Black plate (62,1)GMC Sierra Owner Manual - 2011
10-62 Vehicle Care
(B) Tire Width:The three‐digit
number indicates the tire section
width in millimeters from
sidewall to sidewall.
(C) Aspect Ratio
:A two‐digit
number that indicates the tire
height‐to‐width measurements.
For example, if the tire size
aspect ratio is 75, as shown
in item C of the light truck
(LT‐Metric) tire illustration,
it would mean that the tire's
sidewall is 75 percent as high
as it is wide.
(D) Construction Code
:A
letter code is used to indicate
the type of ply construction in
the tire. The letter R means
radial ply construction; the
letter D means diagonal or
bias ply construction; and the
letter B means belted‐bias ply
construction. (E) Rim Diameter
:Diameter of
the wheel in inches.
(F) Load Range
:Load Range.
(G) Service Description
:The
service description indicates the
load index and speed rating of a
tire. If two numbers are given as
in the example, 120/116, then
this represents the load index for
single versus dual wheel usage
(single/dual). The speed rating
is the maximum speed a tire is
certified to carry a load.
Tire Terminology and
Definitions
Air Pressure:The amount
of air inside the tire pressing
outward on each square inch
of the tire. Air pressure is
expressed in psi (pounds per
square inch) or kPa (kilopascal). Accessory Weight
:This
means the combined weight
of optional accessories.
Some examples of optional
accessories are, automatic
transmission, power steering,
power brakes, power windows,
power seats, and air
conditioning.
Aspect Ratio
:The relationship
of a tire's height to its width.
Belt
:A rubber coated layer of
cords that is located between
the plies and the tread. Cords
may be made from steel or
other reinforcing materials.
Bead
:The tire bead contains
steel wires wrapped by steel
cords that hold the tire onto
the rim.

Black plate (113,1)GMC Sierra Owner Manual - 2011
Vehicle Care 10-113
Your dealer has products for
cleaning the interior. When cleaning
the interior, only use cleaners
specifically designed for the
surfaces that are being cleaned.
Permanent damage can result
from using cleaners on surfaces
for which they were not intended.
Apply the cleaner directly to the
cleaning cloth to prevent over-spray.
Remove any accidental over-spray
from other surfaces immediately.
Notice:Using abrasive cleaners
when cleaning glass surfaces on
the vehicle, could scratch the
glass and/or cause damage to
the rear window defogger. When
cleaning the glass on the vehicle,
use only a soft cloth and glass
cleaner. Cleaners can contain solvents that
can become concentrated in the
interior. Before using cleaners,
read and adhere to all safety
instructions on the label. While
cleaning the interior, maintain
adequate ventilation by opening
the doors and windows.
Do not clean the interior using the
following cleaners or techniques:
.Never use a knife or any other
sharp object to remove a soil
from any interior surface.
.Never use a stiff brush. It can
cause damage to the interior
surfaces.
.Never apply heavy pressure or
rub aggressively with a cleaning
cloth. Use of heavy pressure can
damage the interior and does
not improve the effectiveness
of soil removal.
.Use only mild, neutral-pH soaps.
Avoid laundry detergents
or dishwashing soaps with
degreasers. Using too much
soap will leave a residue that
leaves streaks and attracts
dirt. For liquid cleaners, about
20 drops per 3.78 L (1 gal) of
water is a good guide.
.Do not heavily saturate the
upholstery while cleaning.
.Cleaners that contain solvents
can damage the interior.

Black plate (8,1)GMC Sierra Owner Manual - 2011
i-8 INDEX
Lap Belt . . . . . . . . . . . . . . . . . . . . . . . 3-26
Lap-Shoulder Belt . . . . . . . . . . . . . 3-21
LATCH SystemReplacing Parts After aCrash . . . . . . . . . . . . . . . . . . . . . . . 3-66
Latch, Lower Anchors and Tethers for Children . . . . . . . . . . 3-57
Lighter, Cigarette . . . . . . . . . . . . . . 5-11
Lighting Entry . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
Illumination Control . . . . . . . . . . . . 6-7
Lights Airbag On-Off . . . . . . . . . . . . . . . . . 5-21
Airbag Readiness . . . . . . . . . . . . . 5-20
Antilock Brake System(ABS) Warning . . . . . . . . . . . . . . 5-28
Brake System Warning . . . . . . . 5-27
Charging System . . . . . . . . . . . . . 5-24
Cruise Control . . . . . . . . . . . . . . . . 5-32
Engine Oil Pressure . . . . . . . . . . 5-31
Flash-to-Pass . . . . . . . . . . . . . . . . . . 6-3
Four-Wheel-Drive . . . . . . . . . . . . . 5-29
Front Fog Lamps . . . . . . . . . . . . . 5-32 Lights (cont.)
