2011 INFINITI QX56 differential

DLN-174
< UNIT DISASSEMBLY AND ASSEMBLY >[FRONT FINAL DRIVE: R180A]
DIFFERENTIAL ASSEMBLY
 If the tooth contact is near the flank (flank contact), or near the
toe (toe contact), use a thinner drive pinion height adjusting
washer to move the drive pinion farther from the drive gear.
For selecting adjusting washer, refer to the latest parts infor-
mation.
BACKLASH
1. Remove carrier cover. Refer to DLN-168, "Disassembly".
2. Fit a dial indicator to the drive gear face to measure the back- lash.
 If the backlash is outside of the specification, change the thick-
ness of the side bearing adjusting washers.
CAUTION:
Never change the total amount of wash ers as it changes the preload torque.
InspectionINFOID:0000000006222395
INSPECTION AFTER DISASSEMBLY
Drive Gear and Drive Pinion
 Clean up the disassembled parts.
 If the gear teeth never mesh or line-up correctly, det ermine the cause and adjust or replace as necessary.
 If the gears are worn, cracked, damaged, pitted or ch ipped (by friction) noticeably, replace with new drive
gear and drive pinion as a set.
Bearing
 Clean up the disassembled parts.
 If any chipped (by friction), pitted, worn, rusted or scratched marks, or unusual noise from the bearing is
observed, replace as a bearing assembly (as a new set).
Side Gear and Pinion Mate Gear
 Clean up the disassembled parts.
 If any cracks or damage on the surfac e of the tooth is found, replace.
 If any worn or chipped mark on the contact si des of the thrust washer is found, replace.
Side Gear Thrust Washer and Pinion Mate Thrust Washer
 Clean up the disassembled parts.
 If it is chipped (by friction), damaged, or unusually worn, replace.
Oil Seal
PDIA0441E
Backlash : Refer to DLN-185, "Back-
lash".
When the backlash is large: Make drive gear back side adjusting washer thicker,
and drive tooth side adjust ing washer thinner by the
same amount. For selecting adjusting washer, refer to
the latest parts information.
If the backlash is less than specification: Make drive gear back side ad justing washer thinner,
and drive tooth side adjust ing washer thicker by the
same amount. For selecting adjusting washer, refer to
the latest parts information.
SPD513
Revision: 2010 May2011 QX56

DIFFERENTIAL ASSEMBLYDLN-175
< UNIT DISASSEMBLY AND ASSEMBLY > [FRONT FINAL DRIVE: R180A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
 Whenever disassembled, replace.
 If wear, deterioration of adherence (sealing force lips ), or damage is detected on the lips, replace them.
Differential Case
 Clean up the disassembled parts.
 If any wear or crack on the contact sides of the differential case is found, replace.
Revision: 2010 May2011 QX56

DLN-176
< UNIT DISASSEMBLY AND ASSEMBLY >[FRONT FINAL DRIVE: R180A]
DRIVE PINION
DRIVE PINION
Exploded ViewINFOID:0000000006222396
1. Bushing 2. Bearing cap 3. Side bearing
4. Side bearing adjusting washer 5. Drive pinion 6. Pinion height adjusting washer
7. Pinion rear bearing 8. Collapsible spacer 9. Gasket
10. Drain plug 11. Side oil seal (left side) 12. Pinion front bearing
13. Front oil seal 14. Companion flange 15. Drive pinion lock nut
16. Gear carrier 17. Side shaft 18. Side shaft bearing
19. Snap ring 20. Snap ring 21. Side oil seal (right side)
22. Drive gear 23. Differential case assembly 24. Housing spacer
25. Filler plug 26. Carrier cover
A: Oil seal lip B: Screw hole C. Comply with the assembly proce-
dure when tightening. Refer to DLN-
169, "Assembly".
: Apply gear oil. : Apply anti-corrosion oil.
: Apply multi-purpose grease.
JPDID0390GB
Revision: 2010 May2011 QX56

DRIVE PINIONDLN-177
< UNIT DISASSEMBLY AND ASSEMBLY > [FRONT FINAL DRIVE: R180A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
DisassemblyINFOID:0000000006222397
1. Remove the side shaft. Refer to DLN-165, "Disassembly".
2. Remove the differential assembly. Refer to DLN-168, "
Disassembly".
3. Remove the drive pinion lock nut with a flange wrench (commer- cial service tool).
4. Put matching mark (B) on the end of drive pinion. The matching mark should be in line with the matching mark (A) on companion
flange (1).
CAUTION:
For matching, marks use paint. Never damage companion
flange and drive pinion.
5. Remove the companion flange with the puller (commercial ser- vice tool).
6. Press the drive pinion assembly. CAUTION:
Never drop drive pinion assembly.
: Apply Genuine Silicone RTV or equivalent. Refer to GI-22, "Recommended Chemical Products and Sealants".
: Apply Genuine High Strength Thread Locking Sealant or equivalent. Refer to GI-22, "
Recommended Chemical Products
and Sealants".
Refer to GI-4, "
Components" for symbols not described above.
PDIA0702E
PDIA0799J
PDIA0703E
PDIA0704E
Revision: 2010 May2011 QX56

