2011 INFINITI QX56 BATTERY

PCS-18
< ECU DIAGNOSIS INFORMATION >[IPDM E/R]
IPDM E/R
17
(B) Ground Cooling fan motor
ground
Output Ignition switch ON 0 V
18
(B) Ground Ground — Ignition switch ON 0 V
19
(V) Ground Front fog lamp (RH) Output Lighting
switch 2ND or
AUTO (Light
is illuminated)Front fog lamp switch
OFF
0 V
Front fog lamp switch ON Battery voltage
20
(W) Ground Front fog lamp (LH) Output Lighting
switch 2ND or
AUTO (Light
is illuminated)Front fog lamp switch
OFF
0 V
Front fog lamp switch ON Battery voltage
21
(L) Ground
Headlamp washer re-
lay control Output
Ignition switch
ON Headlamp washer acti-
vated
0 V
Headlamp washer deacti-
vated 12 V
23
(GR/R) Ground Cranking request Output Select lever P or N (Ignition switch ON) 0 V
Select lever in any position other than P or
N (Ignition switch ON)
12 V
Engine running 12 V
24
(W/G) Ground Oil pressure switch Input Ignition switch
ONEngine stopped 0 V
Engine running 12 V
25
(L/Y) Ground Front wiper stop posi-
tion InputIgnition switch
ON Front wiper stop position 0 V
Any position other than
front wiper stop position
12 V
26
(P) Ground CAN-L Input/
Output ——
27
(L) Ground CAN-H
Input/
Output ——
30
(R/W) Ground Starter relay control Output  Ignition switch OFF or ACC
 At engine cranking
0 V
 Ignition switch ON
 Engine running 12 V
31
(B) Ground Injector relay control Output  Approximately 1 second after turning
the ignition switch ON
 Engine running 0 - 1.5 V
Approximately 1 second or more after turn-
ing the ignition switch ON Battery voltage
32
(LG) Ground Hood switch Input Close the hood 12 V
Open the hood 0 V
33
(R) Ground Alternator control Output Ignition switch OFF or ACC 0 V
Ignition switch ON 6 V
34
(P/B) Ground Horn relay control Output The horn is deactivated Battery voltage
The horn is activated 0 V
Te r m i n a l N O .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
+–
Revision: 2010 May2011 QX56

PCS
IPDM E/RPCS-19
< ECU DIAGNOSIS INFORMATION > [IPDM E/R]
C
D
E
F
G H
I
J
K L
B A
O P
N
35
(W) Ground ECM relay power sup-
ply OutputIgnition switch OFF
(More than a few seconds after turning ig-
nition switch OFF)
0 V
 Ignition switch ON
 Ignition switch OFF (For a few seconds after turning ignition
switch OFF) Battery voltage
36
(V) Ground ECM relay power sup-
ply
OutputIgnition switch OFF or ACC 0 V
Ignition switch ON Battery voltage
37
(L) Ground Parking lamp (RH) Output Ignition switch
ONLighting switch OFF 0 V
Lighting switch 1ST Battery voltage
38
(Y) Ground Tail lamp (RH) Output Ignition switch
ONLighting switch OFF 0 V
Lighting switch 1ST Battery voltage
39
(L/B) Ground Front wiper HI Output Ignition switch
ONFront wiper switch OFF 0 V
Front wiper switch LO 9 V
Front wiper switch HI Battery voltage
41
(L/G) Ground ECM relay control Output Ignition switch OFF
(More than a few seconds after turning ig-
nition switch OFF)
Battery voltage
 Ignition switch ON
 Ignition switch OFF (For a few seconds after turning ignition
switch OFF) 0 - 1.5 V
42
(L) Ground Battery power supply Output Ignition switch OFF
(More than a few seconds after turning ig-
nition switch OFF)
0 V
 Ignition switch ON
 Ignition switch OFF (For a few seconds after turning ignition
switch OFF) Battery voltage
43
(LG) Ground Parking lamp (LH) Output
Ignition switch
ONLighting switch OFF 0 V
Lighting switch 1ST Battery voltage
44
(L/W) Ground Tail lamp (LH), license
plate lamp
OutputIgnition switch
ON Lighting switch OFF 0 V
Lighting switch 1ST Battery voltage
45
(Y/R) Ground Front wiper LO Output Ignition switch
ONFront wiper switch OFF 0 V
Front wiper switch LO Battery voltage
46
(L/W) Ground
Steering lock unit pow-
er supply OutputIgnition switch ACC or ON 0 V
Ignition switch
OFF
A few seconds after
opening the driver door
Battery voltage
Ignition switch
LOCK Press the push-button ig-
nition switch
Battery voltage
48
(BR) Ground P/N position Input Select lever in any position other than P or
N (Ignition switch ON)
0 V
Select lever P or N (Ignition switch ON) 12 V
49
(R) Ground Headlamp HI (RH) Output Lighting
switch 2ND or
AUTO (Light
is illuminated)Lighting switch other than
HI and PASS
0 V
 Lighting switch HI
 Lighting switch PASS Battery voltage
Te r m i n a l N O .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
+–
Revision: 2010 May2011 QX56

