2011 HONDA RIDGELINE fuse

´
Ref er to the above illustrations f or
wiring information.The trailer jumper harness is used to
install the controller f or the electric
trailer brakes. For more inf ormation,
see on page .Insert the trailer brake f use into the
secondary under-hood f use box (see
page ).
298 381
Except RT models Except RT models
T railer Connect or Socket s T railer Jumper Harness
Trailer BrakesT railer Brake Fuse
Towing a Trailer
302
7-PIN TRAILER SOCKET
SMALL
LIGHT
(GREEN)
BACK LIGHT
(YELLOW)
GROUND
(WHITE) GROUND
(BLACK)
ELECTRIC BRAKE
(BROWN/WHITE)
LEFT
TURN/
STOP
(RED) BRAKE
(20A)
(BLUE)
B
CHARGE
(BLACK)
RIGHT
TURN/
STOP
(BROWN)
ELECTRIC
BRAKE
(BLUE) BRAKE LIGHTS
(SKY BLUE)
Main MenuTable of Contents

This section covers the more
common problems that motorists
experience with their vehicles. It
gives you inf ormation about how to
safely evaluate the problem and what
to do to correct it. If the problem has
stranded you on the side of the road,
you may be able to get going again.
If not, you will also f ind instructions
on getting your vehicle towed.......................
Compact Spare Tire . 360
....................
Changing a Flat Tire . 361
.............
If the Engine Won’t Start . 369
................................
Jump Starting . 370
..............
If the Engine Overheats . 372
.........
Low Oil Pressure Indicator . 374
..........
Charging System Indicator . 374
.......
Malf unction Indicator Lamp . 375
...............
Brake System Indicator . 376
..............................................
Fuses . 378
..............................
Fuse Locations . 381
......................
Emergency Towing . 383
..........
If Your Vehicle Gets Stuck . 383
Taking Care of the Unexpected
T aking Care of t he Unexpect ed
359
Main Menu

The vehicle’s f uses are contained in
threefuseboxes.The primary under-hood f use box is
on the passenger’s side. The
secondary f use box is next to the
brake f luid reservoir. To open them,
pushthetabsasshown.
The interior f use box is on the
driver’s lower lef t side. To remove
the f use box lid, put your f inger in
the notch on the lid, and pull it
outward slightly, then pull it toward
you and take it out of its hinges. If something electrical in your
vehicle stops working, check f or a
blown f use f irst. Determine f rom the
chart on pages and , or the
diagram on the f use box lid, which
f use or f uses control that device.
Check those f uses f irst, but check all
the f uses bef ore deciding that a
blown f use is the cause. Replace any
blown f uses, and check if the device
works.
381 382
Checking and Replacing Fuses
Fuses
378
UNDER-HOOD (SECONDARY)
UNDER-HOOD (PRIMARY)
INTERIOR
NOTCH
Main MenuTable of Contents

Check the smaller f uses in the
under-hood f use boxes and all the
fuses in the interior fuse box by
pulling out each one with the f use
puller provided in the primary
under-hood f use box.
Turn the ignition switch to the
LOCK (0) position. Make sure the
headlights and all other
accessories are of f .
Check each of the large f uses in
the primary under-hood f use box
by looking through the side
window at the wire inside.
Removing these f uses requires a
Phillips-head screwdriver.
Remove the cover f rom the f use
box. 4.
3.
1. 2.
CONT INUED
Fuses
T aking Care of t he Unexpect ed
379
BLOWN
FUSE PULLER
BLOWN
FUSE
Main MenuTable of Contents

If the driver’s power window f use is
removed, the AUTO f unction of the
driver’s window may be disabled. To
reset the AUTO f unction, see page.
If you cannot drive the vehicle
without f ixing the problem, and you
do not have a spare fuse, take a fuse
of the same rating or a lower rating
f rom one of the other circuits. Make
sureyoucandowithoutthatcircuit
temporarily (such as the accessory
power socket or radio).
If you replace the blown f use with a
spare f use that has a lower rating, it
might blow out again. This does not
indicate anything wrong. Replace the
f use with one of the correct rating as
soon as you can.
Look f or a blown wire inside the
fuse.If itisblown,replacethefuse
withoneof thesparefusesof the
same rating or lower. If the radio f use is removed, the
audio system will disable itself . The
nexttimeyouturnontheradioyou
will see ‘‘CODE’’ in the f requency
display. Use the preset bars to enter
thecode(seepage ).If the replacement fuse of the
same rating blows in a short time,
there is probably a serious
electrical problem in your vehicle.
Leave the blown fuse in that
circuit and have your vehicle
checked by a qualif ied technician.
5. 6.
128 206
Fuses
380
BLOWN
Replacing a f use with one that has a
higher rating greatly increases the
chances of damaging the electrical
system. If you do not have a
replacement f use with the proper
rating f or the circuit, install one with
a lower rating.
Main MenuTable of Contents

