Black plate (5,1)Chevrolet Aveo Owner Manual - 2011
Instruments and Controls 5-5
Rear Window
Wiper/Washer
{WARNING
In freezing weather, do not use
the washer until the windshield is
warmed. Otherwise the washer
fluid can form ice on the
windshield, blocking your vision.
The vehicle may have a rear
window wiper/washer.
Turn the rear wiper/washer
band to operate the rear window
wiper/washer.
OFF: Turns the rear window
wiper/washer off.
Z: Turns the rear wiper on for
intermittent wipes.
Y: Sprays washer fluid onto the
rear window and the wiper operates
continuously. The windshield washer reservoir is
used for the windshield and rear
window. Check the fluid level if
either washer is not working. See
Washer Fluid on page 10‑24.
Clock
There is a digital clock located in
the center of the instrument panel,
above the center air outlets. When
the ignition is turned to ACC/
ACCESSORY or ON/RUN, the time
is displayed in the digital clock.
There are three buttons for adjusting
the digital clock:
H (Hour):
Press once to go forward
one hour. To go forward more than
one hour, press and hold the button
until the correct hour is reached. M (Minute):
Press once to go
forward one minute. To go forward
more than one minute, press and
hold the button until the correct
minute is reached.
S (Set): Press to reset the time to
the nearest hour.
For example, if the set button is
pressed while the time is between
8:00 and 8:29, the display is set to
8:00. If this button is pressed while
the time is between 8:30 and 8:59,
the display is set to 9:00.
After disconnecting the battery or
replacing the fuse, reset the clock.
Power Outlets
Accessory power outlets can be
used to plug in electrical equipment,
such as a cell phone or MP3 player.
The accessory power outlet is
located next to the parking brake on
the center console.
