TRAFFIC INFORMATION










CONFIGURE THE FILTERING AND
DISPLAY OF TMC MESSAGES

Then select the radius of the fi lter in
miles (km) required in accordance
with the route, press the dial to
confi rm.
When all of the messages on the
route are selected, the addition of a
geographical fi lter is recommended
(within a radius of 3 miles (5 km) for
example) to reduce the number of
messages displayed on the map.
The geographical fi lter follows the
movement of the vehicle.

The fi lters are independent and their results are cumulative.
We recommend a fi lter on the route and a fi lter around the vehicle of:


- 2 miles (3 km) or 3 miles (5 km) for a region with heavy traffi c,

- 6 miles (10 km) for a region with normal traffi c,

- 30 miles (50 km) for long journeys (motorway).


Press the TRAFFIC button again or
select the Traffi c Menu function and
press the dial to confi rm.
Press the TRAFFIC button.
TMC (Traffi c Message Channel) messages contain information on
traffi c and weather conditions, received in real time and transmitted to
the driver in the form of audible announcements and symbols on the
navigation map.
The navigation system can then suggest an alternative route to avoid a
traffi c problem.

Select the "Geo. Filter" function and
press the dial to confi rm.

Messages on route

The list of TMC messages appears under the Traffi c Menu sorted
in order of proximity.

All warning messages

Traffi c Menu



Select the fi lter of your choice:

Only warnings on route


All messages

The messages appear on the map
and on the list.
To exit, press ESC.
Geo. Filter

11
RADIO
SCREEN MENU MAP


"Traffic" Menu


Messages on route
Only warnings on route
All warning messages
All messages

Within
2 miles (3 km)
Geo. Filter

Within
3 miles (5 km)

Within
6 miles (10 km)


Within
30 miles (50 km)


Within 60 miles (100 km)





"Music" Menu


Select music
Sound settings

Balance/Fader


Bass/Treble

Linear
Equalizer

Classic
Jazz
Rock/Pop
Techno Vocal

Loudness


Speed dependent volume


Reset sound settings




"Radio" Menu


Waveband

AM


Linear
FM


Manual tune
Sound settings

Balance/Fader


Bass/Treble


Equalizer














MAIN FUNCTION


OPTION A

option A1


option A2




OPTION B...

1
2
3
1
2
4
1
2
3
4
3
3
3
3
2
2
2
2
4
4
4
4
4
3
3
3
3
3
2
3
2
2
3
3
3
3
1
2
3
2
3

309Visual search
Technical data - Maintenance


Running out of Diesel 180

Checking levels 183 -185


- oil

- brake fluid

- coolant

- screenwash fluid


- additive (Diesel with par ticle emis sions f ilter)



Changing bulbs 203 -209


- front

- rear

- interior

Petrol engines 230-233
LPG engine 234-235
Diesel engines 236 -237
Dimensions 238-239
Identification markings 240

Bonnet 179 -180
Under-bonnet layout, petrol 181
Under-bonnet layout, Diesel 182
Batter y 217-218
Energy economy mode 219
Checking components 186-187


- battery

- air filter/passenger compartment filter

- oil filter

- par ticle emissions filter (Diesel)

