2011 Lexus IS220d service

1
2
3
4
5
6
IS250/220d/200d_EE
5
3-7. Other interior features
Sun visors ........................... 362
Vanity mirrors .................... 363
Clock .................................. 364
Satellite switches ................ 365
Ashtrays ............................. 368
Cigarette lighter.................. 369
Power outlet ....................... 370
Seat heaters ........................ 371
Seat heaters and ventilators 374
Armrest............................... 377
Rear sunshade .................... 378
Trunk storage extension ..... 380
Coat hooks.......................... 381
Floor mat ............................ 382
Trunk features .................... 383
4-1. Maintenance and care
Cleaning and protecting
the vehicle exterior........... 388
Cleaning and protecting
the vehicle interior ........... 392
4-2. Maintenance
Maintenance requirements . 3954-3. Do-it-yourself maintenance
Do-it-yourself service
precautions ....................... 398
Hood ................................... 401
Positioning a floor jack ...... 402
Engine compartment .......... 404
Tires ................................... 420
Tire inflation pressure ........ 424
Wheels................................ 426
Air conditioning filter ........ 428
Electronic key battery ........ 431
Checking and replacing
fuses ................................. 433
Light bulbs ......................... 448
5-1. Essential information
Emergency flashers ............ 458
If your vehicle needs to
be towed ........................... 459
If you think something is
wrong ............................... 465
Fuel pump shut off system . 466
4Maintenance and care
5When trouble arises

IS250/220d/200d_EE
27
Installation of an RF-transmitter system
The installation of an RF-transmitter system in your vehicle could affect
electronic systems such as:
Multiport fuel injection system/sequential multiport fuel injection system
Cruise control system
Dynamic radar cruise control system
Anti-lock brake system
SRS airbag system
Seat belt pretensioner system
Be sure to check with any authorized Lexus dealer or repairer, or another
duly qualified and equipped professional for precautionary measures or spe-
cial instructions regarding installation of an RF-transmitter system.
Further information regarding frequency bands, power levels, antenna posi-
tions and installation provisions for the installation of RF-transmitters, is
available on request at any authorized Lexus dealer or repairer, or another
duly qualified and equipped professional.
Scrapping your Lexus
The SRS airbag and seat belt pretensioner devices in your Lexus contain
explosive chemicals. If the vehicle is scrapped with the airbags and seat belt
pretensioners left as they are, this may cause an accident such as fire. Be
sure to have the systems of the SRS airbag and seat belt pretensioner
removed and disposed of by a qualified service shop or by any authorized
Lexus dealer or repairer, or another duly qualified and equipped profes-
sional, before you scrap your vehicle.

239
2-5. Driving information
2
When driving
IS250/220d/200d_EE
Winter driving tips
Carry out the necessary preparations and inspections before driving
the vehicle in winter. Always drive the vehicle in a manner appropriate
to the prevailing weather conditions.
Pre-winter preparations
Use fluids that are appropriate to the prevailing outside
temperatures.
• Engine oil
• Engine coolant
• Washer fluid
Have a service technician inspect the level and specific
gravity of battery electrolyte.
Have the vehicle fitted with four snow tires or purchase a
set of tire chains for the rear tires.
Ensure that all tires are the specified size and the same brand, and
that chains match the size of the tires.
Before driving the vehicle
Perform the following according to the driving conditions.
Do not try to forcibly open a window or move a wiper that
is frozen. Pour warm water over the frozen area to melt the
ice. Wipe away the water immediately to prevent it from
freezing.
To ensure proper operation of the climate control system
fan, remove any snow that has accumulated on the air inlet
vents in front of the windshield.
Remove any ice that has accumulated on the vehicle chas-
sis.

326
3-4. Using the hands-free phone system (for mobile phones)
IS250/220d/200d_EE
Conditions under which the system will not operate
If using a mobile phone that does not support Bluetooth®
If the mobile phone is switched off
If you are outside service range
If the mobile phone is not connected
If the mobile phone's battery is low
If the mobile phone is behind the seat or in the glove box or console box
If metal is covering or touching the phone
When using the hands-free system
The audio system and voice guidance are muted when making a call.
If both parties speak at the same time, it may be difficult to hear.
If the incoming call volume is overly loud, an echo may be heard.
Try to face toward the microphone as much as possible when speaking.
In the following circumstances, it may be difficult to hear the other
party:
• When driving on unpaved roads
• When driving at high speeds
• When a window is open
• When the air conditioning is blowing directly on the microphone
• When the air conditioning is set to high