ÎÎÎ
Î Î
Î Î
Î
Î
µ
µ
µ´
Î
Î If equipped
If equipped
1 23456789
101112
123456 Back Light
VSA FSR
VSA MTR
VTM-4
Front Accessory Sockets
Electric Brake 13141516171819202122 23
7 89
1011
Left Headlight Low Beam
Not Used
Lef t Headlight High Beam
Small Lights
Right Headlight High Beam
Right Headlight Low Beam
Back Up
FI ECU (PCM)
DBW
Front Fog Light
Heated Seat
MG Clutch
10 A
10 A
15 A
10 A
10 A
7.5 A
15 A
15 A
20 A
15 A
7.5 A
(7.5 A) 20 A
40 A
20 A
15 A
(20 A) (20 A)
(7.5 A) (20 A)7.5 A
(20 A) 20 A
20 A
40 A
15 A
40 A
20 A
30 A
30 A
40 A
40 A
120 A
60 A
50 A Horn, Stop
Def roster
Back Up, ACC
Hazard
Option 1
AC Inverter
Cooling Fan
Condenser Fan
Heater MotorSeat
Battery
BIGIMain
Power Window
Spare Fuses
Small Lights
Stop/Turn Lights
Charge
TPMS
Moonroof
:
:
No.
No. Circuits Protected No.No.
Circuits Protected
Amps.
Amps. Amps.Amps. Circuits Protected
Circuits Protected
24 28
Fuse Locations
T aking Care of t he Unexpect ed
381
PRIMARY UNDER-HOOD FUSE BOX
SECONDARY UNDER-HOOD FUSE BOX
Main MenuTable of Contents

Î
Î
ε µ µ
Î
No. No. Circuits Protected
No. Amps.
Circuits Protected
Amps. Amps.
Circuits Protected
1 23456789
10
If equipped
1112131415161718192021222324252627282930313233
IG, Wiper
Not Used
Driver’s Power Seat Lumbar
Driver’s Power Seat Sliding
Not Used
Driver’s Power Seat Reclining
Not Used
IG ACG
IG Fuel Pump
IG Washer
IG Meter
IG SRS
IGP
Left Rear Window
Right Rear Window
Passenger’s Window
Back Window
Driver’s Window
VBSOL2
IG HAC
IG VSA/ABS
ACC
Not Used
1 7.5 A
Bed Lights
IG Coil
Daytime Running LightLAF
Radio
Interior Lights
Back Up
Door Lock
Rear Accessory SocketOPDS
7.5 A
15 A
10 A
15 A
20 A
10 A
7.5 A 20 A
10 A
7.5 A 30 A
(10 A)
(20 A)
(20 A) 15 A
15 A
7.5 A
7.5 A 10 A
7.5 A
20 A
20 A
20 A
20 A
20 A
7.5 A 10 A
7.5 A
7.5 A
(7.5 A) STS
:
Fuse Locations
382
INTERIOR FUSE BOX UPPER AREA
INTERIOR FUSE BOX
Driver’s Side
Main MenuTable of Contents

µ µ
µµ µ µµµµµµµµµµµµµ µ µÎ
Î
ÎÎ
Specif icat ions
Technical Inf ormation
389
Fuses
Engine
Alignment
Lights Battery
Tires
Capacities
Interior
Under-hoodType
BorexStroke
Displacement
Compression ratio
Spark plugs
Toe-in
CamberCaster3.50 x 3.66 in (89.0 x 93.0 mm)
211.8 cu-in (3,471 cm
)
10.0 : 1
ILZKR7B11 SXU22HCR11
0.00 in (0.0 mm)
0.00 in (0.0 mm) 0°50’
0°50’
1°53’
P245/65R17 105T
Water cooled 4-stroke SOHC VTEC,
V6 gasoline engine
0.45 US qt (0.43
)
0.48 US qt (0.45)
4.8 US qt (4.5
)
Headlights
Front turn signal/parking/
hazard lights
Daytime running light
Fog light
Rear turn signal/hazard lights
Brake/Taillights
Back-up lights
License plate lights
High-mount brake lights
Individual map lights
Bed lights
Console compartment light
Glove box light
Vanity mirror light
Door courtesy lights 12 V 60/55 W (HB2)
12 V 28/8 W
12 V 21 W
12 V
12 V
12 V
12 V
12 V
12 V
12 V
12 V
12 V
12 V
12 V
21/5 W
18 W
3CP
3CP8W5W
3CP
1.4 W
3.4 W2W
3.8 W
Capacity 12 V 12 V72 AH/20 HR
60 AH/5 HR Size
Pressure
60 psi (420 kPa , 4.2 kgf/cm
)
32 psi (220 kPa , 2.2 kgf/cm)
T165/90R17 105M
12 V 55 W
12 V 60 W
P245/60R18 104T
See page 382 or the fuse label
attached to the inside of the fuse
box lid under the dashboard.
See page 381 or the fuse box lid.
Transfer
assembly
fluid
Windshield
washer
reservoir
FrontRear
FrontRear
Front
FrontRear NGK:
DENSO:
High/Low
ChangeTotal
Front/Rear
Spare
Front/Rear
Spare
1:2: U.S. RT, RTS models, and Canadian DX, VP models
U.S. RTL models, and Canadian EX-L models
(HB3)(H11)
12
