Electronic key: Keyless Entryand Starting
This system allows you to unlock, lock and star t
your vehicle while keeping the key on your person and in the defined zone around the vehicle.
48, 94
Exterior

Stop & Start

This system puts the engine temporarily into standby during stops
in the traffic (red lights, traffic jams, etc...). The engine restarts
automatically as soon as you want to move off. The Stop & Start
system reduces fuel consumption and exhaust emissions, and offers
the comfor t of complete silence when stationary.
116

Directional lighting

This lighting automatically provides additional forward visibility when cornering.
14
1

Daytime running lamps
This lighting, switched on automatically when
starting the engine, makes your vehicle more
visible to other road users.
135

11Familiarisation
Interior


Head-up display

This system projects speed and cruise control/speed limiter information onto a smoked strip
in the driver's field of vision, so that they do not need to take their eyes off the road.

Central storage containing
various systems
It is illuminated, cooled and provides storage
and locations for s
ystems and loose items (USB Player , location for 0.5 litre bottle, ...).
Audio and communication
systems
These systems benefit from the latest
technology: MP3 compatible audio systems, USB player, Bluetooth hands-free system, satellite navigation system with colour screen,
auxiliary inputs, Hi-Fi audio system, ...
eMyWay
120
7
8
299
245
Audio system

Massage function

This system provides a lumbar massage for aperiod of about 60 minutes. The massage is
done in 6 cycles of 10 minutes.
72
Electric parking brake
It combines the functions of automatic application on switching off the engine and automatic release when moving off. Manual application and release remains possible.
97

19Familiarisation
Monitoring
On switching on, the dial needles go to the extent of their travel then return to 0.
A.With the ignition on, the bars indicate the
fuel remaining.
B.With the engine running, the associated
low level warning lamp should go off.

Instrument panel
1.
With the ignition on, the orange and redwarning lamps come on. 2.With the engine running, these warninglamps should go off.
If a warning lamp remains on, refer to the page concerned.


Warning lamps
29
C.
With the ignition on, the instrument panelscreen should indicate the oil level.
If the levels are not correct, top up the level which is low.
28

21Familiarisation

If this warning lamp comes on in
the instrument panel, automatic application/release is deactivated
.
The parking brake must be appliedand released manually.

y
Before leaving the vehicle, check
that the the brake warning lamp and
the P warning lamp in the controllever A
are on fixed (not flashing).
97


If towing a trailer or caravan or if theslope might vary (transpor t by boat or lorry, recovery of the vehicle...) make a maximum application of theparking brake - by making a long pull on the control lever A- to immobilise the vehicle.
* Accordin
g to country of sale.

Driving safely


Electric parking brake


Manual Application/Release
Manual application
of the parking brake is possible by pulling
the control lever A. With the ignition on, manual releaseof theparking brake is possible by pressing the brake pedal
and pulling
then releasing
the control lever A
.

On opening the driver's door with theengine running, if an audible signalis heard, apply the parking brake
manually. Do not leave a child alone in the vehicle with the ignition on; they might release the parking brake.
Automatic Application/Release *
Press the accelerator and release the clutch(manual gearbox), the parking brake is releasedautomatically and progressively as you
move off. With the vehicle stationary, the parking brakeis applied automatically on switching off the
engine.

Driving safely
Speed limiter "LIMIT"
1.
Selecting speed limiter mode.2.
Decrease the programmed value.3.
Increase the programmed value.4.
Pause/resume speed limiter.5.
Display of the memorised speeds (by the audio system memory).These values must be set with the engine running.
12
3
125

Cruise control "CRUISE"
1.Selecting cruise control mode.
2. Programming a speed/Decrease
the programmed value. 3. Programming a speed/Increase
the programmed value. 4.Pause/resume cruise control.
5.Display of the memorised speeds (by the
audio system memory).
In order to be programmed or activated, the
vehicle speed must be higher than 25 mph
(40 km/h), with at least 4th gear engaged on
a manual gearbox (2nd gear on an electronicgear control or automatic gearbox).

Display in the instrument panel
The cruise control or speed limiter mode
appears in the instrument panel when it isselected.
Cruise control
S
peed limiter

23Familiarisation
Driving safely


Stop & Start


Going into engine STOP mode
116
The "ECO"warning lamp comes
on in the instrument panel and the
en
gine goes into standby; with theelectronic gearbox system andspeeds below 5 mph (8 km/h), press the brakepedal or put the gear lever in position N.
In certain circumstances, the STOP modemay not be available; the "ECO"warning lamp flashes for a few seconds, then goes off.
Going into engine START mode
Deactivation/Reactivation
117
11
7
The system is automatically reactivated every time the engine is star ted withthe STA R T/STOP button.

Before refuelling or doing anything under the bonnet, you must switchoff the ignition with the START/STOP button. Th
e "ECO"
warning lamp goes off
and the engine restar ts with theelectronic gearbox system:
- with the
gear lever in position A
or Mrelease the brake pedal,
- or with the gear lever in position N
andbrake pedal released, move the gear lever
to position A or M ,
- or engage reverse.
In certain circumstances, STA R T m o d e m ay beinvoked automatically; the "ECO"
warning lampflashes for a few seconds, then goes off. You can deactivate the s
ystem at any time bypressing the "ECO OFF"
button; the button's
warning lamp comes on.
Gear shift indicator
107

The system may suggest, when appropriate,
that you change up a gear.
