2011 HONDA PILOT TPMS

ÎÎ
Î Î
Î
Î
Î
The U.S. instrument panel is shown. Dif f erences f or the Canadian models are noted in the text. 4WD models only If equipped
1:
2:
Instrument Panel
Inst rument s and Cont rols
On vehicles wit hout navigat ion syst em
67
HIGH BEAM INDICATOR
CRUISE CONTROL INDICATOR
CRUISE MAIN INDICATOR
PARKING BRAKE AND BRAKE
SYSTEM INDICATORSEAT BELT REMINDER
INDICATOR
TIRE PRESSURE MONITORING SYSTEM (TPMS) INDICATOR
ANTI-LOCK BRAKE SYSTEM INDICATOR
CHARGING SYSTEM INDICATOR
LOW OIL PRESSURE INDICATOR
VTM-4 INDICATOR
LIGHT CONTROL INDICATOR
DAYTIME RUNNING LIGHTS INDICATOR
IMMOBILIZER SYSTEM
INDICATOR
LOW TIRE PRESSURE INDICATOR
INFORMATION DISPLAY VEHICLE STABILITY ASSIST (VSA)
SYSTEM INDICATOR
STARTER SYSTEM INDICATORDOOR-OPEN INDICATOR
SUPPLEMENTAL RESTRAINT SYSTEM
INDICATOR
(P.70)
(P.70)
(P.77)
(P.79)
(P.70)
(P.79)
(P .76)
(P.73)
(P.78) (P.74)
(P.83) (P.75)
LOW FUEL INDICATOR
(P.80)(P.
79)
(P.
72) (P.
69) (P.
71)
(P.78)
(P.78)
(P.72) (P.
78)
LIGHTS ON INDICATOR (P.78) (P.
75)
(P.79)
MALFUNCTION INDICATOR LAMP
FUEL ECONOMY INDICATOR
A/T TEMPERATURE INDICATOR
VSA ACTIVATION INDICATOR
(P .73)
SECURITY SYSTEM INDICATORWASHER LEVEL INDICATOR
SIDE AIRBAG OFF
INDICATOR (P.72)
FOG LIGHT
INDICATOR (P.78)
(P.80)
(P. 81)
MAINTENANCE INFORMATION INDICATOR
(P.77)
2
2
1 1
1
10/01/26 18:34:24 31SZA620_072
2011 Pilot

Î
ÎÎ
The U.S. instrument panel is shown. Dif f erences f or the Canadian models are noted in the text.: 4WD models only
Instrument Panel
On vehicles wit h navigat ion syst em
68
ANTI-LOCK BRAKE SYSTEM
INDICATOR
HIGH BEAM INDICATOR
SIDE AIRBAG OFF INDICATOR
CRUISE MAIN INDICATOR
FOG LIGHT
INDICATOR
PARKING BRAKE AND BRAKE
SYSTEM INDICATORSEAT BELT REMINDER
INDICATOR
SUPPLEMENTAL
RESTRAINT SYSTEM
INDICATOR
DOOR-OPEN INDICATOR
MESSAGE INDICATOR
SECURITY SYSTEM INDICATOR
LOW OIL PRESSURE INDICATOR
VTM-4 INDICATOR
CHARGING SYSTEM INDICATOR
MALFUNCTION INDICATOR LAMP
FUEL ECONOMY INDICATOR
IMMOBILIZER SYSTEM
INDICATOR
MULTI-INFORMATION DISPLAY LOW FUEL INDICATOR
LIGHTS ON INDICATOR
CRUISE CONTROL INDICATOR
VSA ACTIVATION
INDICATOR
VEHICLE STABILITY ASSIST
(VSA) SYSTEM INDICATOR A/T TEMPERATURE INDICATOR (P.70)
(P.77) (P.70)
(P.70)
(P.79)
(P.76)
(P.73) (P.73)
(P.78) (P.87)(P.
81)
(P.77)
(P.79)
(P.
80) (P.
72)
(P.
69)
(P.
71)
(P.
78)
(P.
78)
(P.
72)
(P.78)
(P.78)
(P.78)
(P.72)
LOW TIRE PRESSURE/
TPMS INDICATOR (P.74)
10/01/26 18:34:32 31SZA620_073
2011 Pilot

