2011 HONDA CROSSTOUR navigation system

If you see an error message on the
audio display while playing a USB
f lash memory device, f ind the
solution in the chart to the right. If
you cannot clear the error message,
take your vehicle to your dealer.Error Message
Solution
Cause
There is a problem with the USB adapter unit.
Appears when the overcurrent protection
feature of the system stops supplying power to
USB because an incompatible device is
connected. Disconnect the device. Then, turn
the audio system off, and turn it on again. Do
not reconnect the device that caused the error.
Appears when the files in the USB flash
memory device are DRM or an unsupported
format. This error message appears for about 3
seconds, then plays the next song.
Appears when the USB flash memory device is
emptyortherearenoMP3,WMA,orAACfiles
in the USB flash memory device. Save some
MP3, WMA, or AAC files in the USB flash
memory device.
Appears when an unsupported device is
connected. See page 171for the specification
information for the USB flash memory device.
If it appears when a supported device is
connected, reconnect the device.
USB ROM Error
Abnormal power
source
Use of unsupported
files
No files in USB flash
memory device
Use of unsupported
USB f lash memory
device
USB Flash Memory Device Error Messages (Models without navigation system)
178
USB ERROR
BAD USBDEVICE
PLEASE CHECK OWNERSMANUAL
UNPLAYABLE FILE
USB NO SONG
UNSUPPORTED
10/08/27 14:37:46 31TP6610_183
2011 Accord Crosstour

Most audio system f unctions can still
be controlled by standard buttons,
dials, and knobs, but some f unctions
can only be accessed using the
interf ace dial. The interf ace dial has
two parts, a knob and a selector.The knob turns lef t and right. Use it
to make selections or adjustments to
a list or menu on the screen.
The selector can be pushed lef t,
right, up, down, and in. Use the
selector to scroll through lists, to
select menus, and to highlight menu
items. When you make a selection,
press ENTER to go to that selection.In addition to the standard audio
controls, the audio system in your
vehicle can be operated using the
voice control system. See the
Navigation System Manual f or
complete details.
Interf ace Dial
Voice Control System
Audio System (Models with navigation system)
Features
179
KNOBENTER
SELECTOR
10/08/27 14:37:53 31TP6610_184
2011 Accord Crosstour

Playing the FM/A M Radio (Models with navigation system)
180
INTERFACE DIALCENTER DISPLAY
SKIP BAR NAVIGATION SCREEN
POWER/VOLUME KNOB
TUNE BAR FM/AM BUTTON
CATEGORY BAR
AUDIO BUTTON SOUND BUTTON
U.S. model is shown. SCAN/A.SEL
(SCAN/AUTO SELECT) BAR
10/08/27 14:37:58 31TP6610_185
2011 Accord Crosstour

The ignition switch must be in the
ACCESSORY (I) or the ON (II)
position. Press the AUDIO button to
view the audio control display. Turn
the system on by pressing the
power/volume knob or the FM/AM
button. Adjust the volume by turning
the power/volume knob.
The band and f requency that the
radio was last tuned to are shown on
the display. To change bands, pressthe FM/AM button. You can also
change bands by pushing the
interf ace selector up. Each time you
push it up, the band will change to
FM1, FM2, or AM. On the FM bands,
STEREO will be shown on the
navigation screen and ST on the
center display, if the station is
broadcasting in stereo. Stereo
reproduction on AM is not available.
On the AM band, AM noise
reduction turns on automatically.
You can use any of f ive methods to
f ind radio stations on the selected
band: tune, skip (seek), scan, the
preset buttons, and auto select.
On the FM band, you can also use
the f eatures provided by the radio
data system (RDS). For more
information on the RDS, see
.
CONT INUED
T o Play the FM/A M Radio T o Select a Station
Playing the FM/A M Radio (Models with navigation system)
Features
181
STEREO ICONBAND
10/08/27 14:38:07 31TP6610_186
page 184
2011 Accord Crosstour

