2011 HONDA ODYSSEY TPMS

Replace your tires with radial tires of
the same size, load range, speed
rating, and maximum cold tire
pressure rating (as shown on the
tire’s sidewall).
Mixing radial and bias-ply tires on
your vehicle can reduce braking
ability, traction, and steering
accuracy. Using tires of a dif f erent
size or construction can cause the
ABS and vehicle stability assist
system (VSA) to work inconsistently.
The ABS and VSA system work by
comparing the speed of each wheel.
When replacing tires, use the same
size originally supplied with the
vehicle. Tire size and construction
can af f ect wheel speed and may
cause the system to activate.Replacement wheels are available at
your dealer.
It is best to replace all f our tires at
thesametime.If thatisnotpossible
or necessary, replace the two f ront
tires or two rear tires as a pair.
Replacing just one tire can seriously
af f ect your vehicle’s handling.
If you ever replace a wheel, make
sure that the wheel’s specif ications
match those of the original wheels.
Also be sure you use only TPMS
specif ic wheels. If you do not, the
tire pressure monitoring system will
not work.TiresReplacing T ires and Wheels646
Installing improper tires on your
vehicle can affect handling and
stability. This can cause a crash
in which you can be seriously
hurt or killed.
Always use the size and type of
tires recommended in this
owner’s manual.
10/07/17 11:00:57 31TK8600_651
2011 Odyssey

´
Wheels: Tires marked ‘‘M S’’ or ‘‘All
Season’’ on the sidewall have an all-
weather tread design suitable for
most winter driving conditions.
For the best perf ormance in snowy
or icy conditions, you should install
snow tires or tire chains. They may
be required by local laws under
certain conditions.
Tires:
See page f or inf ormation about
DOT Tire Quality Grading, and page
f or tire size and labeling
inf ormation. If you mount snow tires on your
vehicle, make sure they are radial
tires of the same size and load range
as the original tires. Mount snow
tires on all f our wheels. The traction
provided by snow tires on dry roads
maybelowerthanyouroriginaltires.
Check with the tire dealer f or
maximum speed recommendations.
690
692
All models except Touring models
All models except Touring models
Touring models
Touring models
Tires
Wheel and T ire Specif ications Winter Driving Snow T ires
Maint enance
647
17x7J
18x7J
P235/65R17 103T
P235/60R18 102T(TPMS)
(TPMS)
10/07/17 11:01:07 31TK8600_652
2011 Odyssey

Use the compact spare tire as a
temporary replacement only. Get
your regular tire repaired or replaced,
and put it back on your vehicle as
soon as you can.The low tire pressure indicator
comes on and stays on af ter you
replace the flat tire with the
compact spare tire. Af ter several
miles (kilometers) driving with the
compact spare tire, the TPMS
indicator comes on and the low
tire pressure indicator goes of f .
After the flat tire is replaced with
the spare tire, the low tire
pressure/TPMS indicator stays on.
Af ter several miles (kilometers)
driving with the spare, this
indicator begins to f lash, then
stays on again. You will also see a
‘‘CHECK TPMS SYSTEM’’
message on the multi-information
display (see page ).
Follow these precautions:
Do not use your compact spare
tire on another vehicle unless it is
thesamemakeandmodel. Do not mount snow chains on the
compact spare tire. This tire gives a harsher ride and
less traction on some road
surf aces. Use greater caution
while driving. Never exceed 50 mph (80 km/h).
Check the air pressure of the
compact spare tire every time you
check the other tires. It should be
inf lated to:
577
Except Touring modelsTouring models
Compact Spare Tire65460 psi (420 kPa , 4.2 kgf/cm
)
10/07/17 11:01:51 31TK8600_659
2011 Odyssey

µµ
µ
µ
µµ
µ
µ
µ
Î
Î
Î Î
Î
Amps.
No. No. Amps.
Circuits Protected Circuits Protected7.5 A
7.5 A
7.5 A
7.5 A
7.5 A
7.5 A
20 A
20 A
15 A
7.5 A 20 A
7.5 A
7.5 A 20 A
20 A
20 A
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17 18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
20 A
20 A
15 A
7.5 A
7.5 A
7.5 A
7.5 A
7.5 A
7.5 A
7.5 A
7.5 A
20 A
40 A
Door Lock Motor 1 (Lock)
Door Lock Motor 2 (Lock)
Driver’s Door Lock Motor
(Lock)
Door Lock Motor 1 (Unlock)
Door Lock Motor 2 (Unlock)
Driver’s Door Unlock
Door Lock Main
Not Used
Driver’s Side Power Slide
Door Closer
Rear Fuse Box
Meter
Primary Under-hood
Fuse Box
Accessory
STS
Driver’s Power Seat Sliding
Moonroof
Rear Left Power Window Driver’s Power Window
Fuel Pump
Passenger’s Side Fuse Box
VSA
ACG AS
STRLD
HAC
DRL
ACC Key Lock
Driver’s Power Seat
Lumbar Support
TPMS
Driver’s Power Seat Reclining
Driver’s Side Power
Slide Door Motor
: If equipped
Fuse Locations680INTERIOR FUSE BOX (Driver’s side)
10/07/17 11:04:59 31TK8600_685
2011 Odyssey