- brake pads/discs


Engine compartment
fuses 210, 213 -216

A
ABS and EBFD systems ............................. 142
Accessories ................................................ 225
Accessories socket, 12 V ............................ 122
Access to rear seats ............................... 79, 80
Adjusting headlamps .................................. 111
Adjusting head restraints .............................. 78
Adjusting the steering wheel ......................... 83
Air conditioning ............................................. 22
Air conditioning
(digital) .................................................. 65, 71
Air conditioning (manual) ........................65, 68
Air filter ........................................................ 186
Air intake ....................................................... 71
Air recirculation ............................................. 71
Air vents ........................................................ 64
Anti-lock braking system
(ABS) ........................................................ 142
Anti-pinch ...................................................... 94
Anti-theft steering lock .................................. 90
Assistance call .................................... 141, 246
Audible warning .......................................... 141
Audio streaming
(Bluetooth) ................................................ 292
Audio system ...................... 282, 283, 296, 298
Automatic gearbox .............................. 162, 187
Automatic illumination
of headlamps .....................................107, 110
Automatic operation
of hazard warning lamps .......................... 141
Automatic rain sensitive
windscreen wipers .............................112, 114
Auxiliary socket ...........................................266
Auxiliary sockets .........................................290Capacity, fuel tank ...................................... 100
CD MP3 ...............................................265, 287
Central locking ........................................ 89, 97
Changing a bulb .......................... 203, 207, 208
Changing a fuse .......................................... 210
Changing a wheel ....................................... 196
Changing a wiper blade ...................... 115, 220
Changing the date ....................................... 270
Changing the remote control battery ............ 92
Changing the time ...................... 270, 293, 294
Checking levels ................................... 183, 185
Checking the engine oil level ........................ 43
Checking tyre pressures (using the kit) ...... 190Checks ................................ 181, 182, 186, 187
Children ........................................132, 134-136
Child seats ......................................... 128, 132
Closing the boot ......................................89, 99
Closing the doors ....................................89, 96
Connectors, audio .............. 122, 266, 288, 290
Control stalk, wipers .............................112-114
Coolant level ......................................... 40, 183
Coolant temperature ..................................... 40
Coolant temperature indicator ...................... 40
Cour tesy lamps ........................................... 209
Cour tesy mirror ........................................... 121
Cruise control .............................................. 171
Cup holder ................................................... 120
Cur tain airbags ................................... 152, 153 Battery ................................................. 186, 217
Battery, remote control ...........................92, 93
Battery recharge ......................................... 217
Bench seat, rear ............................................ 82
Black panel .................................................... 45
Bluetooth (hands-free) ................ 267, 268, 291
Bluetooth (telephone) .......................... 267, 268
Bonnet ......................................................... 179
Boot ............................................................... 99
Boot lamp ............................................ 117, 209
Brake discs .................................................. 187
Brake lamps ................................................ 207
Brake pads .................................................. 187
Brakes ......................................................... 187
Braking assistance system ......................... 142
B
C
Dashboard fusebox ..................................... 210
Date (display) .............................................. 270
Deactivating the passenger airbag ............. 149
Defrosting ................................................ 68, 74
Demisting ................................................ 68, 71
Dials and gauges .................................... 26, 28
Diesel additive level .................................... 185
Diesel engine .............................. 101, 182, 236
Dimensions ................................................. 238
Dipped beam .......................................106, 204
Dipstick .................................................. 43, 183
Direction indicators ............................. 140, 207
Door mirrors .................................................. 84
D

Map reading lamps ............................. 116, 209
Markings, identification ............................... 240
Mat .............................................................. 123
Menu, main .................................................284
Mini fuel level .............................................. 100
Misfuel prevention ....................................... 102
Monochrome screen .................. 284, 296, 298
Motorway function (direction indicators) ..... 140
Mountings for ISOFIX seats ............... 134, 136
MP3 CD ...............................................265, 287
Multifunction screen
(with audio equipment) ...................52, 55, 59
Music media players ...................................264
MyWay ..........................................59, 250, 272
R
Navigation ................................................... 253
Number plate lamps .................................... 207
NP
Paint colour code ........................................ 240
Parking brake ...................................... 156, 187
Par ticle emission filter ........................ 185, 186
Passenger compar tment filter .................... 186
Petrol engine ............................... 101, 181, 230
Player, CD MP3 ...................................265, 287
Priming the fuel system .............................. 180
Protecting children .......128, 132, 134-136, 149
Puncture ...................................................... 190
Radio ...................................................263, 285
Rear foglamp ............................................... 207
Rear foglamps ............................................. 108
Rear head restraints ..................................... 82
Rear parcel shelf ......................................... 125
Rear parking sensors .................................. 173
Rear screen (demisting) ................................ 74
Rear seats ..................................................... 82
Rear view mirror ............................................ 85
Rear wash-wipe .......................................... 113
Rear wiper ................................................... 113
Recharging the battery ............................... 217
Reduction of electrical load ........................ 220
Refitting a wheel ......................................... 199
Reinitialising the electric windows ................ 94
Reinitialising the remote control ................... 92
Remote control ..................................88, 89, 93
Removing a wheel ...................................... 199
Removing the mat ....................................... 123
Repair kit, puncture ..................................... 190 Keeping children safe ................. 128, 134, 149
Key in ignition warning .................................. 90
Key with remote control .................... 88 -90, 93
LLabels, identification ................................... 240
Lamps, warning and indicator ...........30, 34, 35
Lateral airbags .................................... 151, 153
LED lamps ........................................... 111, 206
Level, brake fluid ......................................... 183
Levels and checks........................ 181-183, 185
Lighting, guide-me home .................... 109, 110
Lighting, interior ...........................116, 117, 209
Lighting bulbs (replacement) ...... 203, 207, 208
Lighting rheostat ........................................... 44
Lighting stalk ............................................... 106
Loading.......................................................... 22
Load reduction mode .................................. 220
Localised assistance call ............................ 246
Localised emergency call ........................... 246
Locating your vehicle .................................... 90
Locking from the inside ................................. 97
LPG .............................................................234
Luggage retaining strap .............................. 124
K
Main beam ..........................................106, 205
Manual gearbox .................. 157, 158, 166, 187M
Oil filter ........................................................ 186
Oil level .................................................. 43, 183
Opening the bonnet .................................... 179
Opening the boot ....................................88, 99
Opening the doors ........................... 88, 96, 98
Opening the fuel
filler flap .................................................... 100
Operation indicator lamps .......................30, 34
O

