Monitoring
Service indicator
More than 1 800 miles (3 000 km)remain before the next service is due
When the ignition is switched on, no ser vice information appears in the screen. S
ystem which informs the driver when the next ser vice is due, in accordance with themanufacturer's servicing schedule.
The point at which the ser vice is due is calculated from the last indicator zero reset. Itis determined by two parameters:


- the distance travelled,

- the time elapsed since the last ser vice.
Between 600 miles (1 000 km) and 1 800 miles (3 000 km) remain before the next service is due
For 5 seconds after the ignition is switched on, the
spanner symbolising the ser vice operations comes
on. The distance recorder displa
y line indicates the
distance remaining before the next ser vice is due.
Example:
1 700 miles (2 800 km) remain before the next service is due.
For 5 seconds after the ignition is switched on,
the screen indicates:
5 seconds a
fter the ignition is switched on,the spanner goes off; the distance recorder fresumes its normal operation. The screen thenindicates the total and trip distances.
Less than 600 miles (1 000 km) remainbefore the next service is due
Example:
400 miles (900 km) remain before
the next service is due.
For 5 seconds after the ignition is switched on,
the screen indicates:
5 seconds after the i
gnition is switched on,
the distance recorder resumes its normal
operation. The spanner remains onto indicate
that a service must be carried out soon.


Illumination of the key is accompaniedby a message in the instrument panel screen.

Service overdue
For 5 seconds after the ignition is switched on, the
spanner flashesto indicate that the service must be carried out as soon as possible.Example:the ser vice is overdue by 300 miles(300 km).
For 5 seconds after the ignition is switched on,
the screen indicates:
The distance remaining may be weighted by the time factor, dependingon the driving conditions.
Therefore, the spanner may also comeon if you have exceeded the two year service interval.
Following this operation, if you wish to disconnect the battery, lock the vehicle and wait at least five minutes for the zero reset to be taken into account. 5 seconds a
fter the ignition is switched on,
the distance recorder resumes its normal
operation. The spanner remains on.
Service indicator zero reset

After each ser vice, the ser vice indicator mustbe reset to zero.
The procedure for resetting to zero is as follows: )
switch off the ignition,)
press and hold the trip distance recorder
zero reset button,) switch on the ignition; the distance recorder display begins a countdown, )
when the display indicates "=0", release
the button; the spanner disappears.
Retrieving the serviceinformation

You can access the service information at
any time. )Press the trip distance recorder zero reset button.
The ser vice information is displayed for a few seconds, then disappears.

System for manual adjustment of the brightness of the instruments and controls in relation to
the exterior brightness.
Lighting dimmer

Activation

When the lighting is on:
)press the button to change the brightness
of the instruments and controls,)when the level of brightness required isreached, release the button.

Deactivation

When the lighting is off, or in day mode on
vehicles fitted with daytime running lamps,pressing the button does not have any effect.

System which measures the total distance
travelled by the vehicle during its life.
The total and trip distances are displayed for
thir ty seconds when the ignition is switched off,
when the driver's door is opened and when the
vehicle is locked or unlocked.
Total distance recorder
System which measures a distance travelledduring a day or other period since it was reset
to zero by the driver. ) With the ignition on, press the button until
zeros appear.



Trip distance recorder
In order to obser ve legislation, changethe units of distance (miles or km) tothose for the country you are passing through, using the configuration menu.

Tr i p c o m p u t e r
)When the trip required is displayed, press
the control for more than two secondsor use the left hand thumb wheel of the
steering mounted controls.
Tr ips "1"
and "2"are independent but their use is identical.
For example, trip "1"
can be used for daily
figures, and trip "2"
for monthly figures.
Instrument panel screen
Information displa
y
)Press the button on the end of the wiper control stalk
to display the various tabs in succession.- Th
e current information tab with:
●
the range,
●
the current fuel consumption,
●
the Stop & Star t time counter.


-
Trip "1"
with:
●
the average speed, for the first trip.
●
the average fuel consumption,


-
Trip "2"with:
●
the average speed, for the second trip.
●
the average fuel consumption,




Tr ip reset
- Radio or media.
- Satellite navigation.

