DAS
DIAGNOSIS SYSTEM (ADAS CONTROL UNIT)
DAS-299
< SYSTEM DESCRIPTION > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
Active Pedal
CAUTION:
 Shift the selector lever to “P” po
sition, and then perform the test.
 Never depress the accelerator pedal excessively. (T he engine speed may rise unexpectedly when
finishing the test.)
NOTE:
 Depress the accelerator pedal to check when performing the test.
 The test can be performed only when the engine is running.
NOTE:
The test is finished in 10 seconds after starting
DCA INDICATOR
NOTE:
The test can be performed only when the engine is running.
LDP BUZZER
WARNING SYSTEM IND
Test item Operation Description Accelerator pedal operation
Active Pedal MODE1
Transmit the accelerator pedal feedback force control signal
to the accelerator pedal actuator via ITS communication. Constant with a force of 25 N
for 8 seconds
MODE2 Constant with a force of 15 N
for 8 seconds
MODE3 Change up to a force of 25 N for
8 seconds
MODE4 Change up to a force of 15 N for
8 seconds
Test start Starts the tests of “MODE1”, “MODE2”, “MODE3” and
“MODE4” —
Reset Stops transmitting the accelerator pedal feedback force
control signal below to end the test.
—
End Returns to the “SELECT TEST ITEM” screen —
JPOIA0061GB
Te s t i t e m Opera-
tion Description DCA system switch indicator
DCA INDICATOR Off
Stops transmitting the DCA system switch indicator signal be-
low to end the test
—
On Transmits the DCA system switch indicator signal to the com-
bination meter via CAN communication ON
Te s t i t e m
Opera-
tion Description Warning buzzer
LDP BUZZER Off
Stops transmitting the warning buzzer signal below to end the
test
—
On Transmits the warning buzzer signal to the warning buzzer ON
Revision: 2010 May2011 QX56

DAS
DIAGNOSIS SYSTEM (LANE CAMERA UNIT)DAS-301
< SYSTEM DESCRIPTION > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
DIAGNOSIS SYSTEM (LANE CAMERA UNIT)
CONSULT-III Function (LANE CAMERA)INFOID:0000000006223717
APPLICATION ITEMS
CONSULT-III performs the following functions by communicating with the lane camera unit.
WORK SUPPORT
SELF DIAGNOSTIC RESULT
Refer to DAS-316, "DTC Index".
DATA MONITOR
Diagnosis mode Description
Work Support Performs the camera aiming
Self Diagnostic Result Displays the name of a malfunctioning system stored in the lane camera unit
Data Monitor Displays lane camera unit input/output data in real time
Ecu Identification Displays lane camera unit part number
CAN Diag Support Monitor Displays a reception/transmission state of ITS communication
Work support items Description
AUTO AIM Outputs camera unit, calculates dislocation of the camera, and displays adjustment direction.
AIM CHECK NOTE:
The item is indicated, but not used
Monitored item
[Unit] Description
LC INACCURAT [On/Off] La ne camera unit status
AIMING DONE [OK/NG] Status that camera aiming is done
AIMING RESULT [OK/NOK] Re sult of camera aiming
CAM HIGH TEMP [NORMAL/
High] Status of lane camera unit high temperature judgment
VHCL SPD SE [km/h] or
[mph] Vehicle speed received from ADAS control unit via ITS communication
TURN SIGNAL [Off, LH, RH,
LH/RH] Status of “Turn signal” determined from ADAS control unit via ITS communication
LANE DETCT LH [On/Off] Left side lane marker detection
LANE DETCT RH [On/Off] Right side lane marker detection
CROSS LANE LH [On/Off] Condition that the vehicle is crossing left lane marker
CROSS LANE RH [On/Off] Condition that the vehicle is crossing right lane marker
WARN LANE LH [On/Off] Warning for left lane marker
WARN LANE RH [On/Off] Warning for right lane marker
VALID POS LH [VLD/INVLD] Lateral position for left lane marker is valid
VALID POS RH [VLD/INVLD] Lateral position for right lane marker is valid
XOFFSET [pixel] Lane camera unit installation condition
AIM CHECK YAW [deg] Check result of camera aiming
AIM CHECK ROLL [deg] Check result of camera aiming
AIM CHECK PITCH [deg] Check result of camera aiming
FCTRY AIM YAW [deg] Lane camera unit installation condition
FCTRY AIM ROL [deg] Lane camera unit installation condition
Revision: 2010 May2011 QX56

