INTRODUCTIONThe oil change indicator system will remind you that
it is time to take your vehicle in for scheduled
maintenance. Based on engine operation condition
the oil change indicator message will illuminate, this
means that service is required for your vehicle. Have
your vehicle serviced as soon as possible, within the
next 800 km. The oil change indicator message will
not monitor the time since the last oil change. Change
your vehicles oil if it has been 6 months since your
last oil change even if the oil change indicator
message is NOT illuminated. Change your engine oil
more often if you drive your vehicle off-road for an
extended period of time.Under no circumstances
should oil change intervals exceed 13,000 km or
6 months, whichever comes first.Your dealer will
reset the oil change indicator message after complet-
ing the scheduled oil change. If this scheduled oil
change is performed by someone other than yourdealer the message can be reset by referring to the
steps described in the Owner’s Manual.
The performance of all scheduled service work is
required to maintain your vehicle in good operat-
ing condition. Chrysler Canada Inc. reserves the
right to deny warranty coverage if the vehicle has
not been properly maintained. While we do not
insist that such work be performed by factory
authorized retailers, we strongly recommend that
an authorized Chrysler, Jeepor Dodge Retailer
perform this work.
AT EACH STOP FOR FUEL
•Check the engine oil level about 5 minutes
after a fully warmed engine is shut off. Check-
ing the oil level while the vehicle is on level
ground will improve the accuracy of the oil
level reading. Add oil only when the level is at
or below the ADD or MIN mark.
•Check the windshield washer solvent and add
if required.ONCE A MONTH
•Check tire pressure and look for unusual wear
or damage.
•Inspect the battery and clean and tighten the
terminals as required.
•Check the fluid levels of coolant reservoir,
brake master cylinder, power steering and
transmission and add as needed.
•Check all lights and other electrical items for
correct operation.
•Check and clean wiper blades. Replace if
required.
AT EACH OIL CHANGE
•Change the engine oil filter.
•Inspect the brake hoses and lines.
VISUAL INSPECTIONS —
INSPECT FOR SIGNS OF COMPONENT
DETERIORATION AND PHYSICAL DAMAGE.
MAINTENANCEScheduled maintenance must be completed to provide the best vehicle performance and reliability. The limited warranties in the
warranty booklet DO NOT COVER repairs required due to improper maintenance. We strongly suggest you keep track of scheduled maintenance and keep receipts
or other documents. Use only recommended MoparLubricants and genuine MoparParts. In the event that a condition arises between maintenance intervals,
please contact your retailer. AVOID PROLONGED PERIODS OF IDLING.
NOTE: WHERE TIME (MONTHS) AND METRAGE ARE INDICATED, FOLLOW THE INTERVAL THAT OCCURS FIRST.

JOBNAME: 288987 2011 Maint-Wa PAGE: 19 SESS: 59 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
Perform Maintenance At
130,000 km or 60 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this
service.
❏Lubricate the front drive shaft fitting. (All 4x4 models except 1500)
❏Inspect the engine air filter if using your vehicle in dusty or off-road conditions;
replace if necessary.
❏Inspect the brake linings; replace if necessary.
❏Inspect the front suspension components, tie rod ends and boot seals; replace if
necessary.
❏Flush and replace the engine coolant at 60 months if not done at 169,000 km.
* Oil changes that are prompted by the oil change indicator system prior to this schedule maintenance interval can
be recorded in the oil change log section.
Perform Maintenance
At
60 Months or
130,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 20 SESS: 59 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
❏Change the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 13,000 km
or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if
it occurs prior to this service.
❏Lubricate the front drive shaft fitting. (All 4x4 models ex-
cept 1500)
❏Inspect the engine air filter if using your vehicle in dusty
or off-road conditions; replace if necessary.
❏Inspect the brake linings; replace if necessary.
❏Inspect the front suspension components, tie rod ends and
boot seals; replace if necessary.
❏Flush and replace the engine coolant at 60 months if not
done at 169,000 km.
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance At
130,000 km or 60 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 25 SESS: 59 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
Perform Maintenance At
169,000 km or 78 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this
service.
❏Lubricate the front drive shaft fitting. (All 4x4 models except 1500)
❏Flush and replace the engine coolant if not done at 60 months.
❏Flush and replace the power steering fluid. (Chassis Cab models only)
* Oil changes that are prompted by the oil change indicator system prior to this schedule maintenance interval can
be recorded in the oil change log section.
Perform Maintenance
At
78 Months or
169,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 26 SESS: 59 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
❏Change the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 13,000 km
or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if
it occurs prior to this service.
❏Lubricate the front drive shaft fitting. (All 4x4 models ex-
cept 1500)
❏Flush and replace the engine coolant if not done at
60 months.
