Black plate (1,1)Cadillac Escalade/Escalade ESV Owner Manual - 2011
In Brief 1-1
In Brief
Instrument Panel
Instrument Panel . . . . . . . . . . . . . . 1-2
Initial Drive Information
Initial Drive Information . . . . . . . . 1-4
Remote Keyless Entry (RKE)System . . . . . . . . . . . . . . . . . . . . . . 1-4
Remote Vehicle Start . . . . . . . . . 1-5
Door Locks . . . . . . . . . . . . . . . . . . . 1-5
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Windows . . . . . . . . . . . . . . . . . . . . . . 1-6
Seat Adjustment . . . . . . . . . . . . . . 1-7
Memory Features . . . . . . . . . . . . . 1-8
Second Row Seats . . . . . . . . . . . 1-9
Third Row Seats . . . . . . . . . . . . . . 1-9
Heated and Ventilated Seats . . . . . . . . . . . . . . . . . . . . . . . . 1-9 Head Restraint
Adjustment . . . . . . . . . . . . . . . . . 1-10
Safety Belts . . . . . . . . . . . . . . . . . . 1-10
Sensing System for Passenger Airbag . . . . . . . . . . 1-10
Mirror Adjustment . . . . . . . . . . . . 1-11
Steering Wheel Adjustment . . . . . . . . . . . . . . . . . 1-12
Throttle and Brake Pedal Adjustment . . . . . . . . . . . . . . . . . 1-12
Interior Lighting . . . . . . . . . . . . . . 1-12
Exterior Lighting . . . . . . . . . . . . . 1-13
Windshield Wiper/Washer . . . . 1-14
Climate Controls . . . . . . . . . . . . . 1-15
Transmission . . . . . . . . . . . . . . . . 1-15
Vehicle Features
Radio(s) . . . . . . . . . . . . . . . . . . . . . 1-16
Satellite Radio . . . . . . . . . . . . . . . 1-16
Portable Audio Devices . . . . . . 1-16
Bluetooth
®. . . . . . . . . . . . . . . . . . . 1-17
Steering Wheel Controls . . . . . 1-17 Cruise Control . . . . . . . . . . . . . . . 1-18
Navigation System . . . . . . . . . . . 1-18
Driver Information
Center (DIC) . . . . . . . . . . . . . . . 1-19
Side Blind Zone
Alert (SBZA) . . . . . . . . . . . . . . . 1-20
Rear Vision Camera (RVC) . . . . . . . . . . . . . 1-20
Ultrasonic Parking Assist . . . . 1-20
Power Outlets . . . . . . . . . . . . . . . 1-21
Universal Remote System . . . 1-21
Performance and Maintenance
StabiliTrak®System . . . . . . . . . 1-21
Tire Pressure Monitor . . . . . . . . 1-22
Engine Oil Life System . . . . . . 1-22
Fuel E85 (85% Ethanol) . . . . . 1-23
Driving for Better Fuel Economy . . . . . . . . . . . . . . . . . . . 1-23
Roadside Service . . . . . . . . . . . . 1-23
OnStar
®. . . . . . . . . . . . . . . . . . . . . 1-24

Black plate (7,1)Cadillac Escalade/Escalade ESV Owner Manual - 2011
In Brief 1-7
Seat Adjustment
To adjust the seat:
.Move the seat forward or
rearward by sliding the control
forward or rearward.
.Raise or lower the front or rear
part of the seat cushion by
moving the front or rear of the
control up or down.
.Raise or lower the entire seat
by moving the entire control up
or down.See
Power Seat Adjustment on
page 3‑3 for more information.
Lumbar Adjustment
To adjust the lumbar support:
.To increase or decrease lumbar
support, press and hold the front
or rear of the control.
.To raise or lower the height of
the support, press and hold the
top or bottom of the control.
See Lumbar Adjustment on
page 3‑6 for more information. Reclining Seatbacks
To recline the seatback:
.Tilt the top of the control
rearward to recline.
.Tilt the top of the control forward
to raise.
See Reclining Seatbacks on
page 3‑6 for more information.

Black plate (8,1)Cadillac Escalade/Escalade ESV Owner Manual - 2011
1-8 In Brief
Memory Features
The controls on the driver door are
used to program and recall memory
settings for the driver seat, outside
mirrors, power steering column, and
the adjustable throttle and brake
pedals.Storing Memory Positions
To save into memory:
1. Adjust the driver seat, including
the seatback recliner and
lumbar, both outside mirrors,
power steering column, and the
throttle and brake pedals.
See Power Mirrors on page 2‑16
and Adjustable Throttle and
Brake Pedal on page 9‑31 for
more information.
Not all mirrors and adjustable
throttles and brake pedals will
have the ability to save and
recall their positions.
2. Press and hold “1”until
two beeps sound.
3. Repeat for a second driver position using “2.”
To recall, press and release “1”or
“2.” The vehicle must be in P (Park).
A single beep will sound. The seat, outside mirrors, steering column,
and adjustable throttle and brake
pedals will move to the positions
previously stored for the identified
driver.
See
“Memory Features” under
Power Seat Adjustment on page 3‑3
and Vehicle Personalization on
page 5‑40 for more information.
Easy Exit Positions
This feature can move the driver
seat rearward and the power
steering column up and forward to
allow extra room to exit the vehicle.B: Press to recall the easy exit
positions. The vehicle must be in
P (Park).
See “Memory Features” under
Power Seat Adjustment on page 3‑3
and Vehicle Personalization on
page 5‑40 for more information.