This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position.
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position. If it comes on while driving,
it indicates that one or more of your
vehicle’s tires are signif icantly low
on pressure.
If this happens, pull to the side of the
road when it is saf e, check which tire
has lost the pressure, and determine
the cause. If it is because of a flat tire,
replace the flat tire with the compact
spare (see page ), and have the
f lat tire repaired as soon as possible.
If two or more tires are underinf lated,
call a prof essional towing service
(see page ). For more
inf ormation, see page . This indicator has two f unctions:
If it comes on while driving, it
indicates that one or more of your
vehicle’s tires are signif icantly low
on pressure.
You will also see a ‘‘CHECK TIRE
PRESSURE’’ message on the
multi-inf ormation display (see
page ).
Check the tire pressure monitor
on the multi-information display
and determine the cause (see page ). If this happens, pull to the side
of the road when it is saf e,
check which tire has lost
pressure on the multi-
inf ormation display, and
determine the cause. If it is
because of a flat tire, have the
flat tire repaired as soon as
possible. If two or more tires are
underinf lated, call a prof essional
towing service. For more
inf ormation, see page .
1.
508 420 96
424 531
531
On vehicles without navigation system On vehicles with navigation system
Instrument Panel Indicators
Low Tire Pressure/
TPMS Indicator
Low Tire Pressure
Indicator
74
10/01/26 18:35:51 31SZA620_079
2011 Pilot

This indicator comes on when there
is a problem with the starter system.
For more inf ormation, see page .
If you see a ‘‘CHECK STARTER
SYSTEM’’ message on the multi-
inf ormation display, there is a
problem with the starter system (see
page ).
If this indicator begins to f lash,
there is a problem with the tire
pressure monitoring system
(TPMS). You will also see a
‘‘CHECK TPMS SYSTEM’’
message on the multi-inf ormation
display. The indicator continues to
f lash f or a while (approximately 1
minute), then stays on. If this
happens, have your dealer check
the system as soon as possible.
For more inf ormation, see page
. This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position.
If this indicator comes on and stays
on at any other time, or if it does not
come on when you turn the ignition
switch to the ON (II) position, there
is a problem with the TPMS. With
this indicator on, the low tire
pressure indicator and the tire
pressure monitor will not come on
when a tire loses pressure. Take the
vehicle to your dealer to have the
system checked.
2.
426 411
96
On vehicles without navigation system On vehicles without navigation system
On vehicles with navigation system
Instrument Panel Indicators
Starter System
Indicator Tire Pressure Monitoring
System (T PMS) Indicator
Inst rument s and Cont rols
75
U.S. Canada
10/01/26 18:36:04 31SZA620_080
2011 Pilot

Some examples are:Lowering your vehicle with a
non-Honda suspension kit that
signif icantly reduces ground
clearance can allow the
undercarriage to hit speed bumps
or other raised objects, which
could cause the airbags to deploy.
Raising your vehicle with a
non-Honda suspension kit can
af f ect the handling, stability, and
reliability.
Removing parts f rom your vehicle,
or replacing components with
non-Honda components could
seriously af f ect your vehicle’s
handling, stability, and reliability.
Non-Honda wheels, because they
are a universal design, can cause
excessive stress on suspension
components and will not be
compatible with the tire pressure
monitoring system (TPMS).
Larger or smaller wheels and tires
can interf ere with the operation of
your vehicle’s anti-lock brakes and
other systems.
Modif ying your steering wheel or
any other part of your vehicle’s
safety features can make the
systems inef f ective.
If you plan to modif y your vehicle,
consult your dealer.
Modif ying Your Vehicle
A ccessories and Modif ications
Bef ore Driving
403
10/01/26 19:32:47 31SZA620_408
2011 Pilot

