2011 HONDA RIDGELINE fuel cap

(f luid capacities and tire pressures)
(seat belts, SRS, and child protection)
(main controls)
(indicators, gauges, multi-inf ormation display, dashboard, and steering column)
(fuel, vehicle break-in, and cargo loading)
(engine and transmission operation)
(vehicle specif ications, tires, and emissions controls) (warranty and contact inf ormation)
(how to order)
(f lat tire, jump starting, overheating, and f uses)
(
)
(minder, f luid checking, minor services, and vehicle storage)
climate control, audio, steering wheel, security, cruise control, HomeLink, and other convenience items
Contents
................................................................................................................................................
Index .I
..................................................
Service Inf ormation Summary . last page
............................................................
Driver and Passenger Saf ety .5
...............................................................................................
Your Vehicle at a Glance .3
.......
Instruments and Controls .59
.......................................................................
Bef ore Driving .247
.........................................................................................
Driving .267
..............................................
T echnical Inf ormation .385
..................
Warranty and Customer Relations (U.S. and Canada only) . 403
..................................................................................
A uthorized Manuals (U.S. only) .407
........................................
T aking Care of the Unexpected .359
..............
Features .145
.................................................
Maintenance .311INDEX
1Owner
Main Menu
2011 Ridgeline Online Reference Owner's Manual

The inf ormation display in the
instrument panel shows you the
engine oil lif e and maintenance
service items when the ignition
switch is in the ON (II) position. This
inf ormation helps to keep you aware
of the periodic maintenance your
vehicle needs f or continued trouble-
f ree driving. Ref er to page f or
more inf ormation.Your vehicle’s onboard diagnostic
system will detect a loose or missing
f uel f ill cap as an evaporative system
leak. The f irst time a leak is detected
a ‘‘CHECK FUEL CAP’’ message
appears on the information display.
If the system still detects a leak in
your vehicle’s evaporative emissions
system, the malf unction indicator
lamp (MIL) comes on. If the f uel f ill
cap was not already tightened, turn
the engine of f , and check or
retighten the f uel f ill cap until it
clicks at least once. The MIL should
go off after several days of normal
driving once the cap is tightened or
replaced. If the MIL does not go of f ,
have your vehicle inspected by a
dealer. For more inf ormation, see
page .
Turn the engine of f , and conf irm the
f uel f ill cap is installed. If it is, loosen
it, then retighten it until it clicks at
least once. The message should go
off after several days of normal
driving once you tighten or replace
the f uel f ill cap. To scroll to another
display, press the SELECT button or
TRIP/RESET button.
The ‘‘CHECK FUEL CAP’’ message
will appear each time you restart the
engine until the system turns the
message of f .
313
375
Maint enance Minder Check Fuel Cap Message
Gauges
Inst rument s and Cont rols
81
TM
Main MenuTable of ContentsTable of Contents

CONT INUED
Open the f uel f ill door by pulling
onthehandletotheleftof the
driver’s seat.
Park with the driver’s side closest
to the service station pump. Stop f illing the tank af ter the f uel
nozzle automatically clicks of f . Do
not try to ‘‘top of f ’’ the tank. This
leaves some room in the f uel tank
f or the f uel to expand with
temperature changes.
Remove the f uel f ill cap slowly.
You may hear a hissing sound as
pressure inside the tank escapes.
The fuel fill cap is attached to the
f uel f iller with a tether. Insert the
attachment on the fuel fill cap into
the slit on the f uel f ill door.
If the f uel nozzle keeps clicking of f
even though the tank is not f ull,
there may be a problem with your
vehicle’s fuel vapor recovery
system. The system helps keep
f uel vapor f rom going into the
atmosphere. Try f illing at another
pump. If this does not f ix the
problem, consult your dealer.
1. 2. 3. 4.
Ref ueling
Service Station Procedures
Bef ore Driving
249
Pull
FUEL FILL CAP
ATTACHMENT TETHER
Gasoline is highly flammable
and explosive. You can be
burned or seriously injured
when handling fuel.
Stop the engine, and keep
heat, sparks, and flame away.
Handle fuel only outdoors.
Wipe up spills immediately.
Main MenuTable of Contents