µµ
µ The skip (seek)
f unction searches up and down f rom
the current f requency to f ind a
station with a strong signal. To
activate it, press either side ( or ) of the SKIP bar, then release
it. You can also activate the skip
f unction (SEEK is displayed on the
screen) by pushing the interf ace
selector to the right or lef t.
The SCAN function
samples all stations with strong
signals on the selected band. To
activate it, press the SCAN side of
the SCAN/A.SEL bar, then release it.
To scan with the interf ace dial, push
the selector down, and then push it
to the right. You will see SCAN
f lashing on the screen.
Use the TUNE bar to tune
the radio to a desired f requency.
Press the right side of the bar to
tune to a higher f requency, or the
lef t side to tune to a lower f requency.
To tune with the interf ace dial, push
the selector down, and turn the knob
to the TUNE icon. Then press
ENTER on the selector, and turn the
knob to the desired f requency. To
exit the TUNE mode, press ENTER
on the selector, then push the
selector up. SK IP (SEEK )
SCAN
TUNE
Playing the FM/A M Radio (Models with navigation system)
182
SCAN ICON
TUNE ICON
10/08/27 14:38:13 31TP6610_187
2011 Accord Crosstour

µ
µ
If you are
traveling and can no longer receive
your preset stations, you can use the
auto select feature to find stations in
the local area.
Push the interf ace selector down to
scroll down the screen, highlight
A.SEL, then press ENTER on the
interf ace selector. You will see
A.SEL on the screen, and the system
goes into scan mode f or several
seconds.
Usethetune,skip(seek),scan,or
RDS function to tune the radio to a
desired station.
Repeat steps 1 through 3 to store a
total of six stations on AM and
twelve stations on FM.
When the system finds a strong
signal, it will stop and play that
station f or about 10 seconds. If you
do nothing, the system will then scan
f or the next strong station and play it
f or 10 seconds. When it plays a
station that you want to listen to,
press the scan side of the bar again,
or push the interf ace selector to the
right again.
Each preset button or
preset icon can store one f requency
on AM and two f requencies on FM. Press the preset button, and hold
it until you hear a beep. You can
also store f requencies with the
interf ace dial. Select the preset
icon you want to store the
f requency on, then press ENTER
on the interf ace selector, and hold
it f or more than 2 seconds.
Select the desired band, AM or
FM. FM1 and FM2 let you store
twosetsof FMfrequencieswith
the preset buttons (on-screen
icons). 2.
3.
4.
1.
CONT INUED
To store a preset memory location:
AUTO SELECT
Preset
Playing the FM/A M Radio (Models with navigation system)
Features
183
PRESET ICON
A.SEL ICON
A.SEL ICON
10/08/27 14:38:22 31TP6610_188
2011 Accord Crosstour

On the FM band, you can select a
favorite station and display the
program service name provided by
the radio data system (RDS).
The RDS INFO display f unction
shows the name of the station you
are listening to. With the audio
system on and the FM band selected,
you can turn this f unction on or of f .
,pressthe
A. SEL side of the bar. This restores
the presets you originally set.
For inf ormation on FM/AM radio
frequencies and reception, see .
You will see ‘‘0’’ displayed if auto
select cannot f ind a strong station f or
every preset button. You can also press the A.SEL side of
the SCAN/A.SEL bar. You will see
A.SEL on the screen, and the system
goes into scan mode f or several
seconds. The system stores the
f requencies of six AM and twelve
FM stations in the preset buttons. press ENTER
on the interf ace selector.
If you do not like the stations auto
select has stored, you can store
other f requencies on the preset
buttons (icons) as previously
described.
To turn of f auto select
To turn of f auto select,
Playing the FM/A M Radio (Models with navigation system)
Radio Data System (RDS)
RDS INFO Display
184
10/08/27 14:38:30 31TP6610_189
page 231
2011 Accord Crosstour

With the FM band selected, you can
select the program type provided by
the RDS. Press the AUDIO button to
display the radio inf ormation on the
screen. Push down the selector on
the interf ace dial, then turn the knob
to select RDS SEARCH icon. Press
ENTER to set your selection. The
principal RDS categories are shown
as f ollows:
If the station you are listening to is
not an RDS station, the audio screen
and the center display continue to
show the f requency.
When you turn of f this f unction by
pressing the TITLE button, the
center display shows ‘‘RDS INFO
OFF.’’
To switch the function between on
and off, press and release the TITLE
button. With the system on, you will
see the ‘‘RDS INFO ON’’ message on
the display. If the station you are
listening to is an RDS station, the
display shows the station name.
CONT INUED
Playing the FM/A M Radio (Models with navigation system)
Radio Data System (RDS) Category
Features
185
RDS SEARCH ICON
RDS INFO DISPLAY ON
10/08/27 14:38:38 31TP6610_190
