2011 HONDA ACCORD COUPE Owners Manual

Tousethevanitymirrorontheback
of the sun visor, pull up the cover.
The vanity mirror lights come on
when you pull up the cover.Touseacoathook,slideitout
slightly, then pull it down.
Make sure the coat hook is f olded up
when you are not using it. This hook
is not designed f or large or heavy
items.Pull up the lid to open each pocket.
Vanity Mirror
Coat HookCenter Pockets
Interior Convenience Items
118
Vehicle without navigation system
is shown.
10/06/18 15:57:17 31TA5630_123
2011 Accord Sedan

The ceiling light has a three-position
switch: ON, Door Activated, and
OFF. In the Door Activated (center)
position, the light comes on when
you:After all doors are closed tightly, the
light dims slightly, then f ades out in
about 30 seconds.
The ceiling light (with the switch in
the center position) comes on when
you remove the key f rom the ignition
switch. If you do not open a door, the
light stays on, then f ades out in
about 30 seconds.
Turn on a spotlight by pushing the
lens. Push the lens again to turn it
of f . You can use the spotlights at all
times.
If you leave any door open without
the key in the ignition switch, the
ceiling light will go of f af ter about 15
minutes.
Unlock the driver’s door with the
keyorremotetransmitter. Open any door.
CONT INUED
Ceiling L ight Spotlights
Interior Lights
Inst rument s and Cont rols
119
DOOR ACTIVATED POSITION
LX, LX-P, SE
10/06/18 15:57:26 31TA5630_124
2011 Accord Sedan

The spotlights have a two-position
switch. In the DOOR position, the
lights come on when you open any
door. The lights f ade out in about 30
seconds af ter the doors are closed
tightly. In the OFF position, the
lights do not come on.The spotlights (with the switch in
the DOOR position) also come on
when you unlock the door with the
key or the remote transmitter, and
when you remove the key f rom the
ignition switch.
The courtesy light in each f ront door
comes on when the door is opened,
and goes out when the door is closed.
Your vehicle also has a courtesy light
in the ignition switch. This light
comesonwhenyouopenthedriver’s
door. It f ades out in about 30
seconds af ter the door is closed.
Except LX
,LX-P, and SE
Courtesy Lights
Interior Lights
120
DOOR ACTIVATED SPOTLIGHT OFF POSITION
10/06/18 15:57:32 31TA5630_125
2011 Accord Sedan

The heating and air conditioning
system in your vehicle provides a
comf ortable driving environment in
all weather conditions.
The standard audio system has
many f eatures. This section
describes those f eatures and how to
use them.
Your vehicle has an anti-theft audio
system that requires a code number
to enable it.
The security system helps to.............
Vents, Heating, and A/C . 122
...............
Climate Control System . 128
................................
Audio System .136
..........
Playing the FM/AM Radio . 137
................................
Playing a Disc .144
.......
Disc Player Error Messages . 150
................................
Audio System .151
..........
Playing the FM/AM Radio . 152
................
Playing the XM
Radio . 159
.................................
Playing Discs .165
...
Disc Changer Error Messages . 175
............................
PlayinganiPod
. 176
.................
iPod
Error Messages . 184
Playing a USB Flash Memory ........................................
Device .185
USB Flash Memory Device ........................
Error Messages .193
................................
Audio System .194
..........
Playing the FM/AM Radio . 195
................
Playing the XM
Radio . 207
.................................
Playing Discs .214
...
Disc Changer Error Messages . 225............................
PlayinganiPod
. 226
.................
iPod
Error Messages . 234
Playing a USB Flash Memory ........................................
Device .235
USB Flash Memory Device ........................
Error Messages .244
..................
Protecting Your Discs . 245
............
FM/AM Radio Reception . 248
................
Remote Audio Controls . 250
......................
Auxiliary Input Jack .252
.................
Radio Thef t Protection . 253
..........................
Setting the Clock .254
............................
Security System .257
.........................................
Compass .259
...............................
Cruise Control .263
HomeLink
Universal ................................
Transceiver .266
........
HandsFreeLink
. 270
...
Rearview Camera and Monitor . 294
LX, LX-P,andU.S. SE models
EX, EX-L, Canadian SE, andV6
models without navigation system
Models with navigation system Bluetooth
Except LX
Except LX
,LX-P, and SE
Features
Features
121
10/06/18 18:02:48 31TA5630_126
discourage vandalism and theft of
your vehicle.
2011 Accord Sedan