PCS-20
< ECU DIAGNOSIS INFORMATION >[IPDM E/R]
IPDM E/R
50
(LG/B) Ground Headlamp HI (LH) Output Lighting
switch 2ND or
AUTO (Light
is illuminated)Lighting switch other than
H and PASS
0 V
 Lighting switch HI
 Lighting switch PASS Battery voltage
51
(BR/Y) Ground Headlamp LO (LH) Output Lighting switch OFF 0 V
Lighting switch 2ND or AUTO (light is illu-
minated)
Battery voltage
52
(W) Ground Headlamp LO (RH) Output Lighting switch OFF 0 V
Lighting switch 2ND or AUTO (light is illu-
minated)
Battery voltage
54
(SB) Ground ECM power supply Output Approximately 1 second or more than after
turning the ignition switch ON
0 V
 Approximately 1 second after turning the ignition switch ON
 Engine running Battery voltage
55
(O) Ground Throttle control motor
relay power supply
OutputIgnition switch OFF
(More than a few seconds after turning ig-
nition switch OFF)
0 V
 Ignition switch ON
 Ignition switch OFF (For a few seconds after turning ignition
switch OFF) Battery voltage
56
(L) Ground A/C compressor power
supply OutputEngine run-
ning A/C switch OFF 0 V
A/C switch ON
(A/C compressor is oper-
ating)
Battery voltage
57
(V) Ground Ignition relay power
supply
OutputIgnition switch OFF or ACC 0 V
Ignition switch ON Battery voltage
58
(BR/R) Ground Ignition relay power
supply
OutputIgnition switch OFF or ACC 0 V
Ignition switch ON Battery voltage
59
(W/B) Ground Ignition relay power
supply
OutputIgnition switch OFF or ACC 0 V
Ignition switch ON Battery voltage
60
(V/R) Ground
Throttle control motor
relay control OutputIgnition switch ON
→ OFF 0 - 1.0 V
↓
Battery voltage
↓
0 V
Ignition switch ON 0 - 1.0 V
61
(W) Ground Ignition relay power
supply
OutputIgnition switch OFF or ACC 0 V
Ignition switch ON Battery voltage
62
(SB) Ground Ignition relay power
supply
OutputIgnition switch OFF or ACC 0 V
Ignition switch ON Battery voltage
63
(P) Ground Steering lock unit con-
dition-2
InputSteering lock is unlocked 0 V
Steering lock is locked 12 V
64
(G/Y) Ground A/T shift selector
(detention switch) InputIgnition switch
ON Select lever P 0 V
Select lever in any posi-
tion other than P
12 V
65
(L) Ground
Steering lock unit con-
dition-1 InputSteering lock is unlocked 12 V
Steering lock is locked 0 V
Te r m i n a l N O .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
+–
Revision: 2010 May2011 QX56

PCS
IPDM E/RPCS-21
< ECU DIAGNOSIS INFORMATION > [IPDM E/R]
C
D
E
F
G H
I
J
K L
B A
O P
N
Fail-SafeINFOID:0000000006220173
CAN COMMUNICATION CONTROL
When CAN communication with ECM and BCM is impossible,
IPDM E/R performs fail-safe control. After CAN
communication recovers normally, it also returns to normal control.
If No CAN Communication Is Available With ECM
If No CAN Communication Is Available With BCM
66
(SB) Ground
Push-button ignition
switch InputPress the push-button ignition switch 0 V
Release the push-button ignition switch 12 V
68
(O) Ground Ignition relay monitor Input Ignition switch OFF or ACC 12 V
Ignition switch ON 0 V
69
(W/B) Ground Ignition power supply Output Ignition switch OFF or ACC 0 V
Ignition switch ON Battery voltage
72
(Y/R) Ground Cooling fan control Output Ignition switch
OFF 5 V
ACC 0 V
ON
2. 5 V
Engine running
Te r m i n a l N O .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
+–
JMMIA0404GB
Control part Fail-safe operation
Cooling fan  Transmits the pulse duty signal (PWM signal) 100% when the ignition switch is turned ON.
 Transmits the pulse duty signal (PWM signal)
0% when the ignition switch is turned OFF.
A/C compressor A/C relay OFF
Alternator Transmits the power generation command signal (PWM signal) 0%
Control part Fail-safe operation
Headlamp  Turns ON the headlamp low relay when the ignition switch is turned ON
 Turns OFF the headlamp low relay when the ignition switch is turned OFF
 Headlamp high relay OFF
Parking lamp
 License plate lamp
 Illumination
 Tail lamp
 Side marker lamp  Turns ON the tail lamp relay when the ignition switch is turned ON
 Turns OFF the tail lamp relay when the ignition switch is turned OFF
Front wiper motor  The status just before activation of fail-safe control is maintained until the ignition switch is
turned OFF while the front wiper is operating at LO or HI speed.
 The wiper is operated at LO speed until the ignition switch is turned OFF if the fail-safe con-
trol is activated while the front wiper is set in the INT mode and the front wiper motor is op-
erating.
 Return automatically wiper to stop position when ignition switch is turned ON if fail-safe con-
trol is activated while front wiper motor is operated and wiper stops in the other position than
stop position.
Front fog lamp Front fog lamp relay OFF
Horn Horn OFF
Revision: 2010 May2011 QX56