µ
Thediagramsinthissectiongive
you the dimensions and capacities of
your vehicle and the locations of the
identif ication numbers. It also
includes inf ormation you should
know about your vehicle’s tires and
emissions control systems.
................
Identif ication Numbers . 686
................................
Specif ications .688
DOT Tire Quality Grading ......................
(U.S. Vehicles) .690
Unif orm Tire Quality ..................................
Grading .690
.................................
Treadwear .690
......................................
Traction .690
.............................
Temperature .691
.................................
Tire Labeling .692
Tire Pressure Monitoring System (TPMS) Required Federal ............................
Explanation .694
.......................
Emissions Controls .697
.....................
The Clean Air Act .697
Crankcase Emissions Control ....................................
System .697
Evaporative Emissions Control ....................................
System .697
Onboard Ref ueling Vapor ................................
Recovery .697
...
Exhaust Emissions Controls . 698
....................
PGM-FI System .698
Ignition Timing Control ................................
System .698 Exhaust Gas Recirculation
...................
(EGR) System . 698
Three Way Catalytic ...........................
Converter .698
....................
Replacement Parts . 698
..
Three Way Catalytic Converter . 699
........................
Emissions Testing .700
....
Testing of Readiness Codes . 700
T echnical Inf ormation
T echnical Inf ormation
685
10/07/17 11:05:30 31TK8600_690
2011 Odyssey

µ
As an added safety feature, your
vehicle has been equipped with a tire
pressure monitoring system (TPMS)
that illuminates a low tire pressure
telltale
when one or more of your tires is
signif icantly under-inf lated.
Accordingly, when the low tire
pressure telltale illuminates, you
should stop and check your tires as
soon as possible, and inf late them to
the proper pressure.Driving on a signif icantly under
inf lated tire causes the tire to
overheat and can lead to tire failure.
Underinf lation also reduces f uel
efficiency and tire tread life, and may
af f ect the vehicle’s handling and
stopping ability.
Please note that the TPMS is not a
substitute for proper tire
maintenance, and it is the driver’s
responsibility to maintain correct tire
pressure, even if under-inf lation has
not reached the level to trigger
illumination of the TPMS low tire
pressure telltale.
(If your vehicle has tires of a
dif f erent size than the size indicated
on the vehicle placard or tire
inf lation pressure label, you should
determine the proper tire inf lation
pressure f or those tires.) Each tire, including the spare (if
provided), should be checked
monthly when cold and inf lated to
the inf lation pressure recommended
by the vehicle manuf acturer on the
vehicle placard or tire inf lation
pressure label.
All modelsTire Pressure Monitoring System (TPMS) Required Federal Explanation694
10/07/17 11:06:57 31TK8600_699
2011 Odyssey

µ
Always check the TPMS malf unction
telltale af ter replacing one or more
tires or wheels on your vehicle to
ensure that the replacement or
alternate tires and wheels allow the
TPMS to continue to f unction
properly.
TPMS malf unctions may occur f or a
variety of reasons, including the
installation of replacement or
alternate tires or wheels on the
vehicle that prevent the TPMS f rom
f unctioning properly. When the malf unction indicator is
illuminated,
the system may not be able to detect
or signal low tire pressure as
intended. Your vehicle has also been equipped
with a TPMS malf unction indicator
to indicate when the system is not
operating properly. The TPMS
malf unction indicator is provided by
a separate telltale, which displays the
symbol ‘‘TPMS’’ when illuminated.
Except Touring models
Tire Pressure Monitoring System (TPMS) Required Federal Explanation
T echnical Inf ormation
695
10/07/17 11:07:03 31TK8600_700
2011 Odyssey

µ
TPMS malf unctions may occur f or a
variety of reasons, including the
installation of replacement or
alternate tires or wheels on the
vehicle that prevent the TPMS f rom
f unctioning properly.
Always check the TPMS malf unction
telltale af ter replacing one or more
tires or wheels on your vehicle to
ensure that the replacement or
alternate tires and wheels allow the
TPMS to continue to f unction
properly.
When the malf unction indicator is
illuminated, the system may not be
able to detect or signal low tire
pressure as intended. Your vehicle has also been equipped
with a TPMS malf unction indicator
to indicate when the system is not
operating properly. The TPMS
malf unction indicator is combined
with the low tire pressure telltale.
When the system detects a
malf unction, the telltale will f lash f or
approximately one minute and then
remain continuously illuminated.
This sequence will continue upon
subsequent vehicle start-ups as long
as the malfunction exists.
Touring modelTire Pressure Monitoring System (TPMS) Required Federal Explanation696
