2-2. Instrument cluster
2
When driving
CT200h_EE (OM76041E)
Customization
Settings (e.g. on/off operation of the ECO lamp) can be changed.
(Customizable features P. 655)
NOTICE
To prevent damage to the engine and its components
Do not let the indicator needle of the tachometer enter the red zone, which
indicates the maximum engine speed.
The engine may be overheating if the high coolant temperature warning
light comes on or flashes. In this case, immediately stop the vehicle in a
safe place, and check the engine after it has cooled completely. (P. 6 2 7 )

222
2-2. Instrument cluster
CT200h_EE (OM76041E)
Indicators and warning lights
The indicator and warning lights on the instrument cluster and center
panel inform the driver of the status of the vehicle’s various systems.
Instrument cluster
Center panel

223
2-2. Instrument cluster
2
When driving
CT200h_EE (OM76041E)
Indicators
The indicators inform the driver of the operating state of the
vehicle’s various systems.
Turn signal indicator
(P. 213)“ECO MODE” indica-
tor (P. 206)
Tail light indicator
(P. 232)“SPORT MODE” indi-
cator (P. 206)
Headlight high beam
indicator (P. 233)
(if equipped)
Cruise control indicator
(P. 248, 252)
(if equipped)
Front fog light indicator
(P. 237)
(if equipped)
Radar cruise control
indicator (P. 252)
Rear fog light indicator
(P. 237)
(if equipped)
Lexus parking assist-
sensor indicator (P.
269)
“READY” indicator
(P. 196)Slip indicator
(P. 287, 290)
EV indicator (P. 3 6 )
(if equipped)
“PCS” warning
(P. 293)
EV drive mode indica-
tor (P. 201)
*1,
*1,

224
2-2. Instrument cluster
CT200h_EE (OM76041E)
*1: These lights turn on when the “POWER” switch is turned to the
ON mode to indicate that a system check is being performed. They
will turn off after the hybrid system is on, or after a few seconds.
There may be a malfunction in a system if a light does not come
on, or if the lights do not turn off. Have the vehicle inspected by
any authorized Lexus dealer or repairer, or another duly qualified
and equipped professional.
*2: The light flashes to indicate that the system is operating.
*3: The light comes on when the system is turned off. The light
fl h f t th l t i di t th t th t i ti
Shift position indicators
(P. 204)SRS airbag on-
off
indicator *

225
2-2. Instrument cluster
2
When driving
CT200h_EE (OM76041E)
CAUTION
If a safety system warning light does not come on
Should a safety system light such as the ABS and SRS airbag warning light
not come on when you start the hybrid system, this could mean that these
systems are not available to help protect you in an accident, which could
result in death or serious injury. Have the vehicle inspected by any autho-
rized Lexus dealer or repairer, or another duly qualified and equipped pro-
fessional immediately if this occurs.
Warning lights
Warning lights inform the driver of malfunctions in any of the
vehicle’s systems. (P. 558)
*1: These lights turn on when the “POWER” switch is turned to ON
mode to indicate that a system check is being performed. They
will turn off after the hybrid system is on, or after a few seconds.
There may be a malfunction in a system if a light does not come
on, or if the lights do not turn off. Have the vehicle inspected by
any authorized Lexus dealer or repairer, or another duly quali-
fied and equipped professional.
*2Th li h fl h i di lf i
(if equipped)
(if equipped)
*1*1*1*1*1
*1*1*1*1,*1*1
*1*1

232
CT200h_EE (OM76041E)
2-3. Operating the lights and windshield wipers
Headlight switch
The headlights can be operated manually or automatically.
Turning the end of the lever turns on the lights as follows:
The front position,
tail, license plate
and instrument
panel lights turn on.
The headlights and
all lights listed
above turn on.
The headlights and
front position lights
turn on and off auto-
matically.
(When the
“POWER” switch is
in ON mode.)

233
2-3. Operating the lights and windshield wipers
2
When driving
CT200h_EE (OM76041E)
Turning on the high beam headlights
With the headlights on, push
the lever away from you to
turn on the high beams.
Pull the lever toward you to the
center position to turn the high
beams off.
Pull the lever toward you and
release it to flash the high
beams once.
You can flash the high beams
with the headlights on or off.
Manual headlight leveling dial (if equipped)
The level of the headlights can be adjusted according to the num-
ber of passengers and the loading condition of the vehicle.
Raises the level of the head-
lights
Lowers the level of the head-
lights

234
2-3. Operating the lights and windshield wipers
CT200h_EE (OM76041E)Guide to dial settings
Occupancy and luggage load conditionsDial positionOccupantsLuggage load
DriverNone0
Driver and front
passengerNone0
All seats occupiedNone1.5
All seats occupiedFull luggage loading2.5
DriverFull luggage loading4