This section gives you tips on
starting the engine under various
conditions, and how to operate the
automatic transmission. It also
includes important inf ormation on
parking your vehicle, the braking
system, the Variable Torque
Management
4-wheel drive
(VTM-4
) system, the vehicle
stability assist (VSA
), aka
Electronic Stability Control (ESC),
system, the tire pressure monitoring
system (TPMS), and f acts you need
if you are planning to tow a trailer or
drive of f -highway. ........................
Driving Guidelines .410
........................
Preparing to Drive .410
.......................
Starting the Engine .411
Check Starter System .................................
Message .412
..............
Automatic Transmission . 413
............................
VTM-4
System .418
...........................................
Parking .419
Tire Pressure Monitoring System ......................................
(TPMS) .420
.............................
Braking System .428
...............
Anti-lock Brakes (ABS) . 429
Vehicle Stability Assist (VSA
),
aka Electronic Stability ........
Control (ESC), System . 431
...........................
Towing a Trailer .434
Of f -Highway Driving ..................................
Guidelines .449
Driving
Driving
409
10/01/26 19:33:51 31SZA620_414
2011 Pilot

When the low tire pressure indicator
is on, one or more of your tires is
signif icantly underinf lated. You
should stop and check your tires as
soon as possible, and inf late them to
the proper pressure as indicated on
the vehicle’s tire inf ormation placard.
If you think you can saf ely drive a
short distance to a service station,
proceed slowly, and inf late the tire to
the recommended pressure shown
on the driver’s doorjamb.
If the tire is f lat, or if the tire
pressure is too low to continue
driving, replace the tire with the
compact spare tire (see page ).
If you cannot make the low tire
pressure indicator go out af ter
inf lating the tires to the specif ied
values, have your dealer check the
system as soon as possible.Driving on a signif icantly under
inf lated tire causes the tire to
overheat and can lead to tire failure.
Underinf lation also reduces f uel
efficiency and tire tread life, and may
af f ect the vehicle’s handling and
stopping ability.
Becausetirepressurevariesby
temperature and other conditions,
the low tire pressure indicator may
come on unexpectedly.
Each tire has its own pressure
sensor (not including the spare tire).
If the air pressure of a tire becomes
signif icantly low while driving, the
sensor in that tire immediately sends
a signal that causes the low tire
pressure indicator to come on. Your vehicle is equipped with a tire
pressure monitoring system (TPMS)
that turns on every time you start the
engine and monitors the pressure in
your tires while driving.
508
On vehicles without navigation systemLow Tire Pressure
Indicator
Tire Pressure Monitoring System (TPMS)
420
10/01/26 19:35:58 31SZA620_425
2011 Pilot

For example, if you check and f ill
your tires in a warm area, then drive
in extremely cold weather, the tire
pressure will be lower than
measured and could be underinf lated
and cause the low tire pressure
indicator to come on. Or, if you
check and adjust your tire pressure
in cooler conditions, and drive into
extremely hot conditions, the tire
maybecomeoverinflated.However,
the low tire pressure indicator will
not come on if the tires are
overinf lated.
Refer to page for tire inflation
guidelines.
Although your tire pressure is
monitored, you must manually check
thetirepressuresmonthly.This indicator comes on and stays on
if there is a problem with the tire
pressure monitoring system.
If this happens, the system will shut
of f and no longer monitor tire
pressures. Have the system checked
by your dealer as soon as possible.
If the low tire pressure indicator or
TPMS indicator comes on, the VSA
system automatically turns on even if
the VSA system is turned of f by
pressing the VSA OFF switch (see
page ). If this happens, you
cannot turn the VSA system of f by
pressing the VSA OFF switch again.
Each tire, including the spare, should
be checked monthly when cold, and
set to the recommended inf lation
pressure as specif ied on the tire
information label and in the owner’s
manual (see page ).
When you restart the vehicle with
thecompactsparetire,theTPMS
indicator may also come on and stay
on after driving several miles
(kilometers).
The appropriate tire indicator and
low tire pressure indicator comes on
if a tire becomes signif icantly
underinf lated. See
on page .
496 497
432
74
Low Tire
Pressure Indicator Tire Pressure Monitoring
System (T PMS) Indicator
T ire Pressure Monitor
Tire Pressure Monitoring System (TPMS)
Driving
421
10/01/26 19:36:12 31SZA620_426
2011 Pilot