High-Beam On . . . . . . . . . . . . . . . . 5-32
High/Low Beam Changer . . . . . . 6-3
Low Fuel Warning . . . . . . . . . . . . 5-31
Safety Belt Reminders . . . . . . . . 5-19
Security . . . . . . . . . . . . . . . . . . . . . . 5-32
StabiliTrak
®Indicator . . . . . . . . . 5-30
Tire Pressure . . . . . . . . . . . . . . . . . 5-30
Tow/Haul Mode . . . . . . . . . . . . . . . 5-29
Locking Rear Axle . . . . . . . . . . . . . 9-73
Locks Automatic Door . . . . . . . . . . . . . . . . 2-9
Delayed Locking . . . . . . . . . . . . . . . 2-8
Door . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Lockout Protection . . . . . . . . . . . . . 2-9
Power Door . . . . . . . . . . . . . . . . . . . . 2-8
Safety . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Loss of Control . . . . . . . . . . . . . . . . . 9-6
Low Fuel Warning Light . . . . . . . . 5-31
Lower Anchors and
Tethers for Children
(LATCH SYSTEM) . . . . . . . . . . . 3-57
Lumbar Adjustment . . . . . . . . . . . . . 3-6
Front Seats . . . . . . . . . . . . . . . . . . . . 3-6
M
MaintenanceRecords . . . . . . . . . . . . . . . . . . . . .11-12
Maintenance Schedule Recommended Fluids andLubricants . . . . . . . . . . . . . . . . . . . 11-8
Scheduled Maintenance . . . . . . 11-2
Transfer Case . . . . . . . . . . . . . . . . 9-54
Malfunction Indicator Lamp . . . . 5-25
Manual Mirrors . . . . . . . . . . . . . . . . 2-15
Manual Mode . . . . . . . . . . . . . . . . . . 9-50
Manual Windows . . . . . . . . . . . . . . 2-19
Memory Features . . . . . . . . . . . . . . 1-13
Messages Airbag System . . . . . . . . . . . . . . . . 5-48
Anti-Theft Alarm System . . . . . . 5-48
Battery Voltage andCharging . . . . . . . . . . . . . . . . . . . . 5-41
Brake System . . . . . . . . . . . . . . . . 5-42
Door Ajar . . . . . . . . . . . . . . . . . . . . . 5-43
Engine Cooling System . . . . . . . 5-44
Engine Oil . . . . . . . . . . . . . . . . . . . . 5-45
Engine Power . . . . . . . . . . . . . . . . 5-45

Black plate (10,1)GMC Sierra Owner Manual - 2011
i-10 INDEX
Passenger Airbag StatusIndicator . . . . . . . . . . . . . . . . . . . . . 5-23
Passenger Sensing System . . . 3-40
Perchlorate Materials Requirements, California . . . . . 10-3
Personalization Vehicle . . . . . . . . . . . . . . . . . . . . . . . 5-52
Phone Bluetooth . . . . . . . . . . . . . . . . . . . . . 7-50
Pickup Conversion to Chassis Cab . . . . . . . . . . . . . . . . 9-129
Pickup-Box Identification and Fender Marker
Lamps . . . . . . . . . . . . . . . . . . . . . . 10-45
Power Door Locks . . . . . . . . . . . . . . . . . . . . 2-8
Mirrors . . . . . . . . . . . . . . . . . . . . . . . . 2-16
Outlets . . . . . . . . . . . . . . . . . . . . . . . 5-10
Protection, Battery . . . . . . . . . . . . 6-10
Retained Accessory (RAP) . . . 9-40
Seat Adjustment . . . . . . . . . . . . . . . 3-4
Steering Fluid . . . . . . . . . . . . . . . 10-29
Windows . . . . . . . . . . . . . . . . . . . . . 2-19 Pregnancy, Using Safety
Belts . . . . . . . . . . . . . . . . . . . . . . . . . 3-26
Privacy Radio FrequencyIdentification (RFID) . . . . . . . 13-19
Program Courtesy Transportation . . . . .13-11
Proposition 65 Warning, California . . . . . . . . . . . . . . . . . . . . . 10-3
R
Radio FrequencyIdentification (RFID) . . . . . . . . 13-19
Statement . . . . . . . . . . . . . . . . . . 13-19
Radios AM-FM Radio . . . . . . . . . . . . . . . . . . 7-8
CD/DVD Player . . . . . . . . . . . . . . . 7-22
Reception . . . . . . . . . . . . . . . . . . . . 7-14