Black plate (10,1)Cadillac Escalade/Escalade ESV Owner Manual - 2011
1-10 In Brief
Head Restraint
Adjustment
Do not drive until the head restraints
for all occupants are installed and
adjusted properly.
To achieve a comfortable seating
position, change the seatback
recline angle as little as necessary
while keeping the seat and the
head restraint height in the proper
position.
For more information seeHead
Restraints on page 3‑2 andPower
Seat Adjustment on page 3‑3.
Safety Belts
Refer to the following sections for
important information on how to use
safety belts properly.
.Safety Belts on page 3‑22.
.How to Wear Safety Belts
Properly on page 3‑25.
.Lap-Shoulder Belt on page 3‑31.
.Lower Anchors and Tethers for
Children (LATCH System) on
page 3‑63.
Sensing System for
Passenger Airbag
The passenger sensing system,
if equipped, will turn off the right
front passenger frontal airbag
under certain conditions. The driver
airbags, seat‐mounted side impact
airbags and roof‐rail airbags are not
affected by this.
If the vehicle has one of the
indicators pictured in the following
illustrations, then the vehicle has a
passenger sensing system for the
right front passenger position.
The passenger airbag status
indicator, if equipped, will be visible
on the overhead console when the
vehicle is started.

Black plate (12,1)Cadillac Escalade/Escalade ESV Owner Manual - 2011
1-12 In Brief
Steering Wheel
Adjustment
The power tilt wheel control is
located on the left side of the
steering column.
Push the control up or down to tilt
the steering wheel up or down.
To set the memory position, see
“Memory Features”inPower Seat
Adjustment on page 3‑3.
Throttle and Brake Pedal
Adjustment
The vehicle has adjustable throttle
and brake pedals that allow you to
change their positions.
The switch used to adjust the
pedals is located on the center
console below the climate control
system.
Press the right and left arrows to
move the pedals either closer or
further from your body.
Adjustable Throttle and Brake Pedal
on page 9‑31
Interior Lighting
Dome Lamps
The dome lamps are located in the
overhead console.
They come on when any door is
opened and turn off after all the
doors are closed.
Turn the instrument panel
brightness knob located below
the dome lamp override button,
clockwise to the farthest position to
manually turn on the dome lamps.
The dome lamps remain on until the
knob is turned counterclockwise.

Black plate (4,1)Cadillac Escalade/Escalade ESV Owner Manual - 2011
2-4 Keys, Doors and Windows
If enabled through the DIC, the turn
signal lamps flash twice to indicate
unlocking has occurred. SeeVehicle
Personalization on page 5‑40.
If enabled through the DIC, the
exterior lamps turn on briefly if
it is dark enough outside. See
“Approach Lighting” underVehicle
Personalization on page 5‑40.
Pressing
Kon the RKE transmitter
disarms the content theft‐deterrent
system. See Anti-Theft Alarm
System on page 2‑13.
/(Remote Vehicle Start): For
vehicles with this feature, press
/
to start the engine from outside the
vehicle using the RKE transmitter.
See Remote Vehicle Start on
page 2‑5 for additional information.
&(Power Liftgate): Press and
hold to open and close the liftgate.
The taillamps flash and a chime
sounds to indicate when the liftgate
is opening and closing.
m(Liftglass): Press and hold to
open the liftglass.
L(Vehicle Locator/Panic
Alarm): Press and release to
locate the vehicle. The turn signal
lamps flash and the horn sounds
three times.
Press and hold
Lfor
three seconds to activate the
panic alarm. The turn signal
lamps flash and the horn sounds
repeatedly for 30 seconds.
The alarm turns off when the
ignition is moved to ON/RUN
or
Lis pressed again. The ignition
must be in LOCK/OFF for the panic
alarm to work.
The vehicle comes with
two transmitters. Each transmitter
will have a number on top of
it, “1” or“2”. These numbers
correspond to the driver of the
vehicle. For example, the memory
seat position for driver 1 will be
recalled when using the transmitter
labeled “1”, if enabled through the
DIC. See “Memory Features” under
Power Seat Adjustment on page 3‑3
for more information.
Programming Transmitters to
the Vehicle
Only RKE transmitters
programmed to this vehicle
will work. If a transmitter is lost
or stolen, a replacement can be
purchased and programmed through
your dealer. When the replacement
transmitter is programmed to this
vehicle, all remaining transmitters
must also be reprogrammed.
Any lost or stolen transmitters
will no longer work once the
new transmitter is programmed.
Each vehicle can have up to eight
transmitters programmed to it.
See your dealer to have transmitters
programmed to the vehicle.
Battery Replacement
Replace the battery if the REPLACE
BATTERY IN REMOTE KEY
message displays in the DIC.
See “REPLACE BATTERY IN
REMOTE KEY” underKey and
Lock Messages on page 5‑35
for additional information.

