Page 110 of 396
This system allows automatic simultaneous locking of the doors and boot as soon as the speed of the vehicle exceeds 6 mph (10 km/h).
Anti-intrusion security
Operation
Activation/Deactivation
You can activate or deactivate this function
permanently.
)
With the ignition on, press this button
until an audible signal star ts and a
corresponding message is displayed. If one of the doors or the boot is open,
the automatic central locking does not take
place.
This is signalled by the sound of the
locks rebounding, accompanied by
illumination of this warning lamp in the
instrument panel, an audible signal
and the display of an aler t message.
Carr ying long and voluminous
objects
If you want to drive with the boot open,
you should press the central locking
button to lock the the doors. Other wise,
every time the speed of the vehicle
exceeds 6 mph (10 km/h), the locks
will rebound and the alerts mentioned
above will appear.
In the event of a serious impact with
deployment of an airbag, the vehicle's
doors unlock automatically to allow the
exit of occupants and access for the
security services.
Pressing the central locking button unlocks
the vehicle.
Above 6 mph (10 km/h), this locking is
temporary. The state of the system stays in memory when
switching off the ignition.
Page 111 of 396
109Access
Alarm *
System which protects and provides a deterrent against theft and break-ins. It provides the following types of monitoring.
- exterior perimeter
The system checks for opening of the vehicle.
The alarm is triggered if anyone tries to open a
door, the boot, the bonnet...
- interior volumetric
The system checks for any variation in the
volume in the passenger compartment.
The alarm is triggered if anyone breaks a
window, enters the passenger compar tment or
moves inside the vehicle.
Locking the vehicle with full
alarm system
- tilt
The system checks for any change in the
attitude of the vehicle.
The alarm is triggered if the vehicle is lifted,
moved or knocked.
Self-protection function
The system checks for the putting out of
ser vice of its components.
The alarm is triggered if the battery, the central
control or the siren wiring are put out of ser vice
or damaged.
For all work on the alarm system,
contact a CITROËN dealer or a
qualified workshop.
Activation
)
Switch off the ignition and get out of the vehicle.
)
Press the locking button on the remote control.
The monitoring system is active: the indicator
lamp in the button flashes once per second.
After the locking button on the remote control
is pressed, the exterior perimeter monitoring
is activated after a delay of 5 seconds and the
interior volumetric and anti-tilt monitoring after
a delay of 45 seconds.
Deactivation
)
Press the unlocking button on the remote
control.
The alarm system is deactivated: the indicator
lamp in the button goes off.
If an opening (door, boot...) is not
closed fully, the vehicle is not locked
but the exterior perimeter monitoring
will be activated after a delay of
45 seconds at the same time as
the interior volumetric and anti-tilt
monitoring.
*
According to country.
Page 116 of 396
Boot
System allowing the mechanical unlocking of
the boot in the event of a battery or central
locking system malfunction.
Ta i l g a t e r e l e a s e
Unlocking
)
Fold back the rear seats to gain access to
the lock from inside the boot.
)
Inser t a small screwdriver into hole A
of the
lock to unlock the tailgate.
)
Move the latch to the left.
)
After unlocking the boot or the vehicle
using the remote control or the key, press
the opening control, then raise the tailgate.
Opening
Closing
)
Lower the boot lid using the interior grab
handle.
- when the engine is running
,
this warning lamp comes on,
accompanied by the display of an
aler t message for a few seconds,
- when the vehicle is moving
(speed above
6 mph (10 km/h)), this warning lamp comes
on, accompanied by an audible signal and
the display of an aler t message for a few
seconds.
Locking after closing
If the fault persists after closing again, the boot
will remain locked.
If the tailgate is not closed correctly:
Page 140 of 396
This comes on automatically when the boot is
opened and switches off automatically when
the boot is closed.
Boot lamp
The lighting time varies according to
the circumstances:
- when the ignition is off,
approximately ten minutes,
- in energy economy mode,
approximately thirty seconds,
- when the engine is running, no limit.
Page 154 of 396
)
Lower the rear armrest.
)
Pull the flap handle downwards.
)
Lower the flap.
)
Load the objects from inside the boot.
Ski fl ap
Arrangement for storing and transporting long
objects.
Opening
)
Lower the rear armrest for a more
comfortable position.
This also gives access to the ski flap.
Rear armrest
Comfor t system for the rear passengers.
Page 155 of 396
153Fittings
1.
Rear parcel shelf
(see details on a following page)
2.
Hooks
(see details on a following page)
3.
12 V accessor y socket
(see details on a following page)
4.
To r c h
(see details on following pages)
5.
Lashing rings
6.
Storage box
(see details on following pages)
7.
Retaining strap
8.
Storage net
Boot fi ttings
Page 156 of 396
To remove the shelf:
)
unhook the two cords,
)
raise the shelf slightly, then remove it.
There are several options for storing the shelf:
- either upright behind the front seats,
- or flat at the base of the boot.
Rear parcel shelf
The hooks can be used to secure shopping
bags.
Hooks
Access to the storage box
An additional hook under the shelf is
used to hold up the boot floor using its
cord, to facilitate access to the tools
and spare wheel or the temporary
puncture repair kit...
Page 157 of 396
155Fittings
)
To connect a 12 V accessory
(max power: 120 W), remove the cap and
connect an appropriate adaptor.
)
Turn the key to the ignition on position.
12 V accessory socket
This is a removable lamp, fitted in the boot
wall, which can be used to light the boot or as
a torch.
For the boot lamp function, refer to the
"Visibility - § Boot lamp" section.
To r c h
Operation
This torch operates with NiMH type
rechargeable batteries.
It has a battery life of approximately 45 minutes
and charges while you are driving.
Obser ve the polarities when fitting the
rechargeable batteries.
Never replace the rechargeable batteries
with normal disposable batteries.
