2011 Lexus IS220d isofix

125
1-7. Safety information
1
Before driving
IS250/220d/200d_EEKey of letters inserted in the above table:
U: Suitable for “universal” category child restraint system
approved for the use in this mass group.
L1: Suitable for “LEXUS BABY-SAFE (0 to 13 kg [0 to 28 lb.])”
approved for the use in this mass group.
L2: Suitable for “LEXUS DUO+ (without ISOFIX, 9 to 18 kg [20
to 39 lb.])” approved for the use in this mass group.
L3: Suitable for “LEXUS KID (15 to 36 kg [34 to 79 lb.])”
approved for the use in this mass group.
X: Not suitable seat position for children in this mass group.
The child restraint systems mentioned in the table may not be
available outside of the EU area.
Other child restraint systems different from the systems mentioned
in the table can be used, but the suitability of the systems must be
carefully checked with the child restraint system manufacturer and
retailer.

126
1-7. Safety information
IS250/220d/200d_EE
Child restraint system suitability for various seating positions
(with ISOFIX rigid anchor)
Provided information in the table shows your child restraint system
suitability for various seating positions.
Mass groups Size class FixtureVehicle ISOFIX
positions
Rear outboard
CarrycotF
ISO/L1X
G
ISO/L2X
(1) X
0
Up to 10 kg (22
lb.)
(0 - 9 months)E
ISO/R1X
(1) X
0
+
Up to 13 kg (28
lb.)
(0 - 2 years)E
ISO/R1X
D
ISO/R2X
C
ISO/R3X
(1) X
I
9 to 18 kg
(20 to 39 lb.)
(9 months - 4
years)D
ISO/R2X
C
ISO/R3X
B
ISO/F2IUF
B1
ISO/F2XX
A
ISO/F3X
(1) X
II, III
15 to 36 kg
(34 to 79 lb.)
(4 12 ears)(1) X

127
1-7. Safety information
1
Before driving
IS250/220d/200d_EE(1) For CRS which do not carry the ISO/XX size class identifica-
tion (A to G), for the applicable mass group, the car manufac-
turer shall indicate the vehicle specific ISOFIX child restraint
system(s) recommended for each position.
Key of letters inserted in the above table:
IUF:Suitable for ISOFIX forward child restraints systems of uni-
versal category approved for use in this mass group.
X: ISOFIX position not suitable for ISOFIX child restraint sys-
tems in this mass group and/or this size class.
The child restraint systems mentioned in the table may not be
available outside of the EU area.
Other child restraint systems different from the systems mentioned
in the table can be used, but the suitability of the systems must be
carefully checked with the child restraint system manufacturer and
retailer.

130
1-7. Safety information
IS250/220d/200d_EE
Installing child restraints
Follow the child restraint system manufacturer's instructions. Firmly
secure child restraints to the rear seats using a seat belt or a ISOFIX
rigid anchor (ISOFIX child restraint system). Attach the top strap
when installing a child restraint.
Installation with a seat belt
(P. 131)
ISOFIX rigid anchors (ISO-
FIX child restraint system)
(P. 134)
These exclusive fixing bars
are provided for the outside
rear seats. (Buttons display-
ing the location of the
anchorages are attached to
the seats.)
Anchor bracket
(for top strap) (P. 134)
Anchor brackets are provided
for all rear seats.

134
1-7. Safety information
IS250/220d/200d_EE
Installation with ISOFIX rigid anchors (ISOFIX child restraint sys-
tem)
Flip the cover, and latch the
buckles onto the exclusive fix-
ing bars.
If the child restraint has a top
strap, the top strap should be
latched onto the anchor bracket.
Child restraint systems with a top strap
Secure the child restraint using
a seat belt or ISOFIX rigid
anchors and lock the head
restraint in place at the original
position.
STEP1

564
Alphabetical index
IS250/220d/200d_EE
Back-up lights
Replacing light bulbs ............453
Wattage .................................552
Battery
Checking ...............................415
If the vehicle has a discharged
battery.................................524
Preparing and checking before
winter .................................239
Bluetooth
® audio* .....................308
Bluetooth® phone* ....................323
Bottle holders ............................360
Brake
Parking brake ........................171
Brake assist................................224
Care
Exterior .................................388
Interior ..................................392
Seat belts...............................393
Cargo hooks ..............................384
CD changer*..............................273
CD player* ................................273
Chains ........................................239
Child restraint system
Baby seats, definition ...........121
Baby seats, installation .........130
Child seats, definition ...........121
Child seats, installation.........130
Installing CRS with ISOFIX
rigid anchor ........................134
Installing CRS with seat belts ....
131
Installing CRS with top straps ....
134Junior seats, definition ......... 121
Junior seats, installation....... 130
Child safety
Airbag precautions............... 116
Battery precautions ...... 419, 527
Child restraint system .......... 121
Child-protectors ..................... 59
How your child should wear
the seat belt.......................... 77
Installing child restraints ..... 130
Moon roof precautions........... 92
Power window lock switch .... 85
Power window precautions.... 88
Removed electronic key battery
precautions ........................ 436
Seat belt comfort guide .......... 75
Seat belt precautions .............. 77
Seat heater precautions 373, 376
Trunk precautions .................. 65
Child-protectors .......................... 59
Cigarette lighter ........................ 369
Cleaning
Exterior ................................ 388
Interior ................................. 392
Seat belts .............................. 393
Clock ........................................ 364
Coat hooks ................................ 381
Condenser ................................. 415
Console box .............................. 356
Cooling system
Engine overheating .............. 528
Cornering assist sensors ........... 217