PCS
POWER SUPPLY AND GROUND CIRCUITPCS-31
< DTC/CIRCUIT DIAGNOSIS > [IPDM E/R]
C
D
E
F
G H
I
J
K L
B A
O P
N
POWER SUPPLY AND GROUND CIRCUIT
Diagnosis ProcedureINFOID:0000000006220185
1.CHECK FUSES AND FUSIBLE LINK
Check that the following IPDM E/R fuses or fusible links are not blown.
Is the fuse fusing?
YES >> Replace the blown fuse or fusible link after repairing the affected circuit if a fuse or fusible link is blown.
NO >> GO TO 2.
2.CHECK POWER SUPPLY CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Check voltage between IPDM E/R harness connector and the ground.
Is the measurement value normal?
YES >> GO TO 3.
NO >> Repair the harness or connector.
3.CHECK GROUND CIRCUIT
Check continuity between IPDM E/R harness connectors and the ground.
Does continuity exist?
YES >> INSPECTION END
NO >> Repair the harness or connector.
Signal name Fuses and fusible link No.
Battery power supply C (100 A)
N (60 A)
37 (10 A)
(+) (− ) Voltag e
(Approx.)
IPDM E/R
Connector Terminal
E9 1
Ground Battery voltage
2
E10 8
IPDM E/R
GroundContinuity
Connector Terminal
E11 9 Existed
E12 18
Revision: 2010 May2011 QX56

PCS-32
< REMOVAL AND INSTALLATION >[IPDM E/R]
IPDM E/R
REMOVAL AND INSTALLATION
IPDM E/R
Removal and InstallationINFOID:0000000006220186
CAUTION:
IPDM E/R integrated relays are not serviceable pa
rts, and must not be removed from the unit.
REMOVAL
1. Disconnect the battery cable from the negative terminal.
2. Remove the IPDM E/R cover A.
3. Remove the IPDM E/R (1) while pressing the pawls (A).
4. Disconnect the harness connector and then remove the IPDM E/R.
INSTALLATION
Install in the reverse order of removal.
JMMIA0331ZZ
Revision: 2010 May2011 QX56

PCS
PRECAUTIONSPCS-33
< PRECAUTION > [POWER DISTRIBUTION SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
PRECAUTION
PRECAUTIONS
Precaution for Supplemental
Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000006220187
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the “SRS AIR BAG” and “SEAT BELT” of this
Service Manual.
WARNING:
 To avoid rendering the SRS inoper ative, which could increase the risk of personal injury or death in
the event of a collision that would result in air ba g inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
 Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintentional act ivation of the system. For removal of Spiral Cable and Air Bag
Module, see the “SRS AIR BAG”.
 Do not use electrical test equipm ent on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
 When working near the Air Bag Diagnosis Sensor Unit or other Air Bag System sensors with the
ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s)
with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly
causing serious injury.
 When using air or electric power tools or hammers , always switch the ignition OFF, disconnect the
battery, and wait at least 3 minutes before performing any service.
Precaution Necessary for Steering Wh eel Rotation after Battery Disconnect
INFOID:0000000006220188
NOTE:
 Before removing and installing any control units, first tu rn the push-button ignition switch to the LOCK posi-
tion, then disconnect both battery cables.
 After finishing work, confirm that all control unit connectors are connected properly, then re-connect both
battery cables.
 Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work.
If a DTC is detected, perform trouble diagnos is according to self-diagnosis results.
For vehicle with steering lock unit, if the battery is disconnected or discharged, the steering wheel will lock and
cannot be turned.
If turning the steering wheel is required with the batte ry disconnected or discharged, follow the operation pro-
cedure below before starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables. NOTE:
Supply power using jumper cables if battery is discharged.
2. Turn the push-button ignition switch to ACC position. (At this time, the steering lock will be released.)
3. Disconnect both battery cables. The steering lock wil l remain released with both battery cables discon-
nected and the steering wheel can be turned.
4. Perform the necessary repair operation.
Revision: 2010 May2011 QX56

PCS-34
< PRECAUTION >[POWER DISTRIBUTION SYSTEM]
PRECAUTIONS
5. When the repair work is completed, re-connect bot
h battery cables. With the brake pedal released, turn
the push-button ignition switch from ACC position to ON position, then to LOCK position. (The steering
wheel will lock when the push-button igniti on switch is turned to LOCK position.)
6. Perform self-diagnosis check of all control units using CONSULT-III.
Revision: 2010 May2011 QX56