Screw the fuel fill cap back on
until it clicks at least once.
If you do not properly tighten the
cap, you will see a ‘‘CHECK FUEL
CAP’’ message on the inf ormation
display (see page ).If the system still detects a leak in
the vehicle’s evaporative emissions
system, the malf unction indicator
lamp (MIL) comes on. If the f uel f ill
cap was not already tightened, turn
the engine of f , and check or
retighten the f uel f ill cap until it
clicks at least once. The MIL should
go off after several days of normal
driving once the cap is tightened or
replaced. If the MIL does not go of f ,
have your vehicle inspected by a
dealer. For more inf ormation, see
page .
Your vehicle’s on board diagnostic
system will detect a loose or missing
f uel f ill cap as an evaporative system
leak. The f irst time a leak is detected
a ‘‘TIGHTEN FUEL CAP’’ message
appears on the multi-inf ormation
display. Turn the engine of f , and
conf irm the f uel f ill cap is installed. If
it is, loosen it, then retighten it until
it clicks at least once. The message
should go of f af ter several days of normal driving once you tighten or
replace the f uel f ill cap. To scroll to
another message, press the INFO
button. The ‘‘TIGHTEN FUEL CAP’’
message will appear each time you
restart the engine until the system
turns the message of f .
If you do not properly tighten the
cap, you will see a ‘‘TIGHTEN
FUEL CAP’’ message on the multi-
inf ormation display.
Push the f uel f ill door closed until
it latches.
5. 6.
81
375
On models without navigation systemOn models with navigation system On models with navigation system
Tighten Fuel Cap Message
Service Station Procedures
250
Main MenuTable of Contents

If this indicator comes on
while driving, it means one
of the engine’s emissions control
systems may have a problem. Even
though you may f eel no dif f erence in
your vehicle’s perf ormance, it can
reduce your f uel economy and cause
increased emissions. Continued
operation may cause serious damage.
If you have recently ref ueled your
vehicle, the indicator coming on
could be due to a loose or missing
f uel f ill cap. Tighten the cap until it
clicks at least once. Tightening the
cap will not turn the indicator of f
immediately; it can take several days
of normal driving. If the indicator comes on repeatedly,
even though it may turn of f as you
continue driving, have your vehicle
checked by the dealer as soon as
possible.
The indicator may also come on with
the ‘‘D’’ indicator.
You will also see a ‘‘CHECK FUEL
CAP’’ message on the inf ormation
display.
You will also see a ‘‘TIGHTEN FUEL
CAP’’ message on the multi-
inf ormation display.
You will also see a ‘‘CHECK
EMISSION SYSTEM’’ message on
the multi-information display (see
page ).90On models without navigation system
On models with navigation system
On models with navigation system
Malf unct ion Indicat or L amp
T aking Care of t he Unexpect ed
375
If you keep driving with the
malf unction indicator lamp on, you can
damage your vehicle’s emissions
controls and engine. Those repairs may
not be covered by your vehicle’s
warranties.
Main MenuTable of Contents

µµ
Î Î
Î Î Î
Î
Î
Î
ÎÎÎ Î
Î
Î
Specif icat ions
388
Air Conditioning
Seating Capacities
Dimensions
Capacities
Weights 206.9 in (5,255 mm)
77.8 in (1,976 mm)
70.3 in (1,786 mm)
Refrigerant type
Charge quantity
Lubricant type HFC-134a (R-134a)
19.4 21.2 oz (550 600 g)
ND-OIL8
Total
FrontRear 32
5
1,470 lbs (670 kg)
1,520 lbs (690 kg)
10,088 lbs (4,575 kg)
Length
Width
Height
Wheelbase
Track
66.9 in (1,700 mm)
67.1 in (1,705 mm)
122.0 in (3,100 mm)
The GCWR must be reduced 2 percent for every 1,000 feet (305
meters) of elevation. Fuel tank
Engine
coolant
Engine oil Automatic
transmission
fluidRear
differential
fluid
22.01 US gal (83.3
)
1.64 US gal (6.2)
2.14 US gal (8.1)
4.2 US qt (4.0
)
4.5 US qt (4.3
)
5.3 US qt (5.0
)
3.3 US qt (3.1)
8.5 US qt (8.0)
2.79 US qt (2.64
)
3.01 US qt (2.85)
Including the coolant in the reserve tank and that remaining in the
engine
Reserve tank capacity:
0.16 US gal (0.6
)
Excluding the oil remaining in the engine
71.2 in (1,808 mm)
Gross vehicle weight rating
Gross combined weight
rating (GCWR)
Maximum load limit
(Payload) See the tire information label
attached to the driver’s doorjamb. Approx.
FrontRear
1: 2:
1: 2: 3:
ChangeTotal
Change
Including
filter
Without
filter
Total
ChangeTotal
Change Total
On vehicles without moonroof
On vehicles with moonroof
1:
2:
On vehicles without moonroof
On vehicles with moonroof
1
231 2
1
2
Main MenuTable of Contents