Satellite . . . . . . . . . . . . . . . . . . . . . . . 7-10
Reading Lamps . . . . . . . . . . . . . . . . . 6-9
Rear Axle . . . . . . . . . . . . . . . . . . . . . 10-37 Locking . . . . . . . . . . . . . . . . . . . . . . . 9-73 Rear Doors . . . . . . . . . . . . . . . . . . . . 2-10
Rear Seat Audio (RSA)
System . . . . . . . . . . . . . . . . . . . . . . . 7-48
Rear Seat Entertainment System . . . . . . . . . . . . . . . . . . . . . . . 7-39
Rear Seat Audio (RSA) . . . . . . . 7-48
Rear Seats . . . . . . . . . . . . . . 3-10, 3-11
Rear Vision Camera (RVC) . . . . 9-78
Rear Windows . . . . . . . . . . . . . . . . . 2-20
Rearview Mirrors . . . . . . . . . . . . . . 2-18 Automatic Dimming . . . . . . . . . . . 2-18
Reclining Seatbacks . . . . . . . . . . . . 3-6
Recommended Fluids and Lubricants . . . . . . . . . . . . . . . . . . . . 11-8
Recommended Fuel . . . . . . . . . . . 9-84
Records Maintenance . . . . . . . . . . . . . . . . .11-12
Recreational Vehicle Towing . . . . . . . . . . . . . . . . . . . . .10-103
Reimbursement Program, GM Mobility . . . . . . . . . . . . . . . . . . 13-7
Remote Keyless Entry (RKE) System . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Black plate (14,1)GMC Sierra Owner Manual - 2011
i-14 INDEX
U
Ultrasonic Parking Assist . . . . . . 9-76
Uniform Tire QualityGrading . . . . . . . . . . . . . . . . . . . . . 10-80
Universal Remote System . . . . . 5-61 Operation . . . . . . . . . . . . . . . . . . . . . 5-67
Programming . . . . . . . . . . . . . . . . . 5-61
Using this Manual . . . . . . . . . . . . . . . . iv
V
Vehicle Canadian Owners . . . . . . . . . . . . . . . iii
Control . . . . . . . . . . . . . . . . . . . . . . . . 9-3
IdentificationNumber (VIN) . . . . . . . . . . . . . . . 12-1
Load Limits . . . . . . . . . . . . . . . . . . . 9-25
Messages . . . . . . . . . . . . . . . . . . . . 5-41
Personalization . . . . . . . . . . . . . . . 5-52
Reminder Messages . . . . . . . . . . 5-50
Remote Start . . . . . . . . . . . . . . . . . . 2-5
Security . . . . . . . . . . . . . . . . . . . . . . 2-12
Towing . . . . . . . . . . . . . . . . . . . . . 10-103 Vehicle Care
Tire Pressure . . . . . . . . . . . . . . . 10-66
Vehicle Identification Service Parts IdentificationLabel . . . . . . . . . . . . . . . . . . . . . . . . 12-1
Ventilation, Air . . . . . . . . . . . . . . . . . 8-11
Visors . . . . . . . . . . . . . . . . . . . . . . . . . 2-20
Voltmeter Gauge . . . . . . . . . . . . . . 5-18
W
Warning Brake System Light . . . . . . . . . . . 5-27
Warning Lights, Gauges,
and Indicators . . . . . . . . . . . . . . . . 5-12
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . iv Cautions and Danger . . . . . . . . . . . .iv
Hazard Flashers . . . . . . . . . . . . . . . 6-5
Washer Fluid . . . . . . . . . . . . . . . . . 10-29
Washer Fluid Messages . . . . . . . 5-51 Wheels
Alignment and Tire
Balance . . . . . . . . . . . . . . . . . . . 10-81
Different Size . . . . . . . . . . . . . . . 10-79
Replacement . . . . . . . . . . . . . . . 10-82
When It Is Time for New Tires . . . . . . . . . . . . . . . . . . . . . . . . 10-76
Where to Put the Restraint . . . . 3-56
Windows . . . . . . . . . . . . . . . . . . . . . . 2-18 Manual . . . . . . . . . . . . . . . . . . . . . . . 2-19
Power . . . . . . . . . . . . . . . . . . . . . . . . 2-19
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . 2-20
Windshield Wiper/Washer . . . . . . . . . . . . . . . . . 5-5
Winter Driving . . . . . . . . . . . . . . . . . 9-21
Wiper Blade Replacement . . . . 10-41