Black plate (1,1)Cadillac Escalade/Escalade ESV Owner Manual - 2011
Seats and Restraints 3-1
Seats and
Restraints
Head Restraints
Head Restraints . . . . . . . . . . . . . . . 3-2
Front Seats
Power Seat Adjustment . . . . . . . 3-3
Lumbar Adjustment . . . . . . . . . . . 3-6
Reclining Seatbacks . . . . . . . . . . 3-6
Heated and Ventilated FrontSeats . . . . . . . . . . . . . . . . . . . . . . . . 3-8
Rear Seats
Heated Rear Seats . . . . . . . . . . . 3-9
Second Row Seats (60/40Split Bench Seat) . . . . . . . . . . . 3-10
Second Row Seats (Bucket Seats) . . . . . . . . . . . . . . . . . . . . . . 3-13
Third Row Seats . . . . . . . . . . . . . 3-18
Safety Belts
Safety Belts . . . . . . . . . . . . . . . . . . 3-22
How to Wear Safety Belts Properly . . . . . . . . . . . . . . . . . . . . 3-25
Lap-Shoulder Belt . . . . . . . . . . . 3-31 Safety Belt Use During
Pregnancy . . . . . . . . . . . . . . . . . . 3-36
Lap Belt . . . . . . . . . . . . . . . . . . . . . 3-37
Safety Belt Extender . . . . . . . . . 3-38
Safety System Check . . . . . . . . 3-38
Safety Belt Care . . . . . . . . . . . . . 3-38
Replacing Safety Belt System Parts After a Crash . . . . . . . . . 3-39
Airbag System
Airbag System . . . . . . . . . . . . . . . 3-39
Where Are the Airbags? . . . . . 3-42
When Should an AirbagInflate? . . . . . . . . . . . . . . . . . . . . . 3-44
What Makes an Airbag Inflate? . . . . . . . . . . . . . . . . . . . . . 3-45
How Does an Airbag
Restrain? . . . . . . . . . . . . . . . . . . . 3-46
What Will You See After an Airbag Inflates? . . . . . . . . . . . . 3-46
Passenger Sensing System . . . . . . . . . . . . . . . . . . . . . 3-48
Servicing the Airbag-Equipped Vehicle . . . . . . . . . . . . . . . . . . . . . 3-52
Adding Equipment to the Airbag-Equipped Vehicle . . . 3-53
Airbag System Check . . . . . . . . 3-54
Replacing Airbag System Parts After a Crash . . . . . . . . . 3-54
Child Restraints
Older Children . . . . . . . . . . . . . . . 3-55
Infants and YoungChildren . . . . . . . . . . . . . . . . . . . . 3-57
Child Restraint Systems . . . . . 3-60
Where to Put the Restraint . . . 3-62
Lower Anchors and Tethers for Children (LATCH
System) . . . . . . . . . . . . . . . . . . . . 3-63
Replacing LATCH System Parts After a Crash . . . . . . . . . 3-71
Securing Child Restraints (Rear Seat Position) . . . . . . . . 3-72
Securing Child Restraints (Center Front Seat
Position) . . . . . . . . . . . . . . . . . . . 3-75
Securing Child Restraints (Right Front Seat
Position) . . . . . . . . . . . . . . . . . . . 3-75

Black plate (3,1)Cadillac Escalade/Escalade ESV Owner Manual - 2011
Seats and Restraints 3-3
Push down on the head restraint
after the button is released to make
sure that it is locked in place.
The head restraints are not
designed to be removed.
The vehicle's 2nd-row seats have
head restraints in the outboard
seating positions that cannot be
adjusted.
The vehicle's 3rd-row seat,
if equipped, has headrests that
can be adjusted up and down.Front Seats
Power Seat Adjustment
To adjust a power seat:
.Move the seat forward or
rearward by sliding the control
forward or rearward.
.Raise or lower the front or rear
part of the seat cushion by
moving the front or rear of the
control up or down.
.Raise or lower the entire seat
by moving the entire control up
or down.
To adjust the seatback, see
Reclining Seatbacks on page 3‑6.
