2011 HONDA PILOT check engine light

This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position. If it comes on at any other
time, there is a problem with the
automatic lighting control system.
Have your vehicle checked by your
dealer as soon as possible.
If you see a ‘‘CHECK LIGHT
CONTROL SYSTEM’’ message on
the multi-information display, there
is a problem with the automatic
headlight control system. Take your
vehicle to a dealer to have it checked.If this indicator comes on when the
ignition switch is turned to the ON
(II) position and the parking brake is
released, it means there is a problem
in the high beam headlight’s circuit.
Have your vehicle checked by your
dealer.
If you see a ‘‘CHECK DRL
SYSTEM’’ message on the multi-
inf ormation display, there is a
problem with the daytime running
light system. Take your vehicle to a
dealer to have it checked.While the engine is operating in its
most economical range, this
indicator may come on and stay on.
It goes of f when your vehicle uses
extra f uel.
This indicator comes on if any door
is not closed tightly.
On vehicles without navigation system On vehicles without navigation system
On vehicles with navigation system On vehicles with navigation system
Light Control Indicator
Daytime Running Lights
Indicator
Door-open Indicator Fuel Economy Indicator
Instrument Panel Indicators
Inst rument s and Cont rols
79
10/01/26 18:36:57 31SZA620_084
2011 Pilot

This shows the temperature of the
engine’s coolant. During normal
operation, the pointer should rise to
about the middle of the gauge. In
severe driving conditions, the pointer
may rise to the upper zone. If it
reaches the red (hot) mark, pull
safely to the side of the road. For
instructions and precautions on
checking the engine’s cooling
system, see page .
This shows how much f uel you
have. It may show slightly more
or less than the actual amount.519
Gauges
Temperature Gauge
Fuel Gauge
82
SPEEDOMETER
FUEL GAUGE
TEMPERATURE GAUGE
TACHOMETER
INFORMATION DISPLAY
SELECT/RESET KNOB
SPEEDOMETER
TEMPERATURE GAUGE
SELECT/RESET KNOB
TACHOMETER
MULTI-INFORMATION DISPLAYFUEL GAUGE
On vehicles with navigation system On vehicles without navigation system
U.S. models are shown.
Avoid driving with an extremely low
f uel level. Running out of f uel could
cause the engine to misf ire, damaging
the catalytic converter.
10/01/26 18:37:35 31SZA620_087
2011 Pilot

CONT INUED
If you think you can saf ely drive a
short distance to a service station,
proceed slowly to the station, then
inflate the tire to the recommended
pressure.
If the tire is f lat, or if the tire
pressure is too low to continue
driving, replace the tire with the
compact spare tire (see page ).
Driving on a signif icantly under-
inf lated tire causes the tire to
overheat and can lead to tire failure.
Under-inf lation also reduces f uel
efficiency and tire tread life, and may
af f ect the vehicle’s handling and
stopping ability.
Becausetirepressurevariesby
temperature and other conditions,
the low tire pressure/TPMS
indicator may come on unexpectedly.
When the low tire pressure/TPMS
indicator is on, one or more of your
tires is signif icantly underinf lated.
Youshouldstopandcheckyourtires
as soon as possible, and inflate them
to the proper pressure as indicated
on the vehicle’s tire inf ormation
placard.
It is possible that the pressures
shown on the multi-inf ormation
display and the pressures you
manually measure are slightly
dif f erent.
If the dif f erence is signif icant or you
cannot make the low tire pressure/
TPMS indicator and message on the
multi-inf ormation display go out af ter
inf lating the tires to the specif ied
values, have your dealer check the
system as soon as possible.
Each tire has its own pressure
sensor. If the air pressure of a tire
becomes signif icantly low, the
sensor in that tire immediately sends
a signal that causes the low tire
pressure/TPMS indicator in the
instrument panel to come on. If this
happens, you will see which tire is
losing pressure on the multi-
inf ormation display along with a
‘‘CHECK TIRE PRESSURE’’
message. Your vehicle is equipped with a tire
pressure monitoring system (TPMS)
that turns on every time you start the
engine and monitors the pressure in
your tires while driving.
509On vehicles with navigation systemLow Tire Pressure/
TPMS Indicator
Tire Pressure Monitoring System (TPMS)
Driving
423
10/01/26 19:36:33 31SZA620_428
2011 Pilot

