P2539, P2541, P2542 LOW FUEL PRESSURE SENSOR
EC-485
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
NO >> Repair or replace error-detected parts.
6.CHECK LOW FUEL PRESSURE SENSOR SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between low fuel pressu re sensor harness connector and ECM harness connector.
4. Also check harness for short to ground and to power.
Is inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace error-detected parts.
7.CHECK LOW FUEL PRESSURE SENSOR
Refer to EC-485, "
Component Inspection".
Is inspection result normal?
YES >> Check intermittent incident. Refer to GI-40, "Intermittent Incident".
NO >> Replace low fuel pressure sensor.
Component InspectionINFOID:0000000006289706
1.CHECK LOW FUEL PRESSURE SENSOR
WITH CONSULT-III
1. Turn ignition switch OFF.
2. Reconnect harness connector disconnected.
3. Start the engine.
4. Select “DATA MONITOR” mode with CONSULT-III.
5. Check that the “L/FUEL PRES SEN V” value.
WITHOUT CONSULT-III
1. Turn ignition switch OFF.
2. Reconnect harness connector disconnected.
3. Start the engine.
4. Check low fuel pressure sensor signal voltage.
+ −
Continuity
Low fuel pressure sensor ECM
Connector Terminal Connector Terminal F25 2 F111 23 Existed
Data monitor item Condition Va l u e
(Approx.)
L/FUEL PRES SEN V Engine speed: idle
3,000 –3,300 mV
Engine speed: 3,000 rpm (no load)
Revision: 2010 May2011 QX56

P2A00, P2A03 A/F SENSOR 1EC-487
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P2A00, P2A03 A/F SENSOR 1
DTC LogicINFOID:0000000006217987
DTC DETECTION LOGIC
To judge the malfunction, the A/F signal computed by ECM fr
om the A/F sensor 1 signal is monitored so it will
not shift to LEAN side or RICH side.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Clear the mixture ratio self-learning value. Refer to EC-152, "
Work Procedure".
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Turn ignition switch ON.
4. Turn ignition switch OFF and wait at least 10 seconds.
5. Start engine and keep the engine speed between 3,500 and 4,000 rpm for 1 minute under no load.
6. Let engine idle for 1 minute.
7. Keep engine speed between 2,500 and 3,000 rpm for 20 minutes.
8. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-487, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217988
1.RETIGHTEN A/F SENSOR 1
Loosen and retighten the A/F sensor 1. Refer to EX-5, "
Exploded View".
>> GO TO 2.
2.CHECK A/F SENSOR 1 CONNECTOR
1. Disconnect A/F sensor 1 harness connector.
2. Check that water is not inside connectors.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness connector.
3.CHECK FOR INTAKE AIR LEAKAGE
1. Reconnect A/F sensor 1 harness connector.
2. Start engine and run it at idle.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P2A00 A/F SENSOR1 (B1)
(Air fuel ratio (A/F) sensor 1 (bank 1)
circuit range/performance)  The output voltage computed by ECM from
the A/F sensor 1 signal shifts to the lean side
for a specified period.
 The A/F signal computed by ECM from the
A/F sensor 1 signal shifts to the rich side for
a specified period.  A/F sensor 1
 A/F sensor 1 heater
 Fuel pressure
 Fuel injector
 Intake air leaks
P2A03 A/F SENSOR1 (B2)
(Air fuel ratio (A/F) sensor 1 (bank 2)
circuit range/performance)
Revision: 2010 May2011 QX56

EC-490
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
ASCD BRAKE SWITCH
ASCD BRAKE SWITCH
Component Function CheckINFOID:0000000006217989
1.CHECK ASCD BRAKE SWITCH FUNCTION
WITH CONSULT-III
1. Turn ignition switch ON.
2. Select “BRAKE SW1” in “DAT A MONITOR” mode with CONSULT-III.
3. Check “BRAKE SW1” indication under the following conditions.
WITHOUT CONSULT-III
1. Turn ignition switch ON.
2. Check the voltage between ECM harness connector terminals as per the following.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-490, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006217990
1.CHECK ASCD BRAKE SWITCH POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ASCD brake switch harness connector.
3. Turn ignition switch ON.
4. Check the voltage between ASCD brake switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.DETECT MALFUNCTIONING PART
Check the following.
 10 A fuse (No. 3)
 Harness for open or short between ASCD brake switch and fuse
 Loose or poor connection for each connector and harness
>> Repair open circuit or short to ground in harness or connectors.
3.CHECK ASCD BRAKE SWITCH INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between ASCD brake s witch harness connector and ECM harness connector.
Monitor item Condition Indication
BRAKE SW1
(ASCD brake switch) Brake pedalSlightly depressed OFF
Fully released ON
ECM Condition Voltage (V)
Connector +–
Te r m i n a l Te r m i n a l
E80 147
(ASCD brake switch signal) 175 Brake pedalSlightly depressed Approx. 0
Fully released Battery voltage
ASCD brake switch
Ground Voltage
Connector Terminal
E109 1 Ground Battery voltage
Revision: 2010 May2011 QX56