4Maintenance and care
387
4-1. Maintenance and care
Cleaning and protecting
the vehicle exterior ........ 388
Cleaning and protecting
the vehicle interior ......... 392
4-2. Maintenance
Maintenance
requirements .................. 395
4-3. Do-it-yourself
maintenance
Do-it-yourself service
precautions..................... 398
Hood ................................ 401
Positioning a floor jack .... 402
Engine compartment ........ 404
Tires ................................. 420
Tire inflation pressure ...... 424
Wheels ............................. 426
Air conditioning filter ...... 428
Electronic key battery ...... 431
Checking and replacing
fuses ............................... 433
Light bulbs ....................... 448

395
4
Maintenance and care
IS250/220d/200d_EE
4-2. Maintenance
Maintenance requirements
To ensure safe and economical driving, day-to-day care and regular
maintenance is essential. Lexus recommends the following mainte-
nance.
Scheduled maintenance
Scheduled maintenance should be performed at specified
intervals according to the maintenance schedule.
For full details of your maintenance schedule, read the “Lexus
Service Booklet” or “Lexus Warranty Booklet”.
Do-it-yourself maintenance
What about do-it-yourself maintenance?
Many maintenance items are easy to do yourself if you have a lit-
tle mechanical ability and a few basic automotive tools.
Note, however, that some maintenance tasks require special tools
and skills. These are best performed by qualified technicians. Even
if you're an experienced do-it-yourself mechanic, we recommend
that repairs and maintenance be conducted by any authorized
Lexus dealer or repairer, or another duly qualified and equipped
professional. Any authorized Lexus dealer or repairer will keep a
record of maintenance, which could be useful should you ever
require Warranty Service. Should you choose to select a qualified
and equipped professional other than an authorized Lexus repairer

397
4-2. Maintenance
4
Maintenance and care
IS250/220d/200d_EE
Where to go for service?
In order to maintain your vehicle in the highest possible condition, Lexus
recommends that all repairs and service operations be carried out by autho-
rized Lexus dealers or repairers or other duly qualified and equipped profes-
sionals. For repairs and services covered by your warranty, please visit an
authorized Lexus dealer or repairer, who will use genuine Lexus parts in
repairing any difficulties you may encounter. There can also be advantages
in utilizing authorized Lexus dealers or repairers for non-warranty repairs
and services, as members of the Lexus network will be able to expertly
assist you with any difficulties you may encounter.
Your Lexus dealer or repairer, or another duly qualified and equipped pro-
fessional service department will perform all of the scheduled maintenance
on your vehicle - reliably and economically due to their experience with
Lexus vehicles.
Does your vehicle need repair?
Be on the alert for changes in performance and sounds, and visual tip-offs
that indicate service is needed. Some important clues are:
Engine missing, stumbling, or pinging
Appreciable loss of power
Strange engine noises
A fluid leak under the vehicle (However, water dripping from the air
conditioning after use is normal.)
Change in exhaust sound (This may indicate a dangerous carbon monox-
ide leak. Drive with the windows open and have the exhaust system
checked immediately.)
Flat-looking tires, excessive tire squeal when cornering, uneven tire
wear
Vehicle pulls to one side when driving straight on a level road
Strange noises related to suspension movement
Loss of brake effectiveness, spongy feeling brake pedal, pedal almost
touches the floor, vehicle pulls to one side when braking
Engine coolant temperature continually higher than normal
If you notice any of these clues, take your vehicle to any authorized Lexus
dealer or repairer, or another duly qualified and equipped professional, as
soon as possible. Your vehicle may need adjustment or repair.

398
IS250/220d/200d_EE
4-3. Do-it-yourself maintenance
Do-it-yourself service precautions
If you perform maintenance yourself, be sure to follow the correct pro-
cedures as given in these sections.
ItemsParts and tools
Battery condition (P. 415)
•Warm water
• Baking soda
• Grease
• Conventional wrench
(for terminal clamp bolts)
Engine coolant level (P. 413)
• “Toyota Super Long Life Cool-
ant” or similar high-quality eth-
ylene glycol-based non-silicate,
non-amine, non-nitrite and non-
borate coolant with long-life
hybrid organic acid technology.
“Toyota Super Long Life Cool-
ant” is pre-mixed with 50%
coolant and 50% deionized
water.
• Funnel (used only for adding
coolant)
Engine oil levelP. 409)
• “Toyota Genuine Motor Oil” or
equivalent
• Rag or paper towel, funnel
(used only for adding oil)
Fuses (P. 438)• Fuse with same amperage rating
as original
Radiator, condenser and inter-
cooler