Î
Î
: If equipped
Vents, Heating, and A/C
LX,LX-P,SE,U.S.EX,andU.S.EXV6
122
MODE CONTROL
BUTTONS
FAN CONTROL DIAL RECIRCULATION BUTTON
TEMPERATURE CONTROL DIAL
MAX A/C BUTTON AIR CONDITIONING (A/C)
BUTTON
REAR WINDOW DEFOGGER/
HEATED MIRROR BUTTON
REAR WINDOW DEFOGGER
BUTTON
10/06/18 15:57:42 31TA5630_127
2011 Accord Sedan

Turn this dial to increase or decrease
the fan speed and airflow.
Turning this dial clockwise increases
the temperature of the airflow.
This button turns the air
conditioning on and of f . The
indicatorinthebuttonisonwhen
the A/C is on.The system automatically
turns on the A/C and switches to
recirculation mode (see page to
use this setting). Air f lows f rom the
center and side vents in the
dashboard. Pressing the , A/C,
or any of the mode buttons cancels
MAX A/C, but the A/C stays on. When the recirculation indicator is
on, air f rom the vehicle’s interior is
sent throughout the system again.
When the indicator is off, air is
brought in f rom the outside of the
vehicle (fresh air mode).
The outside air intakes f or the
heating and cooling system are at
the base of the windshield. Keep this
area clear of leaves and other debris.
Thesystemshouldbeleftinfresh
air mode under almost all conditions.
Keeping the system in recirculation
mode, particularly with the A/C of f ,
can cause the windows to fog up.
Switch to recirculation mode when
driving through dusty or smoky
conditions, then return to fresh air
mode.
This button turns the rear window
def ogger on and of f (see page ).
Pushing this button also turns the
power mirror heaters on and of f .
/
74
126
Except U.S. LX, LX-P andSE
Vents, Heating, and A/C
Fan Control
T emperature Control
Air Conditioning (A/C) Button
MAX A/C Button Recirculation Button
Rear Window Def ogger
Button
Features
123
10/06/18 15:57:56 31TA5630_128
2011 Accord Sedan

ÎÎ
Î When you select or ,
the system automatically switches to
f resh air mode and turns on the A/C.
You cannot turn the A/C of f in this
mode.
Air f lows f rom the def roster
vents at the base of the windshield. When you select , the system
automatically switches to f resh air
mode. If you switch the mode f rom or to , the system
keeps the A/C on. The A/C
indicator will not come on if it was
off to start with.
To turn of f the A/C, press the A/C
button to illuminate the indicator,
then press it again to turn off the
A/C.
When you switch to or mode f rom , the A/C
turnsoff.Butifitwasontostart
with, the A/C stays on.
Airf low is divided between
the f loor vents and the def roster
vents at the base of the windshield.
Use the mode control buttons to
select the vents air flows from. Some
air will f low f rom the dashboard
corner vents in all modes.
Air flows from the center
and corner vents in the dashboard,
and the vents on the back of the
center console .
Airf low is divided between
the vents in the dashboard and the
back of the center console , and the
f loor vents.
Air f lows f rom the f loor
vents.
If equipped
:
Vents, Heating, and A/C
Mode Control
124
10/06/18 15:58:09 31TA5630_129
2011 Accord Sedan

CONT INUED
The ventilation system draws in
outside air, circulates it through the
interior, then releases it through
vents near the rear window.
The direction of airf low f rom the
vents in the center and each side of
the dashboard, and on the back of
the center console is adjustable.The heater uses engine coolant to
warm the air. If the engine is cold, it
will be several minutes bef ore you
f eel warm air coming f rom the
system.
Select .
When you select , the system
automatically switches to f resh air
mode. If you switch the mode
f rom or , the system
also automatically turns on the
A/C. This helps prevent the
windows f rom f ogging up
unintendedly. The A/C indicator
willnotcomeonifitwasoffto
start with (see the f irst column on
this page).
Set the f an to the desired speed.
Adjust the warmth of the air with
the temperature control dial.
Set the temperature to the lower
limit.
Make sure the A/C is of f .
Select and fresh air mode.
Set the f an to the desired speed.
Turn on the A/C by pressing the
button. The indicator in the button
comesonwhenafanspeedis
selected.
Make sure the temperature is set
to maximum cool.
Select .
If the outside air is humid, select
recirculation mode. If the outside
air is dry, select f resh air mode.
Set the f an to the desired speed.
Air conditioning places an extra load
on the engine. Watch the engine
coolant temperature gauge (see page
). If it moves near the red zone,
turn of f the A/C until the gauge
reading returns to normal.
you can
cool it down more rapidly by partially
opening the windows, turning on the
air conditioning, and setting the f an
to maximum speed in f resh air mode.
1.
2.
3.
4.
1.
2.
3.1.
2.
3.
4.
5.66
If the interior is very warm,
Vents, Heating, and A/C
Ventilation
Using the Heater Using the A /C
Features
125
10/06/18 15:58:21 31TA5630_130
2011 Accord Sedan