ELECTRICAL LOAD SIGNALEC-493
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
ELECTRICAL LOAD SIGNAL
DescriptionINFOID:0000000006217994
The electrical load signal (Rear window defogger switch
signal, headlamp switch signal, heater fan switch sig-
nal, etc.) is transferred via the CAN communication line.
Component Function CheckINFOID:0000000006217995
1.CHECK REAR WINDOW DEF OGGER SWITCH FUNCTION
1. Turn ignition switch ON.
2. Select “DATA MONITOR” mode with CONSULT-III.
3. Select “LOAD SIGNAL” and check indication under the following conditions.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Go to EC-493, "
Diagnosis Procedure".
2.CHECK LIGHTING SWITCH FUNCTION
Check “LOAD SIGNAL” indication under the following conditions.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Go to EC-493, "
Diagnosis Procedure".
3.CHECK HEATER FAN CONTROL SWITCH FUNCTION
Select “HEATER FAN SW” and check indication under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-493, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006217996
1.INSPECTION START
Confirm the malfunctioning circuit (rear window defogger, headlamp or heater fan). Refer to EC-493, "
Compo-
nent Function Check".
Which circuit is related to the incident?
Rear window defogger>>GO TO 2.
Headlamp>>GO TO 3.
Heater fan>>GO TO 4.
2.CHECK REAR WINDOW DEFOGGER SYSTEM
Refer to DEF-24, "
Work Flow".
Monitor item Condition Indication
LOAD SIGNAL Rear window defogger switch ON ON
OFF OFF
Monitor item Condition Indication
LOAD SIGNAL Lighting switch ON at 2nd position ON
OFF OFF
Monitor item Condition Indication
HEATER FAN SW Heater fan control switch ON ON
OFF OFF
Revision: 2010 May2011 QX56

ELECTRICALLY-CONTROLLED COOLING FAN COUPLINGEC-495
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
ELECTRICALLY-CONTROLLED COOLING FAN COUPLING
Component Function CheckINFOID:0000000006217997
1.CHECK COOLING FAN FUNCTION
WITH CONSULT-III
1. Start the engine.
2. Perform “FAN DUTY CONTROL” in “ACTIVE TEST” mode with CONSULT-III.
3. Check that cooling fan speed varies according to the percentage.
NOTE:
Speed changes gradually as the percentage changes.
WITHOUT CONSULT-III
1. Start the engine and warm up the engine until engine coolant temperature reaches at least 98°C (209 °F).
2. Check that cooling fan speed increase.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to EC-495, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006217998
1.CHECK DRIVE BELT
1. Turn ignition switch OFF.
2. Check that the drive belt is not broken.
Is inspection result normal?
YES >> GO TO 2.
NO >> Replace drive belt.
2.CHECK ELECTRICALLY-CONTROLLED COOLING FAN COUPLING POWER SUPPLY
1. Disconnect electrically-controlled c ooling fan coupling harness connector.
2. Turn ignition switch ON.
3. Check the voltage between electrically-controll ed cooling fan coupling harness connector and ground.
Is inspection result normal?
YES >> GO TO 3.
NO >> Perform trouble diagnosis for power supply circuit.
3.CHECK ELECTRICALLY-CONTROLLED COOLING FAN COUPLING GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check the continuity between electrically-cont rolled cooling fan coupling harness connector and ground.
Is inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace error-detected parts.
4.CHECK ELECTRICALLY-CONTROLLED COOLING FAN COUPLING CONTROL SIGNAL
WITH CONSULT-III
+ −Vo l ta g e
(Approx.)
Electrically-controlled cooling fan coupling
Connector TerminalF39 1 Ground Battery voltage
+ −Continuity
Electrically-controlled cooling fan coupling
Connector TerminalF39 6 Ground Existed
Revision: 2010 May2011 QX56

