2011 NISSAN ALTIMA HYBRID Quick Reference Guide

FM/AM/XM®* RADIO WITH CD/DVD PLAYER (if so equipped)
01 VOL ON•OFF CONTROL DIAL

Press the VOL ON•OFF control dial to turn the system on or off.

Turn the VOL ON•OFF control dial right or left to increase or decrease the volume.
02 TUNE/FOLDER/AUDIO CONTROL DIAL


To manually tune the radio, turn the TUNE/FOLDER/AUDIO control dial left or right.
03 CD/DVD OPEN/TILT BUTTON


Press the cd/ dVd OPEN/TILT button and the display screen will move down to expose
the cd/ d Vd insert slot.

Press and hold the button again to tilt the screen farther.
*XM® Satellite Radio is only available on vehicles equipped with optional XM® satellite subscription service.
for more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (section 4)” of your
Owner’s Manual.
0201
03
PARKING BRAKE
To apply, firmly depress the parking brake pedal
01 .

To release, firmly press the foot brake
02 , then
press the parking brake pedal
01 and the parking
brake will release.
for more information, refer to the “Starting and driving (section 5)”
of your Owner’s Manual.
0102
7

FUEL-FILLER DOOR
To open the fuel-filler door, pull up on the release lever
located on the floor to the left of the driver’s seat.

The fuel-filler door is located on the left, rear side of
the vehicle.
for more information, refer to the “Pre-driving checks and adjustments
(section 3)” of your Owner’s Manual.
TRUNK LID RELEASE
use one of the following methods to open the trunk:

Push the trunk opener request switch
01 for more
than 1 second while carrying the n iSSAn intelligent
k ey™ with you.

Press theHOLDbutton on the intelligent k ey for more
than 0.5 seconds.

f rom inside the vehicle, push the trunk opener
switch

01 down.
for more information, refer to the “Pre-driving checks and adjustments
(section 3)” of your Owner’s Manual.
01
01
first drive features
8

CRUISE CONTROL
The cruise control system enables you to set a
constant cruising speed.

The system will automatically maintain the set speed
until you tap the brake pedal, accelerate, cancel or
turn the system off.
for more information, refer to the “Starting and driving (section 5)”
of your Owner’s Manual.
BLUETOOTH® HANDS-FREE PHONE SYSTEM (if so equipped)
With an overhead microphone and sound
transmitted through the audio system speakers,
the Bluetooth
® Hands-free Phone System utilizes
Bluetooth wireless technology and voice recognition
to provide hands-free cellular phone communication.
for more information, refer to the “Monitor, climate, audio, phone and
voice recognition systems (section 4)” of your Owner’s Manual or
please visit www.nissanusa.com/bluetooth.
NAVIGATION SYSTEM (if so equipped)
y our navigation System can calculate a route from the current location to a pr\
eferred destination.
The real-time map display and turn-by-turn voice guidance will lead you a\
long the route.

The navigation System will continually update your vehicle’s position. if you have deviated
from the original route, it will recalculate the route from your current\
location.
for more information, refer to your navigation System Owner’s Manual.
9
system guide

10
system guide
HOMELINK® UNIVERSAL TRANSCEIVER (if so equipped)
The HomeLink® system can learn and consolidate the functions of up to three different\

hand-held transmitters, operating items such as; garage doors, property gates, outdoor
and indoor lights or alarm systems.
for more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual, the HomeLink®
website www.homelink.com or call 1-800-355-3515.
HOMELINK®

memo

memo