DAS-304
< ECU DIAGNOSIS INFORMATION >[LDW & LDP]
ADAS CONTROL UNIT
VHCL SPEED SE While driving Displays the ve-
hicle speed cal-
culated by
ADAS control unit
SET VHCL SPD While driving When vehicle speed is set Displays the set
vehicle speed
BUZZER O/P Engine running When the buzzer of the following system operates
 Vehicle-to-vehicle distance control mode
 DCA system
 FCW system
 IBA system
On
When the buzzer of the following system not operates
 Vehicle-to-vehicle distance control mode
 DCA system
 FCW system
 IBA system Off
THRTL SENSOR NOTE:
The item is indicated, but not monitored
0.0
ENGINE RPM Engine running Equivalent to ta-
chometer read- ing
WIPER SW Ignition switch ON Wiper not operating Off
Wiper LO operation Low
Wiper HI operation High
YAW R AT E NOTE:
The item is indicated, but not monitored
0.0
BA WARNING Engine running IBA OFF indicator lamp ON
 When IBA system is malfunctioning
 When IBA system is turned to OFF
On
IBA OFF indicator lamp OFF
 When IBA system is normal
 When IBA system is turned to ON Off
STP LMP DRIVE Drive the vehicle and activate
the vehicle-to-vehicle distance
control mode When ICC brake hold relay is activated On
When ICC brake hold relay is not activated Off
D RANGE SW Engine running When the selector lever is in “D” position or manual
mode
On
When the selector lever is in any position other than “D”
or manual mode Off
NP RANGE SW Engine running When the selector lever is
in “N”, “P” position On
When the selector lever is in any position other than “N”,
“P” Off
PKB SW Ignition switch ON When the parking brake is applied On
When the parking brake is released Off
PWR SUP MONI Engine running Power supply
voltage value of ADAS control unit
VHCL SPD AT While driving Va l u e o f A / T v e -
hicle speed sen- sor signal
THRTL OPENING Engine running Depress accelerator pedal Displays the
throttle position
Monitor item Condition Value/Status
Revision: 2010 May2011 QX56

DAS-306
< ECU DIAGNOSIS INFORMATION >[LDW & LDP]
ADAS CONTROL UNIT
LDP ON INDStart the engine and press dy-
namic driver assistance switch
(When LDP system setting is
ON) LDP ON indicator lamp ON On
LDP ON indicator lamp OFF Off
LANE DPRT W/L Drive the vehicle and activate
the LDW system or LDP sys-
tem Lane departure warning lamp ON On
Lane departure warning lamp OFF Off
LDW BUZER OUT-
PUT Drive the vehicle and activate
the LDW/LDP system or BSW
system When the buzzer of the following system operates
 LDW/LDP system
 BSW system
On
When the buzzer of the following system does not oper-
ate
 LDW/LDP system
 BSW system Off
LDP SYSTEM ON Start the engine and press dy-
namic driver assistance switch
(When LDP system setting is
ON) When the LDP system is ON On
When the LDP system is OFF Off
READY signal Start the engine and press dy-
namic driver assistance switch
(When LDP system setting is
ON) When the LDP system is ON On
When the LDP system is OFF Off
Camera lost Drive the vehicle and activate
the LDW system, LDP system Both side lane markers are detected Detect
Deviate side lane marker is lost Deviate
Both side lane markers are lost Both
Shift position  Engine running
 While driving Displays the
shift position
Turn signal Turn signal lamps OFF
Off
Turn signal lamp LH blinking LH
Turn signal lamp RH blinking RH
Turn signal lamp LH and RH blinking LH&RH
SIDE G While driving Vehicle turning right Negative value
Vehicle turning left Positive value
WARN REQ Drive the vehicle and activate
the LDP system Lane departure warning is operating On
Lane departure warning is not operating Off
STATUS signal Drive the vehicle and activate
the LDP system When the LDP system is ON Stnby
When the LDP system is operating Warn
When the LDP system is canceled Cancl
When the LDP system is OFF Off
Lane unclear While driving Lane marker is unclear On
Lane marker is clear Off
FUNC ITEM Ignition switch ON FUNC1
FUNC ITEM (NV-ICC) Ignition switch ON Off
FUNC ITEM (NV-
DCA) Ignition switch ON
Off
DCA SELECT Ignition switch ON “Distance Control Assist” set with the navigation system
is ON
On
“Distance Control Assist” set with the navigation system
is OFF Off
Monitor item Condition Value/Status
Revision: 2010 May2011 QX56

