2011 Lexus IS200d Owner's Manuals

452
4-3. Do-it-yourself maintenance
IS250/220d/200d_EE
After a fuse is replaced
If the lights do not turn on even after the fuse has been replaced, a bulb
may need replacement. (P. 453)
If the replaced fuse blows again, have the vehicle inspected by any
authorized Lexus dealer or repairer, or another duly qualified and
equipped professional.
If there is an overload in the circuits
The fuses are designed to blow, protecting the wiring harness from damage.
CAUTION
To prevent system breakdowns and vehicle fire
Observe the following precautions.
Failing to do so may cause damage, and possibly a fire or injury.
Never use a fuse of a higher amperage rating than indicated, or use any
other object in place of a fuse.
Always use a genuine Lexus fuse or equivalent.
Never replace a fuse with a wire, even as a temporary fix.
This can cause extensive damage or even fire.
Do not modify the fuses or the fuse box.
NOTICE
Before replacing fuses
Have the cause of electrical overload determined and repaired by any autho-
rized Lexus dealer or repairer, or another duly qualified and equipped pro-
fessional, as soon as possible.

453
4-3. Do-it-yourself maintenance
4
Maintenance and care
IS250/220d/200d_EE
Light bulbs
You may replace the following bulbs yourself. For more information
about replacing other light bulbs, contact any authorized Lexus dealer
or repairer, or another duly qualified and equipped professional.
Preparing a replacement light bulb
Check the wattage of the light bulb being replaced. (P. 552)
Removing the engine compartment cover
P. 407
Front bulb locations
Headlight low beam
(halogen bulb)Front position
Headlight high

454
4-3. Do-it-yourself maintenance
IS250/220d/200d_EE
Replacing light bulbs
Headlight low beams (vehicles with halogen bulbs)
Release the lock and remove
the cover.
Turn the bulb base counter-
clockwise.
Rear bulb locations
Rear fog lightRear turn signal
Back-up light
STEP1
STEP2

455
4-3. Do-it-yourself maintenance
4
Maintenance and care
IS250/220d/200d_EEUnplug the connector while
pulling the lock release.
Headlight high beams (vehicles with halogen headlights)
Release the lock and remove
the cover.
Turn the bulb base counter-
clockwise.
Unplug the connector while
depressing the lock release.
STEP3
STEP1
STEP2
STEP3

456
4-3. Do-it-yourself maintenance
IS250/220d/200d_EEHeadlight high beams (vehicles with discharge headlights)
Turn the cover counterclock-
wise and remove it.
Turn the bulb base counter-
clockwise.
Unplug the connector while
pulling the lock release.
STEP1
STEP2
STEP3

457
4-3. Do-it-yourself maintenance
4
Maintenance and care
IS250/220d/200d_EEFront position lights (vehicles with halogen headlights)
Release the lock and remove
the cover.
Turn the bulb base counter-
clockwise.
Remove the light bulb.
STEP1
STEP2
STEP3

458
4-3. Do-it-yourself maintenance
IS250/220d/200d_EEBack-up lights and rear fog lights
Open the trunk door and
remove the trunk panel cover
clips.
Partly remove the trunk panel
cover and turn the bulb bases
counterclockwise.
Rear fog light
Back-up light
Remove the light bulb.
Rear fog light
Back-up light
Rear turn signal lights
Open the trunk door and
remove the cover.
STEP1
STEP2
STEP3
STEP1

459
4-3. Do-it-yourself maintenance
4
Maintenance and care
IS250/220d/200d_EETurn the bulb base counter-
clockwise.
Remove the light bulb.
Bulbs other than the above
If any of the bulbs listed below has burnt out, have it replaced by
any authorized Lexus dealer or repairer, or another duly quali-
fied and equipped professional.
Headlight high and low beams (discharge bulbs)
Front fog lights
Front turn signal lights
Side turn signal lights
Stop/tail lights
Tail lights
High mounted stoplight
License plate lights
Daytime running lights
Front position lights (vehicles with discharge headlights)
STEP2
STEP3
