1-3. Opening, closing and locking the doors
1
Before driving
CT200h_EE (OM76041E)
Impact detection door lock release system
In the event that the vehicle is subject to a strong impact, all the doors are
unlocked. Depending on the force of the impact or the type of accident,
however, the system may not operate.
Using the mechanical key
The doors can also be locked and unlocked with the mechanical key. (P.
617)
If a wrong key is used
The key cylinder rotates freely to isolate inside mechanism.
Customization
Settings (e.g. unlocking function using a key) can be changed.
(Customizable features P. 655)

99
1-4. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
CT200h_EE (OM76041E)
Linking driving position memory with door unlock operation
(driver’s seat only)
Record your driving position to button 1, 2 or 3 before performing
the following:
Carry only the key (including the card key) to which you want to
link the driving position. If 2 or more keys are in the vehicle, the
driving position cannot be linked properly.
Close the driver’s door and turn the “POWER” switch to
OFF mode.
Press the desired button (1, 2 or
3) to recall the position. Then,
while keep pressing the button,
press the driver’s door lock
switches (either lock or unlock)
until the signal beeps.
The driving position is recalled
when the driver’s door is
unlocked using the entry func-
tion or wireless remote control
and the driver’s door is opened.
STEP1
STEP2

122
1-5. Opening and closing the windows and moon roof
CT200h_EE (OM76041E)
Door lock linked window operation
The power windows can be opened and closed using the mechanical
key.
*
(P. 617)
The power windows can be opened and closed using the wireless remote
control.
* (P. 8 0)
*:This setting must be customized at any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional.
Customization
Setting (e.g. linked door lock operation) can be changed.
(Customizable features
P. 655)
CAUTION
Closing the windows
Observe the following precautions.
Failing to do so may result in death or serious injury.
Check to make sure that all passengers do not have any part of their body
in a position where it could be caught when a window is being operated.
Do not allow children to operate the power windows.
Closing a power window on someone can cause serious injury, and in
some instances, even death.
Jam protection function
Never use any part of your body to intentionally activate the jam protec-
tion function.
The jam protection function may not work if something gets caught just
before the window fully closes.

131
1
Before driving
CT200h_EE (OM76041E)
1-7. Theft deterrent system
Immobilizer system
System maintenance
The vehicle has a maintenance-free type immobilizer system.
Conditions affecting operation
Depending on the surrounding environment and conditions, the immobilizer
system may not operate properly. This may prevent the hybrid system from
starting. (P. 8 2 )
The vehicle’s keys have built-in transponder chips that prevent the
hybrid system from starting if a key has not been previously registered
in the vehicle’s on-board computer.
Never leave the keys inside the vehicle when you leave the vehicle.
The indicator light flashes
after the “POWER” switch
has been turned off to indi-
cate that the system is operat-
ing.
The indicator light stops
flashing after the “POWER”
switch has been turned to
ACCESSORY or ON mode

142
1-7. Theft deterrent system
CT200h_EE (OM76041E)
Triggering of the alarm
The alarm may be triggered in the following situations:
(Stopping the alarm deactivates the alarm system.)
Alarm-operated door lock
When the alarm is operating, the doors are locked automatically to pre-
vent intruders.
Do not leave the key inside the vehicle when the alarm is operating, and
make sure the key is not inside the vehicle when recharging or replacing
the battery.
The doors are unlocked using the
mechanical key.
A person inside the vehicle opens a
door or hood.
The 12-volt battery is recharged or
replaced when the vehicle is locked.

161
1-8. Safety information
1
Before driving
CT200h_EE (OM76041E)
Deactivating the front seat passenger airbag and front passenger
side airbag
Insert the mechanical key into
the cylinder and rotate to the
“OFF” position.
The “OFF” indicator light turns
on (only when the “POWER”
switch is in ON mode).
“PASSENGER AIRBAG” indicator information
If any of the following problems occur, it is possible that there is a malfunc-
tion in the system. Have the vehicle inspected by any authorized Lexus
dealer or repairer, or another duly qualified and equipped professional.
Neither “ON” nor “OFF” comes on.
The indicator does not change when the airbag manual on-off switch is
switched to “ON” or “OFF” position.

167
1-8. Safety information
1
Before driving
CT200h_EE (OM76041E)Key of letters inserted in the above table:
U: Suitable for “universal” category child restraint system
approved for the use in this mass group.
UF: Suitable for forward facing “universal” category child
restraint system approved for the use in this mass group.
L1: Suitable for “LEXUS G 0+, BABY SAFE PLUS” (0 to 13 kg
[0 to 28 lb.]) approved for the use in this mass group.
L2: Suitable for “LEXUS G 0+, BABY SAFE PLUS with SEAT
BELT FIXATION, BASE PLATFORM” (0 to 13 kg [0 to
28 lb.]) approved for the use in this mass group.
L3: Suitable for “LEXUS DUO+” (without ISOFIX, 9 to 18 kg
[20 to 39 lb.]) approved for the use in this mass group.
L4: Suitable for “LEXUS KID” (15 to 36 kg [34 to 79 lb.])
approved for the use in this mass group.
L5: Suitable for “LEXUS KIDFIX” (15 to 36 kg [34 to 79 lb.])
approved for the use in this mass group.
X: Not suitable seat position for children in this mass group.
*1: When you use a child restraint system in this position, adjust
the seat back and fix it at the most upright lock position.
*2: When you use a child restraint system in this position, remove
the head restraint.
Other child restraint system which is different from the system
mentioned in the table can be used.
But the suitability of the systems must be carefully checked with
the child restraint system manufacturer concerned and the seller of
those seats.

169
1-8. Safety information
1
Before driving
CT200h_EE (OM76041E)(1) For the CRS which do not carry the ISO/XX size class identi-
fication (A to G), for the applicable mass group, the car man-
ufacturer shall indicate the vehicle specific ISOFIX child
restraint system(s) recommended for each position.
Key of letters inserted in the above table:
IUF: Suitable for ISOFIX forward-facing child restraints systems
of universal category approved for the use in this mass group.
X: ISOFIX position not suitable for ISOFIX child restraint sys-
tems in this mass group and/or this size class.
*1: When you use a child restraint system in this position, remove
the head restraint.
The child restraint systems mentioned in the table may not be
available outside of the EU area.
Other child restraint systems different from the systems mentioned
in the table can be used, but the suitability of the systems must be
carefully checked with the child restraint system manufacturer and
retailer.