45
Monitoring
If dashes are displayed continuously
while driving in place of the digits, contact a CITROËN dealer or aqualified workshop.

This value may vary following a changein the style of driving or the relief,resulting in a significant change in thecurrent fuel consumption.
A few definitions…
Range
(miles or km)This indicates the distance
which can still be travelled with
the fuel remaining in the tank in relation to the average fuel consumption over the last few miles (kilometres) travelled.
When the range
falls below 20 miles (30 km),
dashes are displayed. After filling with at least5 litres of fuel, the range is recalculated and is
displayed when it exceeds 60 miles (10 0 km).
This function is only displayed from 20 mph (30 km/h).


Current fuel consumption
(mpg or l/100 km or km/l)
This is the average fuel consumption
during the last few seconds.
Average fuelconsumption
(mpg or l/100 km or km/l)
This is the average fuel consumption since the last tripcomputer zero reset.
Average speed
(mph or km/h)
This is the average speed calculated
since the last trip computer zero reset
(ignition on).
Stop & Start timecounter
(minutes/seconds or hours/minutes)
If your vehicle is fitted with Stop & Star t, a time counter calculates the time spent in STOP
mode during a journey. It resets to zero every time the ignition is switched on with the STA R T/STOP button.

01 FIRST STEPS
Short press: select a preset
radio station.
Lon
g press: store the current
radio station.
TA
(Traffi c Announcement)
function On/Off. Displa
y the list of radio stations received,CD/MP3/iPod tracks or folders.
Lon
g press: update the list of stationsreceived.

A
ccess to "Audio
settings
": musical
ambiences, bass, treble,
loudness, distribution, left/
ri
ght balance, front/rear
fader, automatic volume
adjustment.
Select the wave band from AM/FM/DAB.
Short press: CD eject.
Pr
ess and hold: reinitialisethe system.

Select the source:CD, USB, AUX, iPod,
Bluetooth Streaming, Radio.
Abandon the current
operation, go up one level.
Lon
g press: return topermanent display.

On/Off.
MOD
Ebutton: select the type
of permanent display.
Rotation: ad
just volume(each source is independent,
including TA messages and navigation instructions).
Select:
- the previous/next line in a list or menu.
- the previous next media
folder.
- step by step previous
/next radio frequency.
- previous
/next MP3 folder.
Move u
p/down, in "Move the map
" mode.
Select:
- automaticall
y the previous/next radio frequency.
- the previous
/next CD, MP3 or media track.
BLA
CK PANEL
button:
display black screen.

Mute
/restore sound.

SRC

02


-
+
-Rotation
Radio -automatic selection of
next/previous frequency.
Media: previous/next track.

-
Press then rotation: access to6 preset stations.


-
Change the audio source.


-
TEL button:
A
ccept an incoming call
.
Call in progress: access to telephone
menu: hang up, secret mode,
hands-free mode.
-
TEL button (long press):
Reject an incoming call or enda call in progress.
When not making a call, access to
the telephone menu
(Dial, Contacts, Calls log, Voice mailbox).
-
Increase volume.

-
Decrease volume.
-
Radio: display the list of stations.
Media: display the list of tracks.

08
1a
1b
1c
1
2
279
RADIO
By alphabetical list
Pr
ess RADIOor LIST , select the station
of your choice and confi rm.
B
y automatic frequency search
Press or for the automatic searchfor a lower or higher radio frequency.
Or turn the thumb wheel at the steeringmounted controls.
B
y manual frequency search
Pr
ess or to adjust the radiofrequency step by step.
Pr
ess the button on the numerical keypad to recall a preset station.

Or press then turn the thumb wheel at
the steering mounted controls.








SELECTING A STATION


The external environment (hill, building, tunnel, underground car park...) may interfere with the reception, including in RDS station tracking mode. Thisphenomenon is a normal result of the way in which radio waves are transmitted and does not in any way indicate a fault with the audio system.


PRESETTING A STATION


Press one of the buttons on thenumerical keypad for 2 seconds to preset the current station.
An audible si
gnal confi rms that thestation has been preset. The qualit
y of reception is represented by the number of active waves in this symbol.