DAS-308
< ECU DIAGNOSIS INFORMATION >[LDW & LDP]
ADAS CONTROL UNIT
Fail-safe
INFOID:0000000006223719
If a malfunction occurs in each system, ADAS contro l unit cancels each control, sounds a beep, and turns ON
the warning lamp or indicator lamp.
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
+ − Signal name Input/
Output
1
(V/W)
Ground Warning systems
switch
InputIgnition
switch ON When warning systems
switch is not pressed
12 V
When warning systems
switch is pressed 0 V
3
(R/Y) IBA OFF switch Input Ignition
switch
ON When IBA OFF switch is
not pressed
12 V
When IBA OFF switch is
pressed 0 V
4
(LG/B) Warning systems ON
indicator
OutputIgnition
switch ON Warning systems ON indi-
cator ON
0 V
Warning systems ON indi-
cator OFF 12 V
5
(R) ICC brake hold relay
drive signal
OutputIgnition
switch ON —12 V
At “STOP LAMP” test of
“Active test” 0 V
6
(B) Ground — Ignition
switch ON —0 V
7
(L) ITS communication-H — — — —
8
(Y) ITS communication-L — — — —
12
(G/R) Warning buzzer signal Output Ignition
switch ON Warning buzzer operation 0 V
Warning buzzer not oper-
ating
12 V
14
(L) CAN -H — — — —
15
(P) CAN -L — — — —
16
(W/G) Ignition power supply Input Ignition switch ON Battery Voltage
System Buzzer Warning lamp/Indicator lamp Description
Vehicle-to-vehicle distance control mode High-pitched
toneICC system warn
ing lamp Cancel
Conventional (fixed speed) cruise control mode High-pitched
tone
ICC system warn
ing lamp Cancel
Intelligent Brake Assist (IBA) High-pitched
toneIBA OFF indicator lamp Cancel
Forward Collision Warning (FCW) High-pitched
toneIBA OFF indicator lamp Cancel
Distance Control Assist (DCA) High-pitched
tone
ICC system warn
ing lamp Cancel
Lane Departure Warning (LDW) — Lane departure warning lamp Cancel
Revision: 2010 May2011 QX56

DAS-314
< ECU DIAGNOSIS INFORMATION >[LDW & LDP]
LANE CAMERA UNIT
LANE CAMERA UNIT
Reference ValueINFOID:0000000006223722
VALUES ON THE DIAGNOSIS TOOL
Monitor Item Condition Value/Status
LC INACCURAT Lane camera unit malfunction On
Lane camera unit normal Off
AIMING DONE Camera aiming is completed OK
Camera aiming is not adjusted NG
AIMING RESULT Camera aiming is completed OK
Camera aiming is not completed NOK
CAM HIGH TEMP When the temperature around lane camera unit is adequate NORMAL
When the temperature around the lane camera unit is high High
VHCL SPD SE While driving Approximately equivalent to speed-
ometer reading
TURN SIGNAL Turn signal lamp LH and RH blinking LH/RH
Turn signal lamp LH blinking LH
Turn signal lamp RH blinking RH
Turn signal lamps OFF Off
LANE DETCT LH Left side lane marker is detected On
Left side lane marker is not detected Off
LANE DETCT RH Right side lane marker is detected On
Right side lane marker is not detected Off
CROSS LANE LH The vehicle is crossing left side lane marker On
The vehicle is not crossing left side lane marker Off
CROSS LANE RH The vehicle is crossing right side lane marker On
The vehicle is not crossing right side lane marker Off
WARN LANE LH Warning for left side lane On
Not warning for left side lane Off
WARN LANE RH Warning for right side lane On
Not warning for right side lane Off
VALID POS LH Lateral position for left side lane marker is valid VLD
Lateral position for left side lane marker is invalid INVLD
VALID POS RH Lateral position for right side lane marker is valid VLD
Lateral position for right side lane marker is invalid INVLD
XOFFSET Camera aiming is completed Approx. 180 pixel
AIM CHECK YAW NOTE:
The item is indicated, but not used
—
AIM CHECK ROLL NOTE:
The item is indicated, but not used —
AIM CHECK PITCH NOTE:
The item is indicated, but not used —
FCTRY AIM YAW Camera aiming is not completed 0.0 deg
Camera aiming is completed 0
± 5.0 deg
Revision: 2010 May2011 QX56