Constant application of the brakes
when going down a long hill builds
up heat and reduces their ef f ective-
ness. Use the engine to assist the
brakes by taking your f oot of f the
accelerator and downshif ting to a
lower gear.
Check the brakes after driving
through deep water. Apply the
brakes moderately to see if they f eel
normal. If not, apply them gently and
f requently until they do. Be extra
cautious in your driving.
Your vehicle is equipped with disc
brakes at all f our wheels. A power
assist helps reduce the ef f ort needed
on the brake pedal. The emergency
brake assist system increases the
stopping f orce when you depress the
brake pedal hard in an emergency
situation. The anti-lock brake system
(ABS) helps you retain steering
control when braking very hard.
Resting your f oot on the pedal keeps
the brakes applied lightly, builds up
heat, reduces their ef f ectiveness and
reduces brake pad lif e. In addition,
f uel economy can be reduced. It also
keeps your brake lights on all the
time, conf using drivers behind you.As required by the FCC:
This device complies with Part 15 of theFCC rules. Operation is subject to thef ollowing two conditions: (1) This devicemay not cause harmf ul interf erence, and(2) this device must accept anyinterf erence received, includinginterf erence that may cause undesiredoperation.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may causeundesired operation of the device.
Changes or modif ications not expressly
approved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.Braking System
Tire Pressure Monitoring System (TPMS), Braking System
428
10/01/26 19:37:21 31SZA620_433
2011 Pilot

This section explains why it is
important to keep your vehicle well
maintained and how to f ollow basic
maintenance saf ety precautions.
This section also includes
instructions on how to read the
maintenance inf ormation messages
on the inf ormation display or multi-
inf ormation display (depending on
models), and instructions f or simple
maintenance tasks you may want to
take care of yourself .
If you have the skills and tools to
perf orm more complex maintenance
tasks on your vehicle, you may want
to purchase the service manual. See
page f or inf ormation on how to
obtain a copy, or see your dealer.......................
Maintenance Saf ety .454
............
Maintenance Inf ormation . 455
..............................
Fluid Locations .470
......
Engine Compartment Covers . 471
........................
Adding Engine Oil .472
Changing the Engine Oil and ...........................................
Filter .473
..............................
Engine Coolant .475
....................
Windshield Washers .477
....
Automatic Transmission Fluid . 478
.................
Rear Dif f erential Fluid . 480
.............
Transf er Assembly Fluid . 480
....................................
Brake Fluid .481
....................
Power Steering Fluid . 482
....................................
Timing Belt .482
.............................................
Lights .483
..................
Dust and Pollen Filter . 490
................
Cleaning the Seat Belts . 490
.....................................
Floor Mats .491
.................................
Wiper Blades .492
...............................................
Tires .496
...................
Checking the Battery . 504
.............................
Vehicle Storage .505
..................................
Interior Care .506
557
Maintenance
Maint enance
453
10/01/26 19:42:06 31SZA620_458
2011 Pilot

Diagnosing why the engine won’t
start f alls into two areas, depending
on what you hear when you turn the
ignition switch to the START (III)
position:You hear nothing, or almost
nothing. The engine’s starter
motor does not operate at all, or
operates very slowly.
You can hear the starter motor
operating normally, or the starter
motor sounds like it is spinning
f aster than normal, but the engine
does not start up and run.
When you turn the ignition switch to
the START (III) position, you do not
hear the normal noise of the engine
trying to start. You may hear a
clicking sound, a series of clicks, or
nothing at all. If the headlights dim noticeably or
go out when you try to start the
engine, either the battery is
discharged or the connections are
corroded. Check the condition of
the battery and terminal connec-
tions (see page ). You can
then try jump starting the vehicle
f rom a booster battery (see page
).
In this case, the starter motor’s
speed sounds normal, or even f aster
than normal, when you turn the
ignition switch to the START (III)
position, but the engine does not run. Are you using a properly coded
key? An improperly coded key will
cause the immobilizer system
indicator in the instrument panel
to blink rapidly (see page ).
Check these things:
Check the transmission interlock.
The transmission must be in Park
or neutral or the starter will not
operate.
Turn the ignition switch to the ON
(II) position. Turn on the
headlights, and check their
brightness. If the headlights are
very dim or do not come on at all,
the battery is discharged. See on page .
Turn the ignition switch to the
START (III) position. If the
headlights do not dim, check the
condition of the f uses. If the f uses
areOK,thereisprobably
something wrong with the
electrical circuit for the ignition
switch or starter motor. You will
need a qualif ied technician to
determine the problem. See on page .517
531 504
517
78
Nothing Happens or the Starter
Motor Operates Very Slowly T he Starter Operates Normally
Jump Starting
Emergency T owing
If theEngineWon’tStart
516
10/01/26 19:52:25 31SZA620_521
2011 Pilot