ICC BRAKE SWITCHEC-503
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
ICC BRAKE SWITCH
Component Function CheckINFOID:0000000006218008
1.CHECK ICC BRAKE SWITCH FUNCTION
WITH CONSULT-III
1. Turn ignition switch ON.
2. Select “BRAKE SW1” in “DATA MONITOR” mode with CONSULT-III.
3. Check “BRAKE SW1” indication under the following conditions.
WITHOUT CONSULT-III
1. Turn ignition switch ON.
2. Check the voltage between ECM harness connector terminals as per the following.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-503, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006218009
1.CHECK DTC WITH ADAS CONTROL UNIT
Refer to DAS-21, "
CONSULT-III Function (ICC/ADAS)" and DAS-38, "DTC Index".
Are any DTCs detected?
YES >> Perform the Diagnosis Procedur e corresponding to the detected DTC.
NO >> GO TO 2.
2.CHECK OVERALL FUNCTION
WITH CONSULT-III
1. Turn ignition switch ON.
2. Select “BRAKE SW1” in “DATA MONITOR” mode with CONSULT-III.
3. Check “BRAKE SW1” indication under the following conditions.
WITHOUT CONSULT-III
1. Turn ignition switch ON.
2. Check the voltage between ECM harness connector terminals under the following conditions.
Monitor item Condition Indication
BRAKE SW1
(ICC brake switch) Brake pedalSlightly depressed OFF
Fully released ON
ECM
Condition Voltage
Connector +–
Terminal Terminal
E80 147
(ICC brake switch signal) 175 Brake pedalSlightly depressed Approx. 0 V
Fully released Battery voltage
Monitor item Condition Indication
BRAKE SW1
(ICC brake switch) Brake pedalSlightly depressed OFF
Fully released ON
Revision: 2010 May2011 QX56

EC-504
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
ICC BRAKE SWITCH
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 3.
3.CHECK ICC BRAKE SWITCH POWER SUPPLY CIRCUIT-I
1. Turn ignition switch OFF.
2. Disconnect ICC brake switch harness connector.
3. Turn ignition switch ON.
4. Check the voltage between ICC brake switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 4.
4.CHECK ICC BRAKE SWITCH POWER SUPPLY CIRCUIT-II
Check the voltage between ICC brake switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 5.
5.DETECT MALFUNCTIONING PART
Check the following.
 Fuse block (J/B) connector E103
 10 A fuse (No. 3)
 Harness for open or short between ICC brake switch and fuse
>> Repair open circuit or short to ground in harness or connectors.
6.CHECK ICC BRAKE SWITCH
Refer to EC-445, "
Component Inspection (ICC Brake Switch)".
Is the inspection result normal?
YES >> GO TO 9.
NO >> Replace ICC brake switch. Refer to BR-20, "
Removal and Installation".
7.CHECK ICC BRAKE SWITCH INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between ICC brake s witch harness connector and ECM harness connector.
ECM
Condition Voltage (V)
Connector +–
Te r m i n a l Te r m i n a l
E80 147
(ICC brake switch signal) 175 Brake pedalSlightly depressed Approx. 0
Fully released Battery voltage
ICC brake switch
Ground Voltage
Connector Terminal
E68 2 Ground Battery voltage
ICC brake switch Ground Voltage
Connector Terminal
E68 1 Ground Battery voltage
Revision: 2010 May2011 QX56

EC-506
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
IGNITION SIGNAL
IGNITION SIGNAL
Component Function CheckINFOID:0000000006218011
1.INSPECTION START
Turn ignition switch OFF, and restart engine.
Does the engine start?
YES-1 >> With CONSULT-III: GO TO 2.
YES-2 >> Without CONSULT-III: GO TO 3.
NO >> Go to EC-506, "
Diagnosis Procedure".
2.CHECK IGNITION SIGNAL FUNCTION
WITH CONSULT-III
1. Perform “POWER BALANCE” in “A CTIVE TEST” mode with CONSULT-III.
2. Check that each circuit produces a momentary engine speed drop.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-506, "
Diagnosis Procedure".
3.CHECK IGNITION SIGNAL FUNCTION
WITHOUT CONSULT-III
1. Let engine idle.
2. Read the voltage signal between ECM harness connector terminals under the following conditions with an oscilloscope.
NOTE:
The pulse cycle changes depending on rpm at idle.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-506, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006218012
1.CHECK IGNITION COIL POWER SUPPLY CIRCUIT-I
1. Turn ignition switch OFF, wait at least 10 seconds and then turn it ON.
2. Check the voltage between ECM harness connector terminals under the following conditions.
ECM
Voltage signal
Cylinder +–
Connector Terminal Connector Terminal
1
F 111 12
E80 175
213
314
415
517
618
719
820
PBIB0044E
Revision: 2010 May2011 QX56