DAS
LANE CAMERA UNITDAS-315
< ECU DIAGNOSIS INFORMATION > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
TERMINAL LAYOUT
PHYSICAL VALUES
Fail-safeINFOID:0000000006223723
FAIL-SAFE CONTROL BY DTC
Lane Departure Warning (LDW)
If a malfunction occurs in the lane camera unit, AD AS control unit cancels control, and turns ON the lane
departure warning lamp in the combination meter.
Lane Departure Prevention (LDP)
If a malfunction occurs in the lane camera unit, ADAS control unit cancels control, sounds a beep, and turns
ON the lane departure warning lamp in the combination meter.
TEMPORARY DISABLED STATUS AT HIGH TEMPERATURE
Lane Departure Warning (LDW)
 If the vehicle is parked in direct sunlight under high temperature conditions, the system may be deactivated
automatically. And the lane departure warning lamp (yellow) in the combination meter will blinks.
 When interior temperature is reduced, the system wil l resume operation automatically and the lane depar-
ture warning lamp (yellow) in the combination meter will stop blinking.
Lane Departure Prevention (LDP)
FCTRY AIM ROL Camera aiming is not completed 0.0 deg
Camera aiming is completed 0
± 5.0 deg
FCTRY AIM PIT Camera aiming is not completed 0.0 deg
Camera aiming is completed 0
± 5.0 deg
ADAS MALF ADAS control unit malfunction On
ADAS control unit normal Off
Monitor Item Condition Value/Status
JSOIA0232ZZ
Te r m i n a l N o .
(Wire color) Description
ConditionVa l u e
(Approx.)
+ – Signal name Input/
Output
1
(B)
Ground Ground — — 0 V
4
(L) ITS communication-H — — —
5
(B) Ground — — 0 V
7
(W/G) Ignition power supply Input Ignition switch Battery voltage
8
(Y) ITS communication-L — — —
Revision: 2010 May2011 QX56

DAS-336
< BASIC INSPECTION >[LDW & LDP]
ACTION TEST
ACTION TEST
DescriptionINFOID:0000000006223730
 Perform action test to verify the customer's concern.
 Perform action test and check the syst
em operation after system diagnosis.
WARNING:
Be careful of traffic conditions and safety ar ound the vehicle when performing road test.
CAUTION:
 Fully understand the following it ems well before the road test;
- Precautions: Refer to DAS-273, "
Precaution for LDW/LDP System Service".
- System description for LDW: Refer to DAS-277, "
LANE DEPARTURE WARNING (LDW) SYSTEM :
System Description".
- System description for LDP: Refer to DAS-280, "
LANE DEPARTURE PREVENTION (LDP) SYSTEM :
System Description".
- Handling precaution: Refer to DAS-288, "
Precautions for Lane Departure Warning/Lane Departure
Prevention".
Inspection ProcedureINFOID:0000000006223731
WARNING:
Be careful of traffic conditions and safety ar ound the vehicle when performing road test.
CAUTION:
 Fully understand the following it ems well before the road test;
- Precautions: Refer to DAS-273, "
Precaution for LDW/LDP System Service".
- System description for LDW: Refer to DAS-277, "
LANE DEPARTURE WARNING (LDW) SYSTEM :
System Description".
- System description for LDP: Refer to DAS-280, "
LANE DEPARTURE PREVENTION (LDP) SYSTEM :
System Description".
- Handling precaution: Refer to DAS-288, "
Precautions for Lane Departure Warning/Lane Departure
Prevention".
1.ACTION TEST FOR LDW
1. Drive the vehicle.
2. Turn warning systems switch ON (w arning systems ON indicator is ON).
NOTE:
LDP system is OFF.
3. Check the LDW operation according to the following table.
NOTE:
Vehicle condition/ Driver's operation Action Warning sys-
tems ON indi- cator Indication on the combination
meter Buzzer
Less than
Approx. 60 km/h (40 MPH) Close to lane marker No action ON OFF —
Approx. 70 km/h (45 MPH) or more Close to lane marker
Warning
 Buzzer sounds
 Warning lamp
blinks ON
Short contin-
uous beeps
 Close to lane marker
 Turn signal ON (Deviate side) No action ON OFF —
JPOIA0018GB
Revision: 2010 May2011 QX56
