UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS
Instrument Panel Features ............... 242
 Instrument Cluster .................... 243
 Instrument Cluster Descriptions ........... 244
 Electronic Vehicle Information Center (EVIC) . . 254
▫ Electronic Vehicle Information Center (EVIC)
Displays ........................... 256
▫ EVIC White Telltale Lights .............. 260
▫ EVIC Amber Telltale Lights ............. 262
▫ EVIC Red Telltale Lights ............... 264 ▫
Engine Oil Change Indicator System ....... 267
▫ Fuel Economy ...................... 268
▫ Vehicle Speed ....................... 269
▫ Trip Info .......................... 269
▫ Vehicle Info
(Customer Information Features) ......... 270
▫ Units ............................. 271
▫ Keyless Enter-N-Go Display —
If Equipped ........................ 271
▫ Compass / Temperature Display ......... 271
4

▫Customer-Programmable Features
(System Setup) ...................... 274
▫ System Status ....................... 282
 Media Center 730N/430/430N (RHR/RER/
RBZ/RHB) CD/DVD/HDD/NAV —
If Equipped .......................... 283
▫ Operating Instructions (Voice Command
System) — If Equipped ................ 283
▫ Operating Instructions
(Uconnect™ Phone) — If Equipped ....... 283
 Media Center 130 (Sales Code RES) ......... 284
▫ Operating Instructions — Radio Mode ..... 284
▫ Operation Instructions — CD Mode For CD
And MP3 Audio Play ................. 287
▫ Notes On Playing MP3 Files ............ 289▫
Operation Instructions - Auxiliary Mode .... 292
 Media Center 130 With Satellite Radio
(Sales Code RES+RSC) ................... 292
▫ Operating Instructions — Radio Mode ..... 293
▫ Operation Instructions — CD Mode For CD
And MP3 Audio Play ................. 298
▫ Notes On Playing MP3 Files ............ 300
▫ List Button (CD Mode For MP3 Play) ...... 303
▫ Info Button (CD Mode For MP3 Play) ...... 303
▫ Uconnect™ Multimedia (Satellite Radio) —
If Equipped ........................ 304
▫ Operating Instructions
(Uconnect™ Phone) — If Equipped ....... 308
240 UNDERSTANDING YOUR INSTRUMENT PANEL

iPod/USB/MP3 Control — If Equipped ..... 308
▫ Connecting The iPod Or External USB
Device ............................ 309
▫ Using This Feature ................... 310
▫ Controlling The iPod Or External USB
Device Using Radio Buttons ............. 310
▫ Play Mode ......................... 310
▫ List Or Browse Mode ................. 312
▫ Bluetooth Streaming Audio (BTSA) ........ 314
 Uconnect™ Multimedia
(Sirius Backseat TV™) — If Equipped ........ 315
 Video Entertainment System™
(Sales Code XRV) — If Equipped ........... 315
Steering Wheel Audio Controls ............ 316
▫ Radio Operation ..................... 317
▫ CD Player ......................... 318
 CD/DVD Disc Maintenance .............. 318
 Radio Operation And Mobile Phones ....... 319
 Climate Controls ...................... 319
▫ Dual-Zone Automatic Temperature Control
(ATC) — If Equipped ................. 319
▫ Rear Climate Control — If Equipped ...... 326
▫ Operating Tips ...................... 328
▫ Operating Tips Chart ................. 330
4
UNDERSTANDING YOUR INSTRUMENT PANEL 241

INSTRUMENT PANEL FEATURES
1 — Air Outlet6 — Lower Switch Bank11 — Headlight Switch
2 — Instrument Cluster 7 — Hazard Switch12 — Hood Release
3 — Radio 8 — Storage Bin13 — Fuel Door Release
4 — Glove Compartment 9 — ESC Off Switch14 — Dimmer Control
5 — Climate Controls 10 — Ignition Switch
242 UNDERSTANDING YOUR INSTRUMENT PANEL