❏Flush and replace the power steering fluid. (Chassis Cab
models only)
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance At
169,000 km or 78 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 2 SESS: 26 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/02aintervals-diesel
INTRODUCTIONYour vehicle is equipped with an engine oil change
indicator system. This system will alert you when it is
time to change your engine oil by displaying the words
“Oil Change Required” on your Electronic Vehicle Infor-
mation Center (EVIC). The engine oil change indicator
system is duty cycle based, which means the engine oil
change interval may fluctuate depending on your per-
sonal driving style. Driving styles such as frequent stop
and go type driving can increase the frequency of the
engine oil change. This is the result of more frequent
regeneration of the exhaust aftertreatment system, which
can decrease the life of the engine oil. Failure to change
the engine oil per the maintenance schedule can result in
internal engine damage.
Under no circumstances should the oil change interval
exceed 12,000 km or six months whichever occurs first.
For information on resetting the Oil Change Indicator
message, refer to “Oil Change Required If
Equipped,” under “System Status (EVIC Displays)”
in the “Electronic Vehicle Information Center
(EVIC)” Section of the Owner’s Manual.The performance of all scheduled service work is
required to maintain your vehicle in good operating
condition. Chrysler Canada Inc. reserves the right to
deny warranty coverage if the vehicle has not been
properly maintained. While we do not insist that such
work be performed by factory authorized retailers,
we strongly recommend that an authorized Chrysler,
Jeepor Dodge Retailer perform this work.
AT EACH STOP FOR FUEL
•Check the engine oil level about 5 minutes after a
fully warmed engine is shut off. Checking the oil
level while the vehicle is on level ground will
improve the accuracy of the oil level reading. Add
oil only when the level is at or below the ADD or
MIN mark.
•Check the windshield washer solvent and add if
required.
ONCE A MONTH
•Check tire pressure and look for unusual wear or
damage.
•Inspect the batteries, clean and tighten the termi-
nals as required.
•Check the fluid levels of coolant reservoir, brake
master cylinder, and transmission and transfer
case (if equipped) add as needed.
•Drain water from the fuel filter.•Check and clean wiper blades. Replace if required.
AT EACH OIL CHANGE
•
Change the engine oil filter.•Inspect the exhaust system.•Inspect the brake hoses and lines.•Check the automatic transmission fluid level.•Check the manual transmission fluid level.•Check the engine coolant level, hoses, and clamps.•Lubricate outer tie rod ends.
Inspection and service should also be performed any-
time a malfunction is observed or suspected. Retain all
receipts.
VISUAL INSPECTIONS —
INSPECT FOR SIGNS OF COMPONENT
DETERIORATION AND PHYSICAL DAMAGE.
MAINTENANCEScheduled maintenance must be completed to provide the best vehicle performance and reliability. The limited warranties in the
warranty booklet DO NOT COVER repairs required due to improper maintenance. We strongly suggest you keep track of scheduled maintenance and keep receipts
or other documents. Use only recommended MoparLubricants and genuine MoparParts. In the event that a condition arises between maintenance intervals,
please contact your retailer. AVOID PROLONGED PERIODS OF IDLING.
NOTE: WHERE TIME (MONTHS) AND METRAGE ARE INDICATED, FOLLOW THE INTERVAL THAT OCCURS FIRST.

JOBNAME: 288987 2011 Maint-Wa PAGE: 19 SESS: 68 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/02bintervals-diesel
Perform Maintenance At
120,000 km or 60 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 12,000 km or 6 months whichever occurs first.*
❏Rotate tires.
❏Check the diesel exhaust fluid (DEF) tank, refill if necessary.
❏Lubricate the front drive shaft fitting. (4x4)
❏Lubricate the outer tie rod ends. (Chassis Cab only)
❏Inspect the front suspension components, tie rod ends and boot seals; replace if
necessary.
❏Inspect the front (4x4) and rear axle fluid; change if using your vehicle for any of
the following: police, fleet, off-road or frequent trailer towing.
❏Replace the fuel filter element.
❏Flush and replace the engine coolant at 60 months if not done at 156,000 km.
* Oil changes that are prompted by the oil change indicator system prior to this schedule maintenance interval can
be recorded in the oil change log section.
Perform Maintenance
At
60 Months or
120,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 20 SESS: 68 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/02bintervals-diesel
❏Change the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 12,000 km
or 6 months whichever occurs first.*
❏Rotate tires.
❏Check the diesel exhaust fluid (DEF) tank, refill if
necessary.
❏Lubricate the front drive shaft fitting. (4x4)
❏Lubricate the outer tie rod ends. (Chassis Cab only)
❏Inspect the front suspension components, tie rod ends and
boot seals; replace if necessary.
❏Inspect the front (4x4) and rear axle fluid; change if using
your vehicle for any of the following: police, fleet, off-
road or frequent trailer towing.
❏Replace the fuel filter element.
❏Flush and replace the engine coolant at 60 months if not
done at 156,000 km.
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance At
120,000 km or 60 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................