313Alphabetical index
Replacing bulbs .......................... 203, 207, 208
Replacing fuses .......................................... 210
Replacing the air filter ................................. 186
Replacing the oil filter ................................. 186
Replacing the particle emission filter ......... 186
Replacing the passenger
compar tment filter .................................... 186
Replacing wiper blades ....................... 115, 220
Resetting the ser vice indicator ..................... 42
Resetting the trip recorder ............................ 44
Rev counter ............................................. 26, 28
Reversing lamp ........................................... 207
Routine checks ................................... 186, 187
Routine maintenance .................................... 22
Running out of fuel (Diesel) ........................ 180
Safety for children ............................... 132, 136
Satellite navigation
system ....................................................... 253
Scented air freshener ................................... 75
Screen, colour 16/9 .......................59, 250, 272
Screen, multifunction
(with audio equipment) ...................52, 55, 59
Screen-wash reser voir................................ 183
Screen menu map ...................... 272, 296, 298
Screenwash ................................................ 113
Screenwash fluid
level ........................................................... 183
Seat adjustment ...................................... 77, 80
Seat belts ............................................ 145, 147
S
Selector lever,
"SensoDrive" .................................... 159, 187
Serial number,
vehicle ....................................................... 240
Ser vice indicator ........................................... 41
Ser vicing ....................................................... 22
Setting the clock ......................................... 270
Shor t-cut menus ................................. 251, 252
Sidelamps ...................................106, 205, 207
Side repeater............................................... 205
Spare wheel ................................................ 196
Speed limiter ............................................... 169
Speedometer .......................................... 26, 28
Stability control
(ESP)......................................................... 143
Star ting the vehicle ....................... 90, 159, 162
Steering mounted
controls ..................................................... 283
Stopping the vehicle ..................... 90, 159, 162
Stop Star t ....................... 48, 71, 100, 166, 179,
18 6, 217, 271, 295
Storage ................................................ 120, 121
Storage box ................................................. 125
Stowing rings .............................................. 124
Sun visor ..................................................... 121
Synchronising the remote control ................. 92
Systems, ASR and ESP .............................. 143
Table of weights ......................... 230, 234, 236
Tables of engines ....................... 230, 234, 236Tables of fuses ............................................ 210
Tank, fuel ............................................. 100, 102
Technical data ............................ 230, 234, 236
Telephone ........................................... 267, 268
Te m p e r a t u r e
adjustment .................................................. 71
Temperature control
for heated seats ......................................... 79
Te m p o r a r y
tyre repair kit ............................................. 190
Third brake lamp ......................................... 208
Time ................................................... 293, 294
TMC (Traffic info) ........................................ 261
Tools ............................................................ 196
Total distance recorder ................................. 44
To w b a r ......................................................... 223
Towed loads ............................... 230, 234, 236
Towing another
vehicle ....................................................... 221
Traction control (ASR) ................................ 143
Traffic information (TA) .............. 262, 263, 286
Traffic information (TMC) .................... 261, 262
Trip computer .................................... 46 - 48, 55
Trip distance recorder ................................... 44
Tyre pressures ............................................ 240
Ty r e s .............................................................. 22
TUnlocking ...................................................... 88
Unlocking from
the inside .................................................... 97
U