INSTRUMENT CLUSTER
4
UNDERSTANDING YOUR INSTRUMENT PANEL 243

INSTRUMENT CLUSTER DESCRIPTIONS
1. Tachometer
Indicates the engine speed in revolutions per minute
(RPM x 1000).
2. Tire Pressure Monitoring Telltale LightEach tire, including the spare (if provided),
should be checked monthly when cold and
inflated to the inflation pressure recommended
by the vehicle manufacturer on the vehicle
placard or tire inflation pressure label. (If your vehicle
has tires of a different size than the size indicated on the
vehicle placard or tire inflation pressure label, you should
determine the proper tire inflation pressure for those
tires.) As an added safety feature, your vehicle has been
equipped with a Tire Pressure Monitoring System
(TPMS) that illuminates a low tire pressure telltale when
one or more of your tires is significantly under-inflated.
Accordingly, when the low tire pressure telltale illumi-
nates, you should stop and check your tires as soon as
possible, and inflate them to the proper pressure. Driving
on a significantly under-inflated tire causes the tire to
overheat and can lead to tire failure. Under-inflation also
reduces fuel efficiency and tire tread life, and may affect
the vehicle’s handling and stopping ability.
Please note that the TPMS is not a substitute for proper
tire maintenance, and it is the driver ’s responsibility to
maintain correct tire pressure, even if under-inflation has
not reached the level to trigger illumination of the TPMS
low tire pressure telltale.
244 UNDERSTANDING YOUR INSTRUMENT PANEL

Your vehicle has also been equipped with a TPMS
malfunction indicator to indicate when the system is not
operating properly. The TPMS malfunction indicator is
combined with the low tire pressure telltale. When the
system detects a malfunction, the telltale will flash for
approximately one minute and then remain continuously
illuminated. This sequence will continue upon subse-
quent vehicle start-ups as long as the malfunction exists.
When the malfunction indicator is illuminated, the sys-
tem may not be able to detect or signal low tire pressure
as intended. TPMS malfunctions may occur for a variety
of reasons, including the installation of replacement or
alternate tires or wheels on the vehicle that prevent the
TPMS from functioning properly. Always check the
TPMS malfunction telltale after replacing one or more
tires or wheels on your vehicle, to ensure that the
replacement or alternate tires and wheels allow the TPMS
to continue to function properly.CAUTION!
The TPMS has been optimized for the original
equipment tires and wheels. TPMS pressures and
warning have been established for the tire size
equipped on your vehicle. Undesirable system opera-
tion or sensor damage may result when using re-
placement equipment that is not of the same size,
type, and/or style. Aftermarket wheels can cause
sensor damage. Do not use tire sealant from a can or
balance beads if your vehicle is equipped with a
TPMS, as damage to the sensors may result.
3. Malfunction Indicator Light (MIL) The Malfunction Indicator Light (MIL) is part of
an onboard diagnostic system called OBD II that
monitors engine and automatic transmission con-
trol systems. The light will illuminate when the key is in
the ON/RUN position before engine start. If the bulb
4
UNDERSTANDING YOUR INSTRUMENT PANEL 245

does not come on when turning the key from OFF to
ON/RUN, have the condition checked promptly.
Certain conditions, such as a loose or missing gas cap,
poor fuel quality, etc., may illuminate the light after
engine start. The vehicle should be serviced if the light
stays on through several of your typical driving cycles. In
most situations, the vehicle will drive normally and will
not require towing.
CAUTION!
Prolonged driving with the MIL on could cause
damage to the engine control system. It also could
affect fuel economy and drivability. If the MIL is
flashing, severe catalytic converter damage and
power loss will soon occur. Immediate service is
required.
WARNING!
A malfunctioning catalytic converter, as referenced
above, can reach higher temperatures than in normal
operating conditions. This can cause a fire if you
drive slowly or park over flammable substances such
as dry plants, wood, cardboard, etc. This could result
in death or serious injury to the driver, occupants or
others.
4. Electronic Stability Control (ESC) Activation/
Malfunction Indicator Light — If Equipped The “ESC Activation/Malfunction Indicator
Light” in the instrument cluster will come on
when the ignition switch is turned to the
ON/RUN position. It should go out with the
engine running. If the “ESC Activation/Malfunction In-
dicator Light” comes on continuously with the engine
running, a malfunction has been detected in the ESC
246 UNDERSTANDING YOUR INSTRUMENT PANEL
