2011 INFINITI QX56 air conditioning

HAC-46
< ECU DIAGNOSIS INFORMATION >[AUTOMATIC AIR CONDITIONING]
A/C AUTO AMP.
*1: With ACCS (advanced climate control system)
*2: Perform self-diagnosis under sunshine. When performi
ng indoors, aim a light (more than 60 W) at sunload
sensor, otherwise self-diagnosis indicates even though the sunload sensor is functioning normally.
NOTE:
If all of door motor DTCs (B2632, B2633, B2634, B2635, B2636, B2637, B2638, B2639, B263D, B263E,
B263F, B2654, B2655, B2661, B2662, B2663, B2664, B 2665, B2666, B2669, and B266A) are detected, check
door motor communication circuit. Refer to HAC-120, "
Diagnosis Procedure".
B262A*1GAS SENSOR HAC-83, "DTC Logic"
B262B*1GAS SENSORHAC-83, "DTC Logic"
B2630*2SUNLOAD SENSORHAC-86, "DTC Logic"
B2631*2SUNLOAD SENSORHAC-86, "DTC Logic"
B2632 DR AIRMIX DOOR MOT HAC-89, "DTC Logic"
B2633 DR AIRMIX DOOR MOTHAC-89, "DTC Logic"
B2634 PASS AIR MIX DOOR MOTHAC-91, "DTC Logic"
B2635 PASS AIR MIX DOOR MOTHAC-91, "DTC Logic"
B2636 DR VENT DOOR FAILHAC-93, "DTC Logic"
B2637 DR B/L DOOR FAILHAC-93, "DTC Logic"
B2638 DR D/F1 DOOR FAILHAC-93, "DTC Logic"
B2639 DR DEF DOOR FAILHAC-93, "DTC Logic"
B263D FRE DOOR FAIL HAC-95, "DTC Logic"
B263E 20P FRE DOOR FAILHAC-95, "DTC Logic"
B263F REC DOOR FAILHAC-95, "DTC Logic"
B2654 D/F2 DOOR FAILHAC-93, "DTC Logic"
B2655 B/L2 DOOR FAILHAC-93, "DTC Logic"
B2657*1GAS SENSOR CIRCUITHAC-83, "DTC Logic"
B2658*1GAS SENSOR CIRCUITHAC-83, "DTC Logic"
B2661 UPPER VENT DOOR MOT HAC-97, "DTC Logic"
B2662 UPPER VENT DOOR MOTHAC-97, "DTC Logic"
B2663 UPPER VENT DOOR MOTHAC-97, "DTC Logic"
B2664 REAR AIR MIX DOOR MOTHAC-99, "DTC Logic"
B2665 REAR AIR MIX DOOR MOTHAC-99, "DTC Logic"
B2666 REAR MODE DOOR MOTHAC-101, "DTC Logic"
B2667*2PASS SUNLOAD SENSORHAC-103, "DTC Logic"
B2668*2PASS SUNLOAD SENSORHAC-103, "DTC Logic"
B2669 REAR MODE DOOR MOT HAC-101, "DTC Logic"
B266A REAR MODE DOOR MOT HAC-101, "DTC Logic"
B266B REAR IN-VEHICLE SENHAC-106, "DTC Logic"
B266C REAR IN-VEHICLE SEN HAC-106, "DTC Logic"
B27B0 A/C AUTO AMP.HAC-109, "DTC Logic"
DTCItems
(CONSULT-III screen terms) Reference
Revision: 2010 May2011 QX56

ECM, IPDM E/RHAC-47
< ECU DIAGNOSIS INFORMATION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
ECM, IPDM E/R
List of ECU ReferenceINFOID:0000000006275889
ECU Reference
ECM EC-72, "
Reference Value"
EC-93, "Fail-safe"
EC-96, "DTC Inspection Priority Chart"
EC-98, "DTC Index"
IPDM E/R
PCS-15, "
Reference Value"
PCS-21, "Fail-Safe"
PCS-22, "DTCIndex"
Revision: 2010 May2011 QX56

HAC-48
< WIRING DIAGRAM >[AUTOMATIC AIR CONDITIONING]
AUTOMATIC AIR CONDITIONING SYSTEM
WIRING DIAGRAM
AUTOMATIC AIR CO
NDITIONING SYSTEM
Wiring DiagramINFOID:0000000006275890
JCIWM0795GB
Revision: 2010 May2011 QX56

AUTOMATIC AIR CONDITIONING SYSTEMHAC-49
< WIRING DIAGRAM > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
JCIWM0796GB
Revision: 2010 May2011 QX56

HAC-50
< WIRING DIAGRAM >[AUTOMATIC AIR CONDITIONING]
AUTOMATIC AIR CONDITIONING SYSTEM
JCIWM0797GB
Revision: 2010 May2011 QX56

AUTOMATIC AIR CONDITIONING SYSTEMHAC-51
< WIRING DIAGRAM > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
JCIWM0798GB
Revision: 2010 May2011 QX56

HAC-52
< WIRING DIAGRAM >[AUTOMATIC AIR CONDITIONING]
AUTOMATIC AIR CONDITIONING SYSTEM
JCIWM0799GB
Revision: 2010 May2011 QX56

AUTOMATIC AIR CONDITIONING SYSTEMHAC-53
< WIRING DIAGRAM > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
JCIWM0800GB
Revision: 2010 May2011 QX56
