Page 3 of 94
3
OverviewInstrument Panel
Headlight switch
Automatic high
beam
Turn signal lever
Fog light switch
*1
P.36
P.38
P.25
Power (ignition) switch P.17
See P.6
See P.7Windshield wiper and
washer switch
P.39
EV drive mode switch
“ECO MODE” switch
Power mode switch P.22
P.21
P.21
Hybrid transmission shift lever P.19
P position switch P.20
Tilt and telescopic steering control switch *1
Pre-collision braking off switch *1
Tilt and telescopic steering control lever *1
Parking brake pedal *1
Hood lock release lever *1 Door lock switches
P.85
Power window switches P.86
Window lock switch
P.86
Inside door lock buttons
P.85
Driving position
memory switches
*1
Multi-information
display
P.23
Page 69 of 94
69
Audio System (without navigation system)
■Basic operation Po w e r/ Vo l u m e
Audio sources
AM
FM: AM radio/FM radio
SAT: Satellite radio
CD•AUX:CD player/Auxiliary
audio device/USB mem-
ory/iPod/Bluetooth
audio
Sound quality modes
■Radio
Te x t m e s s a g e s
Station presets
Traffic information
Radio tune
RDS genre select
Scanning radio stations
Seek
■Entering station presets
Select the desired station by using the tune, the seek or the scan function.
Press and hold one of the preset buttons (1-6) until you hear a beep, indicating that the
station is set.
Page 79 of 94
79
Garage Door Opener (If Equipped)
The garage door opener (HomeLink® Universal Transceiver) is manufactured under license
from HomeLink®.
■Programming the HomeLink® (for U.S.A. owners)
The HomeLink® compatible transceiver in your vehicle has 3 buttons which can be pro-
grammed to operate 3 different devices. Refer to the programming method below
appropriate for the device.
Overhead console type
Indicator light
Buttons
Inside rear view mirror type
Indicator light
Buttons
The garage door opener can be programmed to operate garage doors, gates, entry
doors, door locks, home lighting systems, security systems, and other devices.
Page 80 of 94
80
■Programming HomeLink®
Overhead console type
Hold your hand-held transmitter within
3 inches of the HomeLink
® buttons.
Press and hold down the desired
HomeLink
® button.
For U.S.A. owners:
While pressing the HomeLink
® but-
ton, press and hold down the button
on the hand-held transmitter until the
indicator light changes from a slow to
a rapid flash.
For Canadian owners:
While pressing the HomeLink
® but-
ton, repeatedly press and release
(cycle) the button on the hand-held
transmitter every 2 seconds until the
indicator light changes from a slow to
a rapid flash.
If your garage door is of the rolling code
type:
Press the training button on the motor-
head unit in your garage.
Press and hold the vehicle’s programmed
HomeLink
® button for 2 seconds and
release it. Repeat this step once again.
If the door does not open, press and
release the same button once again.
■Programming other devices
For U.S.A. owners:
To program an entry gate, see the Owner's Manual.
To program other devices, contact your Lexus dealer.
For Canadian owners:
To program all other devices, follow the same procedure as for garage door programming.
Inside rear view mirror type
Page 85 of 94
85
Door Locks
■Door lock switches
Locks all the doors
Unlocks all the doors
■Inside lock button
Locks the door
Unlocks the door
The front doors can be opened by
pulling the inside handle even if the
lock buttons are in the lock position.
■Rear door child-protector lock
The door cannot be opened from inside the
vehicle when the lock is set.
These locks can be set to prevent chil-
dren from opening the rear doors. Push
down on each rear door switch to lock
both rear doors.
The vehicle can be locked and unlocked using the entry function, wireless remote control
or door lock switch.
For details the entry function or wireless remote control (P.14, 15)
