strong radio waves or electri-
cal noise
●When carrying a portable radio, cellular phone, cordless phone or other
wireless communication devices
●When the electronic key has come into contact with, or is covered by a
metallic object
●When multiple electronic keys are in the vicinity
●When carrying or using the electronic key together with the following
devices that emit radio waves
• Another vehicle’s electronic key
• A wireless key that emits radio waves
• Personal computer
●If window tint with a metallic content or metallic objects are attached to
the rear window

32 1-2. Opening, closing and locking the doors and trunk
AVALON_U (OM41428U)
■Battery-saving function
In the following circumstances, the entry function is disabled in order to pre-
vent the vehicle and electronic key batteries from discharging.
●When the entry function has not been used for 2 weeks or more
●When the electronic key has been left within approximately 3 ft. (1 m) of
the vehicle for 10 minutes or more
The system will resume operation when...
●The vehicle is locked using the door handle lock switch
●The vehicle is locked/unlocked using the wireless remote control function
(P. 38) or the mechanical key (P. 493)
■Electronic key battery depletion
●The standard battery life is 1 to 2 years. (The battery becomes depleted
even if the electronic key is not used.) If the smart key system or the
wireless remote control function does not operate, or the detection area
becomes smaller, the battery may be depleted. Replace the battery when
necessary. (P. 428)
●If the battery becomes low, an alarm will sound in the cabin when the
engine stops. (P. 34)
●To avoid serious deterioration, do not leave the electronic key within 3 ft.
(1 m) of the following electrical appliances that produce a magnetic field.
•TVs
• Personal computers
• Recharging cellular phones or cordless phones
• Table lamps
■To operate the system properly
Make sure to carry the electronic key when operating the system. Do not get
the electronic key too close to the vehicle when operating the system from
the outside of the vehicle.
Depending on the position and holding condition of the electronic key, the
key may not be detected correctly and the system may not operate properly.
(The alarm may go off accidentally, or the door lock prevention may not func-
tion.)

35 1-2. Opening, closing and locking the doors and trunk
1
Before driving
AVALON_U (OM41428U)
■If the smart key system does not operate properly
●Locking and unlocking the doors: Use the mechanical key. (P. 493)
●Starting the engine: P. 494
■When the electronic key battery is fully depleted
P. 428
AlarmSituationCorrection procedure
Interior alarm
sounds onceThe electronic key battery
is low.Replace the battery.
(P. 428)
Interior alarm
sounds continu-
ouslyTried to open the door and
exit the vehicle without
shifting the shift lever to
“P”Shift the shift lever to
“P”.
Interior alarm
rings continu-
ouslyTurned the “ENGINE
START STOP” switch to
ACCESSORY mode while
the driver’s door is open
(Opened the driver’s door
when the “ENGINE START
STOP” switch is in
ACCESSORY mode.)Turn the “ENGINE
START STOP” switch
OFF and close the
driver’s door.
Turned the “ENGINE
START STOP” switch OFF
while the driver’s door is
openClose the driver’s
door.

40 1-2. Opening, closing and locking the doors and trunk
AVALON_U (OM41428U)
■Security feature
P. 3 4
■When the key battery is fully depleted
P. 428
■Conditions affecting operation
Vehicles with smart key system
P. 3 0
Vehicles without smart key system
The wireless remote control function may not operate normally in the fol-
lowing situations.
●Near a TV tower, radio station, electric power plant, airport or other
facility that generates strong radio waves
●When carrying a portable radio, cellular phone or other wireless com-
munication device
●When multiple wireless keys are in the vicinity
●When the wireless key has come into contact with, or is covered by a
metallic object
●When a wireless key (that emits radio waves) is being used nearby
●When the wireless key has been left near an electrical appliance such
as a personal computer
■Customization that can be configured at Toyota dealer
Settings (e.g. 2-step unlocking function, trunk unlocking function) can be
changed. (Customizable features P. 532)

81 1-4. Opening and closing the windows and moon roof
1
Before driving
AVALON_U (OM41428U)
■The power windows can be operated when
Vehicles with smart key system
The “ENGINE START STOP” switch is in IGNITION ON mode.
Vehicles without smart key system
The engine switch is in the “ON” position.
■Operating the power windows after turning the engine off
Vehicles with smart key system
The power windows can be operated for approximately 45 seconds even
after the “ENGINE START STOP” switch is turned to ACCESSORY mode or
turned OFF. They cannot, however, be operated once the driver’s or front
passenger’s door is opened.
Vehicles without smart key system
The power windows can be operated for approximately 45 seconds even
after the engine switch is turned to the “ACC” or “LOCK” position. They can-
not, however, be operated once the driver’s or front passenger’s door is
opened.
■Jam protection function
If an object becomes caught between the window and the window frame,
window travel is stopped and the window is opened slightly.
■When the battery is disconnected
The power windows must be initialized in order to ensure proper operation.
(Perform for each window with the switch for each seat.)
Open the window halfway.
Fully close the window by pulling the switch up and continue hold-
ing the switch for 1 second.
The indicator on the switch changes from a flashing pattern to being on
when initial settings are complete.
