2-2. Instrument cluster
2
When driving
■Indicators
The indicators inform the driver of th e operating state of the vehi-
cle’s various systems.
Turn signal indicator
( P. 161)“ECO MODE” indicator
( P. 1 5 7 )
(U.S.A.)
Headlight indicator
(P. 1 8 6 )“PWR MODE” indicator
( P. 1 5 7 )
(Canada)
Tail light indicator
( P. 1 8 6 )Cruise control indicator
( P. 204, 208)
Headlight high beam
indicator ( P. 1 8 8 )
(if equipped)
Radar cruise control
indicator ( P. 2 0 8 )
(if equipped)
Automatic High Beam
indicator
( P. 1 9 1 )
(if equipped)
“LKA” indicator
( P. 222)
Front fog light indicator
(P. 1 9 7 )“SET” indicator
( P. 204, 208)
“READY” indicator
(P. 1 4 7 )
(if equipped)
Intuitive parking assist
indicator (Refer to
“Navigation System
Owner’s Manual”.)
EV drive mode indicator
(P. 1 5 2 )
(if equipped)
“AFS OFF” indicator
( P. 188)
Eco Driving Indicator
Light ( P. 1 4 0 )Slip indicator
( P. 230, 234)
*1
*1*2

170
2-2. Instrument cluster
*1: These lights turn on when the “POWER” switch is turned to the ON mode
to indicate that a system check is be ing performed. They will turn off after
the hybrid system is on, or after a fe w seconds. There may be a malfunction
in a system if a light does not turn on , or if the lights do not turn off. Have
the vehicle inspected by your Lexus dealer.
*2: The light flashes to indicate that the system is operating.
*3:The light turns on when a part of the system is turned off. The light flashes quickly and “BRAKE!” appear on the multi-information display and head-
up display (if equipped) to indicat e that the system is operating.
VSC OFF indicator
(P. 2 3 0 ) Shift position indicators
(P. 1 5 5 )
(if equipped)
“PCS” warning
(P. 2 3 7 )SRS airbag on-off
indicator ( P. 118)
*1
*1, 3*1

171
2-2. Instrument cluster
2
When driving
CAUTION
■If a safety system warning light does not come on
Should a safety system light such as the ABS and SRS airbag warning light not
come on when you start the hybrid system , this could mean that these systems are
not available to help protect you in an accid ent, which could result in death or seri-
ous injury. Have the vehicle inspected by your Lexus dealer immediately if this
occurs.
■ Warning lights
Warning lights inform the driver of malfunctions in any of the vehi-
cle’s systems. ( P. 4 9 8 )
*1: These lights turn on when the “POWER” switch is turned to ON mode
to indicate that a system check is being performed. They will turn off
after the hybrid system is on, or after a few seconds. There may be a
malfunction in a system if a light does not turn on, or if the lights do not
turn off. Have the vehicle inspected by your Lexus dealer.
*2: The light flashes to indicate a malfunction.
(U.S.A.)(Canada)(U.S.A.)(Canada)
(U.S.A.)(Canada)(if equipped)
(if equipped)(if equipped)(if equipped)
(if equipped)(for driver)(for front
passenger)
*1*1*1*1*1*1*1
*1*1*1*1*1, 2
*1*1, 2*2*2*2*1*1
*2

172
2-2. Instrument cluster
Multi-information display
The multi-information display presents the driver with a variety of driving-
related data including the current outside air temperature.
■Multi-information switches
Menu switch
Changes modes to electronic
feature control mode (if
equipped), customization mode
or back to normal display mode.
“ENTER” switch
Changes trip information items.
This switch is also used to turn
on/off electronic feature con-
trols and to change customiza-
tion settings.

173
2-2. Instrument cluster
2
When driving
■Display contents
Trip information contentsSwitching display items
Energy monitor
Press the “ENTER” switch upward or
downward.
Total distance/Total average fuel
consumption
Current fuel consumption/Aver-
age fuel consumption after refuel-
ing
Cruising range
Average vehicle speed
Outside temperature
Tire inflation pressure
Blank

174
2-2. Instrument cluster
Display order may vary depending on vehicle condition.
Electronic feature control contentsSetting electronic feature controls
AFS (if equipped)P. 1 8 8
Intuitive parking assist
(if equipped)Refer to “Navigation System
Owner’s Manual”.
Other contentsDetails
Customization ( P. 5 8 0 )
Settings of functions such as the
door lock and light illumination time
can be changed
Dynamic radar cruise control
(if equipped) ( P. 2 0 8 )Automatically displayed when using
the dynamic radar cruise control
LKA (Lane Keeping Assist)
(if equipped) ( P. 221)Automatically displayed when using
the lane keeping assist
PCS (Pre-Collision System)
(if equipped) ( P. 236, 508, 511)Automatically displayed if there is a
possibility of collision.

175
2-2. Instrument cluster
2
When driving
Trip information■ Energy monitor
Displays the status of the hybrid system ( P. 3 3 )
■ Total distance/Total average fuel consumption
Displays the total distance and av erage fuel consumption since the last
reset.
Press the “ENTER” switch for 1 second or more when the total distance and
the average fuel consumption is displayed.
“Past Record” screen on the navigation system (if equipped) will also be
reset. ( P. 3 7 )
■Current fuel consumption/Averag e fuel consumption after refueling
Displays the instant fuel consumpt ion and average fuel consumption
after refueling.
■ Cruising range
Displays the estimated maximum distan ce that can be driven with the
quantity of fuel remaining.
• This distance is computed based on your average fuel consumption. As a result, the actual distance that can be driven may differ from that dis-
played.
• When only a small amount of fuel is added to the tank, the display may not
be updated.
Other contentsDetails
Wa r n i n g m e s s a g e ( P. 5 0 7 )
Automatically displayed when a mal-
function occurs in any of the vehi-
cle's systems

176
2-2. Instrument cluster
■Average vehicle speed
Displays the average vehicle speed since the function was reset
The function can be reset by pushing the “ENTER” switch for longer than 1
second when the average vehicle speed is displayed.
■ Outside temperature
Displays the outside temperature
■ Tire inflation pressure
Displays inflation pressure of each tire. There is no correlation between
the order of the displayed values and the tire positions.
It may take a few minutes to display the tire inflation pressure after the
“POWER” switch is turned to ON mode. It may also take a few minutes to
display the tire inflation pressure after the inflation pressure has been
adjusted.
■Electronic feature control can be turned on/off when
The “POWER” switch is in ON mode.
■Conditions for ending electronic feature control
In the following situations, the electronic feature control will end:
●The menu switch is pressed
●The radar cruise control is operated (if equipped)
●The lane keeping assist is operated (if equipped)
●Intuitive parking assist starts operating (if equipped)
●No action is performed for some time after the electronic feature control
screen is displayed
●A warning message appears after the electronic feature control screen is dis-
played