...............
Gas Mileage, Improving . 254
Gasoline
...............
Fuel Reserve Indicator . 68
...........................................
Gauge . 76
................
Octane Requirement . 248
........................
Tank, Filling the . 249
................
Gas Station Procedures . 249
Gauges
...
Engine Coolant Temperature . 76
...............................................
Fuel . 76
...............................
Speedometer . 76 .................................
Tachometer . 76
GAWR (Gross Axle Weight .......................................
Rating) . 294
GCWR (Gross Combined Weight .......................................
Rating) . 294
............
Gearshif t Lever Positions . 272
......................................
Glove Box . 138
GVWR (Gross Vehicle Weight
.......................................
Rating) . 294
....................
Filling the Fuel Tank . 249
Filters
.........................
Dust and Pollen . 345
...............................................
Oil . 328
.............
Flashers, Hazard Warning . 99
...................
Flat Tire, Changing a . 361
.....................................
Floor Mats . 345
Fluids
..........
Automatic Transmission . 331
..........................................
Brake . 334
..........................
Power Steering . 335
.......................
Rear Differential . 333
...................
Transf er Assembly . 333
..................
Windshield Washer . 330
FM Stereo Radio ...................................
Reception . 165
.................
Folding the Rear Seats . 125
........................................
Fog Lights . 97
..........................
Four-way Flashers . 99
..............................
Front Seat . 119, 121
............................
Adjusting . 119, 121
.....................................
Airbags . 9, 25
.......................................
Heaters . 126
.................................................
Fuel . 248
......................
Fill Door and Cap . 249
...........................................
Gauge . 76 ................
Octane Requirement . 248
...............................
Oxygenated . 248
........................
Reserve Indicator . 68
........................
Tank, Filling the . 249
...............................
Fuel Economy . 254
Actual Mileage and EPA FuelEconomy Estimates
.......................
Comparison . 254
......
Calculating Fuel Economy . 256
.............
Fuel Economy Factors . 255
........
Improving Fuel Economy . 255
.....................
Fuses, Checking the . 378
....
Halogen Headlight Bulbs . 336, 339
...........................
HandsFreeLink
. 221
..............................
HFL Buttons . 221
..............
Hazard Warning Flashers . 99
Index
G H
IV
Main Menu

Service Inf ormation Summary
Gasoline:Tire Pressure (measured cold):
Fuel Tank Capacity:
Recommended Engine Oil:
Automatic Transmission Fluid: Power Steering Fluid:
Brake Fluid:
Rear Differential Fluid:
Transfer Assembly Fluid: 32 psi (220 kPa , 2.2 kgf/cm
)
Front/Rear:
Compact Spare Tire:
60 psi (420 kPa , 4.2 kgf/cm
)
22.01 US gal (83.3
)
API Premium grade 5W-20
detergent oil (see page ).
Oil change capacity (including
filter): 4.5 US qt (4.3
)
Honda Genuine ATF-Z1
(automatic transmission fluid)
(see page ). Honda Power Steering Fluid
preferred, or another brand of
power steering fluid as a
temporary replacement. Do not
use ATF (see page ).
Honda Heavy Duty Brake Fluid
DOT 3 preferred, or a DOT 3 or
DOT 4 brake fluid as a temporary
replacement (see page ).
Honda VTM-4 Differential Fluid
(see page ).
Unleaded gasoline, pump octane
number of 87 or higher.
SAE 90 or SAE 80W-90 viscosity
hypoid gear oil, API service
classified GL4 or GL5 only.335
333
332 334
326
Main Menu