Are you using the proper starting
procedure? Ref er toon page .
Do you have f uel? Check the f uel
gauge; the warning indicator may
not be working.
There may be an electrical
problem, such as no power to the
f uel pump. Check all the f uses
(see page ).
If youfindnothingwrong,youwill
need a qualif ied technician to f ind
the problem. See on page . Although this seems like a simple
procedure, you should take several
precautions.
You cannot start your vehicle by
pushing or pulling it.
Put the transmission in neutral or
Park, and set the parking brake. Turn of f all the electrical acces-
sories: heater, A/C, climate
control, audio system, lights, etc. Open the hood, and check the
physical condition of the battery.
In very cold weather, check the
condition of the electrolyte. If it
seems slushy or f rozen, do not try
jump starting until it thaws.
1.
2.
411
525 531
CONT INUED
Starting the
Engine
Emergency
Towing Jump Starting
To Jump Start Your Vehicle:
If the Engine Won’t Start, Jump Starting
T aking Care of t he Unexpect ed
517
A battery can explode if you do
not follow the correct procedure,
seriously injuring anyone
nearby.
Keep all sparks, open flames,
and smoking materials away
from the battery.
If a battery sits in extreme cold, the
electrolyte inside can f reeze.
Attempting to jump start with a f rozen
battery can cause it to rupture.
10/01/26 19:52:40 31SZA620_522
2011 Pilot

CONT INUED
................................................
AAC .300
...
Accessories and Modif ications . 402
ACCESSORY (Ignition Key .....................................
Position) .137
............
Accessory Power Sockets . 186
...........................
AC Power Outlet .187
................
Active Head Restraints . 158
....................
Additives, Engine Oil . 473
...........................
Advanced Airbags .31
.............................
Airbag (SRS) .11, 26
..........
Airbag System Components . 26
......
Air Conditioning System . 192,199
.............
Rear A/C Control . 197,204
.......................
Air Outlets (Vents) .206
.......................
Air Pressure, Tires .496
......................................
Antif reeze .475
Anti-lock Brakes (ABS) ....................
Indicator Light .72, 430
...................................
Operation .429
..............
Anti-thef t, Audio System . 313
Anti-thef t Steering Column ............................................
Lock .137
........
Audio System . 208,210,226,252 Auto Control Mode, Starting
........................................
Engine .411
............................
Auto Door Lock .116
...
Auto Door Locking/Unlocking . 139
.........................
Auto Door Unlock .117
..........
Automatic Climate Control . 199
.......................
Automatic Lighting .127
...
Automatic Seat Belt Tensioners . 24
.............
Automatic Speed Control . 350
..............
Automatic Transmission . 413
..........................
Capacity, Fluid .538
...............
Checking Fluid Level . 478
.......................................
Shif ting .413
Shif t Lever Position ...............................
Indicators .413
................
Shif t Lever Positions . 414
....................
Shif t Lock Release . 416
......................
Auxiliary Input Jack .310
Battery Charging System ...........................
Indicator .70, 521
............................
Jump Starting .517
..............................
Maintenance .504 ............................
Specif ications . 539
..............................
Bef ore Driving .393
....................................
Belts,Seat .9,22
.........................
Beverage Holders .181
........
HandsFreeLink. 361
..................................
Booster Seats .58
Brakes ...........
Anti-lock System (ABS) . 429
.............
Break-in, New Linings . 394
............
Bulb Replacement . 486,488
...........................................
Fluid .481
.......................................
Parking .169
.................
System Indicator . 71,523
........................
Wear Indicators .429
.............................
Braking System .428
.................
Break-in, New Vehicle . 394
Brightness Control, ...............................
Instruments .131Bluetooth
Index
A
B
INDEX
I
10/01/26 19:59:14 31SZA620_564
2011 Pilot