DLN-180
< UNIT DISASSEMBLY AND ASSEMBLY >[FRONT FINAL DRIVE: R180A]
DRIVE PINION
7. Using drift [SST: ST33200000 (J-26082)], press the pinion front
bearing inner race to drive pinion as far as drive pinion nut can
be tightened.
8. Install front oil seal as shown in figure with the drifts (A and B). CAUTION:
 Never reuse oil seal.
 When installing, n ever incline oil seal.
 Apply multi-purpose grease onto oil seal lips, and gear oil
onto the circumference of oil seal.
9. Install companion flange (1). NOTE:
When reusing drive pinion, align the matching mark (B) of drive
pinion with the matching mark (A) of companion flange, and then
install companion flange (1).
10. Temporarily tighten drive pinion lock nut to drive pinion. CAUTION:
 Apply anti-corrosion oil to th e thread and seat of the drive
pinion lock nut
 Never reuse drive pinion lock nut.
11. Tighten to drive pinion lock nut using flange wrench (A), while adjusting pinion bearing preload torque using preload gauge (B).
CAUTION:
 Adjust to the lower limit of the drive pinion lock nut tight-
ening torque first.
 After adjustment, rotate dri ve pinion back and forth 2 to 3
times to check for unusual no ise, rotation malfunction,
and other malfunctions.
12. Install differential case assembly. Refer to DLN-169, "
Assem-
bly".
CAUTION:
PDIA0709E
A: Drift [SST: ST30720000 (J-25405)]
B: Drift [SST: ST27863000 ( — )]
PDIA0717E
PDIA0799J
A: Flange wrench (commercial service tool)
B: Preload gauge [SST: ST3127S000 (J-25765-A)]
Pinion bearing preload : Refer to DLN-185, "Pre-
load Torque".
WDIA0382E
Revision: 2010 May2011 QX56

DRIVE PINIONDLN-181
< UNIT DISASSEMBLY AND ASSEMBLY > [FRONT FINAL DRIVE: R180A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
Never install carrier cover yet.
13. Check and adjust drive gear runout, tooth contact, drive gear to drive pinion backlash. Refer to DLN-171,
"Adjustment".
14. Install side shaft. Refer to DLN-166, "
Assembly".
15. Check and adjust companion flange runout. Refer to DLN-181, "
Adjustment".
16. Check total preload torque. Refer to DLN-171, "
Adjustment".
17. Install carrier cover. Refer to DLN-169, "
Assembly".
AdjustmentINFOID:0000000006222399
PINION GEAR HEIGHT
1. Make sure all parts are clean and that the bearings are well
lubricated.
2. Assemble the pinion gear beari ngs into the differential shim
selector tool [SST: — (J-34309)].
 Pinion front bearing; make sure the J-34309-3 pinion front
bearing seat is secured tightly against the J-34309-2 gauge
anvil. Then turn the pinion front bearing pilot, J-34309-7, to
secure the bearing in its proper position.
 Pinion rear bearing; the pinion rear bearing pilot, J-34309-8,
is used to center the pinion rear bearing only. The pinion rear
bearing locking seat, J-34309-4, is used to lock the bearing to
the assembly.
 Installation of J-34309-9 and J-34309-16; place a suitable
2.5 mm (0.098 in) thick plain washer between J-34309-9 and
J-34309-16. Both surfaces of J-34309-9 and J-34309-16 must
be parallel with a clearance of 2.5 mm (0.098 in).
3. Install the pinion rear bearing inner race into gear carrier. Then place the pinion preload shim selector tool, J-34309-1, gauge
screw assembly.
4. Assemble the pinion front bearing inner race and the J-34309-2 gauge anvil. Assemble them together with the J-34309-1 gauge
screw in gear carrier. Make sure that the pinion height gauge
plate, J-34309-16, turns a full 360 degrees. Tighten the two sec-
tions together by hand.
SPD769
SPD197A
SPD893
SPD199A
Revision: 2010 May2011 QX56

DRIVE PINIONDLN-183
< UNIT DISASSEMBLY AND ASSEMBLY > [FRONT FINAL DRIVE: R180A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
10. Write down exact measurement (the value of feeler gauge).
11. Correct the pinion height washer size by referring to the “pinion head number”.
There are two numbers painted on the drive pinion. The first
one refers to the drive pinion and drive gear as a matched
set. This number should be the same as the number on the
drive gear. The second number is the “pinion head height
number”. It refers to the ideal pinion height from standard
for quietest operation. Use th e following chart to determine
the correct pinion height washer.
12. Select the correct pinion height adjusting washer. For selecting adjusting washer, refer to the latest parts information.
13. Remove the J-34309 differential shim selector tool from the final drive housing. Then disassemble to retrieve the pinion bearings.
COMPANION FLANGE RUNOUT
SPD775
Pinion head height number Add or remove from the standard pinion height ad-
justing washer thickness measurement
− 6
− 5
− 4
− 3
− 2
− 1
0
+1
+2
+3
+4
+5
+6 Add 0.06 mm (0.0024 in)
Add 0.05 mm (0.0020 in)
Add 0.04 mm (0.0016 in)
Add 0.03 mm (0.0012 in)
Add 0.02 mm (0.0008 in)
Add 0.01 mm (0.0004 in)
Use the selected washer thickness
Subtract 0.01 mm (0.0004 in)
Subtract 0.02 mm (0.0008 in)
Subtract 0.03 mm (0.0012 in)
Subtract 0.04 mm (0.0016 in)
Subtract 0.05 mm (0.0020 in)
Subtract 0.06 mm (0.0024 in)SPD542
SPD205A
Revision: 2010 May2011 QX56

DLN-190
< PREPARATION >[REAR FINAL DRIVE: R230]
PREPARATION
Tool name
Description
Flange wrench Removing and installing drive pinion lock nut
Puller Removing companion flange
Sliding hammer Removing differential case assembly
Puller Removing drive pinion rear bearing inner race
Spacer
a: 60 mm (2.36 in) dia.
b: 36 mm (1.42 in) dia.
c: 30 mm (1.18 in) Installing drive pinion front bearing inner race
Power tool Loosing nuts and bolts
NT035
ZZA0119D
NT125
ZZA0700D
ZZA1133D
PBIC0190E
